Home Styles 20 05177 080C User manual

Hardware List
Part List
Home Styles Customer Service: www.homestyles-furniture.com,
[email protected], 888-680-7460, 877-831-0319
20 05177 080C
Side Chair
IMPORTANT
A.
Seat
1 pc.
Hex Wrench
1 pc.
Small Hex Wrench
1 pc.
M6x40
Head Cap Bolt (short)
3 pcs. (+1 extra)
Carefully remove all the parts from the carton and
place them individually on a soft cloth to prevent
scratches or other damage.
Carefully and strictly follow these assembly instructions
to ensure a completed product as designed.
Do not use power tools above 8 volts to assemble.
B.
Leg
1 pc.
C.
Leg
1 pc.
D.
Back Frame
1 pc.
Spring Washer
11 pcs. (+1 extra)
Flat Washer
11 pcs. (+1 extra)
M6x50
Head Cap Bolt
4 pcs. (+1 extra)
M6x70
Head Cap Bolt (long)
4 pcs. (+1 extra)

Assembly Instructions 2/2
STEP 1
Attach Legs (B) and (C) to Seat (A) with
Flat Washers, Spring Washers and
Head Cap Bolts, tightening bolts only
halfway. (See Figure 1)
Figure 1
STEP 2
Attach Back Frame (D) to unit with
Flat Washers, Spring Washers,
Head Cap Bolts (short) and
Head Cap Bolts (long), tightening
bolts only halfway.
(See Figures 2 and 3)
Tighten all Bolts used in Steps 1 and 2.
Head Cap Bolt (long)
Spring Washer
Flat Washer
Head Cap Bolt (short)
Spring Washer
Flat Washer
DFigure 2 Figure 3
Head Cap Bolt
Spring Washer
Flat Washer
A
B
C
IMPORTANT
Use a soft cloth between these parts and the floor.
Do not use power tools above 8 volts to assemble.
Do not tighten all the bolts until each part is properly assembled.
Keep Hex Wrench as the bolts may need to be tightened in the future.

NEVER
use glass cleaners on
finished furniture. Ammonia
chemically attacks the finish.
allow liquids to remain on furniture.
Absorption causes parts to warp
and split and finishes to delaminate.
NEVER
CARE INSTRUCTIONS
Do not use rubber
based placemats.
PREVENT
DISCOLORING
Do not use commercial
waxes and polishes.
PREVENT
YELLOWING
Do not place hot
objects on surface.
PREVENT
FINISH DAMAGE
Do not write
directly on surface.
PREVENT
MARKING
Do not use power tools
above 8 volts to assemble.
PREVENT
CRACKING
Do not place
in direct sunlight.
PREVENT
FADING
with a soft cloth moistened
in lukewarm soap and water.
Buff with a dry clean cloth.
CLEAN
Home Styles will provide replacements free of charge for missing or damaged hardware or parts within 30 days of
purchase. Digital images of the defective parts may be required. If the product was not purchased from an authorized
retail affiliate, Home Styles is under no obligation to provide replacement parts. Parts are not available for fully assembled
items nor are parts available for sale. Replacements for missing or damaged hardware or parts may be requested at:
www.homestyles-furniture.com/customer-service/replacement-parts
Home Styles Customer Service: www.homestyles-furniture.com,
[email protected], 888-680-7460, 877-831-0319
