Honeywell ScanPal EDA71 User manual

ScanPal EDA71
Enterprise Tablet
powered by Android™
User Guide



Disclaimer
Honeywell International Inc. (“HII”) reserves the right to make changes in specifications and other information contained in
this document without prior notice, and the reader should in all cases consult HII to determine whether any such changes
have been made. The information in this publication does not represent a commitment on the part of HII.
HII shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential
damages resulting from the furnishing, performance, or use of this material. HII disclaims all responsibility for the selec-
tion and use of software and/or hardware to achieve intended results.
This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this doc-
ument may be photocopied, reproduced, or translated into another language without the prior written consent of HII.
Copyright 2016-2019 Honeywell International Inc. All rights reserved.
Web Address: www.honeywellaidc.com
Trademarks
Google and Android are trademarks of Google LLC.
Bluetooth trademarks are owned by Bluetooth SIG, Inc., U.S.A. and licensed to Honeywell.
microSD is a registered trademark of SD-3C, LLC.
Qualcomm and Snapdragon are registered trademarks or trademarks of Qualcomm Incorporated in the United States
and/or other countries.
Other product names or marks mentioned in this document may be trademarks or registered trademarks of other compa-
nies and are the property of their respective owners.
Patents
For patent information, refer to www.hsmpats.com.

EDA71 User Guide iii
TABLE OF CONTENTS
Customer Support ........................................................................................................................ ix
Technical Assistance ............................................................................................................. ix
Product Service and Repair ................................................................................................ ix
Limited Warranty .................................................................................................................... ix
Chapter 1 - Tablet Features.............................................................................1
Features of ScanPal EDA71 Enterprise Tablet ................................................................... 1
About EDA71-1 Tablet ........................................................................................................... 1
About the Battery ........................................................................................................................... 3
Charge the Battery Before Use........................................................................................... 4
Replace the Battery................................................................................................................. 4
About the Battery Status....................................................................................................... 6
About the Battery Status LED Setting............................................................................. 6
Check the Battery Level and Usage ................................................................................. 7
About Battery Life and Conservation .............................................................................. 8
Battery Recommendations and Safety Protections................................................... 8
Enable Airplane Mode ........................................................................................................... 9
Power on the Computer ............................................................................................................... 9
Unlock the Screen .......................................................................................................................... 9
Change the Screen Lock to Protect the Computer........................................................ 10
Select a Touch Screen Profile to Optimize Performance............................................. 10
Configure the Screen Backlight ............................................................................................ 11
About the Scan Status LED..................................................................................................... 11
About Audio Features ................................................................................................................ 11
Adjust Speaker Volume ...................................................................................................... 12

iv EDA71 User Guide
Enable Vibrate Mode............................................................................................................12
Audio Settings ........................................................................................................................12
Insert a microSIM or a microSD Card..................................................................................13
How to Transfer Files..................................................................................................................14
Configure USB Connection and Transfer Files .........................................................15
Accessories for the Tablet.........................................................................................................15
Chapter 2 - User Interface and Applications ............................................ 17
About the User Interface...........................................................................................................17
Navigation and Function Buttons..................................................................................18
About Status Bar Icons .......................................................................................................18
Remap a Button or Key........................................................................................................19
Restore Default Button Action .........................................................................................19
View and Manage Notifications ......................................................................................20
Open Quick Settings ............................................................................................................20
Customize the Home Screen ............................................................................................20
Customize the Favorites Tray ...........................................................................................21
Use Google™ Search.............................................................................................................21
About Screen Gestures .......................................................................................................22
Set the Time Zone..................................................................................................................22
About Honeywell Applications................................................................................................23
Applications You Can Download to the Mobile Computer ..........................................24
About Honeywell Enterprise Browser............................................................................24
About Honeywell Launcher...............................................................................................24
Unlock Developer Options .......................................................................................................25
Chapter 3 - Scan Function ............................................................................ 27
Scan Function ...............................................................................................................................27
About Provisioning Mode...................................................................................................27
Scan a Bar Code with the Scan Demo...........................................................................27
About the Scan Wedge Feature .......................................................................................28
Change the Scanner Settings.................................................................................................28
Change the Bluetooth Scanner Settings .....................................................................28

