HETRONIC MINI User manual

YOUR #1 PARTNER IN RADIO REMOTE CONTROLS
Operator Manual
Hetronic, Inc.
4300 Highline Blvd., Bldg. A
Oklahoma City, OK 73108
405-946-3574 Fax [phone]
www.hetronic.com
MINI
System
OPMN_0001_0
9/01

© 2001 Hetronic, Inc.
All rights reserved. No part of this publication may be reproduced, transmitted, transcribed,
stored in a retrieval system, or translated into any language in any form by any means
without the written permission of Hetronic.
Technical information subject to change. Illustrations may not be applicable to your unit.
Hetronic reserves the right to discontinue, make changes to, and add improvements upon
its products at any time without public notice or obligation. Hetronic disclaims liability for
any claims or damages, whether regarding property, personal injury or death arising out of
the use of unauthorized replacement parts or service.
Hetronic, Inc.
4300 Highline Blvd., Bldg. A
Oklahoma City, OK 73108
405-946-3574
Fax [phone]
www.hetronic.com
IFC_7_01

1
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
The Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Model and Serial Numbers . . . . . . . . . . . . . . . 1
Unauthorized Replacement Parts . . . . . . . . . . 2
Before Attempting to Operate This System. . . 2
Theory of Operation. . . . . . . . . . . . . . . . . . . . . 2
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Safety Alerts . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Notations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Practices and Laws . . . . . . . . . . . . . . . . . . . . . 2
Required Operator Training. . . . . . . . . . . . . . . 2
Possible Sources of Danger . . . . . . . . . . . . . . 2
Operation and Work Area Safety. . . . . . . . . . . 2
Protective Features . . . . . . . . . . . . . . . . . . . . . 3
To Stop In An Emergency . . . . . . . . . . . . . . . . 3
Maintenance and Storage . . . . . . . . . . . . . . . . 3
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Mount the Receiver . . . . . . . . . . . . . . . . . . . . . 3
Install Receiver and Output Wiring . . . . . . 3
Connect Electrical Wiring . . . . . . . . . . . . . 3
Connecting Standard External Antenna . . . . . 3
Connecting Gain Flex Antenna . . . . . . . . . . . . 4
Install Transmitter Battery . . . . . . . . . . . . . . . . 4
Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Frequency Channel . . . . . . . . . . . . . . . . . . . . . 4
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Visual Check . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Start-up Procedure . . . . . . . . . . . . . . . . . . . . . 5
Emergency Stop . . . . . . . . . . . . . . . . . . . . . . . 6
Using Motion Pushbuttons. . . . . . . . . . . . . . . . 6
System Shutdown . . . . . . . . . . . . . . . . . . . . . . 6
Low Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Battery Charger . . . . . . . . . . . . . . . . . . . . . . . . 6
Battery Disposal . . . . . . . . . . . . . . . . . . . . . . . 6
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Definitions and Abbreviations . . . . . . . . . . . . . . 9
Installation / Safety Data Sheet. . . . . . . . . . . . . 10
Technical Data Sheets . . . . . . . . . . . . . . . Attached
THE MANUAL
Before operation of unit, carefully and completely read
your manuals. The contents will provide you with an
understanding of safety instructions and controls
during normal operation and maintenance.
MODEL AND SERIAL NUMBERS
When contacting your dealer or Hetronic about service,
repair or replaacement parts, know the model and
serial numbers of the transmitter and receiver.
The numbers are located on the label that is affixed to
the unit itself. Record the serial numbers here:
Transmitter
Receiver
INTRODUCTION
TABLE OF CONTENTS

