HETRONIC NOVA L Instruction Manual

nStart button
oKey switch
pStop button (push / pull)
qControl levers stepless
rToggle switch
sLED status display
tBattery charger with original HETRONIC battery
NOTE: Only use genuine HETRONIC parts. Not doing so
introduces the risk of serious damages and will result
in the loss of your guarantee.
©2011 Hetronic Germany GmbH Version 1.4 hetronic.de
N
N
NO
O
OV
V
VA
A
A
–
–
–
L
L
L
P
P
Pr
r
ro
o
op
p
po
o
or
r
rt
t
ti
i
io
o
on
n
na
a
al
l
l
G
Ge en ne er ra al l d de es sc cr ri ip pt ti io on n
•Ergonomically and ruggedly designed
•Individually configurable transmitter for a multitude of applications
•Key switch, stop button, LED status display, toggle switch, push button, battery
compartment, belly belt, 6 linear control levers maximum in Y direction with 6 proportional
functions or 2 joysticks maximum in X / Y direction with 4 proportional functions
•Receiver programming via transmitter possible (Quick-Set)
•Standard and customized solutions
•Cable control available
•Several types of feedback available (f. e. LCD, LED etc.)
•Tandem operation available
T
T
Te
e
ec
c
ch
h
hn
n
ni
i
ic
c
ca
a
al
l
l D
D
Da
a
at
t
ta
a
a S
S
Sh
h
he
e
ee
e
et
t
t
C
Co on nt tr
r
o
ol l f fu un nc ct ti io on ns s a an nd d a ac cc ce es ss so or
r
i
ie es s

S
Sa af fe et ty y c ch he ec ck k
T
Te ec ch hn ni ic ca al l d da at ta a
D Di im me en ns si io on ns s
O
Op pe er ra at ti io on n o of f t th he e t tr ra an ns sm mi it tt te er r
Material Polyamid with glass fibre
Weight 1600 g
Dimensions H 165/ B 235/ T 110 mm
Diagnostics Status LED
RF technology Synthesizer
RF output < 10 mW
Temperature range -25° up to +70° C
Antenna internal
Frequency range 434/869 Mhz (for EU, further
frequencies on request)
Safety address 20 bit (1 Mio.)
Protection type IP 65 (exceeds Nema 12/13)
Operating time more than 20 h possible
Power supply 3,6V DC
Attention: You have to read and understand the operating manual of the radio remote control
and the machine before operation is started!
Check the proper operation of the stop button before operating the machine.
Please check the following items each time before using the system!
;Check the transmitter for damages
;Check the function of the stop button by means of the LED status display
s
(transmitter ON: LED is flashing / stop button pushed: LED is flashing faster)
;When the transmitter is switched on, you will hear an acoustical signal (standard adjustment)
The transmitter may only be operated by instructed persons!
Insert a fully charged battery into the battery compartment of the transmitter.
Start the transmitter by using the key switch o. Now, the LED status display shas to flash green and
an acoustical signal will prove the system check (approx. 2 seconds).
After the system check you may start the system by activating the start button n. You can control the
designated function by activating the joysticks/control levers q, the toggle switches or the push
buttons r. The activated functions are now transmitted to the receiver. The individual functions of the
buttons are described in the enclosed drawings!
You can stop the system using the stop button p(only use in case of an emergency).
LED status display: Flashing = transmitter activated
Buzzer: A low voltage is signalised by an intermittent sound.
After approx. 30 seconds the transmitter switches off. .
T
T
Te
e
ec
c
ch
h
hn
n
ni
i
ic
c
ca
a
al
l
l D
D
Da
a
at
t
ta
a
a S
S
Sh
h
he
e
ee
e
et
t
t
