Home Decorators Collection RIMGATE 56048 User manual

Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday.
1-800-986-3460
HOMEDEPOT.COM/HOMEDECORATORS
THANK YOU
We appreciate the trust and condence you have placed in Home Decorators Collection through the purchase of this ceiling fan. We strive
to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Home Decorators Collection!
Item #1007 532 479
Model #56048
UL Model #EF200T(B)-52
USE AND CARE GUIDE
RIMGATE 52-INCH CEILING FAN
To view an instructional video on how to install this product:
1. Go to www.homedepot.com and enter either the Item or Model number, found in the top
right corner of the cover of this instruction manual, in the search eld.
2. Click on your product from the list of search results and click on the video link in the
“Product Overview” section.

2
Table of Contents ................................................................2
Safety Information...............................................................2
Warranty ............................................................................... 3
Pre-Installation ....................................................................3
Installation............................................................................6
Assembly..............................................................................7
Operation ...........................................................................14
Care and Cleaning.............................................................15
Troubleshooting.................................................................15
1. To reduce the risk of electric shock, ensure the electricity has been
turned off at the circuit breaker or fuse box before you begin.
2. All wiring must be in accordance with the National Electrical Code ANSI/
NFPA 70 and local electrical codes. Electrical installation should be
performed by a qualified licensed electrician.
3. The outlet box and support structure must be securely mounted and
capable of reliably supporting 35 lb (15.9 kg). Use only UL Listed outlet
boxes marked “Acceptable for Fan Support of 35 lb (15.9 kg) or less”.
4. The fan must be mounted with a minimum of 7 ft (2.1 m) clearance from
the trailing edge of the blades to the oor.
5. Do not operate the reversing switch while the fan blades are in motion.
You must turn the fan off and stop the blades before you reverse the
blade direction.
6. Do not place objects in the path of the blades.
7. To avoid personal injury or damage to the fan and other items, use
caution when working around or cleaning the fan.
8. Electrical diagrams are for reference only. Light kits that are not packed
with the fan must be UL Listed and marked suitable for use with the
model fan you are installing. Switches must be UL General Use Switches.
Refer to the instructions packaged with the light kits and switches for
proper assembly.
9. After making electrical connections, spliced conductors should be turned
upward and pushed carefully up into the outlet box. The wires should be
spread apart with the grounded conductor and the equipment-grounding
conductor on one side of the outlet box.
10. All setscrews must be checked and retightened where necessary
before installation.
WARNING: To reduce the risk of personal injury, do
not bend the blade brackets (also referred to as
anges) during assembly or after installation. Do
not insert objects in the path of the blades.
WARNING: To avoid possible electrical shock, turn
the electricity off at the main fuse box before
wiring. If you feel you do not have enough electrical
wiring knowledge or experience, contact a licensed
electrician.
WARNING: Electrical diagrams are for reference
only. Optional use of any light kit shall be UL Listed
and marked suitable for use with this fan.
Safety Information
Table of Contents
CAUTION: To reduce the risk of personal injury, use
only the screws provided with the outlet box.
READ AND SAVE THESE INSTRUCTIONS.
CAUTION: Changes or modications not expressly
approved by the party responsible for compliance
could void the user’s authority to operate the
equipment.
CAUTION: Do NOT use this fan with a dimmer
switch or wall control. Using a dimmer switch or
wall control will damage the fan.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
--Consult the dealer or an experienced radio/TV technician for help.
CAUTION:
Any changes or modications not expressly approved by the grantee of this device could void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
WARNING: To reduce the risk of re or electric
shock, do not use this fan with any other solid-
state speed control device.

