HiWeigh WX User manual

WX(S)-CST-WTS
TABLE SCALES



@WX WXS CST WTS USER MANUAL
2
Please read the manual in details before operation Please use the right plug and right voltage
Be much attention of 110V or 220V!!!
Adjust the bubble level on the balance position Don’t hit the platform rudely and overload
Don’t put the chemical liquid or other Liquids Don’t open the scale by yourself and please
to avoid damage to the scale call the service people or our distributor
when you get the problem
Please recharge the scale on time to assure the health of the battery, and replace the battery if
it runs out of life. The replaced battery must be handled correctly.
Important Safety And Operation Info

@WX WXS CST WTS USER MANUAL
3
Specifications
4
Power
4
Before using
4
System power consumption
4
Display description
4
Basic function operation
5
Basic parameter setting
5
- A/D count
7
- High / Low limits setting
7
- Auto-power off
8
- Backlight setting
8
- Hold function
8
- RS-232 output
9
- RS-232 baud rate
9
- Communication protocol
9
- RS-232 speed setting
9
- Zero average
11
- G Value setting
11
Advanced function setting
12
- Check weighing (span)
12
- Zero Calibration
12
Guarantee
12
INDEX

@WX WXS CST WTS USER MANUAL
4
SPECIFICATIONS
Accuracy: Class III
Nonlinear: ≤0.01%F.S
System working voltage: DC:5V
Large display connector: Sampling serial output way
Sample rate: 20 times per second (can select)
POWER
Input: 120 ~ 240V
Output: 12 V/ 1A
Rechargeable battery: 6 V/ 4AH
BEFORE USING
1) Place this product on a firm and smooth place, don´t place it in vibration or shaking,
use bench for use on four only adjust foot, adjust the balance using the bubble
level.
2) Use independent source, avoid other electrical disturbance.
3) Don´t put any object on the platter when turn on the balance.
4) Please, turn on 2-3 minutes before using.
5) Avoid temperature change too large and air flow strenuous sites.
6) Don´t overload the balance, don´t exceed the maximal capacity.
SYSTEM POWER CONSUMPTION
Main system power consumption: about 12mA
Main system power consumption (with backlight): about 36mA
Main system power consumption (with backlight and RS-232): about 48mA
Battery life: none backlight, about 320 hours.
DISPLAY DESCRIPTION
WX | WXS Model:

@WX WXS CST WTS USER MANUAL
5
CST | WTS Model:
BASIC FUNCTION OPERATION (WX | WXS)
Press and hold this key for 2 seconds to turn off the balance.
Press this key to turn on the balance
Function 1. To select the desired weight unit.
Function 2. To exit from setup mode.
Function 1. To reset the weight to zero “0”, but the display value has to
be lesser than ± 2% of maximum capacity.
Function 2. To move one space to the left or downward in setup mode.
Function 1. To subtract the container´s weight.
Function 2. To move one space to the right or upward in setup mode.
Function 1. To view gross or net weight when the balance is on tare
status. All other keys will be disabled when gross weight is activated.
Function 2. To increase values upward in setup mode.
Function 1. Key of confirmation in setup mode.
Function 2. Manually transmitting data through RS232 to computer or
printer.
BASIC FUNCTION OPERATION (CST | WXS)
Press and hold this key for 2 seconds to turn off the balance.
Press this key to turn on the balance

@WX WXS CST WTS USER MANUAL
6
Function 1. To select the desired weight unit.
Function 2. To exit from setup mode.
Function 1. To reset the weight to zero “0”, but the display value has to
be
lesser than ± 2% of maximum capacity.
Function 2. To move one space to the left or downward in setup mode.
Function 1. To subtract the container´s weight.
Function 2. To move one space to the right or upward in setup mode.
Function 1. To view gross or net weight when the balance is on tare
status. All other keys will be disabled when gross weight is activated.
Function 2. To increase values upward in setup mode.
Function 1. Key of confirmation in setup mode.
Function 2. Manually transmitting data through RS232 to computer or
printer.
If you know the weight of the container, press this key and input the
container weight value, then put the goods into the container, the
display will show the net weight only.
To set the value of high limit
To set the value of low limit.
To program check weighing High / Low conditions (remark -)
To accumulate weights, the max of the weight times is 9999
To introduce sample value.
To recall accumulations
To enter in counting pieces function.
To view the total accumulation weighings

@WX WXS CST WTS USER MANUAL
7
Backlight
To clear data
BASIC PARAMETER SETTING
Note: (WX keys = CST keys)
To access to functions setting, press the and key at the same time.
Press the to select the parameter (UF-1 ~ UF-9)
.
UF-1 A/D count
1. Press the key to view the A/D count.
2. To move to next parameter press the ►key.
3. To exit and return to normal weighing press the key.
UF-2 High / Low limits setting
1. Press the key to enter.
2. The display will show the message “000000L”
3. Use the keys and to move cursor and press the to select
number.
4. Press the key to confirm.
5. The display will show “00000H”
6. Use the keys and to move cursor and press the to select number.
7. Press the key to confirm.
8. Buzzer beep see remark ( - )

@WX WXS CST WTS USER MANUAL
8
UF-3 Auto-power off
Modes:
- AoFF 00 – Auto-turn off disable.
- AoFF 01 – The balance will automatically turn off after 1 minute of non use.
1. Press the key to access to auto-power configuration.
2. Use the keys and to move from one digit to other and the key
to select the desired mode.
3. Press the key to confirm.
UF-4 Backlight setting
Modes:
- A: Automatic
- ON: Backlight on
- OFF: Backlight off
1. Press the to access to backlight configuration.
2. Use the key to select the desired mode.
3. Press the key to confirm.
UF-5 HOLD function (keeps the reading fixed on display for few seconds after
removing the load from the platter)
Modes:
- HOLD 0 : Disable.
- HOLD 1 : Weighing animals mode.
1. Press the key to access to HOLD function configuration.
2. Use the key to select the desired mode.
3. Press the key to confirm.

