Honeywell SALERMO User manual

SALERMO 48” CEILING FAN
MODEL #10285
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-877-361-3883, Monday - Thursday, 8 am - 6 pm, EST and Friday,
8 am - 5 pm, EST.
Español p. 19

2
WELCOME
PREPARATION
Before beginning the assembly of this product, ensure
that all parts are present. Compare all parts with the
package contents list and hardware contents list. If
any part is missing or damaged, do not attempt to
assemble the product.
After opening the top of the carton, remove the
mounting hardware package from the foam inserts,
then remove the motor from the packaging and
place it on a soft surface, such as a carpet, to avoid
damage to the nish.
Estimated Assembly Time: Under 120 minutes
Tools Required for Assembly (not included): Electrical
Tape, Phillips Screwdriver, Pliers, Safety Glasses,
Step Ladder, and Wire Strippers
Helpful Tools (not included): AC Tester Light, Tape
Measure, Wiring Handbook, and Wire Cutters
CARE AND MAINTENANCE
At least twice each year, lower the canopy to check
the downrod assembly, and then tighten all screws
on the fan. Clean the motor housing with only a soft
brush or lint-free cloth to avoid scratching the nish.
Clean the blades with a lint-free cloth.
Important: Shut off the main power supply before you
begin any maintenance tasks. Do not use water or a
damp cloth to clean the ceiling fan.
FAN WEIGHT
The net weight of this fan is: 14.61 lbs. (6,63 kg).
TABLE OF CONTENTS
ATTACH YOUR RECEIPT HERE
Serial Number
Purchase Date
Care and Maintenance ........................2
Package Contents ...........................3
Safety Information ...........................4
Mounting Options ............................5
Mounting Bracket Installation ...................6
Standard or Angle Mounting Instructions . . . . . . . . . .7
Closemount Instructions .....................10
Wiring ....................................11
Canopy Installation..........................12
Blade Installation ...........................12
Light Kit Installation .........................13
Remote Control ............................14
Operating Instructions .......................15
Replacement Parts List ......................16
Troubleshooting ............................17
Limited Lifetime Warranty.....................18

1
2
6
3
7
4
8
9
10
5
11
12
13
14
15
3
PACKAGE CONTENTS
Unpack your fan and check the contents. You should
have the following items:
1. Blade (3)
2. Mounting Bracket
3. Canopy
4. Canopy Cover
5. Yoke Cover
6. Downrod
7. Downrod Clip
8. Downrod Pin
9. Bulb (2)
10. Yoke
11. Motor Assembly
12. Fitter Plate
13. Light Kit
14. Glass Bowl
15. Remote Pack
16. Hardware bag (not shown): Mounting hardware,
blade attachment hardware, pull chain extensions,
wire connectors, etc.
17. Owner’s Manual (not shown)

4
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble, operate, or install the product.
• Before you begin installing the fan, disconnect the power by removing fuses or turning off the circuit
breakers.
• Make sure that all electrical connections comply with local codes, ordinances, the National Electrical Code,
and ANSI/NFPA 70-199. Hire a qualied electrician or consult a do-it-yourself wiring handbook if you are
unfamiliar with installing electrical wiring.
• Make sure the installation site you choose allows a minimum clearance of 7 ft. (2,14 m) from the blades to
the oor and at least 30 in. (76 cm) from the end of the blades to any obstruction.
DANGER
WARNING
WARNING
When using an existing outlet box, make sure
the outlet box is securely attached to the building
structure and can support the full weight of the
fan. Failure to do this can result in serious injury
or death. The stability of the outlet box is essential
in minimizing wobble and noise in the fan after
installation is complete.
To reduce the risk of re or electric shock, do not use
the fan with any solid-state speed-control device or
control the fan speed with a full-range dimmer switch.
To reduce the risk of re, electric shock, or personal
injury, mount the fan to an outlet box marked
“ACCEPTABLE FOR FAN SUPPORT” and use the
mounting screws provided with the outlet box. Most
outlet boxes commonly used for the support of lighting
xtures are not acceptable for fan support and may
need to be replaced. Consult a qualied electrician if
in doubt. Secure the outlet box directly to the building
structure. The outlet box and its support must be able to
support the moving weight of the fan, at least 35 lbs.
WARNING
CAUTION
CAUTION
CAUTION
To reduce the risk of re, electric shock, or personal
injury, do not bend the blade arms when installing
them, balancing the blades, or cleaning the fan. Do
not insert objects between the rotating fan blades.
Read all instructions and safety information before
installing your new fan. Review the accompanying
assembly diagrams.
FEDERAL COMMUNICATIONS COMMISSION
INTERFERENCE STATEMENT
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to radio or
television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures: Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a
circuit different from that to which the receiver is
connected. --Consult the dealer or an experienced radio/
TV technician for help. Any changes or modications
not expressly approved by the grantee of this device
could void the user’s authority to operate the equipment.
FCC ID: A25-TX005R
Be sure the outlet box is properly grounded or that a
ground (green or bare) wire is present.
!
!
!
!
!
!
!
!
!
!
!
!
!
!

