English
c) Prevent unintentional starting. Ensure the
switch is in the off-position before connecting
to power source and/or battery pack, picking up
or carrying the tool.
Carrying power tools with your finger on the switch
or energising power tools that have the switch on
invites accidents.
d) Remove any adjusting key or wrench before
turning the power tool on.
A wrench or a key left attached to a rotating part of
the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and
balance at all times.
This enables better control of the power tool in
unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away
from moving parts.
Loose clothes, jewellery or long hair can be caught in
moving parts.
g) If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used.
Use of dust collection can reduce dust-related
hazards.
h) Do not let familiarity gained from frequent use
of tools allow you to become complacent and
ignore tool safety principles.
A careless action can cause severe injury within a
fraction of a second.
4) Power tool use and care
a) Do not force the power tool. Use the correct
power tool for your application.
The correct power tool will do the job better and safer
at the rate for which it was designed.
b) Do not use the power tool if the switch does not
turn it on and off.
Any power tool that cannot be controlled with the
switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from
the power tool before making any adjustments,
changing accessories, or storing power tools.
Such preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool.
Power tools are dangerous in the hands of untrained
users.
e) Maintain power tools and accessories. Check
for misalignment or binding of moving parts,
breakage of parts and any other condition
that may affect the power toolʼs operation. If
damaged, have the power tool repaired before
use.
Many accidents are caused by poorly maintained
power tools.
f) Keep cutting tools sharp and clean.
Properly maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits
etc. in accordance with these instructions,
taking into account the working conditions and
the work to be performed.
Use of the power tool for operations different from
those intended could result in a hazardous situation.
h) Keep handles and grasping surfaces dry, clean
and free from oil and grease.
Slippery handles and grasping surfaces do not
allow for safe handling and control of the tool in
unexpected situations.
GENERAL POWER TOOL SAFETY
WARNINGS
WARNING
Read all safety warnings, instructions, illustrations and
specifications provided with this power tool.
Failure to follow all instructions listed below may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-
operated (corded) power tool or battery-operated (cordless)
power tool.
1) Work area safety
a) Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust.
Power tools create sparks which may ignite the dust
or fumes.
c) Keep children and bystanders away while
operating a power tool.
Distractions can cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools.
Unmodified plugs and matching outlets will reduce
risk of electric shock.
b) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators.
There is an increased risk of electric shock if your
body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions.
Water entering a power tool will increase the risk of
electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts.
Damaged or entangled cords increase the risk of
electric shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces the
risk of electric shock.
f) If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply.
Use of an RCD reduces the risk of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired
or under the influence of drugs, alcohol or
medication.
A moment of inattention while operating power tools
may result in serious personal injury.
b) Use personal protective equipment. Always
wear eye protection.
Protective equipment such as a dust mask, non-skid
safety shoes, hard hat or hearing protection used for
appropriate conditions will reduce personal injuries.
(Original instructions)
0000BookNH18DSLEU.indb50000BookNH18DSLEU.indb5 2021/02/1213:50:182021/02/1213:50:18

6
English
5) Battery tool use and care
a) Recharge only with the charger specified by the
manufacturer.
A charger that is suitable for one type of battery pack
may create a risk of fire when used with another
battery pack.
b) Use power tools only with specifically
designated battery packs.
Use of any other battery packs may create a risk of
injury and fire.
c) When battery pack is not in use, keep it away
from other metal objects, like paper clips, coins,
keys, nails, screws or other small metal objects,
that can make a connection from one terminal to
another.
Shorting the battery terminals together may cause
burns or a fire.
d) Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irritation or
burns.
e) Do not use a battery pack or tool that is damaged
or modified.
Damaged or modified batteries may exhibit
unpredictable behaviour resulting in fire, explosion
or risk of injury.
f) Do not expose a battery pack or tool to fire or
excessive temperature.
Exposure to fire or temperature above 130°C may
cause explosion.
g) Follow all charging instructions and do not
charge the battery pack or tool outside the
temperature range specified in the instructions.