2
UNAUTHORIZED REPLACEMENT PARTS
Use only Hetronic replacement parts. The replacement
of any part with anything other than a Hetronic
authorized replacement part may adversely affect the
performance, durabilty, and safety of this system and
may void the warranty. Hetronic disclaims liability for
any claims or damages, whether warranty, property
damage, personal injury or death arising out of the use
of unauthorized replacement parts.
BEFORE ATTEMPTING TO OPERATE THIS
SYSTEM:
1. Make sure all installation has been properly
completed.
2. Understand all Safety Precautions provided in the
manuals.
3. Review control functions and operation of the
machine and this radio remote control system.
THEORY OF OPERATION
The Mini System includes a transmitter and a receiver.
The hand-held transmitter generates the electronic
signal that communicates with the receiver. Hetronic
radio remote control systems operate in the 400-470
MHzrange (70 cm band). The transmitter and receiver
are set with identical address codes and frequency
channels. This allows operation of multiple systems
within the same area without signal inteference.
SAFETY ALERTS
Look for this symbol to point out
important safety precautions. They
mean:
Attention!
Personal Safety Is Involved!
Become Alert!
Obey The Message!
The safety alert symbol is used in decals on the unit
and with proper operation procedures in this manual.
Understand the safety message. It contains important
information about personal safety on or near the unit.
NOTATIONS
NOTE: General reference information for proper
operation and maintenance practices.
IMPORTANT: Specific procedures or information
required to prevent damage to unit or attachment.
PRACTICES AND LAWS
Practice usual and customary safe working
precautions, for the benefit of yourself and others.
Understand and follow all safety messages. Be alert to
unsafe conditions and the possibility of minor,
moderate, or serious injury or death. Learn applicable
rules and laws in your area.
REQUIRED OPERATOR TRAINING
Original purchaser of this unit was instructed by the
seller on safe and proper operation. If unit is to be used
by someone other than original purchaser; loaned,
rented or sold, ALWAYS provide this manual and any
needed safety training before operation.
ALWAYS review the operators manual of any machine
to be controlled by radio remote control.
POSSIBLE SOURCES OF DANGER
This system makes remote control via radio signals
possible. However, the transmission of control
commands can take place around obstacles and out of
the operator’s direct sight. To prevent accidental
start-up and possible injury or damage:
1. Always remove the battery pack from the
transmitter when it is not in use or if the unit is
placed any distance away from the operator.
2. Disconnect the power supply before any
assembly, maintenance or repair work is done.
3. Never remove or alter any of the safety features
of this system.
OPERATION AND WORK AREA SAFETY
The work area must be free from obstacles, debris or
other tripping hazards. Avoid uneven work areas and
any rough terrain. Always be sure of your footing.
Be aware of overhead obstacles that may interfere with
machine operation.
SAFETY
DANGER: IMMINENTLY HAZARDOUS
SITUATION! If not avoided, WILL RESULT in
death or serious injury.
WARNING: POTENTIALLY HAZARDOUS
SITUATION! If not avoided, COULD RESULT
in death or serious injury.
CAUTION: POTENTIALLY HAZARDOUS
SITUATION! If not avoided, MAY RESULT in
minor or moderate injury. It may also be used
to alert against unsafe practices.

3
PROTECTIVE FEATURES
This radio remote control system is equipped with
electronic and mechanical safety features. Processing
of control signals transmitted from other transmitters is
not possible, since transmission coding is unique to
each system.
These safety features help protect the operator, as well
as others within the work area. The machine functions
can be stopped by pushing the emergency stop button
on the transmitter control panel (EMERGENCY STOP).
IMPORTANT: Before operation, always test all safety
features.
TO STOP IN AN EMERGENCY
1. Press the red "EMERGENCY STOP" pushbutton.
2. Wait for all moving machine parts to stop.
3. Refer to machine’s operator manual for further
instructions.
MAINTENANCE AND STORAGE
Always shut off power to the machine and the radio
remote control before any assembly, maintenance or
repair.
MOUNT THE RECEIVER
Install Receiver and Output Wiring
Select a position for the receiver that provides
protection from violent impact from debris or thrown
materials and is easily accessible. The receiver
housing is rated IP66, can withstand direct water jet
spray and is protected against penetration of dust.
Therefore, weather and elements should not be the
primary concern when installing the receiver.
Four mounting holes are required when installing the
receiver unit. The drill pattern is shown in Figure 1.
The receiver wiring is critical for proper system
operation. Make all connections with good quality
contacts or solder joints to ensure proper electrical
contact.
Supply voltage and ground wiring are crucial and must
be connected to reliable connecting circuitry if using a
DC power source. Do not use a chassis ground for this
equipment. The ground wire must be connected
directly to the vehicle battery negative post.
The output control signals should be routed separately
from any wiring that could produce transient voltage
interference. Interference or "induced voltage spikes"
could cause erratic performance.
Connect Electrical Wiring
Connect all remaining wires (power supply, start-stop,
etc.) according to the wiring diagram of the crane and
the radio remote control. Refer to the Wiring Diagram
for your unit that is included in the Technical
Documents Section for detailed wiring specifications.
CONNECTING STANDARD EXTERNAL
ANTENNA
If it is necessary to mount the receiver inside a panel
enclosure, an external antenna is required. Mount the
antenna onto a metal surface that has the same
ground as the receiver. The antenna should be pointing
upward. The area around the antenna should be free of
obstructions, especially metal. See Figure 2.
WARNING: Accidental start-up can cause
serious injury or death. NEVER remove or
modify any safety feature.
INSTALLATION
WARNING: FAILURE TO FOLLOW
INSTRUCTIONS could result in personal
injury and/or damage to equipment. Read and
understand the safety instructions in all
manuals provided.
Figure 1
24.64 (9.70)
23.09 (9.09)
11.61
(4.57)
16.00
(6.30)
9.30
(3.66)
cm (in.)

