ADEMCO 4204 Relay Module – Installation Instructions
GENERAL INFORMATION
The ADEMCO 4204 Relay Module provides from one to
four dry, form-C (SPDT) relay outputs to compatible
control/communicators. It connects to the control’s
keypad wiring terminals.
The 4204 can be mounted inside the control’s cabinet
or mounted remotely depending on the application.
Refer to the UL notes below for certain restrictions.
If mounted remotely, the 4204 has a built-in tamper
switch that allows it to detect and report the removal of
its cover to the control. Second, communication to the
4204 is supervised so that it cannot be disconnected
from the keypad wiring without detection by the control.
If the wiring is cut, a tamper or alarm signal will result,
to indicate that this device (and possibly other devices
connected to the keypad wiring) has become
inoperative.
INSTALLATION
For UL Installations:
When used with controls that do not support cover
tamper or supervise communications wiring to the
4204, mount the 4204 inside the control’s cabinet.
When used with controls that support cover tamper and
supervise communications wiring to the 4204, mount
the 4204 may either be mounted inside the control’s
cabinet or mounted remotely.
When mounted inside the control’s cabinet, some
controls allow the 4204 to be mounted horizontally as
follows: insert the self-tapping screws (provided) in two
adjacent raised tabs on the back of the cabinet. Leave
the heads projecting 1/8”. Hang the 4204 on the screw
heads via two of the slotted holes on the back of its
housing. The 4204’s cover need not, in this case, be
tamper-protected. Set DIP switch 1 to “ON” if the cover
is not used (see table). See the control’s instructions
for additional information.
When the 4204 is mounted remotely, it can be mounted
horizontally or vertically and the built-in tamper switch
can be used. Wires can exit from the side or via the
breakout on the back of its housing. The DIP switch
must be set with its position 1 “OFF” and when the
installation is completed, the unit’s tamper-protected
cover must be replaced.
NOTE: For EN50131-3 compliance a tie-wrap must be
secured around the case of a remotely mounted 4204.
Apply tie-wrap around the case to the right of the large
zone wire opening (4-inch case width). This is in
opposition of the tamper switch and magnet.
NOTE: CE installations require maximum cable length
of 30 meters.
Affix the connections label that accompanies the 4204
to the inside of the 4204’s cover (if the cover is used) or
to the inside of the control’s cover.
CONNECTIONS AND SETTINGS
Select and set an address for the 4204, using its DIP
switch as shown in the DIP switch table. Each 4204
must be assigned a unique address so the control can
identify and communicate with the 4204. The address
to set is determined by the particular control to be used.
See the control’s installation instructions. As shipped,
the DIP switch is set for address “0”.
UL
•
For UL fire installations, no more than
one wire per terminal may be
connected.
• Use only 14-22AWG wire.
NOTE: All power-limited wiring must be separated from
non-power limited wiring by ¼”.
Make connections to the 4204’s four relays via 12-
position terminal block TB2. Refer to the control’s
installation instructions for specific information on how
to program the activation options for the relays.
Make connections to the control’s keypad wiring points
via 4-position terminal block TB1, the 4-pin plug, or both
(wire color connections are the same). See the
diagram on the other side of this page.
SPECIFICATIONS
Physical: 6-7/16” W x 4-1/4” H x 1-1/4” D
(163mm x 108mm x 32mm)
Electrical:
Input Voltage: 12VDC nominal (10-14VDC, from
control’s remote keypad connection
points)
Input Current: 15mA standby + 40mA per active
relay
Contact Rating: 2A max. at 28VDC/AC (resistive
loads)
WARRANTY
For the latest warranty information, please go to:
http://www.honeywell.com/security/hsc/resources/wa
UL
•
For dry, indoor se only. Do not
install in air-handling spaces.
• For UL Commercial B rglary
installations, the 4204 m st be tamper
protected or mo nted in a tamper-
protected cabinet.
• In Commercial Fire applications, the
mod le cannot be mo nted in the
control nit’s cabinet, b t m st be
mo nted in an external UL864-listed
cabinet.

