HIK VISION DS-K3G200X Series User manual

DS-K3G200(L)X Series Tripod Turnsle

Legal Informaon
©2023 Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
About this Manual
The Manual includes instrucons for using and managing the Product. Pictures, charts, images and
all other informaon hereinaer are for descripon and explanaon only. The informaon
contained in the Manual is subject to change, without noce, due to rmware updates or other
reasons. Please nd the latest version of this Manual at the Hikvision website ( hps://
www.hikvision.com/ ).
Please use this Manual with the guidance and assistance of professionals trained in supporng the
Product.
Trademarks
and other Hikvision's trademarks and logos are the properes of
Hikvision in various jurisdicons.
Other trademarks and logos menoned are the properes of their respecve owners.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE PRODUCT
DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS IS" AND "WITH
ALL FAULTS AND ERRORS". HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR
PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION
BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,
INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS
INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION,
WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY,
OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY
RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS
INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY
TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY RIGHTS.
YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
DS-K3G200(L)X Series Tripod Turnsle
i

DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED
TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN
RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATTER
PREVAILS.
Data Protecon
During the use of device, personal data will be collected, stored and processed. To protect data,
the development of Hikvision devices incorporates privacy by design principles. For example, for
device with facial recognion features, biometrics data is stored in your device with encrypon
method; for ngerprint device, only ngerprint template will be saved, which is impossible to
reconstruct a ngerprint image.
As data controller, you are advised to collect, store, process and transfer data in accordance with
the applicable data protecon laws and regulaons, including without limitaon, conducng
security controls to safeguard personal data, such as, implemenng reasonable administrave and
physical security controls, conduct periodic reviews and assessments of the eecveness of your
security controls.
DS-K3G200(L)X Series Tripod Turnsle
ii

Regulatory Informaon
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with "CE"
and comply therefore with the applicable harmonized European standards listed
under the EMC Direcve 2014/30/EU, RE Direcve 2014/53/EU,the RoHS Direcve
2011/65/EU
2012/19/EU (WEEE direcve): Products marked with this symbol cannot be disposed
of as unsorted municipal waste in the European Union. For proper recycling, return
this product to your local supplier upon the purchase of equivalent new equipment,
or dispose of it at designated collecon points. For more informaon see:
www.recyclethis.info
2006/66/EC (baery direcve): This product contains a baery that cannot be
disposed of as unsorted municipal waste in the European Union. See the product
documentaon for specic baery informaon. The baery is marked with this
symbol, which may include leering to indicate cadmium (Cd), lead (Pb), or mercury
(Hg). For proper recycling, return the baery to your supplier or to a designated
collecon point. For more informaon see:www.recyclethis.info
DS-K3G200(L)X Series Tripod Turnsle
iii

Safety Instrucon
These instrucons are intended to ensure that user can use the product correctly to avoid danger
or property loss.
The precauon measure is divided into Dangers and Cauons:
Dangers: Neglecng any of the warnings may cause serious injury or death.
Cauons: Neglecng any of the cauons may cause injury or equipment damage.
Dangers: Follow these safeguards to prevent
serious injury or death.
Cauons: Follow these precauons to prevent
potenal injury or material damage.
Danger:
●All the electronic operaon should be strictly compliance with the electrical safety regulaons,
re prevenon regulaons and other related regulaons in your local region.
●Please use the power adapter, which is provided by normal company. The power consumpon
cannot be less than the required value.
●Do not connect several devices to one power adapter as adapter overload may cause over-heat
or re hazard.
●Please make sure that the power has been disconnected before you wire, install or dismantle the
device.
If the top caps should be open and the device should be powered on for maintenance, make
sure:
1. Power o the fan to prevent the operator from geng injured accidentally.
2. Do not touch bare high-voltage components.
3. Make sure the switch’s wiring sequence is correct aer maintenance.
●Please make sure that the power has been disconnected before you wire, install or dismantle the
device.
●When the product is installed on wall or ceiling, the device shall be rmly xed.
●If smoke, odors or noise rise from the device, turn o the power at once and unplug the power
cable, and then please contact the service center.
●Do not ingest baery, Chemical Burn Hazard.
This product contains a coin/buon cell baery. If the coin/buon cell baery is swallowed, it
can cause severe internal burns in just 2 hours and can lead to death.
Keep new and used baeries away from children. If the baery compartment does not close
securely, stop using the product and keep it away from children. If you think baeries might have
been swallowed or placed inside any part of the body, seek immediate medical aenon.
●If the product does not work properly, please contact your dealer or the nearest service center.
Never aempt to disassemble the device yourself. (We shall not assume any responsibility for
problems caused by unauthorized repair or maintenance.)
DS-K3G200(L)X Series Tripod Turnsle
iv