@WX WXS CST WTS USER MANUAL
9
UF-6 RS-232 Output (optional)
232 0 - RS-232 disable
232 1 - Stable output – Format 1
232 2 - Stream output – Format 1
232 3 - Manual output – Format 1
232 4 - Stable output – Format 2
232 5 - Stream output – Format 2
232 6 - Manual output – Format 2
RS232 Baud rate
b 1200 Baud rate 1200
b 2400 Baud rate 2400
b 4800 Baud rate 4800
b 9600 Baud rate 9600
b 19200 Baud rate 19200
b 38400 Baud rate 38400
1. Press the to enter
2. Press the to select the baud rate
3. Press the key to confirm.
Communication Protocol
UART signal of EIA-RS232 C
Format:
1. Serial output: 1200/2400/4800/9600/19200/34800 BPS
2. Data bits: 8 bits
3. Parity bits: None
4. Stop bits: 1 bit
S t a r t bit D a t a bi ts S t op bi t s
Format 1 (232 1 – 3):
HEAD1 (2 BYTES)
HEAD2 (2 BYTES)
OL – Overload
ST – Stable
NT – Net weight
US – Unstable
GS – Gross weight

@WX WXS CST WTS USER MANUAL
10
F i x ed 18 B Y T E S ASC II ( k g g t lb )
1
2
1
1
2
1
1
2
3
4
5
6
7
8
1
2
1
2
H E AD1 , H E AD2 , DA T A U N IT CR LF
F i x ed 21 B Y T E S ASC II ( t l. T lbo z)
1 2 1 1 21 1 2 3 4 5 6 7 8 9 1 2 3 41 2
H E AD1 , H E AD2 , DA T A U N IT CR LF
F i x ed 19 B Y T E S ASC II ( p c s )
1
2
1
1
2
1
1
2
3
4
5
6
7
8
1
2
3
1
2
H E AD1 , H E AD2 , DA T A U N IT CR LF
1. E x am pl e + 0.876 k g S t a bl e net w e ig h t :
S
T
,
N
T
,
+
0
0
0
.
8
7
6
k
g
0D
0A
2. E x am pl e - 1.568 lb un s t a bl e g r o ss w e ig h t :
U
S
,
G
S
,
-
0
0
1
.
5
6
8
l
b
0D
0A
3. E x am pl e - 20. 5.40 lb o z un s t a bl e g r o ss w e ig h t :
S
T
,
G
S
,
-
1
0

0
5

4
0
l
b
o
z
0D
0A
4. E x am pl e + 1000 p c s s t a bl e net w e ig h t :
S
T
,
N
T
,
+
0
0
0
1
0
0
0
p
c
s
0D
0A
F o r ma t 2 (232 4 ~ 6) :
F i x ed 12 B Y T E S ASC II ( k g g t lb )
1
2
3
4
5
6
7
8
1
2
1
2
DA
T A U N IT CR LF
F i x ed 15 B Y T E S ASC II ( t l. T lbo z)
1
2
3
4
5
6
7
8
9
1
2
3
4
1
2
DA T A U N I T CR LF
F i x ed 13 B Y T E S ASC II ( p c s )
1 2 3 4 5 6 7 8 1 2 3 1 2
DA T A U N IT CR LF

@WX WXS CST WTS USER MANUAL
11
O u tp u t e x am pl e s :
1. E x am pl e + 0.876 k g s t a bl e net w e ig h t :
+
0
0
0
.
8
7
6
k
g
0D
0A
2. E x am pl e - 1.568 lb un s t a bl e g r o ss w e ig h t :
-
0
0
1
.
5
6
8
l
b
0D
0A
3. E x am pl e - 20. 5.40 lb o z un s t a bl e g r o ss w e ig h t :
-
1
0

0
5

4
0
l
b
o
z
0D
0A
4. E x am pl e + 1000 p c s s t a bl e net w e ig h t :
+
0
0
0
1
0
0
0
p
c
s
0D
0A
UF-7 RS-232 Speed setting
1. Press the key to enter.
2. Press the key to select the desired mode.
Mode 1 : Normal
Mode 2: Fast
Mode 3: Slow
3. Press the key to confirm.
UF-8 Zero average
1. Press the key to enter.
2. Press the key to select.
3. Press the key to confirm.
UF-9 G Value setting
1. Press the key to display the G value of manufacture place.
2. If set the G value of local press the key and then the or keys
and key to input the new G value.

@WX WXS CST WTS USER MANUAL
12
ADVANCED FUNCTION SETTING
1. In weight mode, press the and keys, the display will show ECF – 1.
2. Press the or keys to select ECF-1, ECF-2 or ECF-3
* ECF-1 Check weighing (SPAN)
Press the to enter, display will show CALZ.
Press the to zero the display.
Use the keys and to select the digit.
Press key to input the weight value.
Put the calibration weight on the platter and press the key to calibrate.
* ECF-2 Zero Calibration
Press the key to enter.
The display will show CALZ.
Press the key to zero.
Press the key to calibrate.
GUARANTEE
This scale is guaranteed for one year from the delivery date. The guarantee covers
any fabrication defect of the material.
During this period, we cover the labour cost and the spare parts necessary for the
reparation of the scale.
This guarantee does not cover the failures caused by an inappropriate use or
overcharge.
The guarantee does not cover the freight cost (transport) necessary to repair
the scale.



User Manual
v.201811
WX(S)-CST-WTS
