VMM
ROTARY VALVE ACTUATORS
PRODUCT DATA
Application
The Honeywell VMM actuator is designed to provide floating
control in heating and air conditioning systems. High control
performance and a robust design are standard. In com-
bination with the valves DR/ZR/DRU, it is possible to control
very exact heating and cooling water temperatures. The
mechanical interface between actuator and valve is designed
for reliable operation. Actuators with torques from 20 Nm up
to 40 Nm are available for a wide range of rotary mixing
valves (DN 15…200).
Specification per Actuator
torque
(Nm)
order no. actuator run-time
(min./90°)
24Vac floating 230Vac floating
20 VMM20-24 VMM20 1.6
30 VMM30-24 VMM30 2.3
40 VMM40-24 VMM40 3.5
40 VMM40-24F VMM40F 1.2
Attention (VMM40-24F)
Higher temperatures (>50 °C) combined with the min. voltage
(19.2 Vac) could reduce the output torque by approx. 10%.
Higher temperatures (>60 °C) combined with the max. voltage
(28.8 Vac) allow only three full strokes to be carried out
without interruption.
Features
Protected against overload and blocking
Maintenance-free electrical actuator for rotary valves
Clear position indicator
Direct mounting on rotary valves
Manual operation
High torque
Large wiring cabinet
Long lifetime
Specifications
Power supply 230 Vac / 24 Vac; 50 Hz
depending on type (see table)
Power consumption
VMMxx-24: 3.5 VA
VMM40-24F: 9.0 VA
VMMxx: 3.5 VA
VMM40F: 6.0 VA
Control signal 230 Vac / 24 Vac, floating.
depending on type (see table)
Run-time depending on type (see table)
Nominal torque 20 Nm / 30 Nm / 40 Nm.
depending on type (see table)
Angle of rotation 90°
Protection standard IP 54 per EN 60529
Insulation class l per EN 60730
Ambient operating temp. 0 to 60 °C
Water temp. in valve 2 to 130 °C
Relative humidity non-condensing
Weight 1.5 kg
Suitable Valves
DRxxxGMLA; DRxxxGFLA; ZRxxxMA; ZRxxxFA, DRU.
Mounting on the Valve
Before mounting the actuator, position the rotary valve
according to its installation instruction. In the case of boiler
applications, it is recommended that the actuator be mounted
in a vertical position. If mounted in the horizontal position, one
should position an isolation shield between the top of the
valve and the actuator; this is to protect it against radiant heat
and to ensure ambient temperatures of below 60 °C.
Operation
The actuator is powered by a synchronous motor. The spindle
of the actuator rotates 90°. In the end positions, the motor is
switched off by end switches.
Manual operation declutches the gear from the valve. As soon
as the actuator is powered, the valve is driven by the actuator
again.
No adjustment necessary. The actuator is maintenance-free.

VMM – PRODUCT DATA
EN0B-0621GE51 R0916 2
1 2
R
L
0
L
R
0
10 mm (3/8”)
4 mm (5/32”)
3 4
1 2 3A B
M
M MN
Disconnect the
power from the
controller before
opening the
actuator!
!
+ °C - °C

VMM – PRODUCT DATA
EN0B-0621GE51 R0916
3
Dimensions (mm)
Table 1. DRxxxGMLA, dimensions (in mm)
type DN a c SW h i
DR15GMLA 15 110 179 41 55 R1/2“
DR20GMLA 20 110 179 46 55 R3/4“
DR25GMLA 25 115 179 50 58 R1“
DR32GMLA 32 140 188 60 70 R1 1/4“
DR40GMLA 40 150 188 65 75 R1 1/2“
h
c
133
146
ai
Fig. 1. VMM and DRxxxGMLA, dimensions (in mm)
Table 2. DRxxxGFLA, dimensions (in mm)
type DN a b c d e f g h
DR20GFLA 20 140 15 179 65 90 50 4x11 70
DR25GFLA 25 150 15 179 75 100 60 4x11 75
DR32GFLA 32 160 17 188 90 120 70 4x14 80
DR40GFLA 40 170 16 188 100 130 80 4x14 85
DR50GFLA 50 190 16 202 110 140 90 4x14 95
DR65GFLA 65 210 16 219 130 160 110 4x14 105
DR80GFLA 80 250 18 219 150 190 128 4x18 125
DR100GFLA 100 270 18 240 170 210 148 4x18 135
DR125GFLA 125 310 20 267 200 240 178 8x18 155
DR150GFLA 150 330 20 274 225 265 202 8x18 165
DR200GFLA/ DR200GFLA1 200 390 22 314 280 320 258 8x18 195
c
h
d
g
b
133
146
a e f
Fig. 2. VMM and DRxxxGFLA, dimensions (in mm)

