Honeywell HP ProLiant DL360P Gen8 User manual

HP ProLiant DL360P Gen8 Server Planning Installation
Service Guide
HWDOC-X330-G
August 2020

Disclaimer
This document contains Honeywell proprietary information. Information contained herein is to be used
solely for the purpose submitted, and no part of this document or its contents shall be reproduced,
published, or disclosed to a third party without the express permission of Honeywell International Sàrl.
While this information is presented in good faith and believed to be accurate, Honeywell disclaims the
implied warranties of merchantability and fitness for a purpose and makes no express warranties
except as may be stated in its written agreement with and for its customer.
In no event is Honeywell liable to anyone for any direct, special, or consequential damages. The
information and specifications in this document are subject to change without notice.
Copyright 2020 - Honeywell International Sàrl
- 2 -

Contents 3
Chapter 1 - About this Document 6
Chapter 2 - Planning 9
2.1 Overview 9
2.1.1 Software requirements 10
2.1.2 BIOS configuration 10
2.2 Description 10
2.2.1 Honeywell server model number 10
2.2.2 Equipment configuration 11
2.2.3 Electronics module 11
2.2.4 Standard features of HP ProLiant DL360p Gen8 server 12
2.3 Platform information 13
2.4 Slots configuration 14
2.4.1 Slot configuration for Experion node setup 14
2.4.2 Slots configuration 14
2.4.3 General Ethernet configuration 15
2.4.4 Cnet configuration using PCIC interface 15
2.5 Memory configuration 16
2.5.1 Standard memory configuration for 4GB using RDIMM 16
2.5.2 Standard memory configuration 17
2.5.3 Maximum memory configuration 17
2.6 System specifications 18
2.6.17 Hard disk drive specifications 22
2.6.18 Removable media specifications 22
2.6.19 Mouse and keyboard 22
2.6.20 Monitor 22
2.6.21 Video cable 23
2.7 Industrial regulatory compliance 23
2.7.1 Electromagnetic Compatibility 23
2.7.2 Safety compliance 24
2.8 Light industrial regulatory compliance 24
2.8.1 Electromagnetic Compatibility 24
2.8.2 Safety compliance 25
Chapter 3 - Installation 26
3.1 Tasks for installing the server 26
- 3 -

3.1.1 Before you begin 26
3.2 Power and grounding requirements 26
3.3 Cabinet spacing requirements 27
3.4 Installing the server and connecting the cables 28
3.4.1 Honeywell server back panel connections 28
3.4.2 Installing the server 28
3.4.3 Connecting the cables 29
3.4.4 Install air duct baffles and blank panel front covers in cabinet 30
3.5 Starting the server 32
3.5.2 Configuring RAID in HP ProLiant DL360p Gen8 server 32
3.5.3 Starting the TDC emulator services 32
3.5.4 Checking the LCNP4e/LCNp4e2 status 33
Chapter 4 - Operation 34
4.1 Server overview 34
4.1.1 Front view 34
4.1.2 Rear view 35
4.2 Network connections 36
4.2.1 Ethernet network 36
4.2.2 LCN network 36
4.2.3 LCN cables 37
4.2.4 LCN connections 37
4.2.5 MAU connection 37
4.2.6 ControlNet Network 38
4.3 Configuring ControlNet interface card 39
Chapter 5 - Servicing 40
5.1 Remove the server from the rack 40
5.2 Removing the access panel 40
5.3 Servicing the LCNP4e/LCNp4e2 41
5.3.1 Replacing the LCNP4e/LCNp4e2 board 42
5.4 Servicing the hard disk drives and power supply 46
5.4.1 Installing hot spare hard drive 46
5.5 Servicing Honeywell options 47
5.5.1 LCN node setup board configuration 48
5.5.2 Slot requirements for general Ethernet and FTE node setup 48
5.5.3 Add additional memory 48
5.5.4 Verifying correct BIOS settings 50
- 4 -