EDA71 User Guide v
Restore Default Scan Settings .........................................................................................29
Default Scan Settings ..........................................................................................................29
Symbology Settings..............................................................................................................31
Decode Settings.....................................................................................................................31
Imager Settings......................................................................................................................32
Trigger Settings ......................................................................................................................32
Notification Settings ............................................................................................................33
Add a Scan Setting Profile..................................................................................................33
Delete a Scan Setting Profile ............................................................................................34
About the Optional Digital Scan Button .............................................................................34
Enable and Configure the Digital Scan Button .........................................................34
Scan Bar Codes.............................................................................................................................35
About the Scan Engine........................................................................................................36
About Scanning Configuration Bar Codes ..................................................................36
Use the Scan Demo App............................................................................................................36
Change the Scan Demo Symbology Settings ............................................................37
Use the Imager as a Flashlight ........................................................................................37
Chapter 4 - Use the Phone.............................................................................39
About the Phone...........................................................................................................................39
Add or Switch Between Network Carriers...........................................................................40
About the microSIM Card Slot..........................................................................................40
Activate the Phone ................................................................................................................40
Make a Phone Call .......................................................................................................................41
Answer the Phone ........................................................................................................................41
Switch Apps During a Phone Call....................................................................................42
Make an Emergency Phone Call ............................................................................................42
Configure Phone Settings ........................................................................................................42
Chapter 5 - Use the Camera ..........................................................................43
About the Color Camera ............................................................................................................43
How to Zoom............................................................................................................................43
Take a Photo...................................................................................................................................44

vi EDA71 User Guide
Change Camera Settings..........................................................................................................44
Record a Video ..............................................................................................................................45
Change Video Settings ..............................................................................................................45
Use the Camera as a Flashlight .............................................................................................45
Chapter 6 - Configure the Tablet ................................................................ 47
How to Configure the Tablet....................................................................................................47
Start the Settings App .........................................................................................................47
About the Structure of the Settings App ......................................................................47
About Network Communications ..........................................................................................54
Connect to a Wi-Fi Network ..............................................................................................54
Connect to an Ethernet Network.....................................................................................56
How to Connect to Virtual Private Networks ..............................................................57
About Wireless Security.............................................................................................................58
About Certificates .................................................................................................................58
About Bluetooth Communications.......................................................................................59
Connect a Bluetooth Device .............................................................................................60
Rename the Computer and View File History ............................................................60
Rename, Share, or Unpair a Paired Device..................................................................61
About the Scanner Edge App............................................................................................61
About Serial and USB Communications.............................................................................62
USB Troubleshooting...........................................................................................................62
How to Share Your Mobile Data Connection ....................................................................63
Share the Data Connection Through USB or Bluetooth........................................63
About Near Field Communication (NFC) ...........................................................................63
Developer Information...............................................................................................................64
About Provisioning Mode .........................................................................................................65
Enable or Disable Provisioning Mode...........................................................................65
Chapter 7 - Mange and Maintain the Tablet............................................. 67
About Software Updates ...........................................................................................................67
About Transferring Files via USB Connection ...........................................................67
Install Software Updates with AutoInstall .........................................................................68

EDA71 User Guide vii
Optional microSD Card Method ......................................................................................68
About the Honeywell Upgrader ..............................................................................................69
How to View the Installed OTA Version .........................................................................69
Install OTA Updates ..............................................................................................................70
Reboot (Restart) the Computer ..............................................................................................71
About Enterprise Data Reset ...................................................................................................71
Before You Begin....................................................................................................................71
Enterprise Data Reset the Computer.............................................................................72
About Full Factory Reset ...........................................................................................................72
Before You Begin....................................................................................................................72
Full Factory Reset the Computer.....................................................................................73
Clean the Tablet ............................................................................................................................73
Appendix A - Specifications ..........................................................................75
Computer Agency Information ...............................................................................................75
Label Locations......................................................................................................................75
Physical and Environmental Specifications .....................................................................75
Bar Code Symbologies Supported ........................................................................................76
N6703 Imager Engine Reading Distances..................................................................77
N6703 Imager Engine Field of View/Resolution ......................................................77

