hilscher netBRICK NB 100 User manual

User Manual
netBRICK NB 100
Gateway Devices
Hilscher Gesellschaft für Systemautomation mbH
www.hilscher.com
DOC091111UM07EN | Revision 7 | English | 2012-02 | Released | Public

Introduction 2/135
netBRICK NB 100 | Gateway Devices
DOC091111UM07EN | Revision 7 | English | 2012-02 | Released | Public © Hilscher, 2009-2012
Table of Contents
1INTRODUCTION.........................................................................................................6
1.1 About the User Manual ...............................................................................................6
1.1.1 Obligation to read and understand the Manual ....................................................6
1.1.2 List of Revisions ...................................................................................................7
1.2 Legal Notes.................................................................................................................8
1.2.1 Copyright ..............................................................................................................8
1.2.2 Important Notes ....................................................................................................8
1.2.3 Exclusion of Liability .............................................................................................9
1.2.4 Warranty ...............................................................................................................9
1.2.5 Export Regulations .............................................................................................10
1.2.6 Registered Trademarks......................................................................................10
1.2.7 Conventions in this Manual ................................................................................11
1.3 Reference to Hardware, Software, Driver and Firmware..........................................12
1.4 Contents of the Product DVD ...................................................................................13
1.4.1 Directory Structure of the DVD...........................................................................13
1.4.2 Device Description Files.....................................................................................14
1.4.3 Documentation for netBRICK .............................................................................15
1.5 Licenses....................................................................................................................18
2SAFETY ....................................................................................................................19
2.1 General Note ............................................................................................................19
2.2 Intended Use ............................................................................................................19
2.3 Personnel Qualification.............................................................................................19
2.4 References Safety ....................................................................................................19
2.5 Safety Instructions to avoid Personal Injury..............................................................20
2.5.1 Use in Hazardous Locations only.......................................................................20
2.5.2 Danger of unsafe System Operation ..................................................................20
2.6 Safety Instructions to avoid Property Damage .........................................................21
2.6.1 Device Destruction by exceeding allowed Supply Voltage ................................21
2.6.2 Electrostatically sensitive Devices......................................................................21
2.7 Labeling of Safety Messages....................................................................................22
3DESCRIPTION AND APPLICATION.........................................................................23
3.1 Description................................................................................................................23
3.2 Label / Device Names...............................................................................................25
3.2.1 Label...................................................................................................................25
3.2.2 Device Names ....................................................................................................26
3.3 Protocol Conversions................................................................................................27
3.3.1 Protocol Conversion - Ethernet to Fieldbus .......................................................27
3.3.2 Protocol Conversion - Serial Protocols to Fieldbus............................................29
3.4 System Requirements ..............................................................................................30

Introduction 3/135
netBRICK NB 100 | Gateway Devices
DOC091111UM07EN | Revision 7 | English | 2012-02 | Released | Public © Hilscher, 2009-2012
3.5 Configuration Requirements .....................................................................................31
4DEVICE DRAWINGS AND CONNECTIONS ............................................................32
4.1 Dimensioned Drawing...............................................................................................32
4.2 Drilling Template.......................................................................................................32
4.3 LEDs and Control Elements .....................................................................................33
4.3.1 Elements of the netBRICK NB 100-RE-xx Device .............................................33
4.3.2 Elements of the netBRICK NB 100-RS-xx Device .............................................34
4.4 Connections..............................................................................................................35
4.4.1 X1 Power Supply PWR ......................................................................................35
4.4.2 X2 Front Connection...........................................................................................36
4.4.3 X2 Ethernet Connection for NB 100-RE-xx Devices ..........................................36
4.4.4 X2 Serial Connection for NB 100-RS-xx Devices ..............................................37
4.4.5 X3 Fieldbus Connection .....................................................................................38
4.4.6 Diagnostic Interface............................................................................................41
4.5 Schematic Diagram - Galvanic Isolation...................................................................43
4.5.1 Galvanic Isolation NB 100-RE-DP Device .........................................................43
4.5.2 Galvanic Isolation NB 100-RE-DN/CO Device...................................................45
4.5.3 Galvanic Isolation NB 100-RS-DP Device .........................................................46
4.5.4 Galvanic Isolation NB 100-RS-DN/CO Device...................................................47
5MOUNTING AND DISMOUNTING............................................................................48
5.1 Safety Messages on Personal Injury ........................................................................48
5.1.1 Use in Hazardous Locations only in Scope of the UL Standards ......................48
5.1.2 Danger of unsafe System Operation ..................................................................48
5.2 Property Damage Messages ....................................................................................49
5.2.1 Device Destruction by exceeding allowed Supply Voltage ................................49
5.2.2 Electrostatically sensitive Devices......................................................................49
5.3 Mounting ...................................................................................................................50
5.3.1 Use in Hazardous Locations only in Scope of the UL Standards ......................50
5.4 Dismounting..............................................................................................................51
5.4.1 Use in Hazardous Locations only in Scope of the UL Standards ......................51
6INSTALL DRIVER .....................................................................................................52
6.1 Install USB Driver – Windows®7 ..............................................................................52
7COMMISSIONING / DECOMMISSIONING...............................................................59
7.1 Commissioning .........................................................................................................59
7.2 Maintainance ............................................................................................................59
7.3 Decommissioning .....................................................................................................59
8BOOT UP BEHAVIOR...............................................................................................60
8.1 Boot up Behavior on valid Firmware.........................................................................60
8.2 Boot up Behavior on invalid Firmware ......................................................................60
8.2.1 Recover to Factory Default Settings...................................................................60