5.5.5 BIOS settings for 51155539-100 50
5.5.6 BIOS settings for 51155539-200 57
5.6 Spare parts 65
- 5 -

ABOUT THIS DOCUMENT
This guide contains planning, installation and service information for the Honeywell-configured HP
Proliant DL360p Generation 8 (Gen8) server. The instructions and service information contained in this
guide addresses the server, and assumes that associated network communication equipment is pre-
installed by the Honeywell factory or has manuals dedicated to its installation and service. This server
is not a standard HP model and you cannot order it independently from HP.
NOTE
If the Local Control Network (LCN) coaxial based system has been integrated with an Experion
Fault Tolerant Ethernet (FTE) based system, the node (server) may be upgraded to be an
Experion Local Control Network (ELCN) node, which has its ELCN Interface provided via FTE.
This node may be installed as a physical or virtual platform.
If the node is upgraded to an ELCN node, and the node is a physical (a.k.a. bare-metal)
platform, a Local Control Network Processor (LCNP) board coaxial interface to LCN is not used.
The LCN MAU is disconnected, and/or the LCNP board is removed.
Redundant ELCN Bridges are required if the ELCN node is communicating with any other
existing, coaxial-based LCN node.
Some LCN nodes may have been replaced by their ELCN equivalent nodes, and overall system
features/architecture will differ from that of a non-ELCN integrated system (classic LCN/TPN
system). In this case it may be necessary to refer to appropriate ELCN documentation, in
addition to the information provided herein.
The following table lists Honeywell ELCN/Experion publications that may be useful for references.
ELCN Reference Documents Table for Server/Workstation PSIG Documents
- 6 -
CHAPTER
1

Publication Content Type
Experion LCN Hardware
Upgrade Kit Instructions
(51195195-415)
UEA installation
Experion LCN Quick Start
Guide (EPDOC-X480-en-
510A)
General hardware/software/migration information
Experion Software Installation
User's Guide (EPDOC-X136-
en-510A)
Experion software installation (various methods)
Experion LCN Overview and
Implementation Guide
(EPDOC-X478-en-510A)
Bridge hardware installation, software configuration,
operation, servicing/troubleshooting
Experion LCN Planning,
Installation, and Service Guide
(HWDOC-X479-en-E)
ELCN system planning, hardware/software
installation, servicing/troubleshooting
Experion LCN Specification
(ELCN03)
General ELCN technical specifications
Fault Tolerant Ethernet
Installation and Service Guide
(EPDOC-XX36-en510A)
FTE system installation, servicing/troubleshooting
Universal Embedded
Appliance Hardware
Installation and Maintenance
Guide (HWDOC-X469-en-A)
General UEA planning, installation, and service
information before it is commissioned as an ELCN
appliance.
Integrated Experion-TPS
User's Guide (EPDOC-XX66-
en-510A)
Supplementary installation tasks needed before using
TPS Nodes on an Experion system. Describes
configuration tasks needed for TPS Nodes.
Virtualization Planning and
Implementation Guide
(EPDOC-X147-en-A)
Implementing networks, Preparing ESXi host,
Administering virtualization
Server and Client Planning
Guide (EPDOC-X128-en-
510A)
High-level planning/design for Experion servers,
clients, controllers
Process Operations Manual
(SW11-601)
Process operations, alarm/message handling,
reporting, history functions, system operations,
system menu functions, console/station peripheral
devices
- 7 -
Chapter 1 - About this Document