3HOMEDEPOT.COM/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
Pre-Installation
Warranty
SPECIFICATIONS
TOOLS REQUIRED
NOTE: These are approximate measures. They do not
include the amps and wattage used by the light kit.
Phillips
screwdriver
Flat blade
screwdriver
Adjustable
wrench
Electrical
tape
Wire
cutter
Step ladder
Size Speed Volts Watts Amps RPM CFM Net
Weight
Gross
Weight Cubic Feet
52 in.
Low
Medium
High
120
16
32.66
60.39
0.27
0.38
0.5
75
110
150
2119.44
3120.3
4273.94
18.96 lb
(8.6 kg)
25.79 lb
(11.7 kg) 2.69 cu.ft.
The supplier warrants the fan motor to be free from defects in workmanship and material present at time of shipment from the factory for a
lifetime after the date of purchase by the original purchaser. The supplier warrants that the light kit, excluding any glass, to be free from defects in
workmanship and material at the time of shipment from the factory for a period of three years after the date of purchase by the original purchaser.
The supplier also warrants that other fan parts, excluding any glass or acrylic blades, to be free from defects in workmanship and material at the
time of shipment from the factory for a period of one year after the date of purchase by the original purchaser. We agree to correct such defects
without charge or at our option replace with a comparable or superior model if the product is returned. To obtain warranty service, you must present
a copy of the receipt as proof of purchase. All costs of removing and reinstalling the product are your responsibility. Damage to any part, such as
by accident, misuse, improper installation, or by afxing any accessories, is not covered by this warranty. Because of varying climatic conditions
this warranty does not cover any changes in brass nish, including rusting, pitting, corroding, tarnishing, or peeling. Brass nishes of this type give
their longest useful life when protected from varying weather conditions. A certain amount of “wobble” is normal and should not be considered
a defect. Servicing performed by unauthorized persons shall render the warranty invalid. There is no other express warranty. Home Decorators
Collection hereby disclaims any and all warranties, including but not limited to those of merchantability and tness for a particular purpose to the
extent permitted by law. The duration of any implied warranty, which cannot be disclaimed, is limited to the time period as specied in the express
warranty. Some states do not allow a limitation on how long an implied warranty lasts, so the above limitation may not apply to you. The retailer
shall not be liable for incidental, consequential, or special damages arising out of or in connection with product use or performance except as may
otherwise be accorded by law. Some states do not allow the exclusion of incidental or consequential damages, so the above exclusion or limitation
may not apply to you. This warranty gives specic legal rights, and you may also have other rights that vary from state to state. This warranty
supersedes all prior warranties. Shipping costs for any return of product as part of a claim on the warranty must be paid by the customer.
Contact the Customer Service Team at 1-800-986-3460 or visit www.HomeDepot.com/homedecorators.

4
Pre-Installation (continued)
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
Part Description Quantity
AA Extension leadwire 1
BB Wire connecting nut 3
CC Wall mount screws 2
DD Wall anchor 2
CCBB DDAA

5HOMEDEPOT.COM/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
Pre-Installation (continued)
PACKAGE CONTENTS
Part Description Quantity
A Slide-on mounting bracket
(inside canopy)
1
B Canopy 1
C Canopy bottom cover 1
D Ball/downrod assembly 1
E Decorative motor collar cover 1
F Fan motor assembly 1
G Light kit tter assembly 1
H LED bulb 2
I Glass bowl 1
Part Description Quantity
J Blade arm 5
K Blade 5
L Remote control 1
M Receiver 1
N Wall cradle 1
O Battery 1
IMPORTANT: This product and/or components are governed by
one or more of the following U.S. Patents:
5,947,436; 5,988,580; 6,010,110; 6,046,416; 6,210,117
and other patents pending.
A
B
C
D
E
F
G
H
I
J
K
L
M
O
N

6
Installation
MOUNTING OPTIONS
WARNING: To reduce the risk of re, electric shock,
or personal injury, mount the fan to an outlet box
marked “Acceptable for fan support of 35 lb (15.9 kg)
or less” and use the screws provided with the outlet
box. An outlet box commonly used for the support
of lighting xtures may not be acceptable for fan
support and may need to be replaced. If in doubt,
consult a qualied electrician.
If your ceiling fan does not have an existing UL Listed mounting
box, then install one using the following instructions:
□Disconnect the power by removing the fuses or turning off
the circuit breakers.
□Secure the outlet box directly to the building structure.
Use the appropriate fasteners and materials. The outlet box
and its bracing must be able to fully support the weight of
the moving fan (at least 35 lb). Do not use a plastic outlet
box.
The illustrations below show three different ways to mount the
outlet box.
If the canopy (B) touches the ball/downrod assembly (D), then remove
the decorative canopy bottom cover (C) and turn the canopy (B) 180°
before attaching the canopy (B) to the mounting plate.
To hang your fan where there is an existing xture but no ceiling joist,
you may need an installation hanger bar as shown above
(available at any Home Depot store).
NOTE: You may need a longer ball/downrod to maintain
proper blade clearance when installing on a steep, sloped
ceiling. The maximum angle allowable is 20° away from
horizontal.
Outlet Box
Outlet Box
Recessed
Outlet
Box
Provide Strong
Support
Ceiling
Mounting
Plate
Outlet Box
Hanger Bar