Introduction 4/135
netBRICK NB 100 | Gateway Devices
DOC091111UM07EN | Revision 7 | English | 2012-02 | Released | Public © Hilscher, 2009-2012
9TROUBLESHOOTING ..............................................................................................69
9.1 Failure in 10 MBit/s Half Duplex Mode and Workaround..........................................70
10 LEDS.........................................................................................................................71
10.1 LED SYS...................................................................................................................71
10.2 LED APL ...................................................................................................................72
10.3 LEDs Real Time Ethernet Systems ..........................................................................73
10.3.1 LED EtherCAT Master........................................................................................73
10.3.2 LED EtherCAT Slave..........................................................................................74
10.3.3 LED EtherNet/IP Scanner (Master) ....................................................................76
10.3.4 LED EtherNet/IP Adapter (Slave).......................................................................77
10.3.5 LED Open Modbus/TCP.....................................................................................78
10.3.6 LED POWERLINK Controlle Node/Slave...........................................................79
10.3.7 LED PROFINET IO RT Controller ......................................................................81
10.3.8 LED PROFINET IO-RT-Device ..........................................................................82
10.3.9 LED sercos Master .............................................................................................83
10.3.10 LED sercos Slave ...............................................................................................85
10.4 LEDs Fieldbus Systems............................................................................................86
10.4.1 LED PROFIBUS-DP Master...............................................................................86
10.4.2 LED PROFIBUS-DP Slave.................................................................................87
10.4.3 LED CANopen Master........................................................................................88
10.4.4 LED CANopen Slave..........................................................................................89
10.4.5 LED DeviceNet Master.......................................................................................90
10.4.6 LED DeviceNet Slave.........................................................................................90
10.5 LEDs Serial...............................................................................................................91
10.5.1 LED Modbus RTU ..............................................................................................91
10.5.2 LED ASCII ..........................................................................................................92
10.5.3 LED 3964R .........................................................................................................93
11 TECHNICAL DATA ...................................................................................................94
11.1 Technical Data netBRICK 100 Gateway...................................................................94
11.2 Technical Data Real-Time Ethernet Protocols..........................................................98
11.2.1 EtherCAT Master................................................................................................98
11.2.2 EtherCAT Slave..................................................................................................99
11.2.3 EtherNet/IP Scanner (Master) ..........................................................................100
11.2.4 EtherNet/IP Adapter (Slave).............................................................................101
11.2.5 Open Modbus/TCP...........................................................................................102
11.2.6 POWERLINK Controlled Node (Slave) ............................................................103
11.2.7 PROFINET IO-RT-Controller............................................................................104
11.2.8 PROFINET IO-RT-Device ................................................................................105
11.2.9 sercos Master ...................................................................................................106
11.2.10 sercos Slave .....................................................................................................107
11.3 Technical Data Fieldbus Protocols .........................................................................108
11.3.1 CANopen Master ..............................................................................................108
11.3.2 CANopen Slave ................................................................................................109
11.3.3 DeviceNet Master.............................................................................................110
11.3.4 DeviceNet Slave ...............................................................................................111

