Honeywell’s EQUIP®Series is an array of IP-based products that have an open
architecture platform and utilize a single Application Program Interface (API). The
API allows for a common user experience and integration with hybrid Digital
Video Recorders (DVRs) and Network Video Recorders (NVRs).
The Honeywell HCD554IP day/night network camera offers the latest in digital
video surveillance. The 1/3" CCD network camera combines world-class imaging
and camera technology with the EQUIP Series IP networking technology
providing streaming MPEG-4 images in 4CIF, 2CIF, or CIF resolutions with rates
up to 30 frames per second (25 fps for PAL systems).
The HCD554IP day/night camera adapts to varying lighting conditions to ensure
the highest picture quality even in extreme low light conditions. When the light
level drops too low for accurate video identification in color, the camera moves
the IR cut filter out of the optical path and then switches to black and white video
to capture more detail using the increased sensitivity of the CCD to IR light. For
additional control, the on-board alarm input can be configured to switch the
camera from day to night mode to allow synchronization with external lighting.
The HCS554IP has built-in Power over Ethernet (IEEE 802.3af), which allows
power to be supplied to the camera using the network, eliminating the need for a
separate power supply and reducing the cost of installation. For additional
installation flexibility the unit can also be powered with 12 VDC or 24 VAC.
Market Opportunities
The HCD554IP is a network surveillance solution designed for object recognition
that is required in locations where variable and low light conditions exist. Setup is
quick and easy and can be customized through a Web client or from an NVR.
This provides optimum performance for both indoor and outdoor applications.
Features
www.honeywellvideo.com
HCD554IP
• 4CIF, 2CIF, or CIF resolutions
• 1/3" color CCD, 540 TVL
• Excellent low light performance,
down to 0.4 lux
• Camera Sabotage Detection
• MPEG-4 compression
• Remote firmware updates
• Supports both Dynamic and Static IP
addresses
• Variable day/night threshold setting
to accommodate switching to black
and white images in low light
• Multiple levels of password protected
remote access prevents unauthorized
users from altering system settings
• Includes advanced IP locator
software to make system setup easy
• Web server for remote setup of
camera video and network
parameters
• 12 VDC/24 VAC or PoE IEEE 802.3af
choice of power inputs
• Supports CS mount lenses
• Supports two-way audio
EQUIP®SERIES TRUE DAY/NIGHT NETWORK CAMERA

HCD554IP
SPECIFICATIONS
Like all cameras in the EQUIP Series, the HCD554IP network camera uses Honeywell technology for camera
sabotage detection, remote firmware updating and for secure storage of all camera settings. Camera sabotage
detection notifies the user when a camera’s field of view is altered, blinded or blurred. This ensures the video’s
integrity and alerts the customer to either a live event or a system problem that is causing disruption to the video
stream. Honeywell’s technology also allows users
to remotely upload firmware to the camera. Set-up
is quick and easy and can be customized through
a Web client or from an NVR or DVR. The built-in
Web server provides password protected access
to the camera’s video and network setup.
Workstation
NETWORK
EQUIP SERIES
CAMERAS
System Diagram
Internet Explorer or Honeywell IT Utility
Monitors
Monitor
Monitors
Hybrid DVR
NVR
NETWORK
Keyboard
EQUIP SERIES
CAMERAS
Hybrid DVR or NVR

