HOMCOM 370-097 User manual

ASSEMBLY INSTRUCTION
IN221000272V01_UK
370-097
1.Suitable age for 18-36 Months.
2.Maximum user weight: 20KGS.
3.Adult assembly required.
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY

Specification
Item
Maximum weight
Size
Available ages
Specifications
20KGS
73*39*48CM
Children at 18-36 months
WARNING:
(1) This kind of product is fit for the children aged 18-36 month old and
maximum load under 20kg maximum load under 20kg.
(2) WARNING-Never leave the child unattended.
(3) Prevent access to stairs, steps and uneven surface.
(4) Remove hot liquids, electrical flexes and other potential hazards
from reach.
(5) Prevent collisions with glass in doors, windows and furniture.
(6) Instruction for routine maintenance and cleaning or washing.
(7) Before using, this product will be inspected and assembled by the
adult.
(1) Installing and changing batteries should be
fulfilled by adults.
(2) Install the batteries refer to the picture (1) of
the parts: the installation of AA (1.5V)
batteries: open the cover, install the batteries
correctly according to the marks of the positive
and the negative electrodes , finally put on the
cover and fasten the cover.
(3) The unchangeable batteries must not be changed and do not mix
the different types of the batteries( or the new and the old) to use
together.
(4) Take out the used-up batteries and avoid short circuit.
The notices of installing and changing batteries

PART
LIST
M10
A8B1
M5*30 M8
C4
M5
D1
1.Body 4.Front mud plate
2.Windshield
3.Fork
5.Handlebar
6.A rear axle
7.Front wheel
8.Rear wheel *2
Note:
All screws, nuts and small plastic parts are pre-installed in
the corresponding position, please follow the steps to
remove before you install the product.

Gasket
Gasket
Rear wheel
Nut
Step 2 Install front wheel
As shown in the arrow,insert the shaft into the front fork, pass through the gasket X2, the front
wheel, the gasket X2 and the nut (as shown in the figure), and tighten the nut clockwise
Nut
Gasket Gasket
Nut
Gasket
Gasket
Installing the other side wheel is the same as step 1.
INSTALLATION STEPS
Step 1 Install the rear wheel
A rear axle
Gasket Gasket
Rear wheel
Nut
As shown in the arrow, insert the shaft frame into
the car body, pass the gasket, rear wheel, gasket
and nut (as shown in Figure 1) through the axle, and
tighten the nut clockwise (as shown in Figure 2).

Step 4 Install the
Fork
Insert the front fork into the car body and press tight
Step 3 Install mudguard
Insert Front mud plate onto the fork

Step 7 Install the battery
box and take off the cover;
Use three AAA 1.5V cells, please install the batteries properly.
Warning:
Do not mix to use the batteries, such as used, unused, different type, etc.
Keep the child away from the battery.
Loosen the 4x10 mounting screws and open the seat cushion to see the
battery box. Add the dry battery and you can use the music function.
Step 5 Install the
Handlerbar
Step 6 Install the
Windshield
Stuck the windshield on Body
fix thehandle bar&tap sleeve
（1X(5X30)Screw&1XM5 Nut）
