Honeywell EDA50-211 User manual

ScanPal Series
Terminal (Model EDA50-011/EDA50-111/EDA50-211)
Android™ 7.1 OS version
User Guide

ii User Guide for ScanPal Series Terminal
Disclaimer
Honeywell International Inc. (abbr. HII) reserves the rights to modify the specifications and other information
mentioned in this User Guide without prior notification. In any case, users should confirm with HII whether any
changes were made. This publication does not represent any commitments of HII.
HII is not responsible for any technical or editing errors or omissions contained in this manual, nor for any
incidents or indirect damages caused by providing, implementing or using this material. HII is not responsible for
the softwares or hardwares selected or used in order to achieve the desired results.
The proprietary information contained in this article is protected by copyright. All rights reserved. Without prior
written consent from HII, any form of photocopy, copy or translation into other languages is not allowed.
Trademark Rights
Android, Google and other marks are trademarks of Google Inc.
Other product names mentioned in this manual may be trademarks or registered trademarks of their respective
companies, which are owned by these companies.
Patents
For information on patents, please refer to www.hsmpats.com.
Copyright © 2016 Honeywell International Inc. All rights reserved.

Table of Contents
User Guide for ScanPal Series Terminal iii
Table of Contents
1Product Features of ScanPal Series EDA50-X11 Terminal ..........................................................1
About EDA50-X11 Terminal...............................................................................................................2
Battery...............................................................................................................................................6
Charging ....................................................................................................................................6
Replacing batteries ....................................................................................................................7
Battery icon..............................................................................................................................10
Changing power indicators.......................................................................................................12
Checking the remaining battery capacity .................................................................................13
Battery life and maintenance....................................................................................................13
Battery maintenance recommendations and safety protection measures................................14
Enabling Airplane mode...........................................................................................................14
Powering on....................................................................................................................................15
Unlocking the screen.......................................................................................................................15
Scanning Indicator ..........................................................................................................................16
Setting screen backlight..................................................................................................................16
Backlight for Setting Button.............................................................................................................17
Audio features.................................................................................................................................17
Adjusting the ringtone volume for calls and messages ............................................................17
Enabling vibration mode...........................................................................................................19
Audio settings...........................................................................................................................20
Inserting SD card ............................................................................................................................21
File transfer.....................................................................................................................................22
How to view files on EDA50-X11.....................................................................................................22
EDA50-X11 Accessories .................................................................................................................23
2User interface and applications...................................................................................................24
User interface..................................................................................................................................25
The main interface ...................................................................................................................25
Navigation and function keys ...................................................................................................26
Status bar icons........................................................................................................................26
KeyRemap ...............................................................................................................................27
Viewing system messages.......................................................................................................28
Managing system messages....................................................................................................28
Personalizing the main interface..............................................................................................29
Customizing common applications...........................................................................................29
Using GoogleTM........................................................................................................................29
Touch screen gestures.............................................................................................................29
Setting timezones.....................................................................................................................30
Honeywell applications....................................................................................................................31
Download Enterprise Application Lock (Applock)............................................................................33

Table of Contents
iv User Guide for ScanPal Series Terminal
Unlocking developer options...........................................................................................................33
GMS................................................................................................................................................33
3Scan Function ...............................................................................................................................34
Scan Function.................................................................................................................................35
How to transfer data via Android keyboard input......................................................................35
Changing scan settings............................................................................................................36
Restoring default scan settings................................................................................................37
Scanner default settings...........................................................................................................37
Scanning barcodes..........................................................................................................................43
4Using Telecommunication Function............................................................................................44
Telecommunication Function...........................................................................................................45
Activating calls .........................................................................................................................45
Making a call............................................................................................................................46
Answering a call.......................................................................................................................47
Switching applications during a call..........................................................................................47
Making an emergency call...............................................................................................................47
Configuring call settings..................................................................................................................47
5Using Camera................................................................................................................................48
Color camera...................................................................................................................................49
Adjusting camera and video settings...............................................................................................49
Zooming...................................................................................................................................49
Changing camera settings .......................................................................................................49
Taking photos..................................................................................................................................49
Shooting videos...............................................................................................................................50
Changing video settings..................................................................................................................50
6Configuring Terminal ....................................................................................................................51
Terminal configurations ...................................................................................................................52
Setting launch applications ......................................................................................................52
Structure of the Application Settings.........................................................................................52
Network communication..................................................................................................................57
Connecting to Wi-Fi networks ..................................................................................................57
Connecting to a virtual private network....................................................................................60
Wireless Security ............................................................................................................................61
Certificates...............................................................................................................................61
Bluetooth communication................................................................................................................63
Pairing with a Bluetooth-enabled device..................................................................................63
Configuring Bluetooth settings .................................................................................................65
Searching for EDA50-X11........................................................................................................65
Renaming or disconnecting a paired device.............................................................................65
Communication via serial port and USB..........................................................................................66
Near Field Communication..............................................................................................................66

