Honeywell DG-T Series User manual

CONTENTS
Cert. Version 04.20 · Edition 01.22 · EN · 03251549
EN, FR, ES – www.docuthek.com
Pressure switches for gas DG..T
1 Safety ................................1
2 Checking the usage .....................2
3 Installation ............................2
4 Wiring................................3
5 Adjustment............................3
6 Pressure switches with manual reset ........4
7 Tightness test..........................4
8 Maintenance cycles .....................4
9 Accessories ...........................4
10 Technical data ........................5
11 Certification ..........................6
12 Logistics .............................6
13 Disposal .............................6
1 SAFETY
1.1 Please read and keep in a safe place
Please read through these instructions care-
fully before installing or operating. Following the installa-
tion, pass the instructions on to the operator. This unit
must be installed and commissioned in accordance
with the regulations and standards in force. These
instructions can also be found at www.docuthek.com.
1.2 Explanation of symbols
1, 2, 3, a, b, c = Action
➔= Instruction
1.3 Liability
We will not be held liable for damage resulting from
non-observance of the instructions and non-com-
pliant use.
1.4 Safety instructions
Information that is relevant for safety is indicated in the
instructions as follows:
DANGER
Indicates potentially fatal situations.
WARNING
Indicates possible danger to life and limb.
CAUTION
Indicates possible material damage.
All interventions may only be carried out by qualified
gas technicians. Electrical interventions may only be
carried out by qualified electricians.
1.5 Conversion, spare parts
All technical changes are prohibited. Only use OEM
spare parts.
OPERATING INSTRUCTIONS

DG..T · Edition 01.22
EN-2
2 CHECKING THE USAGE
Gas pressure switches DG..T for monitoring increasing
and decreasing gas or air pressure.
Type Positive pressure Negative
pressure
DG..T,
DG..FT
Gas, air, flue gas,
biogas Air, flue gas
DG..HT,
DG..NT
Gas, air, flue gas,
biogas Air, flue gas
DG..ST NH3, O2, air –
DG..NT and DG..HT lock off after switching. They can
be unlocked using the manual reset.
This function is only guaranteed when used within the
specified limits– see page 5 (10 Technical data).
Any other use is considered as non-compliant.
2.1 Type code
DG Pressure switch for gas
6
Adjusting range 0.2–2.4 “WC (0.5-6mbar)
10 Adjusting range 0.4–4 “WC (1-10mbar)
50 Adjusting range 1–20 “WC (2.5-50mbar)
150 Adjusting range 12–60 “WC (30-150mbar)
500 Adjusting range 40–200 “WC (100-500mbar)
HSwitches and locks off with rising pressure
NSwitches and locks off with falling pressure
FSwitches with falling positive pressure
SSwitches with rising and falling positive
pressure; for O2, NH3and air; without approval
TT-product
GWith gold-plated contacts
-2 Electrical connection via screw terminals,
1/2" NPT Conduit, NEMA 4 (IP 65)
-4 Electrical connection via screw terminals,
cable gland, NEMA 4 (IP 65)
-9 Electrical connection via 4-pin plug, with
socket, NEMA 4 (IP 65)
1NPT connection 1x 1/4"
2NPT connection 2x 1/4"
NBlue pilot lamp for 120V AC
T2 Red/green pilot LED for 110 to 230V AC
K2 Red/green pilot LED for 24V DC/AC
AExternal adjustment
Letter H, N, F, S omitted = DG..T switches with rising pressure
2.2 Part designations
1
2
3
4
5
1 Upper housing section with cover
2 Lower housing section
3 Hand wheel
4 1/2" conduit coupling
5 Manual reset (DG..NT and DG..HT only)
2.3 Type label
DG..T
Approval and type: see type label.
For detailed information on the adjusting range, mean
switching differential, max. inlet pressure, lock-off, me-
dium and switching properties, see page 5 (10
Technical data) und and the table on page 3 (5
Adjustment).
3 INSTALLATION
CAUTION
Please observe the following to ensure that the
DG..T is not damaged during installation and
operation:
– Dropping the device can cause permanent
damage. In this event, replace the entire device
and associated modules before use.