MOUNTING OPTIONS
Fig. 1
Fig. 2
Fig. 3
1. Your fan has 3 mounting options:
• Standard (Fig. 1)
• Angle (Fig. 2)
• Closemount (Fig. 3)
Note: The fans in gures 1 through 3 are not the
actual fan in your package, they are representation
of the 3 different mounting options.
Standard mounting is best suited for ceilings 8 ft.
or higher. For taller ceilings you may want to use a
longer downrod (sold separately).
Angle mounting is best suited for angled or vaulted
ceilings. A longer downrod is sometimes necessary
to ensure proper blade clearance. Important: If
using the angle mount, check to ensure the ceiling
angle is not steeper than 10°.
Closemount is more suitable for ceilings lower than
8 ft. (2,44 m) high.
2. Ensure the blades of the fan are at least 30 in.
(76 cm) from any obstruction.
3. Check the downrod length to ensure the blades will
be at least 7 ft. (2,13 m) above your oor.
5

5. Loosen all four mounting bracket screws and
completely remove the two mounting bracket
screws from the round holes of canopy. Set aside
for later use. Detach mounting bracket from canopy
(Fig. 5).
Fig. 6
Fig. 4
Fig. 5 Mounting
Bracket
Screws
Mounting
Bracket
Canopy
6. Secure the mounting bracket to the outlet box using
screws, spring washers, and at washers provided
with the outlet box (not included) (Fig. 6).
Note: It is very important to use proper hardware
when installing the mounting bracket, as it supports
the fan.
Important: If using angle mount, ensure the open
end of the mounting bracket is installed facing the
peak of the ceiling.
4. Turn off the circuit breakers and wall switch leading
to the fan wire leads (Fig 4).
Mounting Bracket
Screw
WARNING
Failure to disconnect the power supply prior to
installation may result in serious injury or death.
! !
6
MOUNTING BRACKET INSTALLATION

Set Screw
7
STANDARD OR ANGLE MOUNTING INSTRUCTIONS
8. Remove the downrod clip and downrod pin from
the downrod (Fig. 8).
Downrod
Clip
Downrod
Pin
Fig. 8
Fig. 7
Fig. 9
Downrod
Canopy
Yoke
Cover
Downrod Pin
Downrod Clip
9. Feed the wires from the motor assembly through
the yoke cover, canopy, and out the top of the
downrod (Fig. 9).
7. Partially loosen the set screws in the yoke of the
motor assembly (Fig. 7).

Fig. 11
Cut Wires
8
STANDARD OR ANGLE MOUNTING INSTRUCTIONS
10. Slide the downrod into the yoke of the motor
assembly, align the holes, and reinstall the
downrod pin and downrod clip. Then re-tighten the
set screws with a Phillips screwdriver (Fig. 10).
11. Depending on the length of downrod you use,
you may need to shorten the wires to simplify the
wiring process. Pull the wires all the way through
the top of the downrod and measure 8 in. of lead
wire, and use wire cutters (not included) to remove
the excess wire (Fig. 11).
12. If you cut back the lead wire in Step 11, strip 1/2 in.
of insulation from the end of each wire. Twist the
stripped ends of each strand of wire (Fig. 12).
Note: If you did not cut back the lead wires in
Step 11, Step 12 is not necessary and you may
proceed to Step 13 instead.
Downrod
Set Screw
Yoke
Downrod
Pin
Downrod
Pin
Fig. 10
Fig. 12
Stripped
Wires

a
WARNING
Failure to align the slot in the downrod with the tab
on the mounting bracket could cause the fan to fall,
which could result in serious injury or death.
!
!
Slot
Tab
9
STANDARD OR ANGLE MOUNTING INSTRUCTIONS
13. Install the ball end of the downrod into the
mounting bracket opening. Align the slot in the ball
with the tab in the mounting bracket. If installed
correctly, the downrod should not rotate in the
mounting bracket (Fig. 13).
14. Insert the receiver into the mounting bracket with
the at side facing the ceiling (Fig.14).
Mounting
Bracket
Receiver
Downrod
Ball
Fig. 13
Fig. 14