4
NOTE: Improper installation of the antenna will result in
intermittent operation.
1. Drill hole, 1.42 cm (.56 inch) dia. through the
enclosure.
2. Remove any burrs from drilled hole and scrape
paint from the area that will ground the antenna to
the enclosure.
3. Assemble the antenna as shown in Figure 2.
4. Disconnect the internal antenna from the circuit
board in the receiver.
5. Connect the external antenna cable to the
antenna connector on the circuit board.
6. Secure extra antenna cable with tie wraps.
IMPORTANT: DO NOT run the antenna cable along
with control or power wiring. Incorrect installation will
cause intermittent operation.
CONNECTING A GAIN FLEX ANTENNA
The Gain Flex antenna can extend the operating range
of the unit up to 300 meters (1000 feet). Be sure there
are no metallic or conductive materials within a 2 meter
(6 feet) radius of the antenna. For the best results,
mount the antenna pointing upward. See Figure 3.
IMPORTANT: Incorrect installation will cause
intermittent operation.
1. Mount the antenna base vertically with the two tie
wraps included in the antenna kit. The antenna
should point upward.
2. Screw the antenna pole onto the antenna base.
3. Disconnect and remove the internal antenna from
the printed circuit board.
4. Connect the antenna cable connector to the
antenna connector on the printed circuit board.
5. Gather extra antenna cable and secure with tie
wraps.
NOTE: Do not run the antenna cable with power or
control wiring. Intermittent operation will result.
INSTALL TRANSMITTER BATTERY
Place the battery in the transmitter at an angle, with the
contacts facing inside. Push the battery into the cavity
until the case is flush against the housing wall. The
battery should now be positioned securely inside the
transmitter. See Maintenance section for detailed
instructions on charging the battery.
FREQUENCY CHANNEL
Each Hetronic radio remote control system contains a
registration-free radio frequency unit. Each system
consists of a transmitter RF unit and a receiver RF unit.
Standard RF Module
The reciever is capable of receiving one of 16 discrete
frequency channels. The frequency channel is set by
Hetronic at the factory. If interference occurs on a
particular frequency, it may be necessary to change the
channel of the receiver and transmitter.
Antenna must be
vertical (pointing up).
Area must be free
of obstructions
Figure 2
2
3
4
1. Antenna Pole
2. Enclosure
3. Antenna Base
4. Antenna Cable
1
Figure 3
2
3
4
1. Antenna Pole
2. Antenna Base
3. Tie Wraps
4. Antenna Cable
1
ADJUSTMENTS

