High Sec Labs K202B User manual

K202B/D Secure KVM Switch User Manual
User Manual
Models:
K202B – Secure 2-port DVI-I KVM Switch w/audio
K202D – Secure 2-port DVI-D KVM Switch w/audio
Rev 2.3 Doc No HDC06143
K202B/D 2-Port Secure KVM Switch

1
K202B/D Secure KVM Switch User Manual
Table o Content
Section 1 – Introduction 2
Package Content 2
Section 2 – Overview 2
Security Features 3
Operational Features 5
Equipment Requirements 6
Safety Precautions 9
Front Panel Features 10
Rear Panel Features 11
Tamper Evident Labels 12
Active Anti-Tampering System 12
Product Specifications 13
Section 3 – Installation 14
Before Installation 14
Installation 15
Section 4 – Operation 18
Operation 18
Section 5 – Troubleshooting 19
Troubleshooting Guide 19
High Sec Labs Warranty Programs 22
High Sec Labs Limited Warranty Terms and Conditions 22
High Sec Labs Security Procedures 24
COPYRIGHT AND LEGAL NOTICE 25
Record o Revisions
Rev Date Description of changes
1.0 Nov 11, 2010 Initial release
1.1 Nov 20, 2011 Internal review for CC evaluation
2.1 Dec 30, 2011 Released for customers
2.2 Feb 4, 2012 Added security procedures text
2.3 April 19, 2012 Added support for composite
device

2
K202B/D Secure KVM Switch User Manual
Introduction
Thank you for purchasing this HSL Small Form-Factor Secure KVM
Switch. This KVM Switch is designed for use in secure defense and
intelligence environments across wide security gaps. This 3rd
Generation Secure KVM Switch offers optical data diode per
channel. Optical data diodes are used to prevent data transfer
between connected computers running at different security levels
even if these computers attempts to attack the KVM. This product
provides the highest security safeguards and features that meet
today’s and will meet future cyber prevention requirements.
This User Manual provides all the details you’ll need to install and
operate your new Switch, in addition to troubleshooting guidance—
in the unlikely event of a problem.
Package Contents
Inside product packaging you will find the following
•K202B/D Secure KVM Switch unit
•12V 1A DC Power Supply
•DVI to VGA adapter plug (K204B only)
•This User Manual
Important: This product is equipped with always-on active anti-tampering system. Any attempt to
open the product enclosure will activate the anti-tamper triggers and render the unit inoperable.
If the unit’s enclosure appears disrupted or if the two channel-select LEDs flash continuously, please
remove product from service immediately and contact HSL Technical Support.
Section 1 - Introduction

3
K202B/D Secure KVM Switch User Manual
Security Features
HSL Secure KVM Switch is the most advanced and secure
commercially available KVM Switch available today. This product is a
derivative of high security KVM product used in newest NATO
nuclear submarines. Below is a summary of some of the security
features incorporated into the product.
Unidirectional Data Paths
Optical diodes used to enforce unidirectional data flow from the
peripheral devices to computers preventing potential leakage paths
between computers even in the severe threat of two infected
computers attacking the KVM.
No Shared Resources
This KVM Switch designed to securely operate even when
peripheral devices are vulnerable to signaling attacks. This KVM
Switch does not allow computer access to any shared resource and
does not share controllable power sources.
Dedicated Processors or Emulation
The Switch features a dedicated processor per computer port to
emulate peripheral devices. This keeps each computer running on
different security levels physically separated and secure at all times,
and prevents any unintended data leakage between computers.
Non-Reprogrammable Firmware
The Switch features custom firmware that is not reprogrammable,
preventing the ability to remotely attack the KVM control logic.
EDID Emulation and Firewall
HSL Secure KVM Switch blocks the computer access to the shared
display by using isolated EDID emulators. This arrangement together
with the internal EDID firewall protects from KVM attacks targeting
the external memory effect of the shared display.
USB Ports Protection
Console USB ports are protected from the use of storage and other
unsafe USB devices through strong filtering (independent of
computer protection means). Unqualified devices are rejected when
connected to the Switch. Only mouse and keyboard data are passed
through.
Heavy-duty Steel Enclosure
HSL Secure KVM Switches uses thick steel components to protect
the product from physical tampering and to minimize radiated
electromagnetic emissions that can be snooped or intercepted.
Active Always-On Anti-Tamper
Active chassis anti-tamper system prevents the KVM electronic
circuitry from being accessed and tampered with by permanently
disabling the product once tampering is detected.
Holographic Tamper-Evident Labels
Serially numbered holographic security tamper-evident label is
placed on the switch enclosure to provide a visual indication if the
switch has been opened or compromised.
Section 2 - Overview