Charging improperly or at temperatures outside
the specified range may damage the battery and
increase the risk of fire.
6) Service
a) Have your power tool serviced by a qualified
repair person using only identical replacement
parts.
This will ensure that the safety of the power tool is
maintained.
b) Never service damaged battery packs.
Service of battery packs should only be performed
by the manufacturer or authorized service providers.
PRECAUTION
Keep children and infirm persons away.
When not in use, tools should be stored out of reach of
children and infirm persons.
CORDLESS AUTO HAMMER SAFETY
WARNINGS
1. Always assume that the tool contains nails.
Careless handling of the Auto Hammer can result in
unexpected firing of nails and personal injury.
2. Do not point the tool towards yourself or anyone
nearby.
Unexpected triggering will discharge the nail causing an
injury.
3. Do not actuate the tool unless the tool is placed
firmly against the workpiece.
If the tool is not contact with the workpiece, the nail may
be deflected away from your target.
4. Disconnect the tool from the power source when
the nail jams in the tool.
While removing a jammed nail, the Auto Hammer may
be accidentally activated if it is plugged in.
5. Do not use this Auto Hammer for fastening electrical
cables.
It is not designed for electric cable installation and may
damage the insulation of electric cables thereby causing
electric shock or fire hazards.
6. Wear ear protectors
Exposure to noise can cause hearing loss.
7. Use auxiliary handle(s), if supplied with the tool.
Loss of control can cause personal injury.
8. Hold power tool by insulated gripping surfaces,
when performing an operation where the fastener
may contact hidden wiring.
Fasteners contacting a “live” wire may make exposed
metal parts of the power tool “live” and could give the
operator an electric shock.
ADDITIONAL SAFETY WARNINGS
1. Make sure to securely hold the tool during
operation.
Failure to do so can result in accidents or injuries.
(Fig. 12)
2. Safe operation through correct usage.
This tool was designed for driving nails into wood and
similar materials. Use it for its intended purpose only.
3. Be careful of ignition and explosions.
Since sparks may fly during nailing, it is dangerous to use
this tool near lacquer, paint, benzine, thinner, gasoline,
gas, adhesives and similar inflammable substances as
they may ignite or explode. Under no circumstances
should this tool therefore be used in the vicinity of such
inflammable material.
4. Always wear eye protection (protective goggles).
When operating the power tool, always
wear eye protection, and ensure that
surrounding people wear eye protection
too.
The possibility of fragments of the nails
that were not properly hit entering the
eye is a threat to sight. Eye protection can be bought at
any hardware store. Always wear eye protection while
operating this tool. Use either eye protection or a wide
vision mask over prescription glasses.
Employers should always enforce the use of eye
protection equipment.
5. Protect your ears and head.
When engaged in nailing work please wear ear muers
and head protection. Also, depending on condition,
ensure that surrounding people also wear ear muers
and head protection.
6. Pay attention to those working close to you.
It would be very dangerous if nails that were not properly
driven in should hit other people. Therefore, always pay
attention to the safety of the people around you when
using this tool. Always make sure that nobody’s body,
hands or feet are close to the nail outlet.
7. Never point the nail outlet towards people.
Always assume the tool contains
fasteners.
If the nail outlet is pointed towards
people, serious accidents may be
caused if you mistakenly discharge the
tool. When connecting and disconnecting the battery,
during nail loading or similar operations, be sure the nail
outlet is not pointed towards anyone (including yourself).
Even when no nails are loaded at all, it is dangerous to
discharge the tool while pointing it at someone, so never
attempt to do so. No horseplay. Respect the tool as a
working implement.
0000BookNH18DSLEU.indb60000BookNH18DSLEU.indb6 2021/02/1213:50:182021/02/1213:50:18

7
English
8. Check rod before use.
Make sure the rod operates properly. Never use the Auto
Hammer unless the rod is operating properly, otherwise
the Auto Hammer could drive a nail unexpectedly. Do
not tamper with or remove the rod, otherwise the rod
becomes inoperable.