7HOMEDEPOT.COM/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
Assembly - Standard Ceiling Mount
Routing the wiresPreparation for standard mounting 21
□Remove the canopy bottom cover (C) from the canopy (B) by
turning the bottom cover counterclockwise until it unlocks.
□Loosen the two canopy screws (PP) located in the bottom of the
mounting bracket (A), and turn the canopy counterclockwise to
remove the mounting bracket (A) from the canopy (B).
Assembling the fan
3
A
B
PP
C
D
B
C
E
F
II
□Loosen, but do not remove, the setscrew (II) on the collar on
top of the fan motor assembly (F).
□Install the ball/downrod (D) by inserting it into the motor collar,
and turning it clockwise until it is tight.
□Re-tighten the setscrew (II) on the collar on top of the fan
motor assembly (F).
3
NOTE: This fan is equipped with a safety tab. Should
the setscrew (II) ever become loose while the fan is
running in reverse, the safety tab will engage and stop
the fan from falling.
CAUTION: To ensure wobble-free operation and to
avoid damage to the fan, the ball/downrod (D) and the
setscrew (II) must be completely tightened.
□Route the wires exiting the top of the fan motor assembly (F)
through the decorative motor collar cover (E) and then the
center of the canopy bottom cover (C).
□Make sure the opening of the canopy (B) is on top and insert
the ball/downrod assembly (D) through the canopy (B).
□Route the wires exiting the top of the fan motor assembly (F)
through the ball/downrod assembly (D) as shown.
B
D
E
C
F

8
Assembly - Hanging the Fan
Attaching the fan to the electrical
box
Hanging the fan
□Pass the 120-Volt supply wires through the center hole in the
slide-on mounting bracket (A).
□Install the ceiling slide-on mounting bracket (A) on the outlet
box by sliding the slide-on mounting bracket (A) over the two
screws (JJ) provided with the outlet box. If necessary, use leveling
washers (not included) between the slide-on mounting bracket
(A) and the outlet box. Note that the at side of the slide-on
mounting bracket (A) is toward the outlet box.
□Securely tighten the two outlet box screws (JJ).
□Carefully lift the fan motor assembly (F ) up to the slide-on
mounting bracket (A).
□Seat the hanger ball portion of the ball/downrod assembly (D)
in the mounting bracket socket. Ensure that the tab on the
slide-on mounting bracket (A) socket is properly seated in the
groove in the hanger ball.
1 2
WARNING: To reduce the risk of re, electric shock, or other
personal injury, mount the fan to an outlet box marked
“Acceptable for fan support of 35 lb (15.9 kg) or less” and
use the mounting screws provided with the outlet box.
NOTE: The mounting bracket (A) is designed to slide into place
on an outlet box with the outlet box screws (JJ).
WARNING: When using the standard ball/downrod mounting,
the tab in the ring at the bottom of the mounting bracket
must rest in the groove of the hanger ball. Failure to properly
seat the tab in the groove may result in fan wobble issues
and potentially damage the wiring.
JJ
A
JJ
A
D
F
B
C
E

9HOMEDEPOT.COM/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
Assembly - Hanging the Fan (continued)
4Installing the receiver
□Position the house supply wires (AAA) to one side of the slide-
on mounting bracket (A). Position the fan wires (BBB) to the
opposite side.
□Insert the narrow end of the receiver (M) (as shown, at side
towards the ceiling) into the slide-on mounting bracket (A) until
it rests on top of the ball/downrod assembly (D).
WARNING: To reduce the risk of re or electric shock,
remember to disconnect power. The electrical wiring must
meet all local and national electrical code requirements.
The electrical source and fan must be 110/120 volt, 60Hz.
Do not use this product in conjunction with any variable wall
control. Incorrect wire connection can damage this receiver.
CAUTION: Do not immerse in water. Do not pull on or cut the
receiver leads shorter. Do not drop or bump the unit.
Setting the code on the
remote control and receiver
3
NOTE: The frequencies on your receiver and hand unit have
been preset at the factory. Before installing the receiver,
make sure the dip switches on the receiver and hand unit
are set to the same positions. The dip switches on the hand
unit are located inside the battery compartment. If you have
two of the same model fans in your home, please follow the
steps below to control each fan independently.
NOTE: The switch marked “O/D” controls the dimming
function of the lights. If you are using non-dimmable bulbs,
use a ballpoint pen or small screwdriver to set the switch
to “O” to disable the dimming function. If you are using
dimmable bulbs, set the switch to “D” to enable the dimming
function.
NOTE: The battery will weaken with age and should be
replaced before leaking takes place, as battery leakage
damages the hand unit. Dispose of the used battery properly
and keep the battery out of the reach of children.
□Remove the remote control (L) battery cover by pressing
rmly on the arrow and sliding the cover off.
□Slide the dip switches (ZZ) to your choice of either up or
down. The factory setting is up.
□Slide the dip switches (ZZ) on the receiver (M) to the same
position as set on the remote control (L).
□Install the 23A 12V battery (O).
□Replace the battery cover on the remote control (L).
□Insert the silicone rubber stopper (OO) into the hole on the
receiver (M) to cover the dip switches.
L
M
ZZ
1 2 3 4
ON
OO
1 2 34
ON 0
1 2 34
ON
D
D 0
D
A
M
M
AAA
BBB
C
B

