•Small and handy transmitter for standard applications and customized solutions
•Easily operated with one hand
•6 functions maximum, start and stop
•Range of application: industrial applications, vehicle technology, agriculture, forestry etc.
•Stop button, LED status display, push buttons, easy to wear with its belt clip, carrying bag
•Available with internal antenna
•Special battery compartment for the use of commercial batteries
•Immediately ready for operation
nStart button
oStop button
pPush button
qLED status display
rOption: battery charger with HETRONIC battery
(Original parts set of HETRONIC)
T
T
Te
e
ec
c
ch
h
hn
n
ni
i
ic
c
ca
a
al
l
l D
D
Da
a
at
t
ta
a
a S
S
Sh
h
he
e
ee
e
et
t
t
r
V1 V2 / V3 V4 V5 / V6
c
d
e
f

S
Sa af fe et ty y c ch he ec ck k
T
Te ec ch hn ni ic ca al l d da at ta a D Di im me en ns si io on ns s
O
Op pe er ra at ti io on n o of f t th he e t tr ra an ns sm mi it tt te er r
The transmitter may only be operated by introduced persons!
Insert a fully charged battery into the battery compartment of the transmitter.
Start the transmitter by using the start button
n . Now, the LED status display q is flashing green.
After the system check you may start the system by activating the start button n. You can control the
designated function by activating the push buttons
p .The activated functions are now transmitted to the
receiver. The individual functions of the buttons are described in the enclosed drawings! You can stop the
system using the stop button
o (only use in case of an emergency).
LED status display: Flashing green = transmitter activated
Flashing red/green = low voltage of the transmitter
Flashing red = transmitter stopped
Material Polyamid with glass fibre
Weight 220 g
Dimensions (H1)125 / (H2)225 /
B 69 / T 50 mm
Diagnostics Status LED
RF technology Synthesizer
RF output < 10 mW
Temperature range -25° up to +70° C
Antenna external or internal
Frequency range 434/869 Mhz (for EU,
further frequencies on
request)
Safety address 20 bit (1 Mio.)
Protection type IP 65
Operating time more than 20 h possible
Power supply 3,6 V DC
T
T
Te
e
ec
c
ch
h
hn
n
ni
i
ic
c
ca
a
al
l
l D
D
Da
a
at
t
ta
a
a S
S
Sh
h
he
e
ee
e
et
t
t
©2011 Hetronic Germany GmbH Version 1.4 hetronic.de
Attention: You have to read and understand the operating manual of the radio remote control
and the machine before operation is started!
Check the proper operation of the stop button before operating the machine.
Please check the following items each time before using the system!
;Check the transmitter for damages
;Check the function of the stop button by means of the LED status display
q
(transmitter ON: LED is flashing green / stop button pushed: LED is flashing red, transmitter off)
