Hocom AEPL-M Series User manual

User Manual
AEPL-M Series
Price Computing Scale

AEPL-M Series
User Manual

AEPL-M Series
User Manual
Cautions
Upon receiving the scale, please take at least 8
hours to recharge the battery before you start to
operate this scale.
Please recharge the battery after a long period of
storage (more than one month). It takes 8~10
hours to fully recharge the battery.
Please assemble the platter before powering on the
scale.
Do not keep the weight placed on the platter for a
long period.
Keep the scale away from the environment with
high temperature, high humidity, heavy press, and
heavy bump.
Always make sure the scale is located in a flat and
plane surface.
1

AEPL-M Series
User Manual
Dimensions
AEP L-M(with Pole Display):
2

AEPL-M Series
User Manual
Symbols on LCD
Accumulation Indication () :
cursor appears on the bottom edge of WEIGHT
LCD (above of M+ printed on the display-overlay),
and indicates the memory bank has stored
accumulative data of weight, unit price, and total
price.
!! Notice: This cursor is available for the scale
with accumulation function only.
NET Weight Indication () :
cursor appears on the bottom edge of WEIGHT
LCD (above of NET printed on the display-overlay),
and indicates the tare weight has been deducted.
Zero Indication () :
cursor appears on the bottom edge of WEIGHT
LCD (above of ZERO printed on the display-overlay),
and indicates the scale is at zero-point.
Indication of kg、100g Weighing Mode () :
cursor flashes on the bottom edge of UNIT PRICE
LCD (above of kg or 100g printed on the
display-overlay), and indicates the present weighing
mode.
3

AEPL-M Series
User Manual
Indication of Weighing Range () :
cursor appears on the bottom edge of UNIT PRICE
LCD (above of W1 or W2 printed on the
display-overlay), and indicates the present weighing
range to be Weighing Range 1 (W1) or Weighing
Range 2 (W2).
!! Notice: The indication of weighing range is
only available for the scale / indicator with
multi-range (2 ranges).
Battery Symbol ( ) :
appears on the bottom edge of WEIGHT LCD,
and indicates the battery is running in low-voltage
status. This is for reminding the user to recharge the
battery.
OPERATION INSTRUCTIONS
Status of the Battery :
When WEIGHT LCD indicates and the scale
sounds beep for four times, it means the battery is
running in low-voltage status. WEIGHT LCD will
indicate continuously for reminding the user to
recharge the battery. If the battery is still running in
low-voltage status without being recharged, WEIGHT
LCD will indicate -OFF- and the scale will sound
beep for eight times. Please power off the scale and
recharge the battery right away.
-
-
-
-
4

AEPL-M Series
User Manual
 0 ~ 9 :
(1) Press these keys to key in the unit price.
(2) Press and hold [0] key till WEIGHT LCD display
shows the voltage of battery. 6.1 ~ 6.5 means the
battery is running in hi-voltage status. Less than
5.5 means the battery is running in low-voltage
status. Please recharge the battery as soon as
possible. Pressing [CE] key could go back to
normal operating-mode.
:
(1) Press this key to set the decimal point for the unit
price.
(2) Press and hold [] key till the scale sounds beep
to enable or disable optional Backlight.
 CE :
Press this key to delete the setting values of unit
price.
5

AEPL-M Series
User Manual
TARE
ZERO
:
(1)Press this key to zero the weight that is lighter
than the division. WEIGHT LCD will show 
cursor on the above of ZERO (printed on the
display-overlay).
(2)While the measured weight is heavier than the
division, pressing this key could get a net weight.
Place a package or container on the platter and
press this key to deduct the tare weight, WEIGHT
LCD will show 0.000 and cursors on the above
of ZERO and TARE (printed on the display-overlay).
 X :
Press this key to operate the multiplication.
Example: Key in 25 »Press [x] key »Press [3] key »
TOTAL PRICE LCD will indicate 75.00 (25 x3 = 75). At
this moment, pressing [+] key could save this figure into to
the memory bank, or pressing [C] key to delete this figure.
+:
Press this key to operate the addition (for
non-weighing items). Key in a unit price and then
press [+] key to save the figure save it into the
memory bank.
6

AEPL-M Series
User Manual
 CHANGE :
Press this key to operate money-change function.
Example:
- with 2kg apples on the platter and its unit price I is
$45/Kg. the customer gives $500.
- The customer requires another two packages of
cigarette and its unit price is $50/package.
Operations:
(1) Put the apples on the platter and key in the unit price:
45, and then press [M+] key to save the total price in to
the memory bank, LCDs will show:
; then press [CE] key could go back to normal
operating mode.
(2) Key in 50, then press [X] key, then [2] key, LCDs will
show:
, press [+] key to save the figure into the memory
bank.
P = 1
90.00
=2
50
100.00
7

AEPL-M Series
User Manual
(3) Press [MR] key to recall show all saved items in the
memory one by one. LCDs will show:
(4)Press [CHANGE] key once and then key in 500,
LCDs will show:
; then press [CE] key could go back to normal
operating mode.
(5)Press [MC] key to delete all accumulated data in
the memory bank.
 M1 ~ M5 :
5 direct PLU for saving the unit prices.
Example:
Save 7.50 into M3 memory bank
Key in [7] [5] [0] >> Press and hold [M3] key till the
scale sounds beep >> Finish setting.
At this moment, press [M3] key could recall $7.50
showed on UNIT PRICE LCD. To modify the setting
figure of M3, please just follow the above steps again.
2.000
45
90.00
P = 2
190.00
P.1- 2
=
100.00
500
190.00
C310.00
8

AEPL-M Series
User Manual
 UNIT :
Press this key once, WEGIHT LCD will indicate ch9 -,
and then press [1] or [2] key to select the weighing
mode:
Press [1] key to select kg mode.
Press [2] key to select 100g mode.
 M+ :
Press this key to save the measured weight, unit
price, and total price into the memory bank (up to 99
data accumulation and 24 data recall).
 MR :
Press this key to recall the data one by one which is
saved in the memory bank by pressing [M+] or [+]
key. When the last data is showed, press [MR] key
again will get the total accumulation unit price on
TOTAL PRICE LCD.
9
2

AEPL-M Series
User Manual
 MC :
Press this key could delete all accumulated data in
the memory bank (the scale will sound beep beep
when [MC] key has been operated).
 01 ~ 40 :
40 direct PLU for saving the unit prices.
Example:
Save 7.50 into [10]memory bank
Key in [7] [5] [0] >> Press and hold [10] key till the
scale sounds beep >> Finish setting.
At this moment, press [10] key could recall $7.50
showed on UNIT PRICE LCD. To modify the setting
figure of [10], please just follow the above steps
again.
10

AEPL-M Series
User Manual
RS232 Interface Connection: <optional device>
RS232 Wiring Configuration:
Baud Rate: 9600
Parity: None
Stop Bit: 1
Data Bit: 8
GND
5
4
3
2
1
9
8
7
6
5
4
3
2
1
9
8
7
6
SCALE
PC
TX
11

AEPL-M Series
User Manual
Recharge the Battery
Power off the scale and connect the power cord to an
AC outlet. CHARGE LED will indicate the ongoing
status of the battery. It takes about 8~10 hours to
fully recharge the battery.
CHARGE LED:
Color of LED
Status of the battery
RED
Initial Connection
ORANGE
Charging
GREEN
Fully-charged
Power Supply
AC: 230V±10%, 50Hz
DC: 6V/4Ah rechargeable battery;
P=0.2W(max)
12

AEPL-M Series
User Manual

AEPL-M Series
User Manual
Price Computing Scale
We do more than you expect