9. Use specified nails only.
Never use nails other than those specified and described
in these instructions.
10. Be careful when connecting the battery.
When connecting the battery and loading nails in
order not to fire the tool by mistake, make sure of the
followings.
Do not touch the trigger.
Do not allow the firing head to contact with any
surface.
Keep the firing head down.
Strictly observe the above instructions, and always
make sure that no part of the body, hands or legs is
ever in front of the nail outlet.
11. Do not carelessly place your finger on the trigger.
Do not place your finger on the trigger except when actually
nailing. If you carry this tool or hand it to someone while
having your finger on the trigger, you may inadvertently
discharge a nail and thus cause an accident.
12. Press the nail outlet firmly against the material to
be nailed.
When driving in nails, press the nail outlet firmly against
the material to be nailed. If the outlet is not applied
properly, the nails may rebound.
13. Keep hands and feet away from the firing head
when using.
It is very dangerous for a nail to hit the
hands or feet by mistake.
14. Beware of the tool’s kickback.
Do not approach the top of the tool with your head etc.
during operation. This is dangerous because the tool
may recoil violently if the nail currently being driven in
comes into contact with a previous nail or a knot in the
wood.
15. Take care when nailing thin boards or the corners
of wood.
When nailing thin boards, the nails may pass right
through, as may also be the case when nailing the
corners of wood due to deviation of the nails. In such
cases, always make sure that there is no one (and
nobody’s hands or feet; etc.) behind the thin board or
next to the wood you are going to nail.
16. Simultaneous nailing on both sides of the same
wall is dangerous.
Under no circumstances should nailing be performed on
both sides of a wall at the same time. This would be very
dangerous since the nails might pass through the wall
and thus cause injuries.
17. Do not use the power tool on scaffoldings, ladders.
The power tool shall not be used for specific application
for example:
– when changing one driving location to another
involves the use of scaoldings, stairs, ladders or
ladder alike constructions, e.g. roof laths,
– closing boxes or crates,
– fitting transportation safety systems e.g. on vehicles
and wagons
18. Remove all remaining nails and battery from Auto
Hammer when:
1) doing maintenance and inspection;
2) checking proper operation of rod and trigger;
3) clearing a jam;
4) it is not in use;
5) leaving work area;
6) moving it to another location; and
7) handing it to another person.
Never attempt to clear a jam or repair the Auto Hammer
unless you have removed battery and all remaining nails
from the Auto Hammer.
The Auto Hammer should never be left unattended since
people who are not familiar with the Auto Hammer might
handle it and injure the themselves.
19. When cleaning the power tool, do not use gasoline
or other inflammable liquids.
If vapour from an inflammable liquid gets into the power
tool, there is a danger that sparks produced when
stapling etc. may cause an explosion.
20. The operating environment for this device is
between 0°C and 40°C so ensure use within this
temperature range. The device may fail to operate
below 0°C or above 40°C.
21. NEVER allow magnets (or similar magnetic devices)
to be adjacent to the Auto Hammer, because the
Auto Hammer has a magnet inside.
Doing so will cause a failure or risk of injury by
malfunction.
22. Resting the unit after continuous work.
23. The power tool is equipped with a temperature
protection circuit to protect the motor. Continuous
work may cause the temperature of the unit to rise,
activating the temperature protection circuit and
automatically stopping operation. If this happens,
allow the power tool to cool before resuming use.
24. This product may cease to operate when an
abnormality is detected.
25. Do not look directly into the light. Such actions could
result in eye injury.
Wipe oany dirt or grime attached to the lens of the LED
light with a soft cloth, being careful not to scratch the
lens.
Scratches on the lens of the LED light can result in
decreased brightness.
PRECAUTIONS FOR BATTERY AND
CHARGER
1. Always charge the battery at an ambient
temperature of 0–40°C.
A temperature of less than 0°C will result in over charging
which is dangerous. The battery cannot be charged at a
temperature greater than 40°C.