Closemount
Screws
Fig. 16
Canopy
Canopy
Receiver
Hook
Canopy
Cover
Fig. 15
Fig. 17
17. Raise the fan and place the canopy on the hook of
the mounting bracket. Then, insert the receiver into
the mounting bracket with the at side facing the
ceiling (Fig. 17).
15. Remove the canopy cover from the bottom of the
canopy (Fig. 15).
Helpful Hint: The downrod, yoke cover and
canopy cover are not used in this type of
installation.
Closemount Screw
16. Align the canopy with the holes in the top of motor
assembly. Then, secure the canopy to the top of
the motor assembly using the three closemount
screws from the hardware bag (Fig. 16).
CLOSEMOUNT INSTRUCTIONS
10

Wire Connector
18. Connect supply and fan wires according to the
diagram (Fig. 18) and these steps:
• Connect the Green wires from the fan and the
mounting bracket to the Bare/Green (ground)
supply wire.
• Connect the Blue wire with white label from the
receiver to the Blue fan wire.
• Connect the Black wire with white label from the
receiver to the Black fan wire.
• Connect the Red wire with red label from the
receiver to the Black (hot/power) supply wire.
• Connect the White wire with red label from the
receiver to the White (neutral) supply wire.
• Connect the White wire with white label from the
receiver to the White fan wire.
Secure all wiring connections with wire connectors
and push all connected wires back into the outlet
box.
Note: The black fan wire is power for fan. The blue
fan wire is power for the light. The white wire from
the fan is common/neutral. The green wires from the
fan and mounting bracket are ground wires.
a
a
CAUTION
WARNING
WARNING
If house wires are different colors than referred to in
the following steps, consult a professional electrician
to determine wiring. Incorrect wire connection can
damage the fan and could cause re or injury.
Ensure black and white wire connections are on
opposite sides of the outlet box.
Be sure outlet box is properly grounded or that a
ground (green or bare) wire is present.
! !
!
!
!
!
Black (hot/power)
White (neutral)
Bare/Green
(ground)
Red
White
White
White
Black
Blue
Blue
Black
Green
Green
Receiver
Fig. 18
11
WIRING

12
CANOPY INSTALLATION
19. Lift the canopy up so the partially installed mounting
bracket screws engage the J-slots on each side of
the canopy. Rotate the canopy clockwise and install
the previously removed mounting bracket screws
from Step 5. Tighten all four screws with a Phillips
screwdriver (Fig. 19).
Mounting
Bracket
Canopy
Fig. 19
Mounting Bracket
Screw
Blade Screw Blade Washer
Mounting
Bracket Screw
BLADE INSTALLATION
Blade Screw
Blade Washer
Blade
Slot
Fig. 20
20. Insert the blade through the slot in the side of the
motor assembly. Align the holes in one blade with
three blade screw holes in the underside of the
motor assembly. Secure with three blade screws
and washers. Repeat for the remaining blades
(Fig. 20).
Underside
of Motor
Blade Screw
Holes

Single-pin
Connector
Fitter Plate Screw Keyhole
Socket
CFL
Fig. 22
22. Install two CFLs in the sockets of the light kit
(Fig. 22).
23. Attach the glass bowl to the light kit by twisting the
bowl tightly in a clockwise direction until it is secure
(Fig. 23).
Assembly is complete. Turn on the circuit breakers
and the wall switch to the fan supply lead wires.
Fig. 23
Light Kit
Glass Bowl
LAMP CONTAINS MERCURY
LA BOMBILLA CONTIENE MERCURIO
Manage in accordance with Spills, Disposal and Site Cleanup
Requirements. In case of breakage, follow clean-up
procedures provided by contacts below.
Manipule según las exigencias sobre derrames, eliminación y
limpieza del lugar. En caso se rompa, siga el método de
limpieza proporcionado por los siguientes contactos.
Hg
www.epa.gov/ccleanup
1-866-284-4010
13
LIGHT KIT INSTALLATION
Fig. 21
21. Loosen two and completely remove one of the
pre-assembled tter plate screws from the tter
plate. Connect the single-pin connector from the
fan to the single-pin connector to the light kit -- blue
to black and white to white.
Then, lift the light kit up until the two loosened
tter plate screws engage the two keyholes in the
light kit. Twist the light kit in a counter clockwise
direction. Then re-install the third tter plate screw
to secure the light kit to the tter plate (Fig. 21).
Fitter Plate Screw

