HOMCOM 370-096 User manual

ASSEMBLY INSTRUCTION
IN221000270V01_UK
370-096
1.Suitable age for 18-36 Months.
2.Maximum user weight: 20KGS.
3.Adult assembly required.
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY

WARNING:
(1) This kind of product is fit for the children aged 18-36 month old and
maximum load under 20kg maximum load under 20kg.
(2) WARNING-Never leave the child unattended.
(3) Prevent access to stairs, steps and uneven surface.
(4) Remove hot liquids, electrical flexes and other potential hazards
from reach.
(5) Prevent collisions with glass in doors, windows and furniture.
(6) Instruction for routine maintenance and cleaning or washing.
(7) Before using, this product will be inspected and assembled by the
adult.
Specification
ltem
Maximum weight
Size
Available ages
Specifications
20KGS
67x40.5x46CM
Children at 18-36 months
(1) Installing and changing batteries should be
fulfilled by adults.
(2) Install the batteries refer to the picture (1) of
the parts: the installation of AA (1.5V)
batteries: open the cover, install the batteries
correctly according to the marks of the positive
and the negative electrodes , finally put on the
cover and fasten the cover.
(3) The unchangeable batteries must not be changed and do not mix
the different types of the batteries( or the new and the old) to use
together.
(4) Take out the used-up batteries and avoid short circuit.
The notices of installing and changing batteries

PART
LIST
1.body
4. wheel*4
2.handlebar
5.A rear axle &
3.Bumper
6. Steering shaft
M10
M8
M10
C4
B4
A9
D1
M4*10
Axle sleeve*2
Note:
All screws, nuts and small plastic parts are pre-installed in
the corresponding position, please follow the steps to
remove before you install the product.

A rear axle
Gasket
wheel
Nut Axle sleev
Gasket
Step 2 Install the bumper
Install the bumper on the front of the car as shown by the arrow
and screw it in place
Installing the other side wheel is the same as step 1.
(4X(4X10)SCREW)
INSTALLATION STEPS
Step 1 Install the rear wheel
As shown in the arrow, insert the shaft frame into the
car body, pass the axle sleeve, gasket, rear wheel,
gasket and nut (as shown in Figure 1) through the axle,
and tighten the nut clockwise (as shown in Figure 2).
A rear axle
Gasket
Gasket
wheel
Nut
Axle sleeve

Step 4 Install the Steering shaft
Turn the car upside down and insert the steering shaft
Step 5 Install the Steering shaft
Nut
Gasket
Insert the handlebar into the steering shaft, insert the gasket,
and secure with a nut(M10*1)
Step 3 Install front wheel
Gasket
Nut
Gasket
Gasket Gasket
Nut
As shown by the arrow, pass the gasket, wheel, gasket and nut
through the front axle and tighten the nut clockwise

Step 6 Install the battery
box and take off the cover;
Use three AAA 1.5V cells, please install
the batteries properly.
Warning:
Do not mix to use the batteries, such as
used, unused, different type, etc.
Keep the child away from the battery.
Loosen the 4x10 mounting screws and
open the seat cushion to see the battery
box. Add the dry battery and you can use
the music function.