The most suitable temperature for charging is that of
20–25°C.
2. Do not use the charger continuously.
When one charging is completed, leave the charger for
about 15 minutes before the next charging of battery.
3. Do not allow foreign matter to enter the hole for
connecting the rechargeable battery.
4. Never disassemble the rechargeable battery or
charger.
5. Never short-circuit the rechargeable battery.
Short-circuiting the battery will cause a great electric
current and overheat. It results in burn or damage to the
battery.
6. Do not dispose of the battery in fire.
If the battery is burnt, it may explode.
7. Using an exhausted battery will damage the
charger.
8. Bring the battery to the shop from which it was
purchased as soon as the post-charging battery life
becomes too short for practical use.
Do not dispose of the exhausted battery.
0000BookNH18DSLEU.indb70000BookNH18DSLEU.indb7 2021/02/1213:50:182021/02/1213:50:18

8
English
9. Do not insert objects into the air ventilation slots of
the charger.
Inserting metal objects or flammable into the charger air
ventilation slots will result in an electrical shock hazard or
damage to the charger.
CAUTION ON LITHIUM-ION BATTERY
To extend the lifetime, the lithium-ion battery equips with the
protection function to stop the output.
In the cases of 1 to 3 described below, when using this
product, even if you are pulling the switch, the motor may
stop. This is not the trouble but the result of protection
function.
1. When the battery power remaining runs out, the motor
stops.
In such a case, charge it up immediately.
2. If the tool is overloaded, the motor may stop. In this
case, release the switch of tool and eliminate causes of
overloading. After that, you can use it again.
3. If the battery is overheated under overload work, the
battery power may stop.
In this case, stop using the battery and let the battery
cool. After that, you can use it again.
Furthermore, please heed the following warning and caution.
WARNING
In order to prevent any battery leakage, heat generation,
smoke emission, explosion and ignition beforehand, please
be sure to heed the following precautions.
1. Make sure that swarf and dust do not collect on the
battery.
During work make sure that swarf and dust do not fall on
the battery.
Make sure that any swarf and dust falling on the power
tool during work do not collect on the battery.
Do not store an unused battery in a location exposed to
swarf and dust.
Before storing a battery, remove any swarf and dust that
may adhere to it and do not store it together with metal
parts (screws, nails, etc.).
2. Do not pierce battery with a sharp object such as a
nail, strike with a hammer, step on, throw or subject the
battery to severe physical shock.
3. Do not use an apparently damaged or deformed battery.
4. Do not use the battery in reverse polarity.
5. Do not connect directly to an electrical outlets or car
cigarette lighter sockets.
6. Do not use the battery for a purpose other than those
specified.
7. If the battery charging fails to complete even when a
specified recharging time has elapsed, immediately stop
further recharging.
8. Do not put or subject the battery to high temperatures or
high pressure such as into a microwave oven, dryer, or
high pressure container.
9. Keep away from fire immediately when leakage or foul
odor are detected.
10. Do not use in a location where strong static electricity
generates.
11. If there is battery leakage, foul odor, heat generated,
discolored or deformed, or in any way appears abnormal
during use, recharging or storage, immediately remove it
from the equipment or battery charger, and stop use.
12. Do not immerse the battery or allow any fluids to flow
inside. Conductive liquid ingress, such as water, can
cause damage resulting in fire or explosion. Store your
battery in a cool, dry place, away from combustible and
flammable items. Corrosive gas atmospheres must be
avoided.
CAUTION
1. If liquid leaking from the battery gets into your eyes,
do not rub your eyes and wash them well with fresh
clean water such as tap water and contact a doctor
immediately.
If left untreated, the liquid may cause eye-problems.
2. If liquid leaks onto your skin or clothes, wash well with
clean water such as tap water immediately.
There is a possibility that this can cause skin irritation.
3. If you find rust, foul odor, overheating, discolor,
deformation, and/or other irregularities when using the
battery for the first time, do not use and return it to your
supplier or vendor.