viii EDA71 User Guide

EDA71 User Guide ix
Customer Support
Technical Assistance
To search our knowledge base for a solution or to log in to the Technical Support
portal and report a problem, go to www.hsmcontactsupport.com.
For our latest contact information, see www.honeywellaidc.com/locations.
Product Service and Repair
Honeywell International Inc. provides service for all of its products through service
centers throughout the world. To obtain warranty or non-warranty service, return
your product to Honeywell (postage paid) with a copy of the dated purchase
record. To learn more, go to www.honeywellaidc.com and select Service & Repair at
the bottom of the page.
Note: The following paragraph is used only in Mobility User Guides:
For ongoing and future product quality improvement initiatives, the tablet comes
equipped with an embedded device lifetime counter function. Honeywell may use
the lifetime counter data for future statistical reliability analysis as well as ongoing
quality, repair and service purposes.
Limited Warranty
For warranty information, go to www.honeywellaidc.com and click Get Resources >
Product Warranty.

xEDA71 User Guide

CHAPTER
1
EDA71 User Guide 1
TABLET FEATURES
This chapter introduces the ScanPal EDA71 Enterprise tablet. Use this chapter to
learn about the basic computer features, functions, and accessories.
Features of ScanPal EDA71 Enterprise Tablet
ScanPal EDA71-0 and EDA71-1 (hereinafter called “EDA71” or “tablet”) with
Android operating system will be introduced in this chapter. Users can learn
something about the main features, functions and accessories of the tablet from
this chapter.
About EDA71-1 Tablet
Honeywell EDA71-1 Enterprise Tablet is a smart phone for enterprise users,
delivering stable and secure enterprise data management and wireless
communications through Android operating system. The main features of ScanPal
EDA71-1 are: large-screen display, high-capacity battery, barcode imaging and
extreme robustness.
• Android™ OS.
• 2 GB dynamic RAM and 32GB flash memory / 4 GB dynamic RAM and 64GB
flash memory.
• Large display with sensitive multi-touch screen.
• High-performance area imaging features with an ergonomic scan trigger.
• LTE/UMTS/CDMA/GSM wireless WAN communications ensure high-speed
data transmission and high-fidelity sound support for all network
technologies.
• IEEE 802.11a/b/g/n/ac.
•Bluetooth4.2.
• Near-field communication (NFC) technology for short-range wireless data
transmission.

2EDA71 User Guide
• High value-added software components support professional imaging and
Optical Character Recognition (OCR) features.
• IP64 Ingress Protection.
• Reliable Micro SD slot that supports up to 128GB expansion.
• Integrated GPS receiver.
• 13 mega pixel color camera.
Front View

EDA71 User Guide 3
Back View
About the Battery
EDA71 uses 3.8V rechargeable lithium ion battery as its main power supply. The
battery capacity is 15.2 watt/hour. Battery life is influenced by many factors, such
as: screen brightness, the length of time before the screen automatically go to
sleep, input configurations, extreme temperature and using behaviors, etc.
Note: Honeywell suggests you to keep the battery charged to avoid data loss. Change
battery only after switching off the device as per normal. Switch on the device after
completing change of battery.
If you need to buy a replaceable battery, please contact regional resellers.
Honeywell recommends using only a Honeywell lithium battery; any damage
caused by use of non-Honeywell battery is not covered by warranty.
Camera Flash/Flashlight
Speaker
Power Button
Scan Button
Battery Door Latch
Battery Door
I/O Connector
microSD
Card Slot
SIM Card
Cover/Slot
NFC
Antenna
Location
Camera
Lens

4EDA71 User Guide
Charge the Battery Before Use
Before using EDA71, you need to make sure the battery (model number: BAT-
EDA50) is fully charged. You can charge the battery before or after installing it to
EDA71. It will take about 5 hours for the battery to be fully charged using original
charger, quad bay charger, single cradle charger.
Note: Honeywell recommends recommend using Honeywell’s original charger; any
damage caused by use of non-Honeywell charger is not covered by warranty.
Note: Using the computer while charging the battery increases the time required to reach
a full charge.
Replace the Battery
If your battery power is low, you need to either charge the battery in the computer,
or replace it with a charged battery.
To recharge the battery:
1. Save all files and close any open applications.
2. Press and hold the Power button until the options menu appears:
3. Tap Battery Swap. Follow the on-screen instructions to place the unit in battery
swap mode.
Once the tablet is powered off:
Warning: Improper use of the battery in this device can cause fire or
chemical burns. Please do not disassemble the battery or heat
it to 100°C (212°F) and above, or incinerate the battery. Make
sure waste batteries are properly disposed. Keep out of reach
of children.
Warning: Do not store the battery without using for a long period of time.
If storing the battery for over 3 months, please make sure to
check the remaining battery power capacity is at least 30%
every 3 months.
Warning: Ensure all components are dry prior to mating the computers
and batteries with peripheral devices. Mating wet components
may cause damage not covered by the warranty.