10
Assembly - Hanging the Fan (continued)
6Wiring the fan to the receiver
□If using the 4.5 in. ball/downrod assembly (D) provided,
wire the receiver to the fan wires by connecting the molded
adaptor plug from the receiver (M) with the molded adaptor
of the fan motor assembly (F) together.
□If you wish to use longer ball/downrod, you can use the
extension lead wire (42 in.) (AA) provided by connecting the
molded adaptor together.
NOTE: The fan comes with 12 in. lead wires for use with
the provided 4.5 in. ball/downrod assembly (D), if you wish
to use longer ball/downrod, you can use the extension lead
wire (42 in.) (AA) provided.
5Wiring the receiver to the
household wiring
IMPORTANT: Use the wire connecting nuts (BB) supplied with
your fan. Secure the connectors with electrical tape and ensure
there are no loose strands or connections.
WARNING: Each wire nut supplied with this fan is designed to
accept up to one 12-gauge house wire and two wires from the
fan. If you have larger than 12-gauge house wiring or more
than one house wire to connect to the fan wiring, consult an
electrician for the proper size wire nuts to use.
□Spread the wires apart so that the green and white wires
are on one side of the outlet box and the black wire is on the
other side.
□Connect the green fan wires to the household ground wire
(this may be a green or bare wire) using a wire connecting
nut (BB).
□Connect the receiver (M) black wire to the household black
(hot) wire using a wire connecting nut (BB).
□Connect the receiver (M) white wire to the household white
wire (neutral) using a wire connecting nut (BB).
□Secure each wire connecting nut using electrical tape.
WARNING: To avoid possible electrical shock, turn the
electricity off at the main fuse box before wiring. If you
feel you do not have enough electrical wiring knowledge or
experience, contact a licensed electrician.
Black
Black
Green (or Bare)
Green
Outlet Box
Receiver
Antenna
White
Receiver (M)
BB (x3)
F
D
M

11 HOMEDEPOT.COM/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
Assembly - Attaching the Blades
Attaching the blade arm
1□Fasten the blade arm (J) to the motor (F) by inserting the
alignment post into the slot on the bottom of the fan motor
assembly (F) and tightening the motor screws (GG) that are
pre-assembled to the blade arm (J).
□Repeat for the remaining four blade arms (J).
Attaching the canopy
□Align the locking slots of the canopy (B) with the two
screws (PP) and alignment post (EE) in the mounting
bracket (A).
□Push up the canopy (B) and turn clockwise until the
alignment post (EE) engages to the round hole and the
screws (PP) engage to the key slots.
□Firmly tighten the two mounting screws (PP).
□Align the oval shape on the canopy (B) with canopy bottom
cover (C),
□Push up the canopy bottom cover (C) until the screw heads
engage to the slots on the canopy bottom cover (C) so that
the canopy bottom cover (C) can be attached to the bottom
of the canopy (B) properly.
7
Assembly - Hanging the Fan (continued)
A
PP
B
EE
C
EE
J
GG
F