1
2
3
4
5
6
Fig. 24
Fig. 25
Fig. 26
LED Indicator
Battery
Battery
Compartment
Fan Power
Wall
Bracket
Screw
Mounting
Slot
14
24. Remove the battery cover (not shown) from the
back of the remote. Insert the battery into the
remote; ensure polarity of battery matches the
polarity indicated in the battery compartment
-- positive (+) to positive (+) and negative (-) to
negative (-). Replace the battery cover and press
the fan power button on the remote to ensure the
LED indicator illuminates and the remote turns on
the fan (Fig. 24). Note: If remote doesn’t turn on the
fan, see TROUBLESHOOTING (page 17).
25. To operate the fan using the remote, press and
release the following buttons:
1- High fan speed
2- Medium fan speed
3- Low fan speed
4- Fan Power - Turns the fan off.
Light Delay Off mode - Press and hold the fan
power button (4) for ve seconds, which will turn
off light after one minute. The LED indicator on
the remote will ash four times to conrm mode
setting.
5- Light Control:
Incandescent Bulbs - Press light control to turn
lights off and on. Press and hold light control to
dim or brighten the lights.
CFL Bulbs -Turns the lights on and off.
Note: Dimmer function does not work with CFL.
6- D/CFL Switch: Switch should be set to “CFL”
to correspond with the CFL. Flip to “D” if you
change to incandescent, which will enable the
dimming function.
26. Use the two wall bracket screws from the remote
pack to mount the wall bracket to a wall (Fig. 26).
Note: The mounting slot on the back of the remote
hangs on top edge of the wall bracket.
REMOTE CONTROL

15
OPERATING INSTRUCTIONS
Fig. 27
Fig. 28
Fig. 29
Reverse
Switch
27. Use the reverse switch, located on the side of the
fan, to optimize your fan for seasonal performance
(Fig. 27).
Using a ceiling fan will allow you to raise your
thermostat in the summer and lower your
thermostat in the winter without sacricing comfort.
Important: Wait for the fan to stop before moving
the reverse switch. The reverse switch must be set
either completely left or right in order for the fan to
function correctly. If the reverse switch is set in the
middle position, the fan will not operate.
28. In warmer weather, push the reverse switch left,
which will result in downward airow creating a
wind chill effect (Fig. 28).
29. In cooler weather, push the reverse switch right
and the fan to low, which will result in upward airow
that can help move stagnant, hot air off the ceiling
area. By mixing the air, the heat may not have to run
as often and may yield energy savings (Fig. 29).

REPLACEMENT PARTS LIST
16
For replacement parts, call the customer service department at 1-877-361-3883, 8 a.m. - 6 p.m., EST, Monday -
Thursday, 8 a.m. - 5 p.m., EST, Friday.
AB
PIECE DESCRIPTION MODEL 10285
PART #
A Blade 10285-A
B Glass Bowl 10285-B
C
Hardware bag (not shown)
contains: Mounting hardware,
blade attachment hardware,
pull chain extensions, wire
connectors, etc.
10285-C