WARNING
If a conductive foreign matter enters in the terminal of lithium
ion battery, the battery may be shorted, causing fire. When
storing the lithium ion battery, obey surely the rules of
following contents.
Do not place conductive debris, nail and wires such as
iron wire and copper wire in the storage case.
To prevent shorting from occurring, load the battery in
the tool or insert securely the battery cover for storing
until the ventilator is not seen (Fig. 2).
REGARDING LITHIUM-ION BATTERY
TRANSPORTATION
When transporting a lithium-ion battery, please observe the
following precautions.
WARNING
Notify the transporting company that a package contains a
lithium-ion battery, inform the company of its power output
and follow the instructions of the transportation company
when arranging transport.
Lithium-ion batteries that exceed a power output of
100 Wh are considered to be in the freight classification
of Dangerous Goods and will require special application
procedures.
For transportation abroad, you must comply with
international law and the rules and regulations of the
destination country.
Wh
Power Output
2 to 3 digit number
0000BookNH18DSLEU.indb80000BookNH18DSLEU.indb8 2021/02/1213:50:182021/02/1213:50:18

9
English
NAMES OF PARTS (Fig. 1 –Fig. 12)
Firing head (outlet)
Rod
LED light
Trigger
Hook
Battery
Latch
Battery cover
Terminals
Ventilation holes
Charger
Nail head
Nail shaft
Nail tip
Magnet
Magnetized area
Nail
Driver unit
Metal joint
Hole
Screw
Groove
Pliers
SYMBOLS
WARNING
The following show symbols used for the machine.
Be sure that you understand their meaning before
use.
NH18DSL: Cordless Auto Hammer
To reduce the risk of injury, user must read
instruction manual
Operators and others in work area must wear
safety glasses with side shields.
Never point tool at yourself or others in work
area.
Disconnect the battery
Do not use on scaoldings, ladders.
Only for EU countries
Do not dispose of electric tools together with
household waste material!
In observance of European Directive 2012/19/EU
on waste electrical and electronic equipment
and its implementation in accordance with
national law, electric tools that have reached
the end of their life must be collected separately
and returned to an environmentally compatible
recycling facility.
Direct current
kg Weight
(According to EPTA-Procedure 01/2014)
ϨSwitching ON
Switching OFF
Warning
Prohibited action
SPECIFICATIONS
1. Cordless Auto Hammer
Model NH18DSL
Voltage 18 V
Number of blows 4000 min-1
Applicable Nail ø1.7 – 4.1 mm (See Table 1)*1
Applicable Nail Length 25 mm to 90 mm*1
Weight*21.3–1.9 kg
Dimension
Height × Length 135 mm × 285 mm (BSL1815)
*1: Opposing Wood: SPF, Cedar
May not be able to fully drive a nail into hard materials such as hemlock spruce, MDF or laminated lumber.
*2: Weight: According to EPTA-Procedure 01/2014. Depending on attached battery. The heaviest weight is measured with
BSL36B18 (sold separately).
NOTE
Due to HiKOKI’s continuing program of research and development, the specifications herein are subject to change
without prior notice.
0000BookNH18DSLEU.indb90000BookNH18DSLEU.indb9 2021/02/1213:50:192021/02/1213:50:19

10
English
NAIL SELECTION
Use nails in following sizes for this Auto Hammer.
Table 1
Min. Max.
4.4 mm
(0.172")
1.7 mm
(0.067")
25 mm (1")
8.7 mm
(0.344")
4.1 mm
(0.162")
90 mm (3-1/2")
WARNING
●Do not use nails in any other size.
They may damage the rod or be shot in a slanting direction.
●Be careful of nail head sizes. Nail head size may vary between large and small with commercially available
bulk nails.
●Do not use hardened nails.
NOTE
May not be able to fully drive a nail into hard materials such as hemlock spruce, MDF or laminated lumber.
0000BookNH18DSLEU.indb100000BookNH18DSLEU.indb10 2021/02/1213:50:202021/02/1213:50:20