12
Assembly - Attaching the Light Kit
Attaching the light kit
1
□Remove and save the three screws (HH) from the light kit
tter assembly (G).
□Connect the wires exiting the bottom of the motor assembly (F)
by connecting the molded adaptor plugs together (blue to blue,
white to white).
□Slide the light kit tter assembly (G) into the switch housing and
secure it using the three screws (HH) that were removed in the
rst step.
CAUTION: To reduce the risk of electric shock, disconnect
the electrical supply circuit to the fan before installing.
Assembly - Attaching the Blades (continued)
Attaching the fan blades
2
□Mount the fan blade (K) to the blade arm (J) by aligning the
three key-slot holes in the blade (K) with the three posts on the
top of the blade arms (J).
□Hold the blade (K) close to the blade arm (J) and press the
blade (K) down rmly. Ensure the key-slot holes are properly
seated on the blade arm posts.
□While still holding the blade (K) down, rmly slide the blade (K)
away from the arm (J) side until the blade (K) engages in the
locking mechanism.
□Make sure the locking mechanism at the rear of the blade arm
(J) springs upward and butts against the edge of the blade (K)
indicating a secure connection.
□Visually inspect the top of the blade arm (J) to ensure the
locking mechanism is securely in place.
□Repeat for the remaining blades (K).
NOTE: This fan features Quick InstallTM blades for fast and easy
blade installation.
J
K
GHH
F

13 HOMEDEPOT.COM/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
Assembly - Attaching the Wall Cradle (Optional)
Installing the glass bowl
2
WARNING: Allow the glass bowl (I) to cool completely
before removing.
CAUTION: Make sure the power is off before attaching
or removing the glass bowl (I).
Mounting the remote control holder
□Slide the screw cover plate up to remove it from the wall
cradle (N).
□Position the wall cradle (N) in the desired position and attach
it to the wall using the included wall mount screws (CC).
□Slide the screw cover plate back onto the wall cradle (N) to
conceal the screws.
NOTE:Screw wall anchors (DD) are included for extra
support. The included screws are designed to screw easily
into the wall. If you would like a more permanent or secure
hold, install the wall anchors (DD) prior to attaching the
wall cradle (N) to the wall.
Sc
rew cover plate
NCC
Assembly - Attaching the Light Kit (continued)
I
II
H
G
QQ
□With power off, install the light bulbs (H) by screwing them
into the light bulb sockets.
□Loosen, but do not remove, the three screws (II) from the
light kit tter assembly (G).
□Carefully slide the glass bowl (I) completely into the
outer rim of the light kit tter assembly (G) so that the
ridge (QQ) of the glass bowl (I) aligns with the screw
holes in the outer rim.
□Secure the glass bowl (I) by nger tightening the three
screws (II) until they touch the glass shade (I). Do not
overtighten the screws.

14
Operating Your Fan
Your fan is equipped with a remote control to operate the fan speed
and lights of your new ceiling fan.
The appropriate speed settings for warm or cool weather depends on
factors such as the room size, ceiling height, and number of fans.
The fan is shipped from the factory with the reversing switch
positioned to circulate air downward. If airow is desired in the
opposite direction, turn your fan off and wait for the blades to stop
turning, then slide the reversing switch (XX) (located in switch cup) to
the opposite position, and turn the fan on again. The fan blades will
turn in the opposite direction and reverse airow.
Warm weather - (Forward) A downward airow creates a cooling effect.
This allows you to set your air conditioner on a warmer setting without
affecting your comfort.
Cool weather - (Reverse) An upward airow moves warm air off of the
ceiling. This allows you to set your heating unit on a lower setting
without affecting your comfort.
A. Warm weather
B. Cool weather
NOTE: Wait for the fan to stop before reversing the direction of
the blade rotation.
USING THE REMOTE CONTROL
Power ON/OFF
□Press and release the button to turn the fan and light on or off.
□Press and hold the button for 5 seconds to use the “walk away
time delay”; this will activate the light for 30 seconds.
Fan Speed - LEDs on the fan speed button will illuminate to the
corresponding speed.
- Press and release 1 time - turns the fan on high speed.
- Press and release 2 times - turns the fan on medium speed.
- Press and release 3 times - turns the fan on low speed.
Light ON/OFF
□Press and release the button to turn the light on or off.
□Press and hold the button to activate the dimmer function (as
long as you have NOT previously set O/D dip switch in your remote
to the “ON” position).
L
Power ON/OFF
Fan speed
Light ON/OFF
& dimmer function
XX
XX