Chapter 1 - About this Document
Publication Content Type
Integrated Experion-TPS
User's Guide (EPDOC-XX66-
en-510A)
Supplementary installation and configuration tasks for
Experion TPS Nodes
Experion PKS R510.1
Migration Planning Guide
(EPDOC-XX70-en-5101A)
Planning information for migration of Experion system
from legacy R4xx system software to Experion
R510.1 software.
Switch Configuration Tool
User's Guide
(EPDOC-X246-en-510A)
Experion switch configuration information
Experion Network Best
Practices (WP-07-02-ENG)
Best practices for planning the installation of Experion
FTE networks, and connecting them into plant IT
networks.
Experion R510 Software
Change Notice (EPDOC-
X166-en-510A)
Describes Experion R510 features/enhancements,
overall product, release interoperabilities, system
dependencies, problem resolutions, known issues,
special considerations
Customer Release Guide
R687 (CRG-687)
TPN/TPS Migration information (ELCN migration
Information included)
TPN R687 Software Change
Notice (TNDOC-X166-en-
6871A)
Document changes, compatibility and
migration/installation processes for the TPS Process
Network Release of R687 software.
Experion Control Building
User's Guide (EPDOC-XX19-
en-510A)
Procedures for basic tasks in the Control Builder
application (configuring hardware devices, continuous
control strategies, sequential control strategies).
1.1 Revision history
Version Date Description
A
August 2020
Initial release
of the
document
- 8 -

PLANNING
lOverview
lDescription
lPlatform information
lSlots configuration
lMemory configuration
lSystem specifications
lIndustrial regulatory compliance
lLight industrial regulatory compliance
2.1 Overview
Platforms sold by Honeywell are engineered for the process control mission of Experion and TPS
systems to provide consistent and robust performance. Through an extensive qualification process,
Honeywell defines specific peripheral devices, slot locations, and BIOS settings for best performance
and reliability, sometimes even adding cooling fans for longer service. Honeywell platforms are then
built to Honeywell specifications by the computer manufacturer.
Honeywell engineering has tested the HP ProLiant DL360p Gen8 server with other Honeywell
hardware and software and has qualified its use for specific configurations as identified in the Software
Change Notice (SCN). This server is not a standard HP model and cannot be ordered independently
from HP. The Technical Assistance Center (TAC) is trained to support Honeywell platforms. Use of any
other server, including a similar HP model, is considered a project special and its TAC support is
limited according to the services policy.
This release of the server is based upon RAID-5 and dual power supply design and provides
computer-based functionality for Experion and TPS systems. For TPS systems and certain Experion
systems configured with Fault Tolerant Ethernet (FTE), the server has an LCNP4e/LCNp4e2 card
installed, which allows connection to the TotalPlant Process Network (TPN) coax through the LCN
Media Access Unit (MAU). Additionally, the server connects to the Ethernet or FTE using the on board
quad NIC.
The peripheral electronics assemblies are based upon either the Peripheral Component Interconnect
Express (PCIe) bus or USB 2.0. All mass storage devices are connected through SATA and PCIe. The
SATA DVDRW drive is connected through the SATA connector on the motherboard. The RAID-5 SAS
controller card is located on server motherboard.
The standard memory of this platform:
lFor 51155539-100 is 4GB (using 1x 4GB ECC RDIMM memory 1600MHz or faster) that can be
upgraded to 8GB (using 2 x 4GB ECC RDIMM memory 1600 MHz or faster).
lFor 51155539-200 is 8GB (using 1x 8GB DDR3 ECC RDIMM memory 1600MHz or faster) that can
be upgraded to 16GB (using 2 x 8GB DDR3 ECC RDIMM memory 1600 MHz or faster).
- 9 -
CHAPTER
2