4
K202B/D Secure KVM Switch User Manual
High Inter-Channel Analog Isolation
HSL Secure KVM Switches offer exceptionally high isolation between
computer channels to prevent analog leakages across the KVM.
Secure Packaging
“Tear away” packaging ensures secure delivery of the Switch as it is
routed to the end user.
Common Criteria EAL-4 Listing
The Switch is listed by the Common Criteria organization. It is
Common Criteria validated to EAL 4+ (Evaluation Assurance Level 4)
to assure the highest level of protection. Product complies with
standard higher than NIAP Protection Profile 2.1.
Section 2 - Overview

5
K202B/D Secure KVM Switch User Manual
Operational Features
The HSL Secure KVM Switch was designed with the user in mind for
today’s IT environment. Below is a summary of some of the features
incorporated into the Product.
USB Support
HSL Secure KVM Switch product designed and tested to support the
widest variety of USB keyboards and mice.
Keyboard Shortcuts Support
HSL Secure KVM Switch is the only Secure KVM that supports
keyboard shortcuts switching mode while providing highest level of
isolation.
DVI-I and HDMI Support
The K202B model supports both digital (DVI-D and HDMI) and
analog video (VGA) displays and video cards.
Audio Support
Switch support audio out switching. Microphone switching not
supported to prevent analog leakages through audio ports.
Display Diagnostic LED
Special display diagnostic LED near console display connector
provides essential guidance during installation.
KVM Extenders Support
HSL Secure KVM Switch supports most copper and fiber KVM
extenders connected to the console port.
Section 2 - Overview

6
K202B/D Secure KVM Switch User Manual
Equipment Requirements
Cables
HSL highly recommends you use HSL Cable Kits for your Switch to
help ensure superior security and performance. These cables offer
the highest quality possible to ensure optimal data and video
transmission.
One Cable Kit is required per connected computer.
Smart Cables from Belkin enables video conversion from computer
VGA output to DVI-D KVM input to enable legacy video mix with
newer DVI computers and display.
Note (K202B only): If VGA display will be used then all computers
must be connected through VGA interface. If one computer is VGA
only then all other computers must be connected through VGA and
display must support DVI-I or VGA.
How to order?
To connect: Use: Order No.
Computer keyboard,
mouse, DVI-D single-link
display
KVM Cable short (1.8 m),
DVI-D to DVI-D Single-Link,
USB, Black
CPN05485
Computer VGA video
output (K202B only)
KVM Cable short (1.8 m),
DVI-A to VGA, USB, Black
CPN05489
Computer audio output KVM Cable short (1.8 m),
Audio Out, Black-Green
CPN05490
Computer VGA output
(display and other
computers are DVI)
KVM Smart-Cable VGA PC to
DVI KVM converter cable
with USB type A to USB type
B, 6ft (1.8 m), black
CPN06011
KVM DVI-I video output
to VGA only display
(K202B only)
DVI-I to VGA display adapter CPN05492
Section 2 - Overview
Important: The use of cables other than those provided by HSL is
not recommended. Use of other cables may affect system security,
may permanently damage the product and may void product
warranty.

7
K202B/D Secure KVM Switch User Manual
Computers
The Switch is compatible with computers, thin-clients, servers and
laptops running on, but not limited to, the following OS platforms
• Windows® 2000
• Windows XP (Home/Professional)
• Windows 2003 Server
• Windows 7
• Windows Vista®
• Red Hat® Linux®
• Ubuntu® Linux®
• Other Linux distributions
• Mac OS® X v10.3 and higher.
Laptop docking stations having DVI, VGA or HDMI display output are
supported.
For latest compatibility list see HSL website or contact HSL support.
USB Keyboard console port
The Switch USB keyboard console port is compatible with the
following types of devices
•Standard USB keyboard (excluding devices having other
internal functions such as USB hub, or composite device);
and
•Bar-code readers emulating USB keyboard.
USB Mouse console port
The Switch USB mouse console port is compatible with the following
types of devices
•Standard USB mouse (excluding USB hubs or other USB
functions in composite device); or
•Standard USB keyboard or Standard KVM Extender
composite device having a keyboard/mouse functions
User Display
The Switch is compatible with the following types of displays
•VGA; or
•DVI-D Single-link; or
•HDMI (adapter to DVI needed); or
•DVI-I.
Note that all computers connected must support the same video
interface selected for the user display.
User Audio Devices
The Switch is compatible with the following types of user audio
devices
•Stereo headset; or
•Amplified stereo speakers.
Remote User Extension
The Switch is compatible with the following types of Remote Fiber
Extender device
•HSL RFE720 Secure Remote Fiber Extender device
connected to the switch console ports; or
•HSL RFE740 Secure Remote Fiber Extender device
connected to the switch console ports.
Section 2 - Overview