15 HOMEDEPOT.COM/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
Troubleshooting
Problem Solution
The fan will not start. □Check the main and branch circuit fuses or breakers.
□Check to make sure the wall switch is in the on position if applicable.
□Check the line wire connections to the fan and switch wire connections in the switch housing.
□Check the battery in the transmitter.
□Ensure you are in the normal range of 10-20 feet.
The fan is noisy. □Ensure all motor housing screws are snug.
□Ensure the screws that attach the fan blade arm to the motor hub are tight.
□Ensure the wire nut connections are not rattling against each other or the interior wall of the switch housing.
□Allow a 24-hour “breaking in” period. Most noises associated with a new fan disappear during this time.
□If you are using the ceiling fan light kit, ensure the screws securing the glassware are tight. Check that the light
bulbs are also secure.
□Ensure the canopy is a short distance from the ceiling. It should not touch the ceiling.
The fan wobbles. □Check that all blade and blade arm screws are secure.
□Most fan wobble problems are caused when blade levels are unequal. Check this level by selecting a point on
the ceiling above the tip of one of the blades. Measure from a point on the center of each blade to the point
on the ceiling. Rotate the fan until the next blade is positioned for measurement. Repeat for each blade. Any
measurement deviation should be within 1/8 in. Run the fan for ten minutes. If the fan continues to wobble
please contact Customer Service and a balancing kit will be sent to you at no charge.
□Because of the fan’s natural movement, some connections may become loose. Check the support connections, brackets, and blade
attachments twice a year. Make sure they are secure. It is not necessary to remove the fan from the ceiling.
□Clean your fan periodically to help maintain its new appearance over the years. Do not use water when cleaning, as this could damage
the motor, or the wood, or possibly cause an electrical shock. Use only a soft brush or lint-free cloth to avoid scratching the nish. The
plating is sealed with a lacquer to minimize discoloration or tarnishing.
□You can apply a light coat of furniture polish to the wood for additional protection and enhanced beauty. Cover small scratches with a
light application of shoe polish.
□You do not need to oil your fan. The motor has permanently-lubricated sealed ball bearings.
WARNING: Make sure the power is off before cleaning
your fan.
Care and Cleaning

Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday.
1-800-986-3460
HOMEDEPOT.COM/HOMEDECORATORS
Retain this manual for future use.

GUÍA DE USO Y MANTENIMIENTO
VENTILADOR DE TECHO RIMGATE, DE 1.32 M
Artículo núm. 1007 532 479
Modelo núm. 56048
Modelo núm. 5EF200T(B)-52
aprobado por UL
¿Preguntas, problemas, piezas faltantes? Antes de devolver a la tienda,
llama al servicio al cliente de Home Decorators Collection,
de lunes a viernes, entre 8:00 a.m. y 7:00 p.m. (hora del Este), y los sábados de 9:00 a.m. a
6:00 p.m. (hora del Este).
1-800-986-3460
HOMEDEPOT.COM/HOMEDECORATORS
GRACIAS
Apreciamos la plena conanza depositada en Home Decorators Collection al comprar este ventilador de techo. Nos esforzamos en crear
continuamente productos de calidad diseñados para mejoras del hogar. Visítanos por Internet para ver nuestra línea completa de productos
disponibles a n de satisfacer la necesidades de mejoras de tu hogar. ¡Gracias por elegir Home Decorators Collection!
Para ver un video instructivo sobre cómo instalar este producto:
1. Visita www.homedepot.com e ingresa en el campo de búsqueda el número del modelo o
artículo, que aparece en la esquina superior derecha de la portada de este manual de
instrucciones.
2. Haz clic sobre tu producto, en la lista de resultados de la búsqueda, y sobre el enlace de
video en la sección “Product Overview” [Información general del producto].

