Manual abstract:
2. To avoid fire or shock hazard, plug the appliance directly into a 120V AC electrical outlet. 3. The heater is hot when in use. To avoid burns, DO NOT let
bare skin touch hot surfaces. If provided, use handles when moving this heater. Keep combustible materials, such as furniture, pillows, bedding, papers,
clothes, and curtains at least 3 ft (0.9 m) from the front of the heater and keep them away from the sides and rear. 4. DO NOT run cord under carpeting.
DO NOT cover cord with throw rugs, runners, or the like. Arrange cord away from traffic area and where it will not be tripped over. 5. This heater is not
intended for use in bathrooms, laundry areas and similar indoor location. NEVER locate heater where it may fall into a bathtub or other water container.
6. Extreme caution is necessary when any heater is used by, or near children or invalids, and whenever the heater is left operating and unattended. 7. Always
unplug the heater when not in use. 8.
When unplugging, be sure to pull by the plug and not the cord. 9. DO NOT insert or allow foreign objects to enter any ventilation or exhaust opening as this
may cause an electric shock or fire, or damage the heater. 10.DO NOT operate heater with a damaged cord or plug, or after the heater malfunctions, has
been dropped or damaged in any manner. Return appliance to manufacturer for examination, electrical or mechanical adjustment, or repair. 11.A heater has
hot and arcing or sparking parts inside. DO NOT use it in areas where gasoline, paint, or flammable liquids are used or stored. 12.
Use appliance only for intended household use as described in this manual. Any other use not recommended by the manufacturer may cause fire, electric
shock, or injury to persons. The use of attachments not recommended or sold by The Holmes Group may cause hazards. 13.DO NOT use outdoors. 14.To
prevent a possible fire, DO NOT block air intakes or exhaust in any manner. DO NOT use on soft surfaces, like a bed, where openings may become blocked.
15.To disconnect heater, turn controls to OFF, then remove plug from outlet.
16.Avoid the use of an extension cord because the extension cord may overheat and cause a risk of fire. However, if you have to use an extension cord, the
cord shall be No. 14 AWG minimum size and rated not less than 1875 watts. 17.
If the heater will not operate, see specific instructions on Auto Safety Shut-off. 18.DO NOT attempt to repair or adjust any electrical or mechanical functions
on this unit. Doing so will void your warranty. The inside of the unit contains no user serviceable parts.
All servicing should be performed by qualified personnel only. PLEASE READ AND SAVE THESE IMPORTANT SAFETY INSTRUCTIONS AUTO SAFETY
SHUT-OFF WITH CERAMIC CONTROL This heater is equipped with a patented, technologically-advanced safety system that requires the user to reset the
heater if there is a potential overheat situation. When a potential overheat temperature is reached, the system will automatically shut the heater off. It can
only resume operation when the user resets the unit. To Reset the Heater: 1. Turn MODE to off and slide switch to manual. 2. Unplug the heater and wait 10
minutes for the unit to cool down. 3. After the 10 minutes, plug the unit in again and operate normally.
THIS PRODUCT IS EQUIPPED WITH A POLARIZED AC (Alternating Current)PLUG (a plug having one blade wider than the other). This plug will fit into
the power outlet only one way. If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, contact qualified personnel to install the
proper outlet. DO NOT DEFEAT THE SAFETY PURPOSE OF THIS POLARIZED PLUG IN ANY WAY. PRE-OPERATING INSTRUCTIONS 1. Carefully
remove your heater from the box. (please save the carton for off-season storage). 2. Make sure the unit is in the OFF position before plugging the heater into
the outlet.
3. Place heater on firm level surface. 4. Avoid overloading your circuit by not using other high wattage appliances in the same outlet. At 1500 Watts, this unit
draws 12.
5 Amps. CLEANING/MAINTENANCE During Season Care: Always unplug the heater, before moving or cleaning.
You're reading an excerpt. Click here to read official HOLMES
HFH595 user guide
http://somemanuals.com/dref/50921

1. Carefully wipe the unit with a soft, damp cloth. Please be very cautious near the motor and heating elements.
2. After cleaning, be sure to completely dry the unit with a cloth or towel. After Season Care: 1. Store heater in a cool, dry location. 2. Holmes recommends
that you store the unit in its original carton. ACCUTEMPTM DIGITAL THERMOSTAT Your heater is equipped with an AccuTempTM Digital Thermostat
that allows you to set your heater to your precise comfort level. Setting the AccuTempTM thermostat: 1. Make sure the Manual/AccuTempTM switch is set to
AccuTempTM. The LCD display will read 25°.
2. Turn the mode control to LO, MED or HI. 3. Push the temperature set button until the display reads your desired temperature. To increase the temperature
push the top button, for lower temperatures push the lower button. When finished setting the temperature, release the button and the display will flash to
indicate the thermostat will be set to that temperature. 4. The display will return to existing room temperature and gradually increase until the room has
reached your pre-set temperature. 5. If the unit will not start in the AccuTempTM mode, please make sure the "set temperature" is higher than the current
room temperature.