HCD554IP
SPECIFICATIONS
Environmental
Temperature Operating: 14°F to 122°F (-10°C to 50°C)
Storage: -4°F to 140°F (-20°C to 60°C)
Relative
Humidity 0% to 85%, non-condensing
IP Specifications
Video
Compression MPEG-4 Part 2 (ISO/IEC 14496-2) SP level 0-3
Resolutions 4CIF
2CIF
CIF
NTSC
704 x 480
704 x 240
352 x 240
PAL
704 x 576
704 x 288
352 x 244
Frame Rate
NTSC/PAL Up to 30/25 fps video in all resolutions
Video
Streaming MPEG-4 controllable frame rate and bandwidth. Constant or variable bit rate (MPEG-4)
Security Multiple user access levels with password
protection
Users 1 Administrator, 4 Guests (unicast)
Video Access
from Web
Browser Camera live view for up to 5 clients. Full control
of all camera settings available to administrator
Minimum
Web
Browsing
Requirements
Pentium IV CPU 3.0 GHz or equivalent AMD,
512 MB RAM, AGP graphics card (32 MB RAM)
Windows®XP 2000, Internet Explorer 6.0 or
later
Supported
Protocols IPv4, HTTP, TCP, RTSP, RTP, UDP, ARP, DNS, RTCP, FTP, ICMP, DHCP, Bonjour, IGMP
Regulatory
Emissions FCC, CE (EN55022)
Immunity CE (EN50130-4)
Safety EN60950-1
UL Listed (file E319174)
Operational
Video Standard NTSC, PAL
Scanning
System 525/60 lines (NTSC), 625/50 lines (PAL)
Image Sensor 1/3" CCD
Number of
Pixels
(H x V) HCD554IP: 768 x 494 (NTSC)
HCD554IPX: 752 x 582 (PAL)
Minimum
Illumination 0.6 lux color/0.4 lux BW @ 50 IRE, F1.2 0.25 lux color/0.15 lux BW @ 30 IRE, F1.2
Horizontal
Resolution Greater than 540 TVL
Automatic Lens
Control DC Iris Level 1-25
Video Output 1.0 Vp-p @ 75 Ohms
S/N Ratio 50 dB or more (AGC off)
Auto Gain
Control Off/On, selectable (10-30 dB)
Automatic
Electronic
Shutter 1/60-1/100,000 sec (NTSC)
1/50-1/100,000 sec (PAL)
White Balance ATW, User Fixed, AWC (Auto or Manual), Fluorescent, MWB (Manual Mode), Indoor,
Outdoor
Back Light
Compensation Off/On, selectable
Gamma 0.45
Audio/Two-Way Line in/out
Electrical
Input Voltage 12 VDC/24 VAC, PoE IEEE 802.3af
Input Range 11–16 VDC, 17–28 VAC
Surge
Suppression 1.5 kW transient
Power
Consumption 8 W (max)
Mechanical
Dimensions
(W x H x D) See Diagram
Weight 1.1 lb (.5 kg) camera only
Construction Housing: Aluminum
Finish: Cool Gray Powder Coat
Camera Mount 1/4-20 UNC mounting ring
Lens Mount CS Lens Mount
Connector
Video Output: BNC connector
Lens: 4 Pin Connector
Power Input: Removable screw block
Network: RJ45 connector
Alarm I/O: Removable screw block
Audio In: 3.5 mm mono phone jack
Audio Out: 3.5 mm mono phone jack

HCD554IP
L/HCD554IP/D
December 2010
© 2010 Honeywell International Inc.
Honeywell Security Group
Honeywell
2700 Blankenbaker Pkwy, Suite 150
Louisville, KY 40299
1.800.796.CCTV (2288)
www.honeywell.com
www.honeywellvideo.com
SPECIFICATIONS
Ordering
HCD554IP EQUIP Series 1/3" CCD High Resolution True Day/Night Camera with DSP, 540 TVL, 12 VDC/24 VAC or
PoE IEEE 802.3af. NTSC
HCD554IPX EQUIP Series 1/3" CCD High Resolution True Day/Night Camera with DSP, 540 TVL, 12 VDC/24 VAC or
PoE IEEE 802.3 af, PAL
NOTE: Honeywell reserves the right, without notification, to make changes in product design or specifications.
System Compatibility
Hybrid DVRs
Fusion III Full Featured Hybrid Digital Video Recorder,
version 3.5 or higher
NVRs
Enterprise
NVR Series Enterprise Class Digital Network Video Recorder System, version 5.6 or higher
DVM Enterprise IP Based Video System, Version
R200.2 or higher
Accessories
Recommended Lens Options
HLD29V8DNL 2.9-8 mm, F0.95, DC Auto Iris Lens,
IR Corrected
HLD27V13DNL 2.7-13.5 mm, F1.3, DC Auto Iris Lens,
IR Corrected
HLD5V50DNL 5.0-50 mm, F1.6, DC Auto Iris Lens,
IR Corrected
Housing and Mounts
HBC5WT Wall/ceiling mount bracket
HHC12 Series Housing with optional heater/blower and
mounts
ETHERNET
VIDEO
OUT
IN
AUDIO
2.65" (67.22 mm)
2.44" (62.00 mm)
1.24" (31.50 mm)
2.44" (62.00 mm)
0.81" (20.70 mm)
5.70" (145.00 mm)