Introduction 5/135
netBRICK NB 100 | Gateway Devices
DOC091111UM07EN | Revision 7 | English | 2012-02 | Released | Public © Hilscher, 2009-2012
11.3.5 PROFIBUS-DP Master.....................................................................................112
11.3.6 PROFIBUS-DP Slave.......................................................................................113
11.4 Technical Data serial Protocols ..............................................................................114
11.4.1 ASCII ................................................................................................................114
11.4.2 Modbus RTU Master/Slave ..............................................................................115
11.4.3 3964R ...............................................................................................................116
12 APPENDIX ..............................................................................................................117
12.1 Wiring Instructions ..................................................................................................117
12.1.1 PROFIBUS .......................................................................................................117
12.1.2 CANopen ..........................................................................................................119
12.1.3 DeviceNet .........................................................................................................120
12.1.4 Ethernet ............................................................................................................122
12.1.5 RS-232 .............................................................................................................123
12.1.6 RS-422 .............................................................................................................124
12.1.7 RS-485 .............................................................................................................126
12.2 Disposal of Waste Electronic Equipment................................................................128
13 LISTS ......................................................................................................................129
13.1 List of Figures .........................................................................................................129
13.2 List of Tables ..........................................................................................................130
14 GLOSSARY.............................................................................................................133
15 CONTACTS.............................................................................................................135

Introduction 6/135
netBRICK NB 100 | Gateway Devices
DOC091111UM07EN | Revision 7 | English | 2012-02 | Released | Public © Hilscher, 2009-2012
1 Introduction
1.1 About the User Manual
This user manual describes the hardware, installation, commissioning, and
operation of the netBRICK NB 100 series of gateways.
1.1.1 Obligation to read and understand the Manual
Important!
!To avoid personal injury and to avoid property damage to your system
or to your device, you must read and understand all instructions in the
manual and all accompanying texts to your device, before installing and
operating your device.
!First read the Safety Instructions in the safety chapter.
!Obey to all Safety Messages in the manual.
!Keep the product DVD providing the product manuals.

Introduction 7/135
netBRICK NB 100 | Gateway Devices
DOC091111UM07EN | Revision 7 | English | 2012-02 | Released | Public © Hilscher, 2009-2012
1.1.2 List of Revisions
Index Date Chapter Revisions
4 2011-01-11 4.4.5.3 ’Use one DeviceNet port only’ added
10.4.5 LED MNS green/red
10.4.6 LED MNS green/red
11.3.3 Technical data updated
11.3.4 Technical data updated
5 2011-05-12 1.3 Section Reference to Hardware, Software, Driver and Firmware:
References updated
1.4.1 Section Directory Structure of the DVD updated
1.4.2 Section Device Description Files updated
1.4.3 Section Documentation for netBRICK expanded
3.3.1 Section Protocol Conversion - Ethernet to Fieldbus:
3 new protocol conversion for SERCOS III Master added
3.5 Section Configuration Requirements updated: Windows®Vista and Windows®7
added.
4.3.1 Section Elements of the netBRICK NB 100-RE-xx Device:
Complete LED names.
6.1 Section Install USB Driver – Windows® 7 added.
8.2 Path names in section Boot up Behavior on invalid Firmware adapted.
10.3.1 Section LED EtherCAT Master added.
10.3.7 Section LED PROFINET IO RT Controller added.
10.3.9 Section LED sercos Master added.
10.5.1 Section LED Modbus RTU added.
10.5.2 Section LED ASCII added.
10.5.3 Section LED 3964R added.
11.2.3 Section technical data EtherNet/IP Scanner (Master) updated:
The max. number of input data is 5712 bytes now.
11.2.4 Section technical data EtherNet/IP Adapter (Slave) updated.
11.2.7 Section technical data PROFINET IO-RT-Controller updated:
The max. number of input data is 5712 bytes now.
11.2.8 Section technical data PROFINET IO-RT-Device updated.
11.2.9 Section technical data sercos Master added.
12.2 Section Disposal of Waste Electronic Equipment added.
6 2011-06-09 10.3.6 SectionLED POWERLINK Controlle Node/Slave added.
2 2012-02-03 1.2.7 Section Conventions in this Manual updated.
2 Chapter Safety revised and completed.
3.2 Section Label / Device Names Label added.
4.4.6 Section Diagnostic Interface Safety Instrctions revised and completed.
5, 7 Section Mounting and Dismounting and Commissioning / Decommissioning
Safety Instrctions revised and completed.
10.3.7 Section LED PROFINET IO RT Controller updated.
10.4.3 Section LED CANopen Master: Correction
11.1 Section Technical Data netBRICK 100 Gateway updated UL.
14 Section Glossary updated.
Table 1: List of Revisions

