Home Styles 20 09100 001C User manual

Hardware List
Part List
Home Styles Customer Service: www.homestyles-furniture.com,
[e-mail],
888-680-7460, 877-831-0319
Tool(s) required for assembly: Phillips screwdriver
20 09100 001C
Kitchen Cart
IMPORTANT
Carefully remove all the parts from the carton and
place them individually on a soft cloth to prevent
scratches or other damage.
Carefully and strictly follow these assembly instructions
to ensure a completed product as designed.
Do not use power tools above 8 volts to assemble.
Small Hex Wrench
1 pc.
Hex Wrench
1 pc.
M6x35
Head Cap Bolt
14 pcs. (+1 extra)
M3.5x25
Wood Screw (long)
32 pcs. (+1 extra)
M3.5x13
Wood Screw (short)
24 pcs. (+1 extra)
M4x16
Wood Screw
16 pcs. (+1 extra)
Adjustable Pin
8 pcs. (+1 extra)
M4x25
Machine Screw
10 pcs.
Knob
2 pcs.
Caster
2 Locking
2 Non-Locking
4 pcs.
Handle
4 pcs.
20 09100 Top carton is also needed for assembly.
J.
Base
1 pc.
A.
Side Panel
1 pc.
B.
Side Panel
1 pc.
G.
Back Rail
1 pc.
H.
Front Rail
1 pc.
N.
Door
1 pc.
O.
Door
1 pc.
T.
Drawer
3 pcs.
U.
Drawer
1 pc.
Refer to later page(s) of these
instructions for drawer assembly.
M.
Arm
1 pc.
R.
Rack Base
1 pc.
S.
Pipe
3 pcs.
K.
Shelf
2 pcs.
P.
Rack Side
1 pc.
Q.
Rack Side
1 pc.
L.
Arm Handle
2 pcs.
C.
Middle Panel
1 pc.
D.
Middle Panel
1 pc.
E.
Back Panel
3 pcs.
I.
Front Rail
3 pcs.
F.
Back Upright
2 pcs.
Wood Plug
10 pcs. (+1 extra)

Assembly Instructions 2/8
IMPORTANT
Use a soft cloth between these parts and the floor.
Do not use power tools above 8 volts to assemble.
Do not tighten all the bolts until each part is properly assembled.
Keep Hex Wrench as the bolts may need to be tightened in the future.
I
I
I
EEE
STEP 2
Attach lower Front Rail (I) to unit.
Attach middle Front Rail (I) to unit.
Attach upper Front Rail (I) to unit.
Slide Back Panels (E) into position.
J
A
CD
Head Cap Bolt
F
F
STEP 1
Attach Side Panel (A) to Base (J) with
Head Cap Bolts. (See Figure 1)
Attach Back Upright (F) to
Middle Panel (C), then attach
to unit.
Attach Back Upright (F) to
Middle Panel (D), then attach
to unit.
Note: Assemble so Arrow labels
on Back Uprights (F) point
to each other.
Arrow labels point to each other.
Figure 1

Assembly Instructions 3/8
Arrow label at front
Locking Caster
Non-Locking Caster
Wood Screw
STEP 4
Turn unit upside down.
Attach Casters to unit with
Wood Screws into pre-drilled holes,
with Locking Casters at front.
(See Figure 2)
Note: Arrow label indicates front of unit.
Figure 2
STEP 3
Attach Back Rail (G) and Front Rail (H)
to unit with Head Cap Bolts.
Note: Arrow label indicates
front of Back Rail (G).
Attach Side Panel (B) to
unit with Head Cap Bolts.
Arrow label at front
G
H
Head Cap Bolt
B

Assembly Instructions 4/8
Figure 4
Figure 3
M
L
L
Head Cap Bolt
Q
P
S
R
STEP 5
Turn unit over to its’ upright position.
Attach Rack Side (P) to unit with Head Cap Bolt. (See Figure 3)
Slide Rack Base (R) and Pipes (S) into Rack Side (P).
Attach Rack Side (Q) to unit with Head Cap Bolt.
Attach Arm Handles (L) to unit with Head Cap Bolts. (See Figure 4)
Slide Arm (M) into position.