VMM – PRODUCT DATA
EN0B-0621GE51 R0916 4
Table 3. ZR...MA, dimensions (in mm)
type DN a c SW h i net wt. (kg)
ZR15MA 15 110 179 41 55 R1/2“ 2.4
ZR20MA 20 110 179 46 55 R3/4“ 2.5
ZR25MA 25 115 179 50 58 R1“ 2.6
ZR32MA 32 140 188 60 70 R1 1/4“ 4.3
ZR40MA 40 150 188 65 75 R1 1/2“ 4.5
a
h
c
133
146
ai
Fig. 3. VMM and ZRxxxMA, dimensions (in mm)
Table 4. ZRxxxFA, dimensions (in mm)
type DN a b c d e f g net wt. (kg)
ZR25FA 25 150 15 179 75 100 60 4x11 4.8
ZR32FA 32 160 16 188 90 120 70 4x14 7.6
ZR40FA 40 170 16 188 100 130 80 4x14 8.5
ZR50FA 50 190 16 202 110 140 90 4x14 11.0
ZR65FA 65 210 16 219 130 160 110 4x14 14.4
ZR80FA 80 250 18 219 150 190 128 4x18 24.3
ZR100FA 100 270 18 240 170 210 148 4x18 32.9
ZR125FA 125 310 18 267 200 240 178 8x18 49.0
ZR150FA 150 330 20 274 225 265 202 8x18 57.0
ZR200FA 200 390 22 314 280 320 258 8x18 84.0
c
d
g
b
a
133
146
af e
Fig. 4. VMM and ZRxxxFA, dimensions (in mm)

VMM – PRODUCT DATA
EN0B-0621GE51 R0916
5
Table 5. DRU, dimensions (in mm)
type DN a b c d e g h R net wt. (kg)
DRU25-2.5 25 55 32 110 89 55 51 182 1 ½ 2.2
DRU25-4.0 25 55 32 110 89 55 51 182 1 ½ 2.2
DRU25-6.3 25 55 32 110 89 55 51 182 1 ½ 2.2
DRU25-10 25 55 32 110 89 55 51 182 1 ½ 2.2
DRU25-16 25 55 32 110 89 55 51 182 1 ½ 2.2
DRU32-10 32 70 44 140 99 70 59 200 2 4.1
DRU32-16 32 70 44 140 99 70 59 200 2 4.1
DRU32-25 32 70 44 140 99 70 59 200 2 4.1
h
133
146
a
c
R
b d
e
gg
Fig. 5. VMM and DRU, dimensions (in mm)

VMM – PRODUCT DATA
Manufactured for and on behalf of the Environmental & Energy Solutions Division of Honeywell Technologies Sàrl, Rolle, Z.A. La Pièce 16, Switzerland by its Authorized Representative:
Automation and Control Solutions
Honeywell GmbH
Böblinger Strasse 17
71101 Schönaich, Germany
Phone [phone]
Fax [phone]
http://ecc.emea.honeywell.com
EN0B-0621GE51 R0916 Subject to change without notice
ACCESSORIES
The VMM is suitable for use in conjunction with the following accessories.
Table 6. Accessories
accessory description remarks
VMP10-90 Feedback potentiometer 10 kOhm Suitable only for VMM30, VMM40F, and
VMM-40-24F
VMS2 Auxiliary switch package
Ready-to-mount assembly consisting of
two switches (3A / 250 V~) and two
switching cams; max. one VMS2 per
actuator.