2
Este equipo fue sometido a prueba y se determinó que cumple con los límites establecidos para un dispositivo digital Clase B según la Parte 15 de las Normas FCC. Estos límites
fueron establecidos para dar protección razonable contra la interferencia dañina en uso residencial. Este equipo genera, consume y puede irradiar energía de radiofrecuencia; si no se
instala y usa de acuerdo con las instrucciones, puede causar interferencia nociva a comunicaciones radiales. Sin embargo, no hay garantía de que no ocurrirá interferencia en cierta
instalación particular. Si este equipo causa interferencia perjudicial a la recepción de radio o televisión, que puede determinarse encendiendo y apagando el equipo, se exhorta al
usuario a tratar de corregir la interferencia mediante una o más de las siguientes medidas:
□Reorientar o reubicar la antena receptora.
□Incrementar la distancia entre el equipo y el receptor.
□Conectar el equipo a un tomacorriente de circuito distinto al que el receptor esté conectado.
□Para obtener ayuda, consulta al distribuidor o algún técnico de radio/TV con experiencia.
PRECAUCIÓN:
Cualquier cambio o modicación no aprobado explícitamente por el beneciario de este dispositivo puede anular la autoridad del usuario para operar este equipo.
Este dispositivo cumple con lo dispuesto en la parte 15 de las normas de la Comisión Federal de Comunicaciones (FCC). El funcionamiento está sujeto a las dos condiciones siguientes:
(1) Es posible que este dispositivo no cause interferencia perjudicial y (2) este dispositivo acepta cualquier interferencia recibida, incluyendo interferencia que podría causar un
funcionamiento no deseado.
ADVERTENCIA: Para reducir el riesgo de incendio
o descarga eléctrica, no uses este ventilador con
ningún dispositivo de estado sólido para control
de velocidad.
Tabla de contenido .............................................................. 2
Información de seguridad...................................................2
Garantía................................................................................3
Preinstalación ......................................................................3
Instalación............................................................................6
Ensamblaje........................................................................... 7
Funcionamiento.................................................................14
Mantenimiento y limpieza.................................................15
Solución de problemas ..................................................... 15
Información de seguridad
Tabla de contenido
LEE Y GUARDA ESTAS INSTRUCCIONES
1. Para disminuir el riesgo de descarga eléctrica, asegúrate de cortar la electricidad
en la caja de disyuntores o de fusibles antes de comenzar.
2. Todo el cableado tiene que cumplir con el Código Nacional de Electricidad ANSI/
NFPA 70 y los códigos eléctricos locales. La instalación eléctrica debe hacerla
un electricista calificado con licencia.
3. La caja eléctrica y estructura de soporte tienen que montarse de forma segura para
poder sostener con conanza 35 lb (15.9 kg). Usa solo cajas eléctricas aprobadas
por UL y marcadas como “Apropiadas para sostener ventiladores de 35 lb (15.9 kg)
o menos”.
4. PRECAUCIÓN: El ventilador debe ir montado con un mínimo de 7 pies (2.1 m) de
separación entre el borde trasero de las aspas y el piso.
5. No usar el interruptor de reversa mientras las aspas del ventilador estén en
movimiento. Tienes que apagar el ventilador y detener las aspas antes de invertir
su dirección de giro.
6. No coloques objetos en la trayectoria de las aspas.
7. Para evitar lesiones personales o daños al ventilador y a otros objetos, ten
cuidado al limpiarlo o al trabajar cerca de él.
8. Los diagramas eléctricos son solo para referencia. Los kits de luces que no
vienen en la caja del ventilador tienen que estar aprobados por UL y marcados
como apropiados para usar con el modelo de ventilador que estás instalando. Los
interruptores deben ser interruptores UL de uso general. Para ensamblar bien,
consulta las instrucciones adjuntas a los kits de luces e interruptores.
9. Después de concluir las conexiones eléctricas, debes voltear los conductores
empalmados hacia arriba y meterlos con cuidado en la caja eléctrica. Los cables
deben estar separados con el cable a tierra y el conductor a tierra del equipo a un
lado de la caja eléctrica.
10. Antes de la instalación, todos los tornillos de fijación tienen que comprobarse
y reajustarse donde sea necesario.
ADVERTENCIA: Para reducir el riesgo de lesiones
personales, no dobles los soportes de las aspas
(también llamados “bridas”) durante ni después de
la instalación. No colocar objetos en la trayectoria
de las aspas.
ADVERTENCIA: Para evitar una posible descarga
eléctrica, desconecta la electricidad en la caja
principal de fusibles antes de realizar el cableado.
En caso de no tener suciente conocimiento o
experiencia sobre cableado eléctrico, contactar a un
electricista certicado.
ADVERTENCIA: Los diagramas eléctricos son solo
para referencia. Cualquier kit de luces opcional
debe estar aprobado por UL y estar marcado como
adecuado para ser usado con este ventilador.
PRECAUCIÓN: Para reducir el riesgo de lesiones
personales, usa sólo los tornillos proporcionados
con la caja eléctrica.
PRECAUCIÓN: NO uses este ventilador con un
interruptor regulador ni con un control de pared.
Usar un interruptor regulador o un control de
pared dañará este ventilador.
PRECAUCIÓN: Los cambios o modicaciones
no aprobados explícitamente por la parte
responsable del cumplimiento normativo pueden
anular la autoridad del usuario para operar este
equipo.