EDA71 User Guide 5
1. Press down the battery cover safety button to move the lock to the unlock
position.
2. Open the battery cover with the battery cover buckle handle
3. Insert the battery (insert the non-connector side first, then press the battery
down to establish a connection between the battery and the phone).
4. Press down the battery cover.
5. Press down the battery cover safety button to move the battery cover safety
lock to the lock position.

6EDA71 User Guide
About the Battery Status
Use the battery icon in the Status bar at the top of the screen to see the charge
level of your battery. If you want more detailed information on your battery, such as
usage time, charge remaining on the battery, or battery health information,
open the Settings app and tap either Battery Honeywell Settings or Battery
Optimizer.
Battery Status Icons
The Battery status LED appears in the upper right corner of the touch screen. The
LED color and behavior (e.g., steady on, blinking, off) indicates the charging status
of the battery. To view status descriptions and to learn how to modify the Battery
LED behavior, see About the Battery Status LED Setting on page 6.
About the Battery Status LED Setting
You can change the behavior of the Battery status LED if the out-of-box behavior
for a charging battery (blinking green) is not acceptable to your environment.
You can choose one of three options:
• Honeywell Battery LED (factory default, out-of-box configuration)
• Default Battery LED (optional Android OS configuration)
• No Battery LED
Honeywell Battery LED Behavior (Factory Default/Out-of-Box Configuration)
Icon Status
The battery charge is at 100%.
The battery charge is at 50%.
The battery charge is low. You need to charge or replace the battery soon.
The battery is critically low. You need to replace the battery now or connect the computer to
a charging accessory.
The computer is connected to external power and the battery is charging.
There is a battery error. Install another battery. If the problem persists, contact Honeywell
technical Support.
Connected to Power LED State Description
No Blinking amber Battery level is below 15%
No Off Battery level is more than 15%
Yes Steady amber Battery level is between 0% and 60%

EDA71 User Guide 7
Default Battery LED Behavior (Optional Android OS Configuration )
Select the No battery LED setting if you want to use the LED as a notification LED
for applications or device management solutions. For more information on how to
use the LED as a notification LED, see http://developer.android.com/guide/
topics/ui/notifiers/notifications.html.
Change the Battery LED Status Behavior
To change the battery status LED behavior:
1. Swipe up from the bottom of the Home screen to access all apps.
2. Tap Settings > Honeywell Settings > Battery LED.
3. Choose one of the options:
•Default Battery LED (optional Android OS configuration)
•Honeywell Battery LED (factory default/out-of-box configuration)
• No Battery LED
Check the Battery Level and Usage
In addition to the Battery status icon and LED, you can monitor the battery status
from the Settings app.
1. Swipe up from the bottom of the Home screen to access all apps.
2. Tap Settings > Battery.
The current percentage of battery power remaining and the amount of usage time
left on the battery appear on the screen. A list shows the battery usage for
individual apps and services. For usage details, select one of the apps or services in
the list. You can also access the Battery saver feature from the battery screen.
Yes Blinking green Battery level is between 60% and 95%
Yes Steady green Battery level is above 95%
Either Blinking red Battery error
Connected to Power LED State Description
No Blinking red Battery level is below 15%
No Off Battery level is 15% or more
Yes Steady red Battery level is below 15%
Yes Steady amber Battery level is between 15% and 90%
Yes Steady green Battery level is 90% or more
No Blinking red Battery level is below 15%
Connected to Power LED State Description