5
If there are multiple radio remote control systems
operating in the same vicinity, take care when selecting
frequency channels that operate each system.
Residual energy from one system can interfere with
other systems if they are in close proximity. Contact
Hetronic or your authorized dealer for assistance in
resetting frequency channels.
The safety checks as described in the following
paragraphs must be completed before the radio remote
control system is activated. These checks must be
performed at least once a day, before the start of any
operation and at all shift changes.
IMPORTANT: A transmitter drawing is included with
each system. Transmitter layout and inscriptions may
vary according to customer requests.
VISUAL CHECK
Always check the transmitter for any physical damaged
before any operation.
• Always keep safety features, guards and controls
in good repair, in place and securely fastened.
• Check equipment for wear or damage.
• Check housings and pushbutton caps for wear or
damage.
IMPORTANT: Never operate a transmitter with worn or
damaged parts. Replace immediately with only
Hetronic parts. Contact Hetronic or your Dealer.
START-UP PROCEDURE
This checklist must be carefully followed before
beginning any operation.
1. Insert battery into the transmitter.
2. Be sure no motion pushbuttons are depressed.
3. Press the Start/Horn button. The transmitter
completes its self-checks and is activated. The
transmitter is now transmitting and ready for use.
IMPORTANT: If any function of the radio remote
control activates with the "EMERGENCY STOP"
engaged, the radio remote control must not be used
until it is repaired.
WARNING: DO NOT change the address
code or frequency channel of the original
transmitter. Contact Hetronic or your
authorized dealer.
DO NOT change the address code settings in
the receiver.
DO NOT operate two transmitters set with the
same frequency and address as the receiver
at the same time.
CAUTION: AVOID INJURY OR DAMAGE -
Operating the transmitter without its antenna
could destroy the final stage of the RF
module. DO NOT attempt to change the
Hetronic pre-set frequency or the 16-bit
address. Personal injury and property
damage could result from transmission
interference and may void the warranty.
OPERATION
WARNING: FAILURE TO FOLLOW
INSTRUCTIONS could result in personal
injury and/or damage to equipment. Read and
understand the safety instructions in all
manuals provided.
O
N
T
-
A
U
S
N
E
M
E
R
G
E
C
Y
S
T
O
P
1. Antenna
2. E-Stop button
3. Start/Horn button
4. Function up
5. Function down
1
2
3
45
Figure 4
WARNING: FAILURE TO FOLLOW
INSTRUCTIONS could result in personal
injury and/or damage to equipment. Test the
"EMERGENCY STOP" function as described
in the machine manufacturer’s operator
manual before beginning any operation.

6
IMPORTANT: To avoid accidental start-up, always
switch the transmitter "OFF" by pressing the E-stop
button and remove the battery when not in use. When
the transmitter is not attached to the operator, the
battery should be removed and stored in a secure
place.
EMERGENCY STOP
In any emergency situation, push the E-Stop
pushbutton. To restart, press the Start/Horn button.
USING MOTION PUSHBUTTONS
The transmitter controls the up and down motion. Only
one pushbutton in each horizontal row should be
activated at a time.
SYSTEM SHUTDOWN
To shut down the radio remote control system, press
the E-stop button and remove the battery. Power is no
longer supplied to the transmitter.
LOW BATTERY
If the transmitter battery voltage drops below a safe
level, approximately 3.6 volts, the Power LED flashes
red for about half a minute. At the end of 30 seconds,
the transmitter shuts itself off and disables the receiver
to block all machine commands.
Shut down the machine according to the
manufacturer’s instructions. Insert fully charged
batteries into the transmitter.
The owner of this radio remote control system should
have the system inspected by a qualified technician at
least once every year.
A qualified technician has professional training,
experience and extensive knowledge in wireless
transmission of control signals. This includes familiarity
with normal regulations for safe working conditions,
accident prevention, guidelines and general
regulations of technology for the respective countries
(CE).
BATTERY CHARGER (OPTIONAL)
The battery charger processor checks the capacity of
the battery until it is fully charged. The maximum
charging time is 4 hours. When the battery is fully
charged, the green LED flashes.You can leave the
battery in the charger until it is needed. This ensures a
full charge. While the battery is charging, the green
LED emits a steady light.
Battery charger uses 115/230 VAC (DC optional) and
plugs into a typical wall outlet.
To prolong battery life, be sure the battery is fully
discharged before recharging. Charging a partially
charged battery shortens the effective life of the
battery.
BATTERY DISPOSAL
IMPORTANT: AVOID ENVIRONMENTAL
POLLUTION. Electronic equipment and components
are considered to be hazardous waste. Discarded
rechargeable batteries are hazardous waste and must
not be disposed of with typical refuse. Contact a
professional hazardous waste disposal service or
Hetronic.
MAINTENANCE

