HOMCOM 370-253V70 User manual

1
Children Electric Motorcycle
ASSEMBLY INSTRUCTION
IN220901139V01_UK
370-253V70
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
Installation and Operation Instructions
Forward and backward operations by manual shift
Lighting and music playback functions

2
Battery: 6V 4AH
Drive Motor: 6V380*1(14000RPM)
Suitable age: 37-60 months
Maximum weight: 25 kg
Car Size: 86x44x58 cm
Speed: 3-5km/h
Hours of Use: Using 45 minutes after Charging 8-10 hours
Charger: Input: 100V-240V Output: 6V0.5A

3

4
①
②
③
④
- Non-rechargeable batteries are not to be recharged,
- The rechargeable batteries should be charged under adult supervision
- Different types of batteries or new and used batteries are not to be mixed,
- Batteries are to be inserted with the correct polarity(+ and -)
- Exhausted batteries are to be removed from the toy.
- The supply terminals are not to be short-circuited,

5
Remove the two fasteners and screws from the head, install the handlebar to the
head, install the fasteners back to the fixed position, and lock them with screws.
Connect the headlight cable interface to the corresponding connection port at the
front end of the body, and then hide the interface inside the body.

6
Install the head to the front of the machine body and align it from the upper hole to
the lower hole. The long screw passes through the position from the upper end face.
Put the shim and nut under it in turn and tighten it with a wrench.

7
Remove the front axle, nuts and shims from the head assembly, install the front
wheel into the front insert, align the holes, and then penetrate the front axle. Install
the shims and nuts on both sides in turn and tighten with wrenchs.
First remove the pre installed screws on the bottom of the body and the foot pedal,
then install the foot pedal on the body, then install the auxiliary wheel assembly into
the bottom and fix it with screws

8
Distinguish the left and right taillight decorative and install them to the corresponding
body holes. Take out the pre installed screws at the fixed position of the motor cover,
install the motor cover, and then fix it with screws.
Open the seat cover, connect the interface of the power cord, open the power switch
to check whether it is powered on, then install the seat cover and tighten the screws.

9
Warning: The toy is to be assembled by an adult. In unassembled state contain
potentially hazardous sharp points, sharp edges and small part, so please keep out
of baby's reach.
Warning: Not to be used in traffic.
Warning: Only adults can install parts and adjust the car, and keep moving parts out
of children 's reach. Children can use the product only in the company of adults,
and the adult cannot leave during the process.
Warning: Never let Children stand or play onto the pedal or on the car.
Warning: Only adults can complete storage battery charging, and must charge the
product before its first use.
Warning: Keep such package materials as plastic bags out of children, or they will
suffocate or kill children.
Warning: Never use parts provided by non-manufacturers. Never let children play
with the charger. The number of connected power by the product can never be over
the recommended number.
Warning: Toys used by children outside of private places may be potentially
dangerous.
Never use the product in such dangerous zones as street, road, slope or drain.
Never change the circuit and additional electric devices.
Never use the product in rainy days or in the water, never pour water or other liquid
into the product, keep the product out of the fire, otherwise it will be damaged.
Only one child can use the product and it's weight cannot exceed 25 KGS.
Turn off the power when not in use and remove battery connector when not using it
for a long time.
As the product has battery charger, check whether wire plug shell and other parts
are damaged or not, and fix those damaged parts.
The product must be assembled by the adult!
Before assembling, screws and pins are dangerous sharp points.
Step 1 :The charging hole is under the seat
Step 2: Put the charger plug into the plug hole.
Step 3: Connect the charger to the power socket.

10

Low battery voltage；
Protection of electric devices; Use the car a few minutes later;
Failure to press the switch button correctly; Use the car according to instructions;
Falling of power connector; Install the connector again;
Battery breakdown; Change battery;
Damage of electric devices; Change electric devices;
Generator breakdown； Change generator.
Falling of battery connector; Install the connector again;
No charging for the charger; Plug the charger again;
Charger breakdown ； Change the charger.
Not full charging of battery
Much-used battery
； Charge fully the battery again;
； Change the battery.
Much-used battery； Change the battery
No electricity for battery； Charge fully the battery again
Overload ； Reduce the load below kilograms
Uneven driving surface；
Charge the battery before first use, otherwise the battery will be damaged forever.
In charging, put DC plug into the power socket, put charger into power plug.
Never use the product during charging it.
The product can be used for one hour and the charging time is 8-10 hours,
exceeding no more than 18 hours.
lt is common for charger and battery to have become heated(temperature under 60
degrees) in charging.
Do not contact the charging interface with water, otherwise short circuit will
happen.
Use the product's own charger, otherwise it will cause damage to the charger and
battery, or short circuit will happen.
Charge the product when not using it for a long time.
How to replace the battery:
1. Open the seat cover, remove the battery cover, unplug the positive and
negative connecting wires of the battery, and take out the old battery;
2. Replace the new battery, plug in the positive and negative connecting wires,
cover the battery cover and lock the screws, and cover the seat cover and
lock the screws.

11
Parents should check whether the wiring, plug, housing and other parts of the charger
are damaged before use, and repair the damaged parts.
After using the product for a period of time, parents should use lubricating oil to
lubricate the cast iron, otherwise those castings will rust; They should keep the product
away from the fire source and put it in a place away from light; In rainy or wet weather,
the product should be placed in the house, or covered with a waterproof cloth to
prevent it from getting damp.
Parents should keep the product away from high-temperature objects such as furnaces
and heaters, otherwise the plastic parts may melt; They should keep the products away
from combustibles in the room. They should keep the product away from indoor
combustibles when charging, otherwise a fire may occur.
Parents should clean the car surface with dry cloth or clean plastic parts with non wax
polishing materials; Do not use chemical solution and water to clean the product.
Children should not drive in wet or rainy weather, otherwise the motor, circuit system
and battery will be damaged.
When not using the product, parents should cut off the power supply of the car and
keep all switches in "stop" or "off" mode.
Parents should not use fuses that do not meet the agreed specifications. The product
structure and circuit system shall not be changed, and the product shall be inspected
and fixed by professionals or under the guidance of professionals.