8EDA71 User Guide
About Battery Life and Conservation
If you store the battery outside of the computer for long periods of time, the battery
slowly discharges. To maintain battery performance, storing the battery in a
charger is recommended. Use the reference table below to learn about how to
conserve battery power.
Battery Recommendations and Safety Protections
• Fully charge the battery before using it. The battery is only partly charged when
get packed.
• Refer to the chapter "charging" to get the right process for battery charging.
Using the battery for other devices may cause damages on the device or the
battery.
• Avoid battery or tablet drops. If you suspect that a battery or tablet fails, send it
to Honeywell service center for verification.
• This battery can only replace another BAT-EDA71-X battery. These batteries
have been tested and meet the appropriate safety standards. If you need to
replace the battery, please contact Honeywell service representatives or the
resellers.
When You Want to: Do this to Save Battery Power:
Use the computer and
the low battery status
icon appears or the
battery light turns on.
Do one of the following:
• Connect the computer to a charging accessory.
• Replace the Battery (see page 4).
Stop using the
computer for
5 minutes or more.
Make sure that the low battery status icon is not on the screen and that
the battery status LED is not on. Press and release the Power button to
put the computer to sleep.
Store the computer for
more than a day.
• If you are storing the computer for a few days (e.g., over the weekend),
install a fully charged battery or connect the computer to a power
source.
• If you are storing the computer for a longer period of time, remove and
charge the battery. When the battery is done charging, store both the
battery and the computer in a cool location.
• If you store the battery for several months, recharge the battery
periodically to keep it at peak performance.
Store the battery
outside of the
computer.
Store the batteries in a charger.
Caution: Improper battery replacement or incompatible device usage may
result in risk of burns, fire, explosion, or other hazard. Dispose of
lithium-ion batteries according to local regulations. Risk of fire and
burns if improperly handled. Do not open, crush, heat above 50°C
(122°F), or incinerate.

EDA71 User Guide 9
• There are security risks in waste batteries. Before cleaning up the battery, stick
the poles with insulation tape.
• Do not modify the battery or attempt to insert foreign objects into the battery.
• Do not solder directly to the battery poles.
• Do not short connect the battery and put the battery away from metal objects.
• Do not drop or mechanically shock or extrude the battery.
• Do not disassemble or open the battery. Do not crush, bend or deform the
battery; Do not puncture, shred or burn the battery.
• Do not immerse the battery in water.
Enable Airplane Mode
If you do not need to connect to any wireless networks, you can enable Airplane
mode to turn Off the radios and save battery power.
1. Swipe up from the bottom of the Home screen to access all apps.
2. Tap Settings > Wireless & Networks.
3. Tap the toggle button next to Airplane mode. An airplane icon appears in the
status bar to indicate Airplane mode is turned On.
Power on the Computer
After you have fully charged and installed a battery, power on the computer for the
first time:
•PressandholdthePower button for approximately 3 seconds, and then release
the button.
Unlock the Screen
The screen lock automatically activates every time the computer is turned On or
when the computer wakes from sleep mode.
• Swipe up from the lock icon at the bottom of the screen.
The level of security provided depends on the type of lock set (e.g., Swipe, Pattern,
PIN, or Password). The default setting, Swipe, provides no protection against unau-
thorized access to your computer.

10 EDA71 User Guide
Change the Screen Lock to Protect the Computer
After you start using the computer, you should change the screen lock to prevent
unauthorized persons from accessing the computer after the screen lock activates
unless they input the correct password, pin, or pattern.
The recommended setting for the Screen lock is to enable a Password lock. Use a
strong password value (e.g., include numbers, characters, special characters, and
mix character case).
1. Swipe up from the bottom of the Home screen to access all apps.
2. Tap Settings > Security & location > Screen lock.
3. Choose one of the following options:
•None
• Swipe
• Pattern
•PIN
•Password
4. Follow the on-screen prompts to complete the setup.
Exit the Settings app.
Select a Touch Screen Profile to Optimize Performance
Optimize screen interactions by selecting a touch screen profile designed
specifically for your use case. For example, if you wear gloves, set the touch screen
profile to Glove use enhanced for the best touch screen response.
Note: Maximum glove thickness of 2 mm (0.08 inches) for touch screen response.
1. Swipe up from the bottom of the Home screen to access all apps.
2. Tap Settings > Honeywell Settings.
3. Choose one of the following option:
• Glove enhanced mode
4. Exit the Settings app.