8
K202B/D Secure KVM Switch User Manual
Power Supply
Use only HSL power supply provided with the switch. In case of a
power supply failure, order a replacement unit from HSL.
Order No.
•EU – CPN06175
•US – CPN06174
•UK - CPN06176
Section 2 - Overview

9
K202B/D Secure KVM Switch User Manual
Sa ety Precautions
Please read the following safety precautions carefully before using
the product
Before cleaning, disconnect the product from DC
power.
Be sure not to expose the product to excessive
humidity.
Be sure to install the product on a clean secure
surface.
Do not place the DC power cord in a path of foot
traffic.
If the product is not used for a long period of time,
remove the product’s wall-mount power supply from
the mains jack.
If one of the following situations occurs, get the
product checked by a qualified service technician
The product’s power supply is overheated,
damaged, broken, causes smoke or shortens
the mains power socket.
Liquid penetrates the product’s case.
The product is exposed to excessive moisture
or water.
The product is not working well even after
carefully following the instructions in this
user’s manual.
The product has been dropped or is physically
damaged.
The product has obvious signs of breakage or
loose internal parts.
The product should be stored and used only in
temperature and humidity controlled environments
as defined in the product’s environmental
specifications.
The wall-mount power supply used with this product
should be the model supplied by the manufacturer
or an approved equivalent provided by HSL or an
authorized service provider. The use of improper
power source will void product warranty.
Section 2 - Overview

10
K202B/D Secure KVM Switch User Manual
Front Panel Features – K202B/D
Section 2 - Overview
1
2 3
6
4
5
1 – Heavy-duty steel enclosure
2 – Channel #1 selected LED
3 – Channel #1 select push-button
4 – Channel #2 select push-button
5 – Channel #2 selected LED
6 - Holographic Tamper Evident Label

11
K202B/D Secure KVM Switch User Manual
Rear Panel Features –K202B/D
Section 2 - Overview
1
2
7
1 – Display diagnostic LED
2 – Audio console output 3.5 mm stereo jack
3 – Console USB Keyboard jack
4 – Console USB Mouse jack
5 – Computer #1 group interface area
6 – DC Power input jack – barrel type
7 – Computer #1 group DVI-I (K202B) / DVI-D (K202D)
video input connector
3
10
4
8
5
6
8 – Computer #1 group audio input jack 3.5 mm stereo
9 - Computer #1 group Keyboard/Mouse USB jack
10 –User display console output (K202B) / DVI-D (K202D)
connector
9

12
K202B/D Secure KVM Switch User Manual
Tamper Evident Labels
HSL Secure KVM Switch uses a holographic tamper evident label to
provide visual indications in case of enclosure intrusion attempt.
These labels indicate white dots or the text “VOID” once removed.
When opening product packaging inspect the tampering evident
label.
I or any reason one or more tamper-evident label is missing,
appears disrupted, or looks di erent than the example shown
here, please call HSL Technical Support and avoid using that
product.
HSL Holographic Tampering Evident Label
Active Anti-Tampering System
HSL Secure KVM Switch is equipped with always-on active anti-
tampering system. If mechanical intrusion is detected by this
system, the Switch will be permanently disabled and LED will blink
continuously.
I product indication tampered state (all LEDs blinking) - please call
HSL Technical Support and avoid using that product.
Section 2 - Overview