– Use approved sealing material only.
– Continuous operation with gases containing
more than 0.1%-by-vol. H2S or ozone
concentrations exceeding 200µg/m3accelerate
the ageing of elastomer materials and reduce
the service life.Check max. ambient temperature
– see page 5 (10 Technical data).
– When using silicone tubes, only use silicone
tubes which have been sufficiently cured.
– Vapours containing silicone can adversely affect
the functioning of electrical contacts.
– Condensation or vapours containing silicone
must not be allowed to get into the housing. At
subzero temperatures, malfunctions/failures due
to icing can occur.
– When installing outdoors, place the DG..T in a
roofed area and protect from direct sunlight
(even IP 65 version).
– Avoid strong impact on the unit.
Installation position
p
s=SK ps=SK+ 0,08 "WC ps=SK-
0,08 "WC
➔ Installation position as required, preferably with
vertical diaphragm. Then the switching point p
S
corresponds to the scale value SK set on the hand
wheel. In other installation positions, the switching
point pSwill change and no longer correspond to
the scale value SK set on the hand wheel. Check
the switching point.

DG..T · Edition 01.22
EN-3
CAUTION
If port 4is at the top, IP 65 will not be satisfied.
4
IP 65
➔ The DG..T must not be in contact with masonry.
Minimum clearance 1" (25mm).
➔Ensure that there is sufficient installation space.
➔Ensure unobstructed view of the hand wheel.
1 Disconnect the system from the electrical power
supply.
2 Close the gas supply.
3 Ensure that the pipeline is clean.
Ports
4
1or 2for
positive pressure (¼" NPT)
4 for
negative pressure (1/8 "
NPT)
1
2*
Pres-
sure Connect Free
Positive 1or 2*4
Negative 4 1 or 2*
Differen-
tial
1 or 2*for higher absolute pressure.
4for lower absolute pressure.
*Port 2only on DG..T..2 with 2x ¼” NPT connections.
CAUTION
Port 4connects the upper diaphragm chamber
with the micro switch. Do not connect port 4to
pipes carrying gas.
➔ The pressure switches are supplied with an inte-
grated vent limiter. In the event of a diaphragm
tear, the vent limiter limits the escape of gas to less
than 1.0 CFH of natural gas at 2.4psi (DG..6T) or
7psi (DG..10T – DG..500T). If necessary, port 4
(1/8" NPT) can be used to connect the venting line.
➔ A filter pad at port 4protects the electrical contacts
in the DG..T from dirt particles in the surrounding
air or in the medium.
➔ Filter pad for port 4: The web app PartDetective
for selecting spare parts is available at www.ad-
latus.org.
4 WIRING
CAUTION
– To ensure that the DL is not damaged during
operation, note the switching capacity, see
page 5 (10 Technical data).
In the case of low switching capacities, such as 24V,
8mA, for example, we recommend using an RCmod-
ule (22Ω, 1μF) in air containing silicone or oil.
1 Disconnect the system from the electrical power
supply.
2 3 4
5
½" NPT Conduit:
ø 0.4" (10 mm)
6
NC
1
COM
3
NO
2
NO
2
NC
1
COM
3
½"NPT
➔ DG..FT, DG..NT: the NO-to-COM connection is inter -
rupted if the pressure drops (contacts 3and 2open).
DG..T, DG..HT: the NC-to-COM connection is inter-
rupted if the pressure rises (contacts 3and1open).
5 ADJUSTMENT
➔The switching point is adjustable via hand wheel.
1 Disconnect the system from the electrical power
supply.
2 Detach the housing cover.
➔ Tightening torques, see page 5 (10 Technical
data).
3 Connect an ohmmeter.
COM
3
NC
1
NO
2
NO
2
NC
1
COM
3
4 Set the switching point using the hand wheel.
5 Connect a pressure gauge.
6
0
1 cm = 1 mbar
(0.4"= 0.4"WC)
7 Apply pressure. In doing so, monitor the ohmmeter
and the pressure gauge.
➔If the DG..T does not trip at the desired switching
point, correct the adjusting range using the hand
wheel. Relieve the pressure and repeat the process.

