DS-80xxHM(F)I/xx Series Mobile DVR
Technical Manual

Hikvision Technical Manual
©2006 –2010 by HIKVISION. All rights reserved.
2
Notices
The information in this documentation is subject to change without notice and does
not represent any commitment on behalf of HIKVISION. HIKVISION disclaims any
liability whatsoever for incorrect data that may appear in this documentation. The
product(s) described in this documentation are furnished subject to a license and
may only be used in accordance with the terms and conditions of such license.
Copyright © 2006-2010 by HIKVISION. All rights reserved.
This documentation is issued in strict confidence and is to be used only for
the purposes for which it is supplied. It may not be reproduced in whole or in
part, in any form, or by any means or be used for any other purpose without prior
written consent of HIKVISION and then only on the condition that this notice is
included in any such reproduction. No information as to the contents or subject
matter of this documentation, or any part thereof, or arising directly or indirectly
therefrom, shall be given orally or in writing or shall be communicated in any
manner whatsoever to any third party being an individual, firm, or company or any
employee thereof without the prior written consent of HIKVISION. Use of this
product is subject to acceptance of the HIKVISION agreement required to use this
product. HIKVISION reserves the right to make changes to its products as
circumstances may warrant, without notice.
This documentation is provided “as-is,” without warranty of any kind.
Please send any comments regarding the documentation to:
overseabusi[email protected]
Find out more about HIKVISION at www.hikvision.com

Hikvision Technical Manual
©2006 –2010 by HIKVISION. All rights reserved.
3
Contents
1. Overview
2. Model Description
3. Features
4. Hardware Interface
5. Specifications

Hikvision Technical Manual
©2006 –2010 by HIKVISION. All rights reserved.
4
1.Overview
DS-80xxHM(F)I/xx series mobile DVR is designed especially for vehicle
surveillance. It has advantages of both digital video recorder (DVR) and
digital video server, along with special vibration control solution for stable
recording in vehicle. The product is widely applied in different kinds of vehicles for
video surveillance such as cash carrying vehicles, buses, passenger vehicles and
railway passenger compartments, etc.

Hikvision Technical Manual
©2006 –2010 by HIKVISION. All rights reserved.
5
2.Model Description
DS-8008HMI/xx: 8-ch video input and 8-ch audio input, max support CIF
real time recording, support 6~36V DC input.
DS-8008HMFI/xx: 8-ch video input and 8-ch audio input, max support
4CIF real time recording, support 6~36V DC input.
DS-8012HMI/xx: 12-ch video input and 12-ch audio input, max support
CIF real time recording, support 6~36V DC input.
DS-8012HMFI/xx: 12-ch video input and 12-ch audio input, max support
4CIF real time recording, support 6~36V DC input.
Note: The default DVRs are without HDD.
A factory recommended HDD should be used for this device.
/xx means 3G module (optional):
/GE: build in EVDO module
/GW: build in WCDMA module
/GS: build in TD-SCDMA module

Hikvision Technical Manual
©2006 –2010 by HIKVISION. All rights reserved.
6
3.Features
Basic Features
Video compression standard: H.264
Video processor: DSP
CPU: Embedded MPU
OS: Real time operating system
Support dual H.264 stream (main stream and sub stream)
Support two 2.5 inch pluggable SATA HDDs
Special Features
Power supply unit: Use special technology of wide range power
input(DC+6V~+36V), over current protection, over voltage protect and
short circuit protection
Adopt patented hard disk vibration-proof and bracing technology
Shut down delay after ignition off (5min~6h)
Daily scheduled power on/off (00:00~24:00)
Support GPS text insertion function (longitude, latitude and vehicle speed)
Time sync through GPS
Support EVDO, TD-SCDMA data transmission
Support E-SATA high speed backup, USB backup
Support mirror recording and master-slave recording.
12V DC power output used for camera power supply
Two pluggable HDDs can work at master/slave mode or mirror mode

Hikvision Technical Manual
©2006 –2010 by HIKVISION. All rights reserved.
7
4.Hardware Interface
Front Panel
1. Pluggable HDD cage
2. HDD lock
3. HDD tightening screw
4. E-SATA
5. Front panel ventilation slot
6. Status indicator
Rear Panel
1. Aviation connector for video, audio, power etc.
2. Video, audio main out
3. Video, audio spot out
4. Voice talk interface
5. RS485, keyboard port, alarm I/O
6. RS485 resistance switch
7. USB
8. LAN

Hikvision Technical Manual
©2006 –2010 by HIKVISION. All rights reserved.
8
9. RS232
10.Power in, ignition switch
11.VGA
12.Driving status interface
13.GPS antenna
14.Wireless network main/aux antenna
15.DC +12V +5V power out

Hikvision Technical Manual
©2006 –2010 by HIKVISION. All rights reserved.
9
5.Specifications
Model
DS-8008/12HMI
DS-8008/12HMFI
Video
compression
H.264
Preview
resolution
4CIF (PAL: 704*576, NTSC: 704*480)
Playback
resolution
2CIF/CIF/QCIF
4CIF/DCIF/2CIF/CIF/QCIF
Video input
8-ch aviation interface (1.0Vp-p, 75Ω)
12-ch aviation interface (1.0Vp-p, 75Ω)
Video output
2-ch aviation interfaces
Frame rate (per
channel)
25(P)/30(N) fps
Stream type
Video/Video&Audio
Bit rate
32kbps~2Mbps, or user-defined (Max. 8Mbps)
Audio input
8-ch aviation interface (Linear
electrical level, 1KΩ)
12-ch aviation interface (Linear electrical
level, 1KΩ)
Audio output
2 channel (Linear electrical level, 600Ω)
Audio
compression
OggVorbis, 16kbps
Voice talk
1 aviation interface (Linear electrical level, 1KΩ)
Communication
interface
1 RJ45 10M/100M adaptive Ethernet Interface, 1 RS232 interface, 1 RS485 interface
HDD
2 pluggable HDDs, each max supports 2000GB
eSATA
interface
1 eSATA interface for high speed backup
USB interface
1 USB interface, can support USB disk, USB HDD, USB DVD-R/W and CD-R/W
VGA interface
(optional)
1 VGA interface, support resolution:
800*600/60Hz, 800*600/60Hz, 1280*1024/60Hz
Alarm in
16
Alarm out
4
Wireless
network
interface
(optional)
2 x SMA Wireless network antenna
Vehicle power
input
DC 6~36V adaptive
Power output
DC 12V/5V output, build in resettable fuse
Power off delay
Shut down delay after ignition off (5min~6h)

Hikvision Technical Manual
©2006 –2010 by HIKVISION. All rights reserved.
10
Scheduled
on/off
Daily scheduled power on/off (00:00~24:00)
Power
consumption
26/30W (without hard disks)
30/40W (without hard disks)
Working
temperature
-15°C~+55°C
Working
humidity
10%~95%
Size
293mm(W)*225mm(D)*90mm(H)
Weight
≤5Kg (without hard disks)
Remote control
Special IR remote control
GPS interface
(optional)
Build in GPS module, SMA antenna
PAL: 176×144(QCIF), 352×288(CIF), 704×288(2CIF), 528×384(DCIF), 704×576(4CIF);
NTSC: 176×120(QCIF), 352×240(CIF), 704×240(2CIF), 528×320(DCIF), 704×480(4CIF).