Cauons:
●Stainless steel may be corroded in some circumstances. You need to clean and care the device by
using the stainless steel cleaner. It is suggested to clean the device every month.
●Do not drop the device or subject it to physical shock, and do not expose it to high
electromagnesm radiaon. Avoid the equipment installaon on vibraons surface or places
subject to shock (ignorance can cause equipment damage).
●Do not place the device in extremely hot (refer to the specicaon of the device for the detailed
operang temperature), cold, dusty or damp locaons, and do not expose it to high
electromagnec radiaon.
●The device cover for indoor use shall be kept from rain and moisture.
●Exposing the equipment to direct sun light, low venlaon or heat source such as heater or
radiator is forbidden (ignorance can cause re danger).
●Do not aim the device at the sun or extra bright places. A blooming or smear may occur
otherwise (which is not a malfuncon however), and aecng the endurance of sensor at the
same me.
●Please use the provided glove when open up the device cover, avoid direct contact with the
device cover, because the acidic sweat of the ngers may erode the surface coang of the device
cover.
●Please use a so and dry cloth when clean inside and outside surfaces of the device cover, do
not use alkaline detergents.
●Please keep all wrappers aer unpack them for future use. In case of any failure occurred, you
need to return the device to the factory with the original wrapper. Transportaon without the
original wrapper may result in damage on the device and lead to addional costs.
●Improper use or replacement of the baery may result in hazard of explosion. Replace with the
same or equivalent type only. Dispose of used baeries according to the instrucons provided by
the baery manufacturer.
●Biometric recognion products are not 100% applicable to an-spoong environments. If you
require a higher security level, use mulple authencaon modes.
●Do not stay in the lane when the device is reboong.
●RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED
BATTERIES ACCORDING TO THE INSTRUCTIONS.
●SUITABLE FOR MOUNTING ON CONCRETE OR OTHER NON-COMBUSTIBLE SURFACE ONLY.
●The instrucons shall require connecon of the equipment protecve earthing conductor to the
installaon protecve earthing conductor.
DS-K3G200(L)X Series Tripod Turnsle
v

Available Models
Product Name Model
Tripod Turnsle DS-K3G200(L)X
DS-K3G200(L)X Series Tripod Turnsle
vi

Contents
Chapter 1 Overview .................................................................................................................... 1
1.1 Introducon ........................................................................................................................... 1
1.2 Main Features ........................................................................................................................ 1
Chapter 2 System Wiring ............................................................................................................ 3
Chapter 3 Installaon ................................................................................................................. 5
3.1 Disassemble Pedestals ........................................................................................................... 5
3.2 Install Pedestals ..................................................................................................................... 5
Chapter 4 General Wiring ........................................................................................................... 7
4.1 Components Introducon ...................................................................................................... 7
4.2 Wiring Electric Supply ............................................................................................................ 8
4.3 Wiring .................................................................................................................................. 10
4.4 Terminal Descripon ............................................................................................................ 10
4.4.1 Lane Control Board Terminal Descripon ................................................................... 10
4.4.2 Access Control Board Terminal Descripon (Oponal) ............................................... 11
4.4.3 Main Oponal Board Terminal Descripon (Oponal) ............................................... 13
4.4.4 Sub Oponal Board Terminal Descripon (Oponal) .................................................. 14
4.4.5 Card Reader Board Terminal Descripon .................................................................... 14
4.4.6 RS-485 Wiring ............................................................................................................. 15
4.4.7 RS-232 Wiring ............................................................................................................. 16
4.4.8 Alarm Input Wiring ..................................................................................................... 16
4.4.9 Exit Buon Wiring ....................................................................................................... 17
4.5 Device Sengs via Buon ................................................................................................... 17
4.5.1 Conguraon via Buon ............................................................................................. 18
4.5.2 Inialize Device ........................................................................................................... 20
Chapter 5 Acvaon ................................................................................................................. 21
5.1 Acvate via SADP ................................................................................................................. 21
DS-K3G200(L)X Series Tripod Turnsle
vii