Memory devices must be of the same type, size and speed from the same memory supplier. There
cache memory options are not provided for this server.
lSoftware requirements
lBIOS configuration
2.1.1 Software requirements
The HP ProLiant DL360p Gen8 server runs on the following operating systems:
lMicrosoft Windows Server 2008 (32-bit) (R400.x)
lMicrosoft Windows Server 2008 R2 (64-bit) (R410.x, R43x.x)
lMicrosoft Windows Server 2016 (R510.x)
The server platform runs the latest version of Application Processing Platform (APP) node or Experion
Server (ESVT, ESV, ACE/SCE, ACE-T, EAS, eServer, EApp). Refer to the latest Experion General
Release Software Change Notice for software applications that have been qualified for use on the HP
ProLiant DL360p Gen8 server platform.
2.1.2 BIOS configuration
All HP ProLiant DL360p Gen8 server platforms must have the BIOS version P71 02/11/2014 or later..
2.2 Description
lHoneywell server model number
lEquipment configuration
lElectronics module
lStorage and media devices
lStandard features of HP ProLiant DL360p Gen8 server
2.2.1 Honeywell server model number
This document applies to the Honeywell server platform identified in the following table.
- 10 -
Chapter 2 - Planning

Chapter 2 - Planning
Model
number Description
Part
number
MZ-
PCSV82
Intel® Xeon® Processor E5-2620V2 with 15M Cache, 2.10
GHz, 7.20 GT/s Intel® QPI) or 4GB RDIMM (1x4GB)
/4x146GB 15K RPM Serial- Attach SCSI 6Gbps 2.5in Hot
plug Hard Drive (QTY4)/P420i SAS Controller (512MB
Cache) (RAID 5 configuration).
51155539-
100
(Obsolete)
MZ-
PCEH04
146GB 2.5” 15K RPM SAS HDD to use as a Hot Spare (not
supplied with standard configuration customer need to buy it if
hot spare is required)
51155539-
903
(Obsolete)
EP-
COAS16
Windows Server 2008 COA -
EP-
COAR28
Windows Server 2008 R2 COA -
EP-
COAS16
Windows Server 2016 standard COA -
EP-
COA2K8
Microsoft Windows Server 2008 (32-bit) COA
MZ-
PCEH05
300 GB 2.5" 15 K RPM SAS HDD to use as a Hotspare (Not
supplied with standard configuration. The customer needs to
buy it if hot spare is required.)
51155539-
907
MZ-
PCEM35
8 GB ECC DDR3 RDIMM MEM EXP(1X8 GB) 1600 MHz or
faster
51155539-
908
MZ-
PCSV82
Intel® Xeon® Processor E5-2630V2 (15M Cache, 2.6 GHz,
7.20 GT/s Intel® QPI)/ 8GB RDIMM(1x8GB)/ 4 x300GB 15K
RPM Serial-Attach SCSI 6Gbps 2.5in Hot plug Hard Drive
(QTY4)/P420i SAS Controller (512MB Cache) (RAID 5
configuration).
51155539-
200
2.2.2 Equipment configuration
The Honeywell-based HP ProLiant DL360p Gen8 server can be installed in Honeywell 1000 mm deep
LCN cabinet only.
2.2.3 Electronics module
The tables in this section provide the electronics module for the Honeywell-based HP ProLiant DL360p
Gen8 server.
- 11 -

Typical operating power requirements
Description DC power AC voltage AC RMS current AC power
Electronic assembly N/A 120 (90-132) Vrms
240 (180-260)
Vrms
0.80
0.41
94W
95W
Maximum operating power requirements
Description DC power AC voltage AC RMS current AC power
Electronic assembly N/A 120 (90-132) Vrms
240 (180-260)
Vrms
1.069A
0.522A
128W
125W
Weight and dimensions
Description Height Width Depth Weight
Assembly 432 mm 434.6 mm 698mm 19.2kg
(42.3lb)
Storage and media devices
This server has four 146 GB (Tab 100) or 300 GB (Tab 200) 2.5” 15K RPM SAS hard drives the
standard mass storage, where drives 0, 1, 2 and 3 are in a RAID-5 configuration. The 5th -146 GB (Tab
100) or 300 GB (Tab 200) 2.5” 15K RPM SAS HDD can be used as a hot spare and is optional. You
must order the 5th - 300 GB 2.5” 15K RPM SAS HDD separately using the model number P/N MZ-
PCEH05.
The server is shipped with a HP USB QWERTY keyboard and mouse. However, if you require a
Honeywell supplied monitor then you must order it separately.
All mass storage devices are connected through SATA and PCIe. SATA DVDRW drive is connected
through the SATA connector on the motherboard. The RAID-5 SAS controller card is located on server
motherboard.
2.2.4 Standard features of HP ProLiant DL360p Gen8 server
The common features of HP ProLiant DL360p Gen8 server are as follows:
lIntel Xeon E5-2620 V2 Ivy Bridge 2.1 GHz or E5 2630V2 2.6 GHz 4 x 256KB L2 Cache 15MB L3
Cache 80W Hexa-Core Processor
l8 GB RAM (using 1x8 GB DDR3 ECC RDIMM memory 1600 MHz or faster)
lEnergy Smart – Two hot-plug high-efficient 460 W power supply
lTwo 110 volt / 230 volts power cords
- 12 -
Chapter 2 - Planning