ÊN8909V4†Š
N8909V4 10/12 Rev. B
4204-01-V1
4204 ADDRESS SETTINGS
("—" means "OFF")
DETERMINE 4204'S ADDRESS: CONTROL'S INSTRUCTIONS SPECIFY ADDRESS
TO USE. "0" ADDRESS SETTING SHOWN (AS SHIPPED).
SWITCH
NUMBER
0 1 2 3 4 5 6 78910 11 12 13 14 15
2
ON
—
ON —ON —ON —ON —ON —ON —ON —
3
ON ON
—
—ON ON ——ON ON ——ON ON ——
4
ON ON ON ON ————ON ON ON ON ————
5
ON ON ON ON ON ON ON ON —————— — —
1 2 3 4 5
Þ
DIP SWITCH SETTINGS
OFF ON
DIP SWITCH (WHITE AREAS DENOTE SWITCH HANDLES)
POSITIONS 2-6:
POSITION 1: ENABLES/DISABLES COVER TAMPER. ON = TAMPER DISABLED,
OFF = TAMPER ENABLED. SHOWN DISABLED AS SHIPPED.
6
ON ON ON ON ON ON ON ON
6 7
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
ON —ON —ON —ON —ON —ON —ON —ON —
ON ON ——ON ON
—
—ON ON ——ON ON ——
ON ON ON ON ——
—
—ON ON ON ON ————
ON ON ON ON ON ON ON ON —————— — —
—————— — —
——————
—
—
ON ON ON ON ON ON ON ON
POSITION 7: NO FUNCTION
TB2
121110
9
87654321
(–) GROUND
(+) 12VDC
YEL
BLK
GRN
RED
13 14 15 16
DIP SWITCH
FOR SETTING DEVICE ADDRESS
AND ENABLING/DISABLING TAMPER
COVER TAMPER (REED) SWITCH
TB1
4204
4-PIN TOUCHPAD PLUG
3
2
RELAY
1
4
TYPICAL
(SHOWN "OFF")
C
NC
NO
C
NC
NO
C
4204-02-V2
NC
NO
C
NC
NO
EITHER OR BOTH
CAN BE USED
DATA IN FROM CONTROL
DATA OUT TO CONTROL
RELAY
RELAY
RELAY
4204 CONNECTIONS
1 2 3 4 5 6 7
Must be connected to a
power-limited source.
If switching power
through a relay, the
power must be from a
power-limited source.
Relays are programmable
but outputs are not
supervised.
Supervised
REFER TO THE INSTALLATION INSTRUCTIONS FOR THE CONTROL WITH WHICH THIS DEVICE IS USED FOR
DETAILS REGARDING THE LIMITATIONS OFTHE ENTIRE ALARM SYSTEM.
FEDERAL COMMUNICATIONS COMMISSION STATEMENTS
The user shall not make any changes or modifications to the equipment unless authori ed by the Installation Instructions or User's Manual. Unauthori ed changes
or modifications could void the user's authority to operate the equipment.
CLASS B DIGITAL DEVICE STATEMENT
This equipment has been tested to FCC requirements and has been found acceptable for use. The FCC requires the following statement for your information:
This equipment generates and uses radio frequency energy and if not installed and used properly, that is, in strict accordance with the manufacturer's instructions,
may cause interference to radio and television reception. It has been type tested and found to comply with the limits for a Class B computing device in accordance
with the specifications in Part 15 of FCC Rules, which are designed to provide reasonable protection against such interference in a residential installation.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• If using an indoor antenna, have a quality outdoor antenna installed.
• Reorient the receiving antenna until interference is reduced or eliminated.
• Move the radio or television receiver away from the receiver/control.
• Move the antenna leads away from any wire runs to the receiver/control.
• Plug the receiver/control into a different outlet so that it and the radio or television receiver are on different branch circuits.
• Consult the dealer or an experienced radio/TV technician for help.
INDUSTRY CANADA CLASS B STATEMENT
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
FCC / IC STATEMENT
This device complies with Part 15 of the FCC Rules, and RSS210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
Cet appareil est conforme à la partie 15 des règles de la FCC & de RSS 210 des Industries Canada. Son fonctionnement est soumis aux conditions suivantes: (1)
Cet appareil ne doit pas causer d’interférences nuisibles. (2) Cet appareil doit accepter toute interférence reçue y compris les interférences causant une réception
indésirable.