DG..T · Edition 01.22
EN-4
Pressure switches (DG..T, DG..FT, DG..ST):
Type
Adjust-
ing
range1)
"WC
(mbar)
Mean
switch-
ing
differ-
ential2)
"WC
(mbar)
Max. inlet
pressure
psi (mbar)
With
venting
line3)
No
venting
line
DG6T 0.2–2.4
(0.5–6)
0.08–
0.12
(0.2–0.3)
8.5
(600)
2.4
(165)
DG10T 0.4–4
(1–10)
0.1–0.16
(0.25–
0.4)
8.5
(600)
7
(480)
DG50T 1–20
(2.5–50)
0.32–0.6
(0.8–1.5)
8.5
(600)
7
(480)
DG150T 12–60
(30–150)
1.2–2
(3–5)
8.5
(600)
7
(480)
DG500T
40–200
(100–
500)
3.2–6.8
(8–17)
8.5
(600)
7
(480)
Pressure switches with manual reset (DG..HT,
DG..NT):
Type
Adjust-
ing
range1)
"WC
(mbar)
Reset
pres-
sure4)
"WC
(mbar)
Max. inlet
pressure
psi (mbar)
With
venting
line3)
No
venting
line
DG10T 0.4–4
(1–10)
0.16–
0.4
(0.4–1)
8.5
(600)
7
(480)
DG50T 1–20
(2.5–50)
0.4–0.8
(1–2)
8.5
(600)
7
(480)
DG150T 12–60
(30–150)
2–6
(5–15)
8.5
(600)
7
(480)
DG500T
40–200
(100–
500)
6–10
(15–25)
8.5
(600)
7
(480)
1) Adjusting tolerance = ±15% of the scale value.
2) Mean switching differential at min. and max. setting
"WC (mbar).
3) Connect the venting line to port 4. Connections, see
page 2 (3 Installation).
4) Difference between switching pressure and possible
reset.
6 PRESSURE SWITCHES WITH MAN-
UAL RESET
➔DG..NT locks off if the pressure drops to the value
set using the hand wheel.
➔DG..HT locks off if the pressure rises to the value
set using the hand wheel.
1 Reset the pressure switch using the manual reset.
➔Requirement for reset:
DG..NT: the pressure must have risen at least to the
set switching point plus the pressure differential be-
tween the switching pressure and possible lock-off.
DG..HT: the pressure must have dropped at least
to the set switching point minus the pressure differ-
ential between the switching pressure and possible
lock-off.
➔For details of the pressure differential between the
switching pressure and possible reset, see table
on page 3 (5 Adjustment).
7 TIGHTNESS TEST
1 Shut off the downstream gas pipeline close to the
valve.
2 Open the valve and the gas supply.
➔Check all used ports for tightness.
➔N2= 13psi (max. 29psi) <15 minutes
3 N
2
4
8 MAINTENANCE CYCLES
Check for external tightness at least once per annum,
at least twice per annum for operation with biogas.
9 ACCESSORIES
9.1 Blue pilot lamp for 110/120VAC
110/120V AC, I = 1.2mA, Order No.: 74916121.
1 2 3
4

DG..T · Edition 01.22
EN-5
NC
1
COM
3
NO
NO 2
N
NO
2
NC
1
COM
3
L1
N
NC
1
COM
3
NO
NC
2
N
NO
2NC
1
COM
3
L1
N
9.2 Red/green pilot LED for 24V DC/AC or for
110V AC to 230V AC
24V DC, I = 16mA; 24V AC, I = 8mA, Order No.:
74921089.
110V AC to 230V AC, Order No.: 74923275.
1 2 3
4
NC
1
COM
3
NO
2
N
NO
21 NC
3 COM
+
–
9.3 Further accessories
Further information about accessories can be found in
Technical Information bulletin DG (identical to DG..T)
– www.docuthek.com.
10 TECHNICAL DATA
10.1 Safety information
Safety information, see Safety manual DG (identical
to DG..T) – www.docuthek.com.
10.2 Ambient conditions
Maximum medium and ambient temperatures:
DG:-40to+140°F (-40to+60°C).
DG..S: 5to+140°F (-15to+60°C).