Chapter 2 - Planning
lSATA DVD-RW drive
lFour 300 GB, 15K RPM, 2.5” SAS hard drives
lIntegrated Matrox G200 video standard
lHP smart array P420i 512MB RAID 5 Configuration
lRear ports with 1 serial, 1Video, 4 USB V2.0, 4 RJ45, 1 ID push button with blue/amber LED
lFront ports with 2 USB 2.0, ID push button with blue/amber LED, 1 video, 1 system power on/off
button
lFour flexible LOM Broadcom® NetXtreme II™ 5709c Gigabit Ethernet NIC with failover and load
balancing
lBus type is PCIe
lConsists of one x4 low profile and one x16 half length full height expansion slot
2.3 Platform information
2.3.1 Honeywell documentation
The following table lists other Honeywell publications that may be useful when installing or operating
the server platform.
Publication Contains information on
FE05: Fault Tolerant Ethernet Installation and Service
Guide
Installing and using FTE.
2.3.2 HP documentation
The following table lists HP publications and other sources of information that is useful when installing,
operating, and servicing the Honeywell server.
Publication Contains information on Available
Information Update Last-minute updates about technical
changes to your computer or advanced
technical-reference material for
experienced users or technicians.
Packaged with the
computer
HP ProLiant
DL360p Gen8
Server
Maintenance and
Service Guide
Maintenance and service information for
the server.
http://www.hp.com
HP ProLiant
DL360p Gen8
Server User Guide
Using the server http://www.hp.com
- 13 -

2.4 Slots configuration
NOTE
A Local Control Network Processor (LCNP) board and LCN Media Access Unit (MAU) are no
longer used if the Server has been upgraded to be an ELCN node.
HP ProLiant DL360p Gen8 server has one riser. The details of the slot are as follows:
Expansion slot Type Form factor Connector width Bus width
1 PCIe3 Low Profile Slot x 8 x 8
2 PCIe3 Full height half length slot X 16 X 16
The following is a list of options that can be configured in your platform.
Model number Honeywell part number Description
TP-LCNP04 51405098-100 LCN Interface card PCIe
TP-LCNP05 51454493-126 LCN Interface PCIe Rev2
lSlot configuration for Experion node setup
lSlots configuration
lGeneral Ethernet configuration
lCnet configuration using PCIC interface
2.4.1 Slot configuration for Experion node setup
FTE Supervisory (Default)
NIC1 and NIC2 onboard NIC.
Slot number Description
Slot-1 -
Slot-2 -
2.4.2 Slots configuration
NOTE
A Local Control Network Processor (LCNP) board and LCN Media Access Unit (MAU) are no
longer used if the Server has been upgraded to be an ELCN node.
HP ProLiant DL360p Gen8 server has one riser. The details of the slot are as follows:
- 14 -
Chapter 2 - Planning

