Home Styles 88 5600 83 User manual

Home Styles Consumer Assistance: www.homestyles-furniture.com,
[email protected], 888-680-7460, 877-831-0319
Tools required for assembly : Phillips screwdriver
Part List
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the wood parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Hardware List
Plug
12 pcs. (+1 extra)
Hex Wrench
1 pc.
M6x35
Head Cap Bolt
12 pcs. (+1 extra)
88 5600 83
Chaise Lounge
Small
Hex Wrench
1 pc.
B.
Side Leg
1 pc.
C.
Side Leg
1 pc.
D.
Seat
1 pc.
F.
Rail
1 pc.
E.
Back
1 pc.
G.
Cushion
1 pc.
A.
Front Leg
1 pc.

IMPORTANT
* Do not tighten up all the bolts until each part is properly assembled.
* You should keep Hex Wrench in a safe place as you may need to tighten up the Head Cap Bolts in the future.
* Use a soft cloth between these parts and the floor.
Assembly Instruction 2 / 3
A
STEP 2
Attach Side Leg (B) to seat unit, Back
(E) and Rail (F) with Head Cap Bolts.
STEP 1
Place Seat (D) upside down on a soft cloth.
Attach Front Leg (A) to Seat (D) with
Head Cap Bolts. (see Figure 1)
Figure 1
Head Cap Bolt
STEP 3
Attach Side Leg (C) to unit with Head
Cap Bolts.
D
E
F
B
C
Head Cap Bolt

Assembly Instruction 3 / 3
G
Figure 2
STEP 3
Cover all bolt holes with
Plugs. (see Figure 2)
STEP 5
The back of the unit is
adjustable.
S
C
P
Plastic Plug
STEP 4
Place Cushion (G) onto the
unit and wrap the cushion
strap around the back of
the unit.