5.2 Acvate Device via iVMS-4200 Client Soware ................................................................... 22
5.3 Acvate via Web Browser .................................................................................................... 23
Chapter 6 Operaon via Web Browser ...................................................................................... 24
6.1 Login .................................................................................................................................... 24
6.2 Forget Password ................................................................................................................... 24
6.3 Overview .............................................................................................................................. 24
6.4 Person Management ............................................................................................................ 25
6.5 Search Event ........................................................................................................................ 27
6.6 Conguraon ....................................................................................................................... 28
6.6.1 View Device Informaon ............................................................................................. 28
6.6.2 Set Time ...................................................................................................................... 28
6.6.3 Set DST ........................................................................................................................ 29
6.6.4 Change Administrator's Password ............................................................................... 29
6.6.5 Online Users ................................................................................................................ 30
6.6.6 View Device Arming/Disarming Informaon .............................................................. 30
6.6.7 Network Sengs ......................................................................................................... 30
6.6.8 Event Linkage .............................................................................................................. 32
6.6.9 Access Control Sengs ............................................................................................... 34
6.6.10 Turnsle .................................................................................................................... 37
6.6.11 Card Sengs ............................................................................................................. 39
6.6.12 Set Privacy Parameters .............................................................................................. 40
6.6.13 Upgrade and Maintenance ....................................................................................... 40
6.6.14 Device Debugging ..................................................................................................... 41
6.6.15 Component Status .................................................................................................... 41
6.6.16 Log Query .................................................................................................................. 42
6.6.17 Cercate Management ........................................................................................... 42
Chapter 7 Client Soware Conguraon ................................................................................... 44
7.1 Conguraon Flow of Client Soware ................................................................................. 44
DS-K3G200(L)X Series Tripod Turnsle
viii

7.2 Device Management ............................................................................................................ 45
7.2.1 Add Device .................................................................................................................. 45
7.2.2 Reset Device Password ................................................................................................ 47
7.2.3 Manage Added Devices .............................................................................................. 48
7.3 Group Management ............................................................................................................. 49
7.3.1 Add Group ................................................................................................................... 49
7.3.2 Import Resources to Group ......................................................................................... 49
7.4 Person Management ............................................................................................................ 50
7.4.1 Add Organizaon ........................................................................................................ 50
7.4.2 Import and Export Person Idenfy Informaon .......................................................... 50
7.4.3 Get Person Informaon from Access Control Device .................................................. 53
7.4.4 Issue Cards to Persons in Batch ................................................................................... 54
7.4.5 Report Card Loss ......................................................................................................... 54
7.4.6 Set Card Issuing Parameters ........................................................................................ 55
7.5 Congure Schedule and Template ....................................................................................... 56
7.5.1 Add Holiday ................................................................................................................. 56
7.5.2 Add Template .............................................................................................................. 57
7.6 Set Access Group to Assign Access Authorizaon to Persons .............................................. 58
7.7 Congure Advanced Funcons ............................................................................................ 60
7.7.1 Congure Device Parameters ...................................................................................... 61
7.7.2 Congure Device Parameters ...................................................................................... 65
7.8 Door Control ........................................................................................................................ 66
7.8.1 Control Door Status ..................................................................................................... 66
7.8.2 Check Real-Time Access Records ................................................................................ 67
Appendix A. DIP Switch ............................................................................................................ 69
A.1 DIP Switch Descripon ......................................................................................................... 69
Appendix B. Buon Conguraon Descripon .......................................................................... 70
Appendix C. Event and Alarm Type ........................................................................................... 72
DS-K3G200(L)X Series Tripod Turnsle
ix

Appendix D. Error Code Descripon .......................................................................................... 73
DS-K3G200(L)X Series Tripod Turnsle
x

Chapter 1 Overview
1.1 Introducon
By adopng the turnsle integratedly with the access control system, person should authencate
to pass through the lane via presenng cards, face, or QR code, etc. It is widely used in aracons,
oce, construcon sites, residences and other indoor scenes.
1.2 Main Features
●Bidireconal (Entering/Exing) lane.
●Support remote control and management by HCP soware.
●High-brightness LED indicates the entrance/exit and passing status except "Pg" type.
DS-K3G200(L)X Series Tripod Turnsle
1

