Dinstar UC120-1V1S1O User manual

Quick Installation Guide
UC120-1V1S1O
UC120-1V2S
UC120-1V2O
UC120-1S1O
UC120-2S
UC120-2O
Thanks for Choosing Dinstar's VoIP Gateway
Please read this guide carefully before installing the gateway. If you need any technical support, please contact us.
Tel: [phone]
Email: [email protected]
Website: www.dinstar.com

UC120 Model and Interfaces
1
Indicators
2
Note: some UC120 models do not have all the indicators described above. Please refer to the corresponding
instructions above according to the indicator displayed on the front panel of the product.
UC120-1V1S1O
WAN
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
0
0
0
1
2
0
1
2
0
1
0
2
1
0
2
LAN LTE FXS FXO
Model Interface
UC120-1V2S
UC120-1V2O
UC120-1S1O
UC120-2S
UC120-2O
Indicators
PWR
RUN
FXS
FXO
WAN/LAN
Wi-Fi
SIM
Definition
Power Indicator
ON
OFF
ON
ON
OFF
OFF
ON
OFF
OFF
The device is powered on
The device is powered off or there is no
power supply
The device is running properly
The device is initializing
The device is running improperly
Fast Flashing
Fast Flashing
Fast Flashing
Fast Flashing
Slow Flashing
Slow Flashing
Slow Flashing
Slow Flashing
Running Indicator
In-use Indicator
In-use Indicator
Network Link Indicator
WiFi Enable/Disable
Indicator
FXO port faulty
FXO port in idle status
In-use
The device is properly connected to network
The device is not connected to network or
network connection is improper
WiFi modular faulty
WiFi disabled or faulty
WiFi enabled
SIM card is detected and registered
to mobile network successfully.
The Indicator flash every 2 seconds.
The device can not detect LTE/GSM module, or LTE
/GSM module is detected but SIM card is not detected;
The indicator flash every 4 seconds.
LTE Indicator
FXS Port in-use
FXS port faulty
FXS port in idle status
ON/OFF
Status Description

Indicators and Ports
3
Installation Attentions
4
• The device acceptsDC12Vinput. Please ensure stable and safe power supply
• To reduce the interference with telephone calls, it’s highly recommended that telephone lines connected
to the gateway should be placed away from power cables
• Please ensure there is enough network bandwidth so as to guarantee stabilized running of the device
• If WiFi is turned on, please ensure the WiFi antennas are well connected with the device
• If you want the device to communicate with the LTE network, please insert an SIM card
UC120-1V1S1O
UC120-1V2O
UC120-1S1O
UC120-1V2S UC120-2S
UC120-2O
FXO
FXS
WAN LAN
Signal strength
Power Jack USB WAN
LAN
WiFi Status
LTE Status
WPS
RST
Power Indicator
RUN Indicator
Telephone Port
PSTN Line
LTE Antenna LTE Antenna WIFI Antenna
SD SIM
SD Card SIM Card
PWR Port0 WiFi
RST RUN LTE
WPS
UC120
DC12V
WAN
WAN
LAN
LAN Port0 Port1
Port1
WIFI Antenna
SD
SD Card
FXO
FXS
WAN LAN
Signal strength
Power Jack USB WAN
LAN
WiFi Status
WPS
RST
Power Indicator
RUN Indicator
Telephone Port
PSTN Line
PWR Port0 WiFi
RST RUN
WPS
UC120
DC12V
WAN
WAN
LAN
LAN Port0 Port1
Port1
FXS
WAN LAN
Signal strength
Power Jack USB WAN
LAN
WiFi Status
LTE Status
WPS
RST
Power Indicator
RUN Indicator
Telephone Port
PSTN Line
LTE Antenna LTE Antenna WIFI Antenna
SD SIM
SD Card SIM Card
PWR Port0 WiFi
RST RUN LTE
WPS
UC120
DC12V
WAN
WAN
LAN
LAN Port0 Port1
Port1
WIFI Antenna
SD
SD Card
WAN LAN
Signal strength
Power Jack USB WAN
LAN
WiFi Status
WPS
RST
Power Indicator
RUN Indicator
Telephone Port
PSTN Line
PWR Port0 WiFi
RST RUN
WPS
UC120
DC12V
WAN
WAN
LAN
LAN Port0 Port1
Port1
FXS
WIFI Antenna
SD
SD Card
WAN LAN
Signal strength
Power Jack USB WAN
LAN
WiFi Status
WPS
RST
Power Indicator
RUN Indicator
Telephone Port
PSTN Line
PWR Port0 WiFi
RST RUN
WPS
UC120
DC12V
WAN
WAN
LAN
LAN Port0 Port1
Port1
FXO
FXO
WAN LAN
Signal strength
Power Jack USB WAN
LAN
WiFi Status
LTE Status
WPS
RST
Power Indicator
RUN Indicator
Telephone Port
PSTN Line
LTE Antenna LTE Antenna WIFI Antenna
SD SIM
SD Card SIM Card
PWR Port0 WiFi
RST RUN LTE
WPS
UC120
DC12V
WAN
WAN
LAN
LAN Port0 Port1
Port1