Chapter 2 - Planning
Expansion slot Type Form factor Connector width Bus width
1 PCIe3 Low Profile Slot x 8 x 8
2 PCIe3 Full height half length slot X 16 X 16
The following is a list of options that can be configured in your platform.
Model number Honeywell part number Description
TP-LCNP04 51405098-100 LCN Interface card PCIe
TP-LCNP05 51454493-126 LCN Interface PCIe Rev2
lSlot configuration for Experion node setup
lSlots configuration
lGeneral Ethernet configuration
lCnet configuration using PCIC interface
2.4.3 General Ethernet configuration
Single NIC (One on-board NIC)
Slot number Description
Slot-1 -
Slot-2 -
Dual NICs (Two on-board NIC)
Slot number Description
Slot-1 -
Slot-2 -
2.4.4 Cnet configuration using PCIC interface
You must purchase the Magma PE3R PCie to PCI converter box separately and use it, since the HP
DL360p Gen 8 server does not natively support the PCI interface.
For more information, refer to the section Configuring ControlNet interface card.
Slot number Description
Slot-1 Magma PCIe host adapter1
Slot-2 -
- 15 -

1Magma PCIe host adapter interface needs to be done using low profile bracket supplied with
Magma.
2.5 Memory configuration
Tab 100 : 4GB (1x4GB) RDIMM 1600 MHz and Tab 200 : 8GB (1x8GB) RDIMM 1600 MHz or faster is
the standard memory configuration for this server.
The label on the outside of the shipping container identifies the capacity of the memory installed.
Honeywell uses the Memory Expansion Model number to help the supplier identify the memory that
must be added with the platform.
Honeywell model
number Description
MZ-PCEM28 4 GB ECC RDIMM MEM EXP (1x4 GB) 1600 MHz or
faster
MZ-PCEM35 8 GB ECC RDIMM MEM EXP(1X8 GB) 1600 MHz or
faster
lStandard memory configuration for 4GB using RDIMM
lStandard memory configuration
lMaximum memory configuration
2.5.1 Standard memory configuration for 4GB using RDIMM
The following table provides the memory configuration for Intel Xeon E5-2620 V2 Ivy Bridge 2.1GHz
processor with 4GB, consisting of one 4GB (1600MHz) RDIMM or faster.
Channels Slot numbers
CPU1
Population order
Channel 1 12 A; 4GB RDIMM
11 E; empty
10 I; empty
Channel 2 9 B; empty
8 F; empty
7 J: empty
Channel 3 1 C; empty
2 G; empty
3 K; empty
- 16 -
Chapter 2 - Planning

Chapter 2 - Planning
Channels Slot numbers
CPU1
Population order
Channel 4 4 D; empty
5 H; empty
6 L; empty
2.5.2 Standard memory configuration
Tab 100 — The following table provides the memory configuration for Intel Xeon E5-2620 V2 Ivy Bridge
2.1GHz processor with 8GB, consisting of two 4 GB ECC RDIMM (2x4) GB (1600MHz) or faster.
Channels Slot numbers
CPU1
Population order
Channel 1 12 A; 4GB RDIMM
11 E; empty
10 I; empty
Channel 2 9 B; 4GB RDIMM
8 F; empty
7 J: empty
Channel 3 1 C; empty
2 G; empty
3 K; empty
Channel 4 4 D; empty
5 H; empty
6 L; empty
Tab 200 — The following table provides the memory configuration for Intel Xeon E5-2630 V2 Ivy Bridge
2.60 GHz 8GB, consisting of One 8 GB ECC RDIMM MEM EXP (1x8 GB) 1600 MHz or faster.
Channels Slot numbers
CPU1
Population order
Channel 1 12 8 GB RDIMM
2.5.3 Maximum memory configuration
Tab 200 — Maximum memory 16GB DDR3 ECC RDIMM (2x8GB) 1600MHz or faster
- 17 -