12
Motocicleta Eléctrica Infantil
MANUAL DE INSTRUCCIONES
IN220901139V01_ES
370-253V90
IMPORTANTE, LEA Y GUARDE PARA FUTURAS REFERENCIAS
Instrucciones de instalación y funcionamiento
Avance y retroceso mediante cambio manual
Funciones de iluminación y reproducción de música
* Peso máximo:25kg.

13
Especificaciones del producto:
Batería: 6V4AH.
Motor de tracción: 6V380*1(14000RPM)
Edad recomendada: 37-60 meses.
Peso máximo: 25 kg.
Medidas del coche: 86x44x58 cm
Velocidad: 3-5 km/h.
Autonomía: 45 minutos aprox. después de una carga de 8-10 horas.
Cargador: Entrada: 100V-240V Salida: 6V0.5A.
PARTES
Cuerpo principal Rueda frontal Ruedas auxiliares
Estructura frontal Manillar Pedal
Cubierta del motor Luz decorativa Cargador
Llave inglesa

14
Lista de Partes
Tornillo de conexión
Fijadores
Manillar
Cubierta del
motor
Luz decorativa
Estructura frontal
Rueda frontal
Pedal
Tuerca
Arandela
Eje delantero
Arandela
Tuerca
Ruedas auxiliares

15
- Las pilas no recargables no deben recargarse.
- Las baterías recargables deben cargarse bajo la supervisión de un adulto.
- No se deben mezclar diferentes tipos de pilas o pilas nuevas y usadas.
- Las pilas deben insertarse con la polaridad correcta (+ y -).
- Las pilas agotadas deben retirarse del juguete.
- Los terminales de alimentación no deben cortocircuitarse.
Funciones
①
②
③
④
Indicaciones de función:
Interruptor de encendido
Adelante
Paro
Atrás
Botón de música
Pedal
Precauciones de la batería

16
Retire los dos fijadores y tornillos del marco delantero, instale el manillar, instale los
fijadores de nuevo y bloquéelos con tornillos.
Conecte la interfaz del cable del faro al puerto de conexión correspondiente en el
extremo frontal del marco y luego oculte la interfaz dentro del marco.
1. Instalación del manillar
2. Conexión del cable del faro

17
Instale la parte delantera del marco y alinéelo desde el orificio superior hasta el
orificio inferior. El tornillo largo pasa por la posición desde la cara superior.
Coloque la arandela y la tuerca debajo de ella y apriételas con una llave.
3. Instalación de la estructura frontal

18
Retire el eje delantero, las tuercas y las arandelas del conjunto del marco
delantero, instale la rueda delantera en el cubo delantero, alinee los orificios y
luego insértela en el eje delantero. Instale las arandelas y las tuercas en ambos
lados y apriete con la llave.
Primero quite los tornillos preinstalados en la parte inferior del marco y el pedal,
luego instale el pedal, luego instale el conjunto de ruedas auxiliares y fíjelo con
tornillos.
4. Instalación de la rueda frontal
5. Instalación del pedal y las ruedas auxiliares

19
Distinga la luz trasera decorativa izquierda y derecha e instálela en los orificios
correspondientes del marco. Retire los tornillos preinstalados en la posición fija de la
cubierta del motor, instálela y luego fíjela con tornillos.
Abra la tapa del asiento, conecte la interfaz del cable de alimentación, abra el
interruptor de encendido para verificar si está encendido, luego instale la cubierta
del asiento y apriete los tornillos.
6. Instalación de las luces traseras y la cubierta del motor
7. Conexión de la fuente de alimentación

20
- Este coche debe ser instalado por los adultos.
- Cuando el coche está desarmado, contiene piezas pequeñas y afiladas; manténgalo
alejado de los niños pequeños.
- No lo utilice en el tráfico.
- Este coche no debe ser utilizado por los niños menores de 3 años.
- Debe usar el cinturón de seguridad al utilizar este coche.
- Se requiere la supervisión de los adultos al utilizar este coche.
- La batería debe ser cargada por los adultos. Cargue el coche antes del primer uso.
- Mantenga el embalaje alejado de los niños por motivo de evitar asfixia.
- Solo utilice las piezas proporcionadas por el fabricante.
- Asegúrese de que los niños no jueguen con el cargador.
Paso 1: el orificio de carga está debajo del asiento
Paso 2: Inserte el enchufe del cargador en el orificio del enchufe.
Paso 3: Conecte el cargador a la toma de corriente.
ADVERTENCIA
- No utilice este coche en calles concurridas, carreteras, pendientes o cerca de
desagües.
- No modifique el circuito ni agregue dispositivos eléctricos al coche.
- No utilice el control remoto bajo la lluvia. Mantenga el coche alejado del agua y otros
líquidos con el fin de evitar daños.
- La carga máxima para este coche es de 25 kg: Este coche solo debe ser utilizado por
un/a niño/a a la vez.
- Asegúrese de apagar la alimentación cuando el coche no esté en uso. Retire el
conector de la batería cuando no esté en uso durante largo período de tiempo.
- Antes de utilizarlo y cargarlo, inspeccione el enchufe y otras piezas en busca de
daños.
Nota
Los pasos de carga son los
siguientes:
Atención: El producto debe ser transportado únicamente por adultos. El producto
no debe utilizarse mientras se carga.