13
K202B/D Secure KVM Switch User Manual
Product Speci ications
Part No. K202B - CGA05266
K202D - CGA06030
Enclosure Welded steel metal enclosure
Power Requirements 12V DC, 1A (maximum) power
adapter with center-pin-positive
polarity
AC Input 100 to 240VAC
No. o Secure Channels 2
No. o Users Supported 1
No. o Computers Supported 2
Displays Supported 1 single-link DVI-D display; analog
VGA display or HDMI with adapter
(K202B only)
Resolution Support Up to 1920x1200 DVI, up to
2048x1536 VGA (K202B only)
Console Keyboard Input USB Type-A female connector
Console Mouse Input USB Type-A female connector
Console Audio Out 3.5mm stereo jack
CPU Keyboard/Mouse Ports USB Type-B jack
CPU Audio Input 3.5mm stereo jack
CPU Video Input Port DVI-I dual-link female
Port Select push-buttons 2
Channel select LED Indicators 2
Operating Temp 32° to 104° F (0° to 40° C)
Storage Temp -4° to 140° F (-20° to 60° C)
Humidity 0 - 80% RH, non-condensing
Warranty 2 years; can be extended to up to 7
years at cost.
Dimensions 135(W) x 57 (D) x 33 (H) mm
5.4 (W) x 2.2 (D) x 1.3 (H) inch
Weight 0.75 Kg. (1.6 lbs.)
Security Accreditation Common Criteria EAL 4+
Made in Israel
Product design li e-cycle 10 years per MIL-HDBK-217E
Section 2 - Overview

14
K202B/D Secure KVM Switch User Manual
Be ore Installation
Unpacking the Product
Before opening the product sealed packaging inspect the seal
condition to assure that product was not accessed or tampered
during delivery. If packaging seal looks suspicious contact HSL
support team and do not use the product.
After seal removal inspect packaging content to verify that required
components included. See packaging content list in page 4 above.
After the Secure KVM Switch removed from its packaging materials
carefully inspect the tampering-evident label to assure that product
is properly sealed. If the label is damaged or missing contact HSL
support and do not use that product.
Where to locate the Switch?
Product must be located in a secure and well protected
environment to prevent potential attacker access.
If longer set of cables or if a Secure Fiber Extender (RFE) are used,
KVM Switch may be remotely located in a locked down facility to
prevent unauthorized users access.
Consider the following when deciding where to place the Switch
•User access to the front panel push-buttons (not needed if
keyboard shortcut is used to switch channels).
•Keyboard and mouse cables length. Cables typically may be
extended to a distance of 4 meters.
•Display cable length. Typically may be extended to around
10 meters without video quality degradation (still depends
on display and cables quality and must be tested prior to
fixed installation).
•The location of the computers in relation to the switch and
the length of available KVM cables (typically 1.8 m)
Note: Due to USB and DVI signal limitations, the cable length cannot
exceed 4.6 m (15 feet).
Warning: Avoid placing cables near fluorescent lights, air-
conditioning equipment, RF equipment or machines that create
electrical noise (e.g., vacuum cleaners).
Section 3 - Installation

15
K202B/D Secure KVM Switch User Manual
Installation
Step 1 Connecting the Console devices to the Switch
See figures in page 11 above for connector locations.
Note: for installation instructions with Remote Fiber Extender
(RFE) – refer to the RFE product User Manual.
•Connect the user display.
Note: K202B - If user display is only VGA
-Verify that all computers are having either VGA or DVI-I
display output.
-Use supplied DVI to VGA adapter.
•Connect the user console keyboard (USB).
•Connect the user console mouse (USB).
Note: If USB mouse is connected to the USB keyboard port or if USB
keyboard is connected to the USB mouse port it would not work!
Note: Keyboards with integrated USB hub, card-reader, storage
device or multimedia extension will be either not supported at all or
only keyboard function will be operating.
•Connect the user headphones or amplified speakers to the
switch audio output jack.
Note: In any case do not connect a microphone to the switch audio
output port.
Step 2 Connecting the Computers
Connect the two computers to the Secure KVM switch through the
following steps
•Connect each computer with KVM cable (DVI and USB or VGA
and USB cables – for details on cables see page 6). USB cable
can be connected to any free USB port in the computer.
Note: If computer is having more than one video output connector
– first test for video output availability by connecting a display
directly to that port.
Note: Note The USB cable must be connected directly to a free USB
port on the computer, with no USB hubs or other devices in
between.
•Connect an audio cable (CPN05490) to the computer audio
output (lime green color) or line output (blue color) jacks.
Step 3 Power up
•Power up user display. Select proper input if applicable (VGA or
DVI-D).
•Power up the Secure KVM Switch by connecting the power. The
display diagnostic LEDs should be solid green for a few seconds
after power up. This indicates the display EDID information has
been captured and secured. If the display diagnostic LED
remains blinking for longer than 10 seconds after power up,
refer to the Troubleshooting section of this user manual.
•Power up the connected computers.
Note: When you power on your computers, the Switch emulates
both a mouse and keyboard on each port and allows your
computers to boot normally. The computer connected to port “1”
will be displayed on the user’s display. Check to see that the
Section 3 - Installation