Table of Contents
User Guide for ScanPal Series Terminal v
7Management and Maintenance ....................................................................................................67
Upgrading system software.............................................................................................................68
Upgrading AutoInstall application.............................................................................................68
Upgrading composite key.........................................................................................................68
Manually upgrading Recovery Menu........................................................................................68
Restarting the Terminal ...................................................................................................................69
Restarting the system ..............................................................................................................69
Restore factory settings ...........................................................................................................70
Cleaning the terminal...............................................................................................................70
Terminal disinfection.................................................................................................................71
8Specifications................................................................................................................................72
Mechanical and environmental specifications.................................................................................72

vi User Guide for ScanPal Series Terminal
Technical Support
If you need installation or troubleshooting help, please contact us via:
Knowledge base: www.hsmknowledgebase.com
Honeywell knowledge base provides thousands of turnkey solutions. If the knowledge base
can't help you solve your problems, you can submit your questions or ask question on
Honeywell technical support website.
Technical support website: www.hsmsupportportal.com
Login Honeywell technical support website to search for knowledge base, submit your
difficulties or questions, ask for call-back services or provide feedbacks. Please provide
more detailed information when filling the forms. You can also upload attachments for
explanation.
Contacts: www.honeywellaidc.com/locations
For the latest contacts, please visit our website.
Product Service and Maintenance
Honeywell International Inc. provides services for all of its products all over the world via
its service centers. For information about the site of service centers, please visit
www.honeywellaidc.com and select English as preferred language, then select Support >
Contact Support > Service and Maintenance. Please contact our service center to get
RMA (Return Material Authorization) numbers before sending the products for
maintenance.
To get Honeywell service during warranty or out of warranty, please send the product
together with the purchase date records to Honeywell service center (postage paid)
Limited Warranty
For information about the warranty, please visit www.honeywellaidc.com and select
English as preferred language, tap Resources > Warranty.
Feedback
Your feedback is very important for us to improve the quality of documentation. Please
contact Technical Communication Departments to submit your feedback on the User Guide:
ACSHSMTechnicalCommunica[email protected].

Chapter 1: Product Features of ScanPal Series EDA50-X11 Terminal
User Guide for ScanPal Series Terminal 1
1Product Features of ScanPal Series
EDA50-X11 Terminal
This chapter is about ScanPal series EDA50-X (X refers to 0 and 1, as in all other cases
below) terminal (hereinafter called “EDA50-X11” or “terminal”) equipped with Android
7.1 OS. Information will be given on the terminal’s basic features, functions and
accessories.

Chapter 1: Product Features of ScanPal Series EDA50-X11 Terminal
2User Guide for ScanPal Series Terminal
About EDA50-X11 Terminal
Honeywell’s EDA50-X11 terminals are smart phones primarily targeted at enterprise users.
It provides, through its Android OS, stable and secure enterprise data management and
wireless communication. The main features of EDA50-X11 are: large-screen display,
high-capacity battery, bar code generation and extreme robustness.
• Android™ 7.1 OS.
• 2 GB dynamic RAM, 8GB flash memory.
• Large display with sensitive multi-touch screen.
• High-performance area imaging features with an ergonomic scan trigger.
• WCDMA / GSM wireless WAN communications ensure high-speed data transmission
and high-fidelity sound support for all network technologies.
• IEEE 802.11a/b/g/n.
• Bluetooth 4.0.
• Near-field communication (NFC) technology for short-range wireless data
transmission.
• High value-added software components support professional imaging and optical
character recognition (OCR) features.
• IP54 Ingress Protection.
• Reliable Micro SD slot that supports up to 32GB expansion.
• Integrated GPS receiver.
• 5 mega pixels color camera.