7
If the system does not operate after normal start-up as
described in Operation Section of this manual, follow
the recommended troubleshooting sequence to help
isolate the cause and determine corrective action.
If the system will not respond to the steps below or the
LEDs indicate a failure, contact the Hetronic Service
Department or your authorized dealer.
TROUBLESHOOTING
PROBLEM PROBABLE CAUSE CORRECTION
Transmitter is activated
but does not broadcast.
(Power LED not
flashing.)
Discharged batteries Replace with fully charged batteries.
Failed electronics board Contact Hetronic or your Dealer for repairs.
Transmitter is
broadcasting, but
machine functions are
not working.
Transmitter is out of range. Move transmitter into designated range.
A motion function was not "Off"
when transmitter was activated.
Be sure all buttons are in "Off" position.
Press Start/horn button.
No power to receiver. Turn on power to receiver.
Fuse is blown in receiver. Check fuses and replace if necessary.
Receiver is set for different
address or frequency channel.
Be sure receiver address and frequency
channel match transmitter. Contact
Hetronic or your Dealer.
All machine motion
works intermittently.
Antenna is loose or
disconnected.
Secure or replace antenna.
Power transients affecting
control.
Be sure all contactors being controlled by
the receiver have surge suppressors
installed.
Control wiring run too near power
wiring.
Be sure that control wiring is run separately
from control wiring.
Transmitter interference from
another Hetronic radio remote
control system.
Two systems within 200 feet of each other
must be at least 2 channels apart. Two
systems within 50 feet must be at least 3
channels apart. Contact Hetronic or your
Dealer for assistance.
Some machine motions
work intermittently.
Loose wiring to that motion. Check wiring for secure connections.
Loose connector inside receiver. Check terminal block connectors. Contact
Hetronic or your Dealer for assistance.
Power transients affecting
control.
Be sure all contactors being controlled by
the receiver have surge suppressors
installed.
Control wiring run too near power
wiring.
Be sure that control wiring is run separately
from control wiring.

8
SPECIFICATIONS
General Data
Frequency 70 cm Band (Selectable 400
Mhz to 470 Mhz) 16 Preset
Range approx. 100 m (330 ft.)
Address 16-bit - 65,000 possible
Operating temperature -25° to +70° C
(-18° F to 158° F)
Data Format 4800 Baud (approx. 55 msec
response time)
Hamming distance 4
Receiver
Protective System IP 66
Voltage Supply 50/110/240 VAC 50/60Hz or
12 to 24 VDC (-50% - +20%)
Output 1 E-Stop relay
6 Motion/function relays - NO
Static current <100 mA
Antenna Built-in (External Optional)
Dimensions
L x W x H cm (in.)
24.6 x 16.0 x 19.3
(9.70 x 6.30 x 3.66)
Weight - Kg (lbs) 2,5 ( 3.6)
Transmitter
Enclosure IP65 Weatherproof
Battery Pack AA [Optional 3.6 V / 1200
mAh (NiMh)]
Operating time 24 hours continuous with AA
batteries, 30 hours
continuous with
rechargeable battery.
Transmitting power < 10 mW
Weight Less than 1 lb. (including
battery)
Dimensions
L x W x H cm (in.)
(Not including antenna)
12.3 cm x 6.9 cm x 3.3 cm
(4.84 x 2.72 x 1.31)
Battery Charger - Optional
Operating voltage 115/220 VAC
Charging time 4 Hours

9
Definitions and Abbreviations
The following terms and abbreviations may be used in
this Operator Manual.
A/D Analog to digital conversion
AK Analog channel (German: Analog
Kanal)
AMP Ampere
Analog Proportional-stepless or infinite
control
AWG American wire gauge
Baud Transmission speed measured in
bits per second
BPS Bits per second
Coder Device that converts parallel signals
into a serial data message
Decoder Device that converts a serial data
message into parallel signals
EMC Electromagnetic compatibility
EMI Electromagnetic immunity
EPROM Electrical programmable read-only
memory
FM Frequency modulation
GND Ground
Hamming
distance
The measurement of data
transmission safety. A low hamming
distance indicates a less sensitive
test. A high hamming distance
indicates extreme sensitivity and is
susceptible to noise interference.
HF High frequency
KHz Kilohertz
Latching An auxiliary function activates when
the option button is pressed once
and released. The function is
deactivated when the option button
is pressed again.
Maintained An auxiliary function activates when
the switch is flipped to an
appropriate position. The function is
deactivated when the switch is
flipped to the "OFF" position.
Momentary An auxiliary function activates when
the option button is pressed and
held. The function is deactivated
when the button is released.
mAH Milliampere hours
mA Milliampere
msec millisecond
MHz Megahertz
mW Milliwatt
NiCd Nickel cadmium (battery)
NiMH Nickel metal hydrite (battery)
PLC Programmable logic controller
PLL Phased locked loop
PWM Pulse width modulation
RF Radio frequency
RMS Root mean squared
Rx Receiver
RxD Receiving data
SMD Surface mount device
SMT Surface mount technology
Synthesizer
technology
Method to electronically generate a
transmitter carrier frequency
TTL Transistor logic
Tx Transmitter
TxD Transmitting data
Ub Operating power
Uv Microvolts
VAC Volts alternating current
VDC Volts direct current

