HIK VISION DS-K4H250S User manual

Title:
DS-K4H250/450/258 series magnetic lock
connect to DS-K2600 series Access Controller
Version:
v1.0
Date:
01/11/2018
Product:
Access Control Device
Page:
1 of 9
DS-K4H250/450/258 series magnetic lock connect to DS-
K2600 series Access Controller
Preparation
Connecting magnetic lock to access controller is mainly applied to swiping card to open the door for
exiting. For magnetic lock and access controller in this document, please check the table below:
Magnetic Lock
Access Controller
DS-K4H250S
DS-K4H250D
DS-K4H450D
DS-K2601
DS-K2602
DS-K2604
DS-K4H258S
DS-K4H258D
Note
This document is simply used to guide users how to wire correctly and ensure access controllers can
control locks.
The access controller model in this document is DS-K2604.
Part 1 is mainly for magnetic lock wiring, and Part 2 and Part 3 are mainly for the situation that users
could get the door status on iVMS-4200 Client.
Notice
1. Please cut off power supply before wiring;
2. Please use a tool to screw magnetic lock screws in following picture, and remove the cover of
magnetic lock, find V+/V- and NO/NC & COM interfaces of magnetic lock in following picture;

Title:
DS-K4H250/450/258 series magnetic lock
connect to DS-K2600 series Access Controller
Version:
v1.0
Date:
01/11/2018
Product:
Access Control Device
Page:
2 of 9
3. Correspondingly, there are lock and door magnetic interfaces in DS-K2600 series access controllers,
as pictures show:
Note: means lock interface; means door magnetic interface;
Access Controller
Interface
DS-K2601
DS-K2602
DS-K2604
Interface
Description
Note
V+/V-
Power Supply
NO/NC, COM
Door Magnetic
Singnal Output
DS-K4H258S/D series magnetic locks
don't have NO/NC and COM interfaces

Title:
DS-K4H250/450/258 series magnetic lock
connect to DS-K2600 series Access Controller
Version:
v1.0
Date:
01/11/2018
Product:
Access Control Device
Page:
3 of 9
Part 1: Lock+ & Lock- Wiring
DS-K4H250S & DS-K4H258S
Please connect as the following picture:
Magnetic lock LED status:
Normal(Close Door)
Normal(Open Door)
Abnormal
DS-K4H250D & DS-K4H450D & DS-K4H258D
Please connect as the following picture:
Magnetic lock LED status:
Normal(Close Door)
Normal(Open Door)
Abnormal

Title:
DS-K4H250/450/258 series magnetic lock
connect to DS-K2600 series Access Controller
Version:
v1.0
Date:
01/11/2018
Product:
Access Control Device
Page:
4 of 9
Part 2: Lock+/Lock- & NC/COM Wiring
Step 1:
DS-K4H250S
Please connect as the following picture:
Magnetic lock LED status:
Normal(Close Door)
Normal(Open Door)
Abnormal
DS-K4H250D & DS-K4H450D
Please connect as the following picture:
COM
V+
V-
NO
NC
NC
V+
COM
V-
NO
Lock1+
Lock1-
Door
Magnetic1
GND

Title:
DS-K4H250/450/258 series magnetic lock
connect to DS-K2600 series Access Controller
Version:
v1.0
Date:
01/11/2018
Product:
Access Control Device
Page:
5 of 9
Magnetic lock LED status:
Normal(Close Door)
Normal(Open Door)
Abnormal
Step 2:
Add access controller to iVMS-4200 Client;
Step 3:
Click Tool Device Arming Control, check your access controller arming status;
The icon means device was armed by iVMS-4200 Client;
Step 4:
Enter Access Control Advanced Function Access Control Parameters interface, set Door
Magnetic Sensor as Remian Closed, and it should be consistent with the wiring of Door Magnetic
Singnal Output;

Title:
DS-K4H250/450/258 series magnetic lock
connect to DS-K2600 series Access Controller
Version:
v1.0
Date:
01/11/2018
Product:
Access Control Device
Page:
6 of 9
Step 5:
Enter Status Monitor Door Status interface, open the door, check door status on iVMS-4200 Client
and the magnetic lock LED status;
Magnetic Lock
LED status
Door Status
Alarm Event
Part 3: Lock+/Lock- & NO/COM Wiring
Step 1:
DS-K4H250S
Please connect as the following picture:
Magnetic lock LED status:
Normal(Close Door)
Normal(Open Door)
Abnormal

Title:
DS-K4H250/450/258 series magnetic lock
connect to DS-K2600 series Access Controller
Version:
v1.0
Date:
01/11/2018
Product:
Access Control Device
Page:
7 of 9
DS-K4H250D & DS-K4H450D
Please connect as the following picture:
Magnetic lock LED status:
Normal(Close Door)
Normal(Open Door)
Abnormal
Step 2:
Add access controller to iVMS-4200 Client;
Step 3:
Click Tool Device Arming Control, check your access controller arming status;
The icon means device was armed by iVMS-4200 Client;
Lock1+
Lock1-
Door
Magnetic1
GND
COM
V+
V-
NO
NC
NC
V+
COM
V-
NO

Title:
DS-K4H250/450/258 series magnetic lock
connect to DS-K2600 series Access Controller
Version:
v1.0
Date:
01/11/2018
Product:
Access Control Device
Page:
8 of 9
Step 4:
Enter Access Control Advanced Function Access Control Parameters interface, set Door
Magnetic Sensor as Remian Open, and it should be consistent with the wiring of Door Magnetic
Singnal Output;
Step 5:
Enter Status Monitor Door Status interface, open the door, check door status on iVMS-4200 Client
and the magnetic lock LED status;
Magnetic Lock
LED status
Door Status
Alarm Event
NOTE: Abnomal in Magnetic lock LED status part could be displaied in following scenario, open door
timeout, abnomally open door(by force), as well as not standard installation cuasing armature plate and
lock body contact are not fully fitted.

Title:
DS-K4H250/450/258 series magnetic lock
connect to DS-K2600 series Access Controller
Version:
v1.0
Date:
01/11/2018
Product:
Access Control Device
Page:
9 of 9