Chapter 1: Product Features of ScanPal Series EDA50-X11 Terminal
User Guide for ScanPal Series Terminal 3
EDA50-X11 front view
Power Indicator
Scan Indicator
Display
Function Key
Home Key
Return Key

Chapter 1: Product Features of ScanPal Series EDA50-X11 Terminal
4User Guide for ScanPal Series Terminal
EDA50-X11 side and bottom views
Left Side View Right Side View
Power Button
Reset Button
Scan Button
Volume U
p
Volume Down
Scan Button
The Bottom
Charging Contact USB Cover

Chapter 1: Product Features of ScanPal Series EDA50-X11 Terminal
User Guide for ScanPal Series Terminal 5
EDA50-X11 rear view
Scan Engine
Speaker
Battery Cover
Safety Lock
Battery Cover
Buckle
Battery Cover
Safety Button
Camera
Battery Cover
Buckle Handle
Battery
Cover
String
Buckle

Chapter 1: Product Features of ScanPal Series EDA50-X11 Terminal
6User Guide for ScanPal Series Terminal
Battery
EDA50-X11 uses 3.8V rechargable lithium ion battery as its main power supply. The
battery capacity is 15.2 watt/hour. Battery life is influenced by many factors, such as:
screen brightness, the length of time before the screen automatically go to sleep, input
configurations, extreme temperature and using behaviors, etc.
Honeywell suggests you to keep the battery charged to avoid data loss. Change battery only
after switching off the device as per normal. Switch on the device after completing change
of battery.
If you need to buy a replacable battery, please contact regional resellers.
Warning: Improper use of the battery of this device can cause a fire or chemical burns.
Please don't disassemble the battery or heat it to 100 °C (212 °F) and above, or
incinerate the battery. Make sure waste batteries are properly disposed. Keep out of
reach of the children.
We would recommend using only Honeywell’s lithium battery; any damage caused by
use of non-Honeywell battery is not covered by warranty.
Charging
Before using EDA50-X11, you need to make sure the battery (model number
BAT-EDA50K) is fully charged. You can charge the battery before or after installing it to
EDA50-X11. It will take about 5 hours for the battery to be fully charged using original
quad charger (cradle charger or otherwise).
We would recommend using Honeywell’s original charger; any damage caused by use
of non-Honeywell charger is not covered by warranty

Chapter 1: Product Features of ScanPal Series EDA50-X11 Terminal
User Guide for ScanPal Series Terminal 7
Replacing batteries
When the battery power is low, you can charge it together with the terminal, or replace it
with a fully-charged battery.
1. Save all the files and close all running Apps.
2. Long press the power key. Until the follow interface pop up:
3. Tap Turn off.

Chapter 1: Product Features of ScanPal Series EDA50-X11 Terminal
8User Guide for ScanPal Series Terminal
After it's turned off, do as the following instructions manually:
1. Press down the battery cover safety button to move the lock to the unlock position at
right;
2. Open the battery cover with the battery cover buckle handle;

Chapter 1: Product Features of ScanPal Series EDA50-X11 Terminal
User Guide for ScanPal Series Terminal 9
3. Insert the battery (Insert the non-connector side first, then press the battery down to
establish connection between the battery and the phone)
4. Press down the battery cover

Chapter 1: Product Features of ScanPal Series EDA50-X11 Terminal
10 User Guide for ScanPal Series Terminal
5. Press down the battery cover safety button to move the battery cover safety lock to the
lock position at left
Battery icon
Battery icon on the status bar shows the power status of the battery. The following table
only contains several of the icons. For detailed information about battery life and power
remained, please go to Settings > Battery.
Battery icon
Icon Status
Battery power is 100% full
Battery power is 50% full
Battery power is too low. Replacing the battery right now.
The terminal has been connected to external power supply for charging.
Battery failure occurs. Please replace the battery. If the failure still exists,
please contact Honeywell technical support.