10
This for must be completed and signed by the person
responsible for installation of this radio remote control
system.
Hetronic assumes no responsibility for the correct
installation of the radio remote control system. The
equipment operator must ensure that the radio remote
control system and the crane/machine operate
correctly together. The operator must also ensure that
all safety devices and features are in place and
operating correctly. The operator is responsible for
understanding and following all safety precautions in
this and other applicable operator manuals.
INSTALLATION AND SAFETY TEST DATA
Machine Data
Manufacturer
Model Number
Serial Number
Year of Production
Radio Remote Control Data
Manufacturer Hetronic
Model Mini
System Type GA 610
Serial Number
I/We installed the radio remote control system, performed the safety test and inspected the crane/machine. The
appropriate instructions and rules of this machine type are followed.
Place
Date
Company
Name of Installation Technician
Signature

Company’s sole liability shall be to repair at its factory, or replace any item returned to it within one year from date of
shipment, which Company finds to contain defective material or workmanship. All items to be repaired or replaced
shall be shipped to Company (Note: return authorization by Company is required) within said one year period, freight
prepaid, as a condition to repair or replace defective material or workmanship. Company’s herein assumed
responsibility does not cover defects resulting from improper installation, maintenance, or improper use. Any corrective
maintenance performed by anyone other than the Company during the warranty period shall void the warranty.
Company shall not be liable for damages of any kind from any cause whatsoever beyond the price of the defective
Company supplied items involved. Company shall not be liable for economic loss, property damage, or other
consequential damages or physical injury sustained by the purchaser or by any third party as a result of the use of any
Company supplied items or materials.
List prices or discounts are subject to change without notice. Quoted prices will be honored for a period of 90 days
from the date of the written quotation unless otherwise stated.
Orders are not subject to alteration or cancellation except upon written consent of Company and payment of proper
cancellation charges, when deemed applicable by Company.
Materials or items may not be returned for credit, without the prior written consent of the Company. Any authorized
return of materials or items shall be subject to a restocking charge equal to 20% of the net invoiced amount after
Company determines that the material or item is in good condition and may be resold without alteration or service.
Terms of payment are NET 30 days. All materials and items are sold F.O.B. Company’s shipping point. Company
retains a security interest in all items sold by it so long as they remain in Company’s possession to secure all
obligations of purchaser to Company. A processing fee will be applied to all invoices for requested prepaid freight
charges other than UPS. A service charge will be incurred on past due accounts extending beyond the terms of sale
described above, at a rate of 1.5% per month of the net balance extending beyond 30 days
The buyer should inspect the goods immediately on their arrival and shall within five days of their arrival give written
notice to the company of any claim that the goods do not conform with the terms of the contract. If the buyer shall fail
to give such notice, the goods shall be deemed to conform with the terms of the contract. Any claim for material or item
shortages must be accompanied by copies of the bill of lading and packing slip.
Delivery schedules or commitments are based upon current production capacities, material or component availability
and inventory and may be changed as conditions require. Company shall not be liable for loss or damage of any kind
resulting from delay or inability to deliver on account of fire, labor troubles, accident, acts of civil or military authorities,
or from any other cause beyond the company’s control.
LIMITED WARRANTY AND TERMS OF SALE
Price: Subject to change without notice
Terms: Net 30 Days
F.O.B.: Hetronic USA, Inc.
Oklahoma City, Oklahoma
Hetronic, Inc., hereafter referred to as Company, guarantees all items
manufactured by it against any defects of material and/or
workmanship for a period of one year from the date of shipment.
Company makes NO OTHER WARRANTY, EXPRESSED OR
IMPLIED, AS TO THE MERCHANTABILITY OR FITNESS OF THE
ITEMS FOR THEIR INTENDED USE OR AS TO THEIR
PERFORMANCE. Any statement, description or specification in
Company’s literature is for the sole purpose of identification of items
sold by the Company and imparts no guarantee, warranty or
undertaking by company of any kind. Components and accessories
not manufactured by Hetronic are not included in this warranty and
are warranted separately by their respective manufacturers.
Hetronic, Inc.
4300 Highline Blvd., Bldg. A
Oklahoma City, OK 73108
405-946-3574
Fax [phone]
www.hetronic.com
Warranty_7_01