NOTE: It is normal for the heater to cycle ON and OFF as it maintains the preset temperature. To prevent the unit from cycling, you need to raise the
thermostat setting. When the preset temperature is made, the fan will run for 30 seconds without heat. This cool down process ensures an accurate and
consistent temperature reading. If you unplug the heater, you will have to reset the AccuTempTM thermostat again by following the above instructions.
Manual Operation: 1. If you want the heater to run continuously, turn the Manual/AccuTempTM switch to Manual and adjust the mode control to LO, MED
or HI. TROUBLESHOOTING If your heater fails to operate: · Make sure the electrical outlet or circuit breaker is working. · Check for obstructions. If you
find an obstruction turn the heater OFF, and unplug the unit.
Carefully remove the obstruction and follow the reset instructions. · The thermostat might be set too low. Adjust the thermostat until the heater restarts. ·
Make sure selector is in LO, MED, or HI setting. If your heater fails to oscillate: · Make sure the oscillation button is pressed. Incorrect Room Temperature
Display: 1. Allow a few minutes for the heater to adjust to the room temperature. 2. Switch unit to Accutemp. Use touch pad to set desired temperature.
Please DO NOT attempt to open or repair the heater. Please see the Warranty for Service Instructions. ILLUSTRATIONS B H C A E D G Figure 1 A.
POWER LIGHT B. MODE CONTROL C. LCD DISPLAY SCREEN D. OSCILLATION SWITCH E. CARRY GRIP F. OSCILLATION BASE G.
TEMPERATURE SET BUTTON H.
MANUAL/ACCUTEMP SWITCH Figure 2 B C A G TM 25 HEAT CONTROLS OFF FAN LOW 500W MED 1000W HI 1500W F H D SERVICE
INSTRUCTIONS 1. Do NOT attempt to repair or adjust any electrical or mechanical functions on this unit. Doing so will void the warranty. 2. If you need to
exchange the unit, please return it in its original carton, with a sales receipt, to the store you purchased it.
If you are returning the unit more than 30 days after the date of purchase, please see the enclosed warranty. 3. If you have any other questions or comments,
feel free to write us: Consumer Service Department The Holmes Group, Canada, Ltd. 6385 Shawson Drive Mississauga, Ontario Canada L5T 1S7 For your
own records, staple or attach your sales receipt to this manual. Also, please take a moment to write the store name/location and date purchased below.
STORE NAME: LOCATION: DATE PURCHASED: (STAPLE RECEIPT HERE) FIVE (5) YEAR LIMITED WARRANTY A. The quality controls used in the
manufacture of this Holmes product are to ensure your satisfaction. B. This Warranty applies only to the original purchaser of this product. C. This Warranty
applies ONLY to repair or replacement of any supplied or manufactured parts of this product that, upon inspection by Holmes authorized personnel, proves to
have failed in normal use due to defects in material or workmanship.
You're reading an excerpt. Click here to read official HOLMES
HFH595 user guide
http://somemanuals.com/dref/50921

Holmes will determine whether to repair or replace the unit. This Warranty does not apply to installation expenses. D. Operating this unit under conditions
other than those recommended or at voltages other than the voltage indicated on the unit, or attempting to service or modify the unit, will render this
WARRANTY VOID.
E. Unless otherwise proscribed by law, Holmes shall not be liable for any personal injury, property or any incidental or consequential damages of any kind
(including water damage) SOME STATES DO NOT ALLOW THE EXCLUSION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE
LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU. F. All parts of this Holmes product are guaranteed for a period of 5 years as follows: 1. Within
the first 30 days from date of purchase, the store from which you purchased your Holmes product should replace this product if it is defective in material or
workmanship (provided the store has in-stock replacement.) 2. Within the first sixty months from date of purchase, subject to the conditions in paragraph H,
Holmes will repair or replace the product if it is defective in material or workmanship providing it is returned to Holmes, freight prepaid, with PROOF OF
PURCHASE date, together with $7.00 for handling and return packing/shipping charges. G. If you have any problem with this product, please write our
Consumer Service Department.
H. IMPORTANT Return INSTRUCTIONS Your warranty depends on your following these instructions if you are returning the unit more than 30 days after
the date of purchase: 1. Carefully pack the item in its original carton or other suitable box to avoid damage in shipping. 2. Before packing your unit for
return; be sure to enclose: a) your name, full address with zip code and telephone number, b) a dated sales receipt or PROOF OF PURCHASE, c) your $7.
00 check for return packaging, and d) The model number of the unit and the problem you are having. (Enclose in an envelope and tape directly to the unit
before the box is sealed.) 3. Holmes recommends you insure the package (as damage in shipment is not covered by your warranty). 4.
All shipping charges must be prepaid by you (as noted in paragraph F). 5. Mark the outside of your package: CONSUMER RETURNS THE HOLMES
GROUP, CANADA, LTD. 6385 SHAWSON DRIVE MISSISSAUGA, ONTARIO CANADA L5T 1S7 SHIPPING AND HANDLING CHARGES: $7.00 This
warranty gives you specific legal rights, and you may have other rights which vary from state to state. The provisions of this warranty are in addition to, and
not a modification of, or subtraction from, the statutory warranties and other rights and remedies contained in any applicable legislation. To the extent that
any provision of this warranty is inconsistent with any applicable law, such provision shall be deemed voided or amended, as necessary, to comply with such
law..