Chapter 1: Product Features of ScanPal Series EDA50-X11 Terminal
User Guide for ScanPal Series Terminal 11
Power indicator on the upper left corner of the terminal shows the battery charging status. It
can also be used as system message indicator. For detailed setting methods, please refer to
http://developer.android.com/guide/topics/ui/notifiers/notifications.html.
Default power indicator description
Connect to
power supply Indicator status Description
No Flashing amber (Orange) Battery power is less than 15% full
No No light Battery power is higher than 15% full
Yes Stable amber
(Orange) Battery power is between 0% to 60% full
Yes Flashing green Battery power is between 60% to 95%
full
Yes Stable green Battery power is higher than 95% full
Yes/no Flashing red Battery failure

Chapter 1: Product Features of ScanPal Series EDA50-X11 Terminal
12 User Guide for ScanPal Series Terminal
Changing power indicators
If the default indicators for battery charging (flashing green) is inappropriate for your
environment, you can change the indicator.
In addition to changing the default power indicator, you can also select:
• Default Battery LED
• No Battery LED
If you prefer the indicator to be solid amber and to change to solid green when in charging,
you need to perform Default Battery LED settings. If you prefer the indicator as message
notification (application or device management solution notification) indicator, you need to
select No Battery LED settings.
Default power indicator meanings
Connect to
power supply Indicator status Description
No Flashing red Battery power is less than 15% full
No No light Battery power is 15% or more
Yes Stable red Battery power is less than 15% full
Yes Stable amber Battery power is between 15% to 90%
full
Yes Stable green Battery power is over 90% full
1. Tap Settings> Honeywell Battery LED
2. Select from the following options:
• Default Battery LED
• HSM Battery LED (Factory settings)
• No Battery LED

Chapter 1: Product Features of ScanPal Series EDA50-X11 Terminal
User Guide for ScanPal Series Terminal 13
Checking the remaining battery capacity
Except for the battery icon and power indicator, you can also get the battery capacity
information from Settings.
1. Tap Settings
2. Tap Battery. The current percentage of remaining battery capacity and the remaining
time will be displayed. The list will present the power consumed by each application
and service. For detailed usage information, please tap the respective applications and
services in the list.
Battery life and maintenance
The battery will discharge slowly if it's placed outside of the terminal.
Tips for battery maintenance
If you have the following
needs: Power saving plan:
Low power icon shows on
the screen or the power
indicator lights on when
the terminal is in use
Long press the power key and choose Turn Off.
The terminal will not be in
use for 5 mins or more
Make sure no low power icon displayed and the power
indicator doesn't light on. Switch to sleep mode by
pressing the Power key.
The terminal will be stored
for more than one day
• If you need to store this terminal for several days
(like a weekend), you need to install a fully charged
battery or connect the terminal to the power supply.
• If you need to store it for a longer time, remove the
battery and charge it. Put the terminal and the battery
in a shady and cool place after the battery is fully
charged.
• If the battery is to be stored for several months,
regular charging is needed for excellent battery
performance.
Store the battery outside
the terminal Put the battery in the charger.

Chapter 1: Product Features of ScanPal Series EDA50-X11 Terminal
14 User Guide for ScanPal Series Terminal
Battery maintenance recommendations and safety protection measures
• Fully charge the battery before using it. The battery is only partly charged when get
packed.
• Refer to the chapter "charging" to get the right process for battery charging. Using the
battery for other devices may cause damages on the device or the battery.
• Avoid battery or terminal drops. If you suspect that a battery or terminal fails, send it
to Honeywell service center for verification.
• This battery can only replace another BAT-EDA50-X11 battery. These batteries have
been tested and meet the appropriate safety standards. If you need to replace the
battery, please contact Honeywell service representatives or the resellers.
• There are security risks in waste batteries. Before cleaning up the battery, stick the
poles with insulation tape.
• Do not modify the battery or attempt to insert foreign objects into the battery.
• Do not solder directly to the battery poles.
• Do not short connect the battery and put the battery away from metal objects.
• Do not drop or mechanically shock or extrude the battery.
• Do not disassemble or open the battery. Do not crush, bend or deform the battery; Do
not puncture, shred or burn the battery.
• Do not immerse the battery in water.
Enabling Airplane mode
If you don't need to connect to any wireless network, you can enable the airplane mode to
turn off all wireless receivers to save power.
1. Tap Settings.
2. Tap More under Wireless & Networks.
3. Open Switch control ofAirplane Mode to enable airplane mode.