17
TROUBLESHOOTING
At least twice each year, lower the canopy to check the downrod assembly, and then tighten all screws
on the fan. Clean the motor housing with only a soft brush or lint-free cloth to avoid scratching the nish.
Clean the blades with a lint-free cloth. You may occasionally apply a light coat of furniture polish to wood
blades for added protection.
Important: Shut off the main power supply before you begin any maintenance tasks. Do not use water or
a damp cloth to clean the ceiling fan.
Problem: The fan does not move
1. Turn the power on or check the fuse.
2. Turn the power off. Loosen the canopy and check all connections.
3. Check that the connectors from the light kit tter and fan are connected properly.
4. Disable the power supply to the fan motor and re-start the motor.
Problem: The fan is noisy.
1. Check and tighten all screws that hold the fan blades to the blade arms and the motor.
2. Check for cracked blade. Replace blade, if necessary.
Problem: There is excessive wobbling
1. Check and tighten all screws that hold the fan blades to the blade arms and the blade arms to the motor.
2. Switch one blade with a blade from the opposite side. Or balance the fan using a balancing kit.
3. Turn off the power. Loosen the canopy and verify that the mounting bracket is secure to the electrical
outlet box.
4. The bracket must be ush without movement against the outlet box.
Problem: The fan operates correctly, but the lights are not working (if applicable).
1. Re-install the bulb(s).
2. Ensure the single-pin connectors in the light kit tter are connected properly.
3. Turn the power off and check all connections at the ceiling outlet box.
4. The fan comes with a 190W limiter. When the total watts of the bulbs is over 190W, the lights do not
work. Replace the bulbs with lower wattage bulbs..
Problem: The remote does not work.
1. (Syncing instructions) Turn off the main power, then turn it back on. Within 30 seconds, press and hold
the high and low speed buttons on the remote at the same time for 5 seconds. The LED indicator will ash
three times, signaling a successful synchronization. Once complete, the fan will start on the low speed
with the light (if applicable) off.
2. Insert new 12V battery in battery compartment of the remote control.
3. If there are several fans in close proximity, turn power off to other fans and re-sync the remote.

18
LIMITED LIFETIME WARRANTY
Subject to the limitations set forth below, Hong Kong China Electric appliance Company (HKC) warrants the fan
motor for this ceiling fan to be free from defects in workmanship and material for the life of the product. Also,
subject to the limitations below, HKC warrants all ceiling fan parts (“ceiling fan parts” excludes the motor and parts
made in whole or in part with glass) to be free from defects in workmanship and material for a period of one year
after the date of purchase by the original purchaser at retail.
All claims must be made by the original purchaser, whether such purchaser purchased the product through a store
or contractor. Ceiling fan part defects must be reported within the rst year from the date of purchase. Parts made in
whole or in part with glass and the nishes of metal and other surfaces are not warranted.
Purchasers are responsible for all costs of removing and reinstalling the product. Any damage to any part caused
by ordinary wear and tear, accident, misuse, or improper installation, is not covered by this warranty. HKC
assumes no responsibility whatsoever for fan installation. Any service performed by a non-licensed electrician will
render the warranty invalid.
HKC’s sole responsibility shall be to repair or replace the motor, parts, or product within the terms stated above.
HKC SHALL NOT BE LIABLE FOR ANY LOSS OR DAMAGE OF ANY KIND, INCLUDING ANY INCIDENTAL
OR CONSEQUENTIAL DAMAGES RESULTING DIRECTLY OR INDIRECTLY, FROM ANY BREACH OF
WARRANTY, EXPRESS OR IMPLIED, OR ANY OTHER FAILURE OF THIS PRODUCT. SOME STATES DO
NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES SO THIS
LIMITATION MAY NOT APPLY TO YOU.
IF THE ORIGINAL PURCHASER CEASES TO OWN THE FAN, THIS WARRANTY IS VOIDED.
Should the purchaser encounter a problem with your fan related to defects in workmanship or materials within the
warranty period associated with the defective part, HKC agrees to replace the defective part without charge, or at
its option, to replace the ceiling fan with a comparable or superior model.
HKC’S WARRANTIES ARE LIMITED TO THE WRITTEN WARRANTIES SET OUT IN THIS HKC CEILING
FAN LIMITED LIFETIME WARRANTY. ALL OTHER EXPRESS AND IMPLIED WARRANTIES, INCLUDING,
WITHOUT LIMITATION, THE IMPLIED WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE AND THE
IMPLIED WARRANTY OF MERCHANTABILITY ARE DISCLAIMED. SOME STATES DO NOT ALLOW THE
DISCLAIMER OF IMPLIED WARRANTIES, SO THIS DISCLAIMER MAY NOT APPLY TO YOU.
To obtain warranty service, please write down your model number and call Customer Service at
1-877-361-3883 Monday - Thursday, 8 am - 6 pm, EST and Friday, 8 am - 5 pm, EST. Please have a copy
of the receipt as proof of purchase.
The Honeywell Trademark is used under license from Honeywell International
Inc. Honeywell International Inc. makes no representations or warranties with
respect to this product. This product is manufactured for:
Hong Kong China Electric Appliance Manufacture Co., Ltd.
3350 Players Club Parkway, Suite 225
Memphis, TN 38125
1-877-361-3883
9163-EN r121515