Installation Instruction
5
• UC120-1V1S1O/1V2S/1V2O
Install WiFi antenna (foldable antenna) and install LTE
antenna (flat paddle antenna) on the rear panel.
Antenna Installation
• Router mode
• Bridge mode
Connect the power adapter to power jack (All models).
Insert SIM card to SIM slot (UC120-1V1S1O/1V2/1V2O).
Connect network cable to WAN and LAN (All models)
Connect analog phone to FXS or connect landline to
FXO (All models).
• UC120-1S1O/2S/2O
Install WiFi antenna (foldable antenna) on the rear panel
of the device.
UC100 supports router mode and bridge mode.
The above figure shows the network connection in router
mode. In router mode, the default IP of WAN port is DHCP,
and the default IP of LAN port is 192.168.11.1.
The above figure shows the network connection in bridge
mode. In bridge mode, WAN and LAN port use the same
IP address. The default IP address is 192.168.11.1.
Note: UC100 can also be connected through WiFi. The
default SSID of the device is "domain_ [last 6 digits of MAC
address] “ without password.
LTE Antenna
WiFi Antenna
PWR Port0 WiFi
RST RUN LTE
WPS
UC120
DC12V
WAN
WAN
LAN
LAN Port0 Port1
Port1
WiFi Antenna
PWR Port0 WiFi
RST RUN LTE
WPS
UC120
DC12V
WAN
WAN
LAN
LAN Port0 Port1
Port1
PWR Port0 WiFi
RST RUN LTE
WPS
UC120
DC12V
WAN
WAN
LAN
LAN Port0 Port1
Port1
Power Adapter
SD SIM
Insert (with the chip facing downwards)
PWR Port0 WiFi
RST RUN LTE
WPS
UC120
DC12V
WAN
WAN
LAN
LAN Port0 Port1
Port1
Telephone Line
Analog Phone
PSTN Line PSTN
PWR Port0 WiFi
RST RUN LTE
WPS
UC120
DC12V
WAN
WAN
LAN
LAN Port0 Port1
Port1
Router/Switch
TCP/IP
192.168.11. XXX
192.168.11.1
Network cable
192.168.1. XXX
Network cable
Switch PC
The same IP segment
PWR Port0 WiFi
RST RUN LTE
WPS
UC120
DC12V
WAN
WAN
LAN
LAN Port0 Port1
Port1
Router/Switch
TCP/IP
192.168.11.XXX
192.168.11.1
Network cable
192.168.11.1
Network cable
Switch PC

Login Web Management System6
Open a web browser and enter the IP address of LAN port (the default IP is 192.168.11.1). You also can enter the IP address
of WAN port, but it’s required to modify the IP address of PC to make it at the same network segment with that of WAN port.
By default, the username is admin, while the password is admin@123#.
Check Mobile Network Status7
For LTE device, view the SIM card status and signal strength on the "status →Overview" page, while for GSM devices, check
the status on the "status →PSTN" page.
Modify Network Configuration8
Please log into the device and click "network → settings" at the top menu bar to configure IP addresses of WAN and LAN port.

The default network mode of UC120 is router mode, and it can be set to bridge mode. In router mode, the IP address of WAN
port and LAN port should be in different network segments. The default IP address of WAN port is obtained by DHCP, while
the default IP address of LAN port is 192.168.11.1. In bridge mode, WAN port and LAN port use the same IP address.
After modification, you need to click "apply" to make the settings take effect
Modify WiFi Settings
9
WiFi is enabled by default. Go to "network → WLAN" page to turn off the wireless or modify relevant parameters.
The default SSID of the device is "domain"_ [last six digits of MAC address] “. Except default SSID, users can create three more
SSIDs. After modifying the WLAN parameters, you need to click "apply" to make the settings take effect.
Create SIP Extensions
10
On the Extension →SIP interface, you can configure the SIP accounts registered in the UC120 by SIP clients (hereby UC120
is regarded as a SIP server ).
If the status of new added SIP account is "enabled", it means that the UC120 accepts the registration of the extension.
If the status of the SIP account is "disabled", it means that the UC120 rejected to register the extension. Up to 60 SIP accounts
can be configured.
The registration status of SIP extension and SIP trunk can be checked on the "status →SIP" page.
After setting, you need to click "apply" to make the settings take effect.