1.2 Legal Notes
1.2.1 Copyright
© Hilscher, 2009-2012, Hilscher Gesellschaft für Systemautomation mbH
All rights reserved.
The images, photographs and texts in the accompanying material (user
manual, accompanying texts, documentation, etc.) are protected by Ger-
man and international copyright law as well as international trade and pro-
tection provisions. You are not authorized to duplicate these in whole or in
part using technical or mechanical methods (printing, photocopying or other
methods), to manipulate or transfer using electronic systems without prior
written consent. You are not permitted to make changes to copyright no-
tices, markings, trademarks or ownership declarations. The included dia-
grams do not take the patent situation into account. The company names
and product descriptions included in this document may be trademarks or
brands of the respective owners and may be trademarked or patented. Any
form of further use requires the explicit consent of the respective rights
owner.
1.2.2 Important Notes
The user manual, accompanying texts and the documentation were created
for the use of the products by qualified experts, however, errors cannot be
ruled out. For this reason, no guarantee can be made and neither juristic
responsibility for erroneous information nor any liability can be assumed.
Descriptions, accompanying texts and documentation included in the user
manual do not present a guarantee nor any information about proper use
as stipulated in the contract or a warranted feature. It cannot be ruled out
that the user manual, the accompanying texts and the documentation do
not correspond exactly to the described features, standards or other data of
the delivered product. No warranty or guarantee regarding the correctness
or accuracy of the information is assumed.
We reserve the right to change our products and their specification as well
as related user manuals, accompanying texts and documentation at all
times and without advance notice, without obligation to report the change.
Changes will be included in future manuals and do not constitute any obli-
gations. There is no entitlement to revisions of delivered documents. The
manual delivered with the product applies.
Hilscher Gesellschaft für Systemautomation mbH is not liable under any
circumstances for direct, indirect, incidental or follow-on damage or loss of
earnings resulting from the use of the information contained in this publica-
tion.

Introduction 9/135
netBRICK NB 100 | Gateway Devices
DOC091111UM07EN | Revision 7 | English | 2012-02 | Released | Public © Hilscher, 2009-2012
1.2.3 Exclusion of Liability
The software was produced and tested with utmost care by Hilscher Ge-
sellschaft für Systemautomation mbH and is made available as is. No war-
ranty can be assumed for the performance and flawlessness of the soft-
ware for all usage conditions and cases and for the results produced when
utilized by the user. Liability for any damages that may result from the use
of the hardware or software or related documents, is limited to cases of in-
tent or grossly negligent violation of significant contractual obligations. In-
demnity claims for the violation of significant contractual obligations are lim-
ited to damages that are foreseeable and typical for this type of contract.
It is strictly prohibited to use the software in the following areas:
•for military purposes or in weapon systems;
•for the design, construction, maintenance or operation of nuclear facili-
ties;
•in air traffic control systems, air traffic or air traffic communication sys-
tems;
•in life support systems;
•in systems in which failures in the software could lead to personal injury
or injuries leading to death.
We inform you that the software was not developed for use in dangerous
environments requiring fail-proof control mechanisms. Use of the software
in such an environment occurs at your own risk. No liability is assumed for
damages or losses due to unauthorized use.
1.2.4 Warranty
Although the hardware and software was developed with utmost care and
tested intensively, Hilscher Gesellschaft für Systemautomation mbH does
not guarantee its suitability for any purpose not confirmed in writing. It can-
not be guaranteed that the hardware and software will meet your require-
ments, that the use of the software operates without interruption and that
the software is free of errors. No guarantee is made regarding infringe-
ments, violations of patents, rights of ownership or the freedom from inter-
ference by third parties. No additional guarantees or assurances are made
regarding marketability, freedom of defect of title, integration or usability for
certain purposes unless they are required in accordance with the law and
cannot be limited. Warranty claims are limited to the right to claim rectifica-
tion.