Channels Slot numbers
CPU1
Population order
Channel 1 12 8GB DDR3 ECC RDIMM
Channel 2 9 8GB DDR3 ECC RDIMM
NOTE
If customer has 51155539-100 with base memory as 4GB.Then order 2 Nos of MZ-PCEM28 to
make it 16GB, Mounting will be as follows
Channels Slot numbers
CPU1
Population order
Channel 1 12 4GB DDR3 ECC RDIMM
Channel 2 9 4GB DDR3 ECC RDIMM
Channel 3 1 4GB DDR3 ECC RDIMM
Channel 4 4 4GB DDR3 ECC RDIMM
If customer has 51155539-200 with base memory as 8GB (1x8GB).Then order 2 No of MZ-
PCEM35 to make it 16GB, Mounting will be as shown above.
2.6 System specifications
2.6.1 Microprocessor
Microprocessor Intel Xeon E5-2620 V2 or Intel Xeon E5-2630 V2 Ivy Bridge 80W
Hexa-Core Processor
Level 2 Cache 1MB
Level 3 Cache 15MB
Chipset Intel® C600 Series Chipset
2.6.2 Expansion slots
PCIe riser Slot1: Low Profile x 8 PCIe 3.0
Slot2: Full-height/half-length x 16 PCIe 3.0
- 18 -
Chapter 2 - Planning

Chapter 2 - Planning
2.6.3 Memory
Architecture 4 GB (1x4 GB) DDR3-12800 or 8 GB (1x 8 GB) or faster
DIMM sockets 24 RDIMM socket
DIMM
capacities
4 GB or 8 GB DDR3 ECC RDIMM
Minimum RAM Tab 100 4 GB (1x4 GB) / Tab 200 8 GB (1x 8 GB) DDR3 ECC
RDIMM for faster
Maximum
RAM
Tab 200 8 GB (2x4 GB) / Tab 200 16 GB (2x 8 GB) DDR3 ECC
RDIMM for faster
2.6.4 Raid controller
RAID
controller
HP Smart Array P420i 512MB FBWC RAID 5 Configuration ( 4 HDD
on RAID)
2.6.5 Optical disk drive
DVD drive SATA DVD R/W
2.6.6 Video
Video type Integrated Matrox G200 video standard
2.6.7 Network interface
Adapter type 4 port (PCIe express 4 lens) HP Flexible LOM
2.6.8 Power
The following provides the specifications for DC power supply.
Wattage Energy Smart – Two hot-plug high-efficient 460W PSU
- 19 -

2.6.9 Environmental
Operating
temperature
+10° to +35° C (50° to 95° F) with a maximum temperature gradation of
10° per hour.
Note : for Altitudes above 2950 feet , the maximum operating
temperature is derated 1°F/550ft.
The displayed temperature ratings are for sea level. An altitude derating
of 1°C per 300 m (1.8°F per 1,000 ft) to 3048 m (10,000 ft) is applicable.
No direct sunlight allowed.
Shipping
temperature
-30°C to 50°C (-22°F to 122°F)
Storage
temperature
-30°C to 60°C (-22°F to 140°F)
Maximum
wet bulb
temperature
28°C (82.4°F)
ATTENTION
All temperature ratings described previously are for sea level.
An altitude derating of 1°C per 300 m (1.8°F per 1,000 ft) to
3048 m (10,000 ft) is applicable. Direct sunlight is not allowed.
Operating
humidity
10% to 90% (non-condensing) with a maximum humidity gradation of
10% per hour
Storage
humidity
5% to 95% (non-condensing) ) with a maximum humidity gradation of
10% per hour
ATTENTION
Storing maximum humidity of 95% is based on a maximum
temperature of 45°C (113°F). Altitude maximum for storage
corresponds to a pressure minimum of 70 KPa.
2.6.10 Physical – form factor
1U rack height 1U, HP Friction Rail Kit
2.6.11 Drive bays
Internal Up to 8 bay SFF Hot plug Drive Cage
External Slim optical drive
- 20 -
Chapter 2 - Planning