3HOMEDEPOT.COM/HOMEDECORATORS
Para obtener asistencia, llama al 1-800-986-3460
Tamaño Velocidad Voltios Vatios Amperios RPM CFM Peso
Neto
Peso
Bruto
Pies
cúbicos
52 plg.
Baja
Media
Alta
120
15
33
62
0.26
0.38
0.52
75
110
150
2119.44
3120.3
4273.94
18.96 lbs
(8.6 kg)
25.79 lbs
(11.7 kgs)
2.69
pies cubicos
Preinstalación
Garantía
ESPECIFICACIONES
El proveedor garantiza de por vida, a partir de la fecha de adquisición por el comprador original, que el motor del ventilador no presenta defectos de fabricación ni
de materiales al momento del envío desde la fábrica. El proveedor garantiza que el kit de luces, excluyendo cualquier vidrio, no tendrá defectos de fabricación ni de
material en el momento del envío desde la fábrica por un período de tres años después de la fecha de compra por parte del comprador original. El proveedor también
garantiza, por un año a partir de la fecha de adquisición por el comprador original, que todas las demás piezas del ventilador, excepto las aspas de vidrio o acrílicas,
no presentarán ningún defecto de fabricación ni de material al momento del envío desde la fábrica. Si el producto es devuelto, aceptamos reparar sus defectos
sin cargo alguno o, a nuestra discreción, reemplazarlo por modelo similar o superior. Para obtener servicio de garantía tiene que presentar una copia del recibo
como comprobante de compra. Todos los costos de retiro y reinstalación del producto correrán por cuenta del cliente. Los daños a cualquier pieza por accidente,
instalación o uso inadecuado, o por montar cualquier accesorio, no están cubiertos por esta garantía. Puesto que las condiciones climáticas pueden variar, esta
garantía no cubre ningún cambio del acabado en latón, como óxido, perforación, corrosión, manchas o descascaramiento. Este tipo de acabados en latón tiene una
la vida útil prolongada si se lo protege contra las condiciones climáticas cambiantes. Cierta “oscilación” es normal y no debe considerase un defecto. Cualquier
servicio prestado por personal no autorizado invalidará la garantía. No hay ninguna otra garantía expresa. Por este medio Home Depot Decorators Collection queda
exonerado de todas y cada una de las demás garantías en el alcance permitido por la ley incluso, pero sin limitarse a, aquellas de comercialización e idoneidad
para determinado propósito. La duración de cualquier garantía implícita que no pueda exonerarse se limita al plazo especicado en la garantía explícita. Algunos
estados no permiten limitaciones sobre la duración de las garantías implícitas, así que es posible que la limitación anterior no se aplique en su caso. El minorista no
será responsable por daños incidentales, emergentes ni especiales derivados del uso o funcionamiento del producto, excepto en los casos en los que la ley así lo
disponga. Algunos estados no permiten excluir ni limitar daños directos o indirectos, así que es posible que la limitación o exclusión anterior no se aplique en este
caso. Esta garantía le otorga derechos legales especícos y es posible que también goce de otros derechos que varían de un estado a otro. Esta garantía sustituye
a todas las garantías anteriores. Los costos de envío en cualquier devolución de productos como parte de una reclamación tienen que ser pagados por el cliente.
Comunícate con el equipo de servicio al cliente por el 1-800-986-3460 o visite www.HomeDepot.com/homedecorators.
HERRAMIENTAS NECESARIAS
NOTA: Estas medidas son aproximadas. No
incluyen ni el amperaje ni el vataje consumido por el kit de luces.
Destornillador
Phillips
Destornillador
plano
Llave
ajustable
Cinta de
electricista
Cortacables/
pelacables
Escalera de tijera

4
Pieza Descripción Cantidad
AA Cable conductor de extensión 1
BB Tuercas de conexión de cables 3
CC Tornillos de montaje en la pared 2
DD Anclaje para pared 2
CCBB DDAA
Pre-instalación (continuación)
SE INCLUYEN LOS HERRAJES
NOTA: Los herrajes no se muestran en
tamaño real.