Introduction 10/135
netBRICK NB 100 | Gateway Devices
DOC091111UM07EN | Revision 7 | English | 2012-02 | Released | Public © Hilscher, 2009-2012
1.2.5 Export Regulations
Das gelieferte Produkt (einschließlich der technischen Daten) unterliegt den
gesetzlichen Export- bzw. Importgesetzen sowie damit verbundenen Vor-
schriften verschiedener Länder, insbesondere denen von Deutschland und
den USA. Die Software darf nicht in Länder exportiert werden, in denen
dies durch das US-amerikanische Exportkontrollgesetz und dessen ergän-
zender Bestimmungen verboten ist. Sie verpflichten sich, die Vorschriften
strikt zu befolgen und in eigener Verantwortung einzuhalten. Sie werden
darauf hingewiesen, dass Sie zum Export, zur Wiederausfuhr oder zum
Import des Produktes unter Umständen staatlicher Genehmigungen bedür-
fen.
1.2.6 Registered Trademarks
Windows®2000 / Windows®XP are registered trademarks of Microsoft
Corporation.
Adobe-Acrobat®is a registered trademark of the Adobe Systems Incorpo-
rated.
EtherCAT®is a registered trademark of Beckhoff Automation GmbH, Verl,
Bundesrepublik Deutschland, formerly Elektro Beckhoff GmbH.
Modbus®is a registered trademark of Schneider Automation

Introduction 11/135
netBRICK NB 100 | Gateway Devices
DOC091111UM07EN | Revision 7 | English | 2012-02 | Released | Public © Hilscher, 2009-2012
1.2.7 Conventions in this Manual
Operation instructions, a result of an operation step or notes are marked as
follows:
Operation Instructions:
"<instruction>
or
1. <instruction>
2. <instruction>
Results:
#<result>
Notes:
Important: <important note>
Note: <note>
<note, where to find further information>
Safety Messages
For information about the labeling of safety messages refer to section
Labeling of Safety Messages on page 22.
Numbering:
... reference to the figure used in that section. If the numbers refer-
ence to a section outside the current section then a cross reference to that
section and figure is indicated.

Introduction 12/135
netBRICK NB 100 | Gateway Devices
DOC091111UM07EN | Revision 7 | English | 2012-02 | Released | Public © Hilscher, 2009-2012
1.3 Reference to Hardware, Software, Driver and Firmware
Hardware
Device Type Revision Port X2 Port X3
NB 100-RE-CO Revision 3 Ethernet CANopen
NB 100-RE-DP Revision 2 Ethernet PROFIBUS-DP
NB 100-RE-DN Revision 4 Ethernet DeviceNet
NB 100-RS-CO Revision 3 RS interface CANopen
NB 100-RS-DP Revision 2 RS interface PROFIBUS-DP
NB 100-RS-DN Revision 2 RS interface DeviceNet
Table 2: Reference to Hardware
Software
Software Software Version
SYCONnet netX setup.exe from 1.310.x.x
Table 3: Reference to Software
Driver
Driver Software Version
USB Driver USB Driver of Windows®
Table 4: Reference to Driver
Firmware
Firmware for the protocol conversion: see section Protocol Conversions on
page 27.