●Fire alarm passing: When triggered, the arms will be dropped automacally for emergency
evacuaon.
●Support PC web browser, easy to do the conguraon.
●Support ISAPI protocol for 3rd party integraon development.
DS-K3G200(L)X Series Tripod Turnsle
2

Chapter 2 System Wiring
The preparaon before installaon and general wiring.
Steps
1. Draw a line based on the outer edge of the le or right pedestal or column.
2. Draw other parallel lines for installing the other pedestals.
Note
The distance between the nearest two line is 836 mm.
3. Slot on the installaon surface and dig installaon holes according to the hole posion. Put 4
expansion bolts for each pedestal.
4. Bury cables. Each lane buries 1 high voltage cable. For details, see the system wiring diagram
below.
Figure 2-1 System Wiring Diagram
Note
●High voltage: AC power input
●The suggested inner diameter of the high voltage conduit is larger than 30 mm.
●The external AC power cord should be double-insulated.
●Before digging holes, evaluate the thickness of the installaon surface to avoid puncturing.
●The network cable must be CAT5e or the network cable has beer performance.
●If the usage scenarios of the equipment include kindergarten and primary school, it is
recommended to design dedicated turnsles for young children and lower grade students to
reduce the safety risks.
DS-K3G200(L)X Series Tripod Turnsle
3

If there is a scene where children pass through alone, it is recommended to use a children's
bracket for face recognion terminal installaon. When installing, it is recommended to
choose a low angle installaon or an external vercal children's bracket. The vercal children's
bracket is recommended to be installed about 0.5 meters in front of the turnsle.
DS-K3G200(L)X Series Tripod Turnsle
4

Chapter 3 Installaon
3.1 Disassemble Pedestals
Before installaon, you should use the key to open the pedestals.
View the pictures below to nd the lock holes.
Figure 3-1 Lock Holes
3.2 Install Pedestals
Before You Start
Prepare for the installaon tools, check the device and the accessories, and clear the installaon
base.
Steps
Note
●The device should be installed on the concrete surface or other non-ammable surfaces.
●To prevent stainless steel from rusng due to dirt during construcon, it is recommended that
the protecve lm be removed aer the installaon is completed. There may be residual
DS-K3G200(L)X Series Tripod Turnsle
5

adhesive at the lm cung posion. It is recommended to use WD-40 protecve liquid to wipe
aer tearing the lm.
●The dimension is as follows.
Figure 3-2 Dimension
1. Prepare for the installaon tools, check the components, and prepare for the installaon base.
2. Seal the boom of the turnsle to avoid water from entering.
3. According to the entrance and exit marks on the pedestals, move the pedestals to the
corresponded posions.
Note
Make sure the installaon holes on the pedestals and the base are aligned with each other.
4. Secure the pedestals with expansion bolts.
Note
●Do not immerse the pedestal in the water. In special circumstances, the immersed height
should be no more than 150 mm.
5. Install the barrier arm.
DS-K3G200(L)X Series Tripod Turnsle
6

Chapter 4 General Wiring
Note
●Aer maintenance, you should close the water-proof cover over the high voltage module.
●When you should maintain or disassemble the high voltage modules, you should remove the
enre high voltage modules and maintain it outside the turnsle. You should unplug the cables
that connected to the peripherals before maintenance to avoid destroy of the device.
4.1 Components Introducon
By default, basic components of the turnsle are connected well. The pedestals can communicate
by wiring the interconnecng cables. And the turnsle supports wiring the AC electric supply for
the whole system's power supply.
Note
The voltage uctuaon of the electric supply is between 100 VAC and 240 VAC, 50 to 60 Hz.
The picture displayed below describes the serial port on the entrance and exit direcon.
Figure 4-1 Serial Port
The picture displayed below describes each component's posion on the turnsle.
Note
The diagram is for reference only.
DS-K3G200(L)X Series Tripod Turnsle
7

Figure 4-2 Components Diagram 1
4.2 Wiring Electric Supply
Wire electric supply with the power switch or power adapter in the pedestal. Terminal L (brown)
and terminal N (Blue) are on the switch, while terminal PE should connect to a ground wire (yellow
and green wire).
For product with power switch, the wiring diagram is as follows:
DS-K3G200(L)X Series Tripod Turnsle
8

For product with power adapter, the wiring diagram is as follows:
Warning
Terminal PE should connect to a ground wire to avoid hazard when people touching the device.
DS-K3G200(L)X Series Tripod Turnsle
9
