10260S Series Actuators
Auto-Manual Switch Replacement Instruction
Document Number
Form: 62-86-33-26
Effective: 06/01
Supersedes: none
Overview
These instructions apply to the following kit: 51500581-501 Auto-Manual Switch Kit and its application to
the 10260S Series Actuators.
Summary
The AUTO-MANUAL switch of the 10260S Actuator is used as a manual override to drive the actuator
motor to position during set up. The Auto-Manual switch kit contains the components needed to add the
switch function to your actuator, or replace a defective switch. Follow the procedure in Table 1 to install the
Auto-Manual switch.
Tools Needed
To perform the replacement procedure, you will need the following tools:
•Medium Flat-blade screwdriver
•Medium Phillips screwdriver
•Small jeweler’s screwdriver set
•Small adjustable wrench
•Needle-nosed pliers
•Heat gun
Procedure
WARNING
Disconnect power before accessing components inside the actuator.
ATTENTION
When working with Printed Wiring Assemblies (PWAs) always protect against electrostatic discharge by
wearing a grounded wrist strap.

Auto-Manual Switch Instruction, continued
Page 2 of 5 62-86-33-26
AUTO-MANUAL
Switch
Terminal Panel
Figure 1 AUTO-MANUAL Switch Location
Table 1 AUTO-MANUAL Switch Installation Procedure
Step Action
1 Remove AC power to the actuator.
2 Remove four screws and the terminal panel cover from the actuator. See Figure 1
3 Remove two screws and pull out the terminal panel from the actuator case.
NOTE: It may be necessary to loosen the external cable entrance on the side of the actuator case to
gain greater access to the AUTO-MANUAL switch location behind the terminal panel.
Procedure continued on next page
⇒

Auto-Manual Switch Instruction, continued
62-86-33-26 Page 3 of 5
Step Action
4 If replacing the switch, disconnect switch wires and remove switch:
•Carefully disconnect auto-manual switch wires at the rear of the terminal panel from the following
lugs: TB1-1, TB1-8,
TB1-9, TB2-12,
TB2-13, TB2-10, TB2-11.
(Looking at the rear of the terminal panel - TB1 is the top terminal board. TB1-1 is the rightmost
terminal on the top terminal board.)
•Disconnect auto-manual switch wires from the connector at P6-1 and P6-2 on the main PWA.
•Remove switch knob by loosening the set screw and then sliding it off the shaft.
•Remove nut securing switch to side of case.
•Pull switch out of case.
5 Slide heat shrink tubing over the body of the new switch so it covers the soldered wire terminals. With
a heat gun, apply hot air to the shrink tubing to seal the wire terminals of the switch.
6 Install new switch:
•Remove plug from access hole in actuator case, (if present) where switch shaft will be installed.
See Figure below.
•.Attach switch label to side of case.
•Remove nut from threads on switch. Insert switch shaft through case access hole. Carefully
rotate switch until is seats in case. Make sure the stub engages the small hole.
•Screw the nut onto the switch shaft and tighten it securely.
•Attach knob to shaft with set screw on flat side of shaft.
AUTO-MANUAL
Switch
Nut
Knob
Label
7 Identify the correct terminal lugs on the back of the terminal panel for connecting the switch wires.
Procedure continued on next page
⇒

Auto-Manual Switch Instruction, continued
Page 4 of 5 62-86-33-26
Step Action
8 Connect switch wires:
•If adding (not replacing) the switch, remove blue and orange wires from TB1-8 and TB1-9.
Connect blue wire to TB2-13 and orange wire to TB2-12.
•If adding or replacing the switch, one at a time connect auto-manual switch wires as follows:
AUTO-MANUAL
Switch Wires
TO: Terminal Panel Lugs
Black
White
Brown
Green
Violet
Orange
Red
TB1-1
TB1-8
TB1-9
TB2-12
TB2-13
TB2-10
TB2-11
Red (24 AWG) Æ
White (24 AWG) Æ
TO: Main PWA Connector
P6-1
P6-2
NOTE: Some terminal lugs have dual (piggyback) wires attached; make sure the wires are attached to
the correct terminals. Make sure piggyback wires on outermost terminals are facing the inner
terminals, not facing away from the terminals. For example, TB1-1 should have its piggyback terminal
positioned between TB1-1 and TB1-2.
9 Reinsert the terminal panel back into the actuator case being careful not to pinch any wires. Secure
terminal panel with two screws.
10 Install a new gasket and replace the terminal panel cover. Secure with four screws.
11 Reapply AC power to the actuator.
12 Verify actuator configuration and check AUTO-MANUAL switch for correct function.
13 Return actuator to service.