16
K202B/D Secure KVM Switch User Manual
keyboard, display, and mouse are working normally. Repeat this
check with the second port to verify that both computers are
connected and responding correctly.
If you encounter an error, check your cable connections for that
computer and reboot. If the problem persists, please refer to the
Troubleshooting section in this User Manual.
Section 3 - Installation

17
K202B/D Secure KVM Switch User Manual
Typical system installation diagram (K202B)
Section 3 - Installation

18
K202B/D Secure KVM Switch User Manual
Operation
Now that you have connected your console and computers to the
Switch, it is ready for use. Default channel after power up is channel
#1 as indicated by channel select LED #1 illumination. You can select
which computer you wish to control by one of the following
methods
1. Switch between computers using ront panel push-buttons
You can select which computer you wish to control by momentarily
pressing the corresponding port selector push-button on the front
of the Switch. The LED number will illuminate to indicate which
computer (or port) is currently selected. It may take approximately
1 second for the video signal to sync after switching ports. This is
normal behavior and is dependent on the display connected. This is
normal operation and ensures that proper synchronization is
established between the display and the connected computers.
Note that keyboard and mouse inputs can only be sent to the
selected computer, and video outputs can only be received from the
selected computer. The Switch also prevents any data transfer
between connected computers, ensuring the security of your
computers.
2. Switch between computers using keyboard shortcuts
You can select which computer you wish to control by typing key
combinations on the keyboard.
To switch KVM to another channel press CNTL+CNTL+ “Channel
number” for example for computer #2 press CNTL+CNTL+2.
Note: The Secure KVM Switch does not have a power switch. It is
highly recommended that the product will be powered
continuously.
Section 4 - Operation
Important Security Note:
If you are aware of potential security vulnerability while installing
or operating this product, we encourage you to contact us
immediately at the following email address:
[e-mail]

19
K202B/D Secure KVM Switch User Manual
Troubleshooting Guide
General
Problem: No power - No video output, none of the front panel LEDs
is illuminating.
Solutions:
•Check that the power supply is properly connected to the mains
socket.
•Check that DC plug is fully inserted into the switch DC jack.
•Check that the device is powered by using optical mouse with
visible red light. If power not available – change power supply.
Problem: Channel select LEDs are blinking. Secure KVM Switch does
not work.
Solutions: Device anti-tampering system was triggered. Change unit
and call HSL technical support.
Problem: KVM does not respond to channel select push buttons.
Solutions:
If RDC is connected then this is a normal behavior. Control the KVM
through the RDC or through keyboard shortcuts.
Video
Problem: No video image in user display (all channels)
Solutions:
•Check that the display is properly powered.
•Check that DVI cable is properly secured at both sides.
•Check at the display on-screen menu that source selected
matches the cable connected to the display.
•Check if display video mode is the same as PC (DVI and DVI
or VGA and VGA).
•Check that display diagnostic LED is steady green – if not –
change display or display cable or call HSL support.
Problem: No video image in user display (specific channel)
Solutions:
•Reboot the computer.
•Check that the video cable connecting computer and KVM is
properly secured at both sides.
•Check that PC video output is sent to the connected video
connector (if PC supports multiple displays).
•Check that PC resolution matches connected display
capabilities.
•Connect the display directly to the PC to confirm that video
output is available and that good image is shown.
Section 5 - Troubleshooting
Important Note:
If you are aware of potential security vulnerability while
installing or operating this product, we encourage you to contact
us immediately at the following email address:
[e-mail]
The secu[email protected] email address is not intended to
reach technical support on HSL products or services. Any
support inquiries should be directed to
[e-mail].