Introduction 13/135
netBRICK NB 100 | Gateway Devices
DOC091111UM07EN | Revision 7 | English | 2012-02 | Released | Public © Hilscher, 2009-2012
1.4 Contents of the Product DVD
The product DVD for the netBRICK NB 100 contains:
•Setup program for the configuration and diagnostic program SYCON.net
•USB Driver
•Documentation
•Firmware
•Device Description Files (GSD, GSDML, EDS, ...)
•Video-Audio Tutorials
•Workshop for netSCRIPT
•Presentations
•Tools
1.4.1 Directory Structure of the DVD
All manuals on this DVD are delivered in the Adobe Acrobat®Reader for-
mat (PDF).
Directory Name Description
Adobe Flash Player Adobe Flash Player installation program
Documentation Documentation in the Acrobat®Reader Format (PDF)
Driver USB Driver for netTAP NT 100 and netBRICK NB 100
EDS Device Description File
Examples Example files for netSCRIPT
Firmware Loadable Firmware
fscommand Files, used for installation
Presentations Product Presentations in PowerPoint pps format
Software Configuration and diagnostic program SYCON.net
Tools Tool for recovery of netTAP 100 devices respectively netBRICK
NB 100 devices
Video-Audio
Tutorials
Video Tutorial in AVI Format
Workshop Workshop for netSCRIPT
Table 5: Directory Structure of the DVD

Introduction 14/135
netBRICK NB 100 | Gateway Devices
DOC091111UM07EN | Revision 7 | English | 2012-02 | Released | Public © Hilscher, 2009-2012
1.4.2 Device Description Files
The directory EDS on the DVD provides device description files for the net-
BRICK NB 100 device.
netBRICK NB 100 as File name
CANopen Slave NB100_CO_COS.eds
DeviceNet Slave NB100_DN_DNS.EDS
EtherCAT Slave Hilscher NB 100-ECS-XX V2.2.xml
EtherNet/IP Adapter HILSCHER NB 100-RE EIS V1.1.EDS
PROFIBUS-DP Slave HIL_0C9C.GSD
PROFINET IO Device GSDML-V2.2-HILSCHER-NB 100-RE PNS-20120202-
134100.xml
sercos III Slave Hilscher NB100 RE S3S FixCFG FSPIO Default.xml only for
default settings.
Note: Use the SDDML export function in SYCON.net to create a
suitable SDDML file.
Table 6: Device Description Files for netBRICK NB 100 on the DVD
The device description files are for the configuration of the used master.

Introduction 15/135
netBRICK NB 100 | Gateway Devices
DOC091111UM07EN | Revision 7 | English | 2012-02 | Released | Public © Hilscher, 2009-2012
1.4.3 Documentation for netBRICK
The following documentation overview gives information, for which items
you can find further information in which manual.
Note: Further information:
All manuals listed in the overview below can be found in the Documenta-
tion directory on the DVD delivered, in the Adobe Acrobat® Reader format
(PDF).
Basic documentation for netTAP NT 100
You always need the following documents:
Manual Contents Document name
User Manual netBRICK NB 100
Installation, Operation and Hardware
netBRICK NB 100 - Gateway Devices UM xx EN.pdf
(this manual)
User Manual Software Installation
Gateway Solutions
Software Installation - Gateway Solutions UM xx
EN.pdf
Operating Instruction
Manual
netGateway DTM for netTAP and netBRICK
Configuration of Gateway Devices
Configuration of the netBRICK NB 100 as
EtherCAT Slave,
EtherNet/IP Adapter,
Open Modbus/TCP,
POWERLINK controlled Node,
PROFINET IO Device,
sercos III Slave
CANopen Slave,
DeviceNet Slave respectively
PROFIBUS-DP Slave
netGateway_DTM_en.pdf
Table 7: Basic Documentation for netBRICK NB 100
netBRICK NB 100 with EtherCAT Master
You need the following additional documents, if you use the protocol
EtherCAT Master on the gateway device:
Manual Contents Document name
Operating Instruc-
tion Manual
DTM for EtherCAT Master devices EtherCAT_Master_DTM_en.pdf
Operating Instruc-
tion Manual
Generic DTM for EtherCAT Slave devices EtherCAT_GenericSlave_DTM_en.pdf
Table 8: Additional Documentation for netBRICK NB 100 with EtherCAT Master
netBRICK NB 100 with EtherNet/IP Scanner/Master
You need the following additional documents, if you use the protocol
EtherNet/IP Scanner/Master on the gateway device:
Manual Contents Document name
Operating Instruc-
tion Manual
DTM for EtherNet/IP Scanner devices EtherNetIP_Scanner_DTM_en.pdf
Operating Instruc-
tion Manual
Generic DTM for EtherNet/IP Adapter devices EtherNetIP_GenericAdapter_DTM_en.pdf
Table 9: Additional Documentation for netBRICK NB 100 with EtherNet/IP Scanner/Master