SIP Trunk
11
SIP trunk can realize the connection between UC120 and IP PBX or SIP servers.
If UC120 is regarded as a terminal and intends to register to a server, you need to configure a SIP trunk connecting UC120
and the server, and then enable register for the SIP trunk.
If the FXS f UC120 intends to register to a server, you need to configure a SIP trunk connecting UC120 and the server, then
enable register for the port and designate the SIP trunk to it.
Configure outbound/inbound rule
12
On the Call Control → Route interface, you can configure routes for incoming calls and outgoing calls.
For the outbound route rule, destination can be FXO trunk, GSM trunk and SIP trunk;
For the inbound route rule, the destination can be SIP extension, FXS extension, local extension, ring group or IVR

Regular Expression
13
Caller/Called number prefix supports regular expression
Regular ExpressionSyntax
Basic Operation
14
Dial *158# to query the IP address of LAN port of the device;
Dial *159# to query the IP address of WAN port of the device;
Dial *114# to query the telephone number of a FXS port;
Restart the device:
(1) Dial *111# to restart the device;
(2) Click "system->Reboot" menu to perform reboot;
RST button:
(1) Under normal running status, press RST button 3 to 6 seconds will restore default username/password, and network
mode will be changed to route mode as well. Other configurations will keep the same;
(2) Under normal running status, press RST button 6 to 12 seconds, the device will restore factory default and reboot
automatically;
(3) When the device is power off, press RST button more than 30 seconds after it power on, the device will clear all the
configurations and restore to mini-system management;
Example：
^0755 matches the phone number start with 0755；
^0755\d{8,9} matches the phone number start with 0755 and following 8 or 9 digits number length；
^0755|^8899|^0110 matches the phone numbers with starting digits of 0755, 8899 or 0110.
Matches the starting position in a number string. For example, ^134 matches the numbers
starting with 134.
Matches the ending position of a string. For example, 2$ matches the numbers ending with 2.
Separates alternate possibilities. For example, 2|3|4 means 2, 3 or 4.
Marks the next character as a special character, a literal, a backreference, or an octal escape.
Matches a single character that is contained within the bracket. For example,[123]matches
1, 2, or 3.[0-9]matches any digit from "0" to "9".
Matches any one characterexceptthose enclosed in [ ]. For example, [^9] matches any
character except 9.
Matches any single character except the newline character. For example, 3.4 matches
314, 324, 334, 344.
Indicates there iszero or oneof the preceding element. For example,colou?rmatches both
color and colour.
Indicates there iszero or moreof the preceding element. For example,ab*cmatches ac, abc,
abbc, abbbc, and so on.
Indicates there isone or moreof the preceding element. For example,ab+cmatches abc, abbc,
abbbc, and so on, but not ac.
Mark any digit, equal to [0-9 ].
Mark any character that is not a digit, equal to [^0-9 ].
Mark any blank character such as a space or a tab.
Mark any character that is not a blank character.
^
$
|
￥
[ ]
[ ^ ]
?
*
+
/d
/D
/s
/S
.

More Details
15
This document only provides instructions for quick installation and basic configuration. For detailed configuration and
parameter explanation, please make reference to User Manual, or ask for online technical support.
Frequently Asked Questions
16
(1) UC120 call priority (from high to low)
a. For the call between extensions, it is not necessary to configure any route, but to dial the extension number
directly, which has the highest priority;
b. DID；
c. The route rule in the "call control →routing" page (the rule with lower index has higher priority);
d. Port registration configured in FXS extension, FXO trunk and GSM trunk.
Can the call between extensions be disabled?
Yes, disable internal call between extensions under the "call control →settings" page.
How many SIP extensions and concurrent calls can UC120 support?
UC120 supports 60 SIP extensions and 15 concurrent calls at max.
Can access the Internet through UC120 during making call through VoLTE?
If the operator's network supports VoLTE and the SIM card used has already enabled VoLTE service, the call will go to
volte network. At this time, the Internet connection of SIM card will not be disconnected during the call;
If the operator's network does not support VoLTE or the SIM card does not enable volte service, the call will automat
ically fall back to 2G / 3G network, at this time, the SIM card Internet connection will be automatically disconnected
(that is, the Internet cannot be accessed during the call).
The Gateway to VoIP World
