Honeywell Farenhyt Series Technical manual

RA-2000/RA-2000GRAY
Remote Annunciator
Product Installation Document
Document 151443:D 2/7/2022 ECN: 151770
Farenhyt™ Series
1 Description
The RA-2000/GRAY is an optional 4x40 remote annunciator that can be
surface or flush-mounted.RA-2000 is the red model. RA-2000GRAY is
the gray model.
1.1 Compatibility
The RA-2000/GRAY is compatible with the Honeywell’s Farenhyt
Series FACPs. For more information, refer to the FACP Manual.
1.2 Specifications
2 Installation
1. Ensure power is turned off at the panel.
2. Mount the RA-2000/GRAY in the desired location. See Section 2.1.
3. Connect the RA-2000/GRAY to the panel. See Figure 5.
4. Use the DIP switches on the back of the RA-2000/GRAY to assign
an ID number. Refer to the FACP manual.
5. The RA-2000/GRAY module must be added to the system through
FACP programming. JumpStart can be used to automatically add
the module or it may be added manually. Refer to the FACP Manual
for more information.
2.1 Mounting
2.1.1 Flush Mounting
Follow these steps to flush mount the RA-2000/GRAY.
1. The backbox dimensions are 9.25” W x 8.375” H. The minimum
depth required is 2". Mount the backbox using the mounting holes
shown below.
2. Remove knockouts as needed for wires. There are 10 knockouts
available, two on each side and two in the back of the cabinet.
3. Wire the annunciator board to the main control panel as shown in
Figure 5.
4. Attach the annunciator and door assembly to back box as shown
below using the supplied screws.
Operating Voltage: 24VDC
Current Standby Current: 27mA
Alarm Current: 53mA
Operating Temperature: 32° to 120° F (0° to 49° C)
Dimensions Flush Mount: Overall:
12.25” W x 11.5” H x 0.875” D
(31.1 cm W x 29.2 cm H x 2.2 cm D)
Backbox: 9.25” W x 8.375”H
(23.5cm W x 21.27cm H)
Surface Mount: Including trim ring:
12.25” W x 11.5” H x 3.0” D
(31.1 cm W x 29.2 cm H x 7.6 cm D)
Table 1 Specifications
BACK BACK BACK
NEXT NEXT NEXT
Model RA-2000
Farenhyt™ Series
Figure 1 RA-2000 Remote Annunciator
mounting holes
mounting holes
Figure 2 RA-2000/GRAY Backbox Mounting
Figure 3 Attaching Annunciator/Door Assembly

Honeywell Security & Fire
12 Clintonville Road
Northford, CT 06472-1610
203.484.7161
www.farenhyt.com
151443 | D | 02-22
©2022 Honeywell International Inc.
2.1.2 Surface Mounting
The RA-100TR Red Trim Ring kit and RA-100TG Gray Trim Ring kit
are available for use when surface mounting the RA-2000/GRAY.
1. Remove the desired knockout.
2. Mark and pre-drill hole in the wall for the center top keyhole
mounting bolt. Refer to Figure 2 for mounting hole locations.
3. Install center top fastener in the wall with the screw head
protruding.
4. Place backbox over the top screw, level and secure.
5. Mark and drill the left and right upper and lower mounting holes.
6. Install remaining fasteners and tighten.
7. Run wires to the control panel. Refer to Figure 5.
8. Place the trim ring over the back box as shown below.
9. Attach the door assembly to the backbox using the screws
provided. Refer to Figure 3.
3 Wiring Connections
Wire the RA-2000/GRAY to the FACP as shown in below.
Figure 4 Installing Trim Ring
SBUS OUT
–+AB
S– S+ AB
ON
12345
6
DIP Switches
remote annunciator
(back view)
supervised,
power-limited,
Class B
Figure 5 SBUS Connections