Introduction 16/135
netBRICK NB 100 | Gateway Devices
DOC091111UM07EN | Revision 7 | English | 2012-02 | Released | Public © Hilscher, 2009-2012
netBRICK NB 100 with PROFINET IO Controller
You need the following additional documents, if you use the protocol
PROFINET IO Controller on the gateway device:
Manual Contents Document name
Operating Instruc-
tion Manual
DTM for PROFINET IO Controller devices PROFINET_IO_Controller_DTM_en.pdf
Operating Instruc-
tion Manual
Generic DTM for PROFINET IO Device devices PROFINET_IO_GenericDevice_DTM_en.pdf
Table 10: Additional Documentation for netBRICK NB 100 with PROFINET IO Controller
netBRICK NB 100 with sercos III Master
You need the following additional documents, if you use the protocol
sercos III Master on the gateway device:
Manual Contents Document name
Operating Instruc-
tion Manual
DTM for sercos III Master devices SERCOS_III_Master_DTM_en.pdf
Operating Instruc-
tion Manual
Generic DTM for sercos Slave devices SERCOS_III_GenericSlave_DTM_en.pdf
Table 11: Additional Documentation for netBRICK NB 100 with EtherCAT Master
netBRICK NB 100 with CANopen Master
You need the following additional documents, if you use the protocol
CANopen Master on the gateway device:
Manual Contents Document name
Operating Instruc-
tion Manual
DTM for CANopen Master devices CANopen_Master_netX_DTM_en.pdf
Operating Instruc-
tion Manual
Generic DTM for CANopen Slave devices CANopen_Generic_Slave_DTM_en.pdf
Table 12: Additional Documentation for netBRICK NB 100 with CANopen Master
netBRICK NB 100 with DeviceNet Master
You need the following additional documents, if you use the protocol
DeviceNet Master on the gateway device:
Manual Contents Document name
Operating Instruc-
tion Manual
DTM for DeviceNet Master devices DeviceNet_Master_netX_DTM_en.pdf
Operating Instruc-
tion Manual
Generic DTM for DeviceNet Slave devices DeviceNet_Generic_Slave_DTM_en.pdf
Table 13: Additional Documentation for netBRICK NB 100 with DeviceNet Master
netBRICK NB 100 with PROFIBUS DP Master
You need the following additional documents, if you use the protocol
PROFIBUS DP Master on the gateway device:
Manual Contents Document name
Operating Instruc-
tion Manual
DTM for PROFIBUS-DP Master devices PROFIBUS_Master_netX_DTM_en.pdf
Operating Instruc-
tion Manual
Generic DTM for PROFIBUS-DP Slave devices PROFIBUS_Generic_Slave_DTM_en.pdf
Table 14: Additional Documentation for netBRICK NB 100 with PROFIBUS DP Master

Introduction 17/135
netBRICK NB 100 | Gateway Devices
DOC091111UM07EN | Revision 7 | English | 2012-02 | Released | Public © Hilscher, 2009-2012
netBRICK NB 100 with ASCII
You need the following additional documents, if you use the protocol
EtherNet/IP Scanner/Master on the gateway device:
Manual Contents Document name
User Manual ASCII Handshake Mechanism ASCII – Handshake Mechanism UM xx EN.pdf
Table 15: Additional Documentation for netBRICK NB 100 with ASCII
netBRICK NB 100 with 3964R
You need the following additional documents, if you use the protocol
EtherNet/IP Scanner/Master on the gateway device:
Manual Contents Document name
User Manual 3964R Handshake Mechanism 3964R – Handshake Mechanism UM xx EN.pdf
Table 16: Additional Documentation for netBRICK NB 100 with 3964R

Introduction 18/135
netBRICK NB 100 | Gateway Devices
DOC091111UM07EN | Revision 7 | English | 2012-02 | Released | Public © Hilscher, 2009-2012
1.5 Licenses
If the netBRICK NB 100 device is used in conjunction with a firmware that
has master functionality (except Modbus RTU or Open Modbus/TCP) a
master license in the netBRICK device must be present.
If the device has a master license can be read out with the software
SYCON.net. This is described in the operating instruction manual netGate-
way_DTM_en.pdf
The master license can be ordered later with SYCON.net and transferred
with SYCON.net into the device. The master license can be ordered with at
Hilscher ‘NXLIC-MASTER’ and has part number 8211.000.