Assembly Instructions 5/8
Figure 6 Figure 7
Figure 5
V
V
K
K
N
O
Head Cap Bolt (middle)
Machine Screw
Knob
Adjustable Pin
STEP 6
Insert Adjustable Pins into side panels and middle panels at desired level.
(See Figure 5)
Place Shelves (K) into position.
Attach Doors (N) and (O) by sliding door hinges into side panel hinges.
(See Figure 6)
Attach Knobs to Doors (N) and (O) with Machine Screws.
(See Figure 7)
Attach Supports (V) to unit with Head Cap Bolts (middle).

Part List
Assembly Instructions 6/8
STEP 9
Attach Handle with Machine Screws.
T1.
Drawer Front
3 pcs.
T2.
Drawer Back
3 pcs.
T5.
Drawer Bottom
3 pcs.
Handle
Machine Screw
T5
Wood Screw (short)
Drawer (T)
T3.
Drawer Side
3 pcs.
T4.
Drawer Side
3 pcs.
STEP 7
Attach Drawer Front (T1) and Drawer
Back (T2) to Drawer Side (T3)
with Wood Screws (long).
Attach Drawer Side (T4) to unit
with Wood Screws (long).
Bottom
T1
T2
T3
T4
Roller at back
Wood Screw (long)
STEP 8
Slide Drawer Bottom (T5) into groove.
Attach Drawer Bottom (T5) to
unit with Wood Screws (short).

Part List
Assembly Instructions 7/8
STEP 12
Attach Handle with Machine Screws.
U1.
Drawer Front
1 pc.
U2.
Drawer Back
1 pc.
U5.
Drawer Bottom
1 pc.
STEP 10
Attach Drawer Front (U1) and Drawer
Back (U2) to Drawer Side (U3)
with Wood Screws (long).
Attach Drawer Side (U4) to unit
with Wood Screws (long).
Handle
Machine Screw
U5
Wood Screw (short)
Drawer (U)
Roller at back
U1
U2
U3
U4
Bottom
Wood Screw (long)
STEP 11
Slide Drawer Bottom (U5) into groove.
Attach Drawer Bottom (U5) to
unit with Wood Screws (short).
U3.
Drawer Side
1 pc.
U4.
Drawer Side
1 pc.

Assembly Instructions 8/8
STEP 13
Attach Top (W) to unit
with Head Cap Bolts
(middle).
Slide Drawers (T)
and (U) into position.
W
T
T
T
UHead Cap Bolt (middle)
STEP 14
Cover all holes with Wood Plugs.
(See Figure 8)
Figure 8
Wood Plug

NEVER
use glass cleaners on
finished furniture. Ammonia
chemically attacks the finish.
allow liquids to remain on furniture.
Absorption causes parts to warp
and split and finishes to delaminate.
NEVER
CARE INSTRUCTIONS
Do not use rubber
based placemats.
PREVENT
DISCOLORING
Do not use commercial
waxes and polishes.
PREVENT
YELLOWING
Do not place hot
objects on surface.
PREVENT
FINISH DAMAGE
Do not write
directly on surface.
PREVENT
MARKING
Do not use power tools
above 8 volts to assemble.
PREVENT
CRACKING
Do not place
in direct sunlight.
PREVENT
FADING
with a soft cloth moistened
in lukewarm soap and water.
Buff with a dry clean cloth.
CLEAN
Home Styles will provide replacements free of charge for missing or damaged hardware or parts within 30 days of
purchase. Digital images of the defective parts may be required. If the product was not purchased from an authorized
retail affiliate, Home Styles is under no obligation to provide replacement parts. Parts are not available for fully assembled
items nor are parts available for sale. Replacements for missing or damaged hardware or parts may be requested at:
www.homestyles-furniture.com/customer-service/replacement-parts
Home Styles Customer Service: www.homestyles-furniture.com,
[e-mail], 888-680-7460, 877-831-0319