Long-term use in the upper ambient temperature
range accelerates the ageing of the elastomer ma-
terials and reduces the service life (please contact
manufacturer).
The set switching point may palpably change in media
and ambient temperatures below -22°F (-30°C).
Transport temperature = ambient temperature.
Storage temperature: -4to+104°F (-20to+40°C).
Enclosure: IP 65.
This unit is not suitable for cleaning with a high-pres-
sure cleaner and/or cleaning products.
10.3 Mechanical data
Gas types: natural gas, town gas, LPG (gaseous),
flue gas, biogas (max. 0.1 %-by-vol. H2S) and air..
Max. inlet pressure pmax. = withstand pressure:
8.5psi (600mbar).
Max. test pressure for testing the entire system:
temporarily (< 15minutes) 29psi (2bar).
Diaphragm pressure switch, silicone-free.
Diaphragm: DG: NBR, DG..S: IIR.
Housing: glass fibre reinforced PBT plastic with low
gas release.
Lower housing section: AlSi 12.
Weight: 9.5 to 11.3 oz (270 to 320 g).
Recommended tightening torque:
Component
Tightening
torque
[Ncm]
Cover screws 65
½" NPT conduit 170 (15 lb")
Rp 1/8 pipe connection on
aluminium lower section 250
Rp 1/4 connection (1/4” NPT) on
aluminium lower section 1300
Rp 1/8 connection on upper
housing section 250
Clamping terminal screws 80
2.76"
(70)
½"
NPT Conduit
0.43"
(11)

DG..T · Edition 01.22
EN-6
10.4 Electrical data
Safety class: 1.
Switching capacity:
Ucosφ
=1 [A]
cosφ
=0.6 [A]
DG..T max. 240V AC max. 5 max. 0.5
DG..TG* < 30V AC/DC max. 0.1 max. 0.05
* With gold contacts
Cable diameter: AWG24 to AWG13 (0.02 to 0.07"
(0.5 to 1.8mm)).
Line entrance: ½" NPT conduit.
Electrical connection type: screw terminals.
11 CERTIFICATION
11.1 China RoHS
Directive on the restriction of the use of hazardous sub-
stances (RoHS) in China. Scan of the Disclosure Table
China RoHS2, see certificates at www.docuthek.com.
FM approved
Factory Mutual Research Klasse: 3510 Flow and pres-
sure safety switches. Designed for applications pursu-
ant to NFPA 85 and NFPA 86. www.approvalguide.com
UL listed
Underwriters Laboratories – UL353 „Limit Controls“,
MH 64186. www.ul.com
12 LOGISTICS
Transport
Protect the unit from external forces (blows, shocks,
vibration).
Transport temperature: see page 5 (10 Technical
data).
Transport is subject to the ambient conditions de-
scribed.
Report any transport damage on the unit or packaging
without delay.
Check that the delivery is complete.
Storage
Storage temperature: see page 5 (10 Technical
data).
Storage is subject to the ambient conditions described.
Storage time: 6months in the original packaging before
using for the first time. If stored for longer than this, the
overall service life will be reduced by the corresponding
amount of extra storage time.
13 DISPOSAL
Devices with electronic components:
WEEE Directive 2012/19/EU – Waste Electrical
and Electronic Equipment Directive
At the end of the product life (number of op-
erating cycles reached), dispose of the pack-
aging and product in a corresponding recycling
centre. Do not dispose of the unit with the usu-
al domestic refuse. Do not burn the product.
On request, old units may be returned carriage paid
to the manufacturer in accordance with the relevant
waste legislation requirements.
© 2022 Elster GmbH We reserve the right to make technical modifications in the interests of progress.
The Honeywell Thermal Solutions family of products includes
Honeywell Combustion Safety, Eclipse, Exothermics, Hauck,
Kromschröder and Maxon. To learn more about our products, visit
ThermalSolutions.honeywell.com or contact your Honeywell Sales
Engineer.
Elster GmbH
Strotheweg 1, D-49504 Lotte
T [phone]
[email protected]
www.kromschroeder.com
Global centralized service deployment coordination:
T [phone] or -555
[email protected]
Translation from the German
FOR MORE INFORMATION