Safety 19/135
netBRICK NB 100 | Gateway Devices
DOC091111UM07EN | Revision 7 | English | 2012-02 | Released | Public © Hilscher, 2009-2012
2 Safety
2.1 General Note
The user manual, the accompanying texts and the documentation are writ-
ten for the use of the products by educated personnel. When using the
products, all safety instructions, safety messages and all valid legal regula-
tions have to be obeyed. Technical knowledge is presumed. The user has
to assure that all legal regulations are obeyed.
2.2 Intended Use
In this manual described devices:
•NB 100-RE-CO
•NB 100-RE-DP
•NB 100-RE-DN
•NB 100-RS-CO
•NB 100-RS-DP
•NB 100-RS-DN
are devices for communication and connect two communication networks.
The NB 100 devices work as gateways between these two networks.
The NB 100 devices are made of a compact housing with IP 67 conformity
and are designed for the mounting on a metallic underground.
2.3 Personnel Qualification
The netBRICK NB 100 Gateway must only be installed, configured and re-
moved by qualified personnel. Job-specific technical skills for people pro-
fessionally working with electricity must be present concerning the following
topics:
•Safety and health at work
•Mounting and attaching of electrical equipment
•Measurement and Analysis of electrical functions and systems
•Evaluation of the safety of electrical systems and equipment
Installing and configuring IT.
2.4 References Safety
[1] ANSI Z535.6-2006 American National Standard for Product Safety Information in
Product Manuals, Instructions, and Other Collateral Materials
[2] EN 61340-5-1 and EN 61340-5-2 as well as IEC 61340-5-1 and IEC 61340-5-2
[3] UL-Report/File E326833 (Project 10CA56304, July 22, 2011)

Safety 20/135
netBRICK NB 100 | Gateway Devices
DOC091111UM07EN | Revision 7 | English | 2012-02 | Released | Public © Hilscher, 2009-2012
2.5 Safety Instructions to avoid Personal Injury
To ensure your own personal safety and to avoid personal injury, you nec-
essarily must read, understand and follow the following safety instructions
and all safety messages in this manual about danger causing personal in-
jury, before you install and operate your netBRICK NB 100 device.
2.5.1 Use in Hazardous Locations only
Important! Outside the scope of the UL standards you are allowed to use
the netBRICK NB 100 device in non-hazardous locations only!
You are allowed to use the netBRICK NB 100 device in hazardous loca-
tions with potentially explosive atmosphere only in scope of the UL Stan-
dards and if the conditions given in the UL-Report/File E326833 (Project
10CA56304, July 22, 2011) are adhered.
According to UL Report/File E326833 the netBRICK NB 100 device is suit-
able for use in NEC500 Class I, Division 2, Groups A, B, C, and D OR
non-hazardous locations only. The diagnostic interface DIAG (USB con-
nector located in the diagnostic area) of the netBRICK NB 100 device is not
suitable for the use in hazardous locations with potentially explosive at-
mosphere.
When using the device in hazardous locations with potentially explosive
atmosphere according to UL you must observe the following safety instruc-
tions.
•Do not connect or disconnect the netBRICK NB 100 device unless
power has been removed or the area is known to be non-hazardous.
•Substitution of components may impair suitability for NEC500 Class I,
Division 2, Groups A, B, C, and D.
•Do not use the diagnostic interface DIAG (USB connector) of the net-
BRICK NB 100 device in hazardous locations. Use the diagnostic inter-
face DIAG only, if power has been removed or the area is known to be
non-hazardous.
•Use only a power supply specified according to the UL standard.
2.5.2 Danger of unsafe System Operation
To prevent harm of persons and property damage, do not remove this de-
vice under runtime conditions before you can not guarantee further a safe
and secure operation of the plant.
