Honeywell oneWireless XYR 6000 User manual

Honeywell Process Solutions
OneWireless
XYR 6000 Transmitters
Quick Start Guide
34-XY-25-21
Revision 12
February 2013

Notices and Trademarks
ii OneWireless XYR 6000 Transmitters Quick Start Guide Revision 12
February 2013
Notices and Trademarks
Copyright 2008 by Honeywell International Inc.
Revision 12, February 2013
While this information is presented in good faith and believed to be accurate, Honeywell disclaims the implied
warranties of merchantability and fitness for a particular purpose and makes no express warranties except as may
be stated in its written agreement with and for its customers.
In no event is Honeywell liable to anyone for any indirect, special or consequential damages. The information and
specifications in this document are subject to change without notice.
Honeywell, PlantScape, Experion PKS, and TotalPlant are registered trademarks of Honeywell International Inc.
Other brand or product names are trademarks of their respective owners.
Honeywell Process Solutions
1860 West Rose Garden Lane
Phoenix, AZ 85027

About This Document
Revision Information
Revision 12 OneWireless XYR 6000 Transmitters Quick Start Guide iii
February 2013
About This Document
This document describes mounting, installation and wiring of the XYR 6000 Wireless Transmitters and antennae.
Configuration, authentication and operation are covered in other documents.
Honeywell does not recommend using devices for critical control where there is a single point of failure or where
single points of failure result in unsafe conditions. OneWireless is targeted at open loop control, supervisory
control, and controls that do not have environmental or safety consequences. As with any process control solution,
the end-user must weigh the risks and benefits to determine if the products used are the right match for the
application based on security, safety, and performance. Additionally, it is up to the end-user to ensure that the
control strategy sheds to a safe operating condition if any crucial segment of the control solution fails.
Revision Information
Document Name
XYR 6000 Transmitters Quick Start Guide Document No.
34-XY-25-21
Rev. No.
Publication
Date
ATEX and IECEx control drawings and Multi DI manual added 5 April 2009
Product Ratings tables, STUW700/701/8x0, Universal IO, 2dBi and 4dBi
antenna and 24V Power Supply details added 6 Sept 2009
FM/CSA/IECEx approval updates 7 Nov 2009
ATEX approval updates 8 March 2010
ISABattery Pack added 9 October 2010
Flange Mount and Remote Seal data, updated Approvals information 10 March 2012
Installation Drawings 11 April 2012
Reference documents and OW R210 software release added 12 February 2013
References
The following list identifies all documents that may be sources of reference for material discussed in this publication.
Document Title Document number
OneWireless XYR 6000 Pressure Transmitter User's Manual 34-XY-25-15
OneWireless XYR 6000 Temperature and DI Transmitter User's Manual 34-XY-25-16
OneWireless XYR 6000 HLAI Transmitter User's Manual 34-XY-25-17
OneWireless XYR 6000 SmartCET Corrosion Transmitter User's Manual 34-XY-25-18
OneWireless XYR 6000 Multi Discrete Input Transmitter User's Manual 34-XY-25-27
OneWireless XYR 6000 Universal Input/Output User's Manual 34-XY-25-30
Continued on next page

About This Document
Support and Contact Info
iv OneWireless XYR 6000 Transmitters Quick Start Guide Revision 12
February 2013
References (continued)
OW-CDX010 OW-CDX010
OneWireless Wireless Builder User’s Guide OW-CDX060
OneWireless Builder Parameter Reference OW-CDX070
OW R210 Hardware Planning and Installation Guide OW-CC0010
OW R210 Wireless Device Manager User’s Guide OW-CC0020
OW R210 Field Device Access Point User’s Guide OW-CC0030
OneWireless R210 Parameter Reference Dictionary OW-CC0050
OneWireless R210 Migration Users Guide OW-CC0080
OW R210 Software Change Notice OW-CCSCN1
Support and Contact Info
United States and Canada
Contact: Honeywell Process Solution
Global Technical Support - Phone: [phone]
Customer Service (HFS) - Phone: [phone]
Outside United States - Phone: [phone]
Calls are answered by dispatcher between 6:00 am and 4:00 pm Mountain Standard
Time. Emergency calls outside normal working hours are received by an answering
service and returned within one hour.
Email support: [email protected]
Mail: Honeywell Process Solutions
1860 West Rose Garden Lane,
Phoenix, Arizona 85027
For more contact details for Europe, Asia, North and South Americas, please see back page.
World Wide Web
Honeywell Process Solution Support Online:
www.honeywellprocess.com/
Elsewhere
Call your nearest Honeywell office. See back page for details.
Training Classes
Honeywell Automation College:
http://www.automationcollege.com

About This Document
Symbol Definitions
Revision 12 OneWireless XYR 6000 Transmitters Quick Start Guide v
February 2013
Symbol Definitions
The following table lists those symbols used in this document to denote certain conditions.
Symbol Definition
ATTENTION: Identifies information that requires special consideration.
TIP: Identifies advice or hints for the user, often in terms of performing a
task.
CAUTION Indicates a situation which, if not avoided, may result in equipment or
work (data) on the system being damaged or lost, or may result in the
inability to properly operate the process.
CAUTION: Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury. It may also be used to
alert against unsafe practices.
CAUTION symbol on the equipment refers the user to the product
manual for additional information. The symbol appears next to required
information in the manual.
WARNING: Indicates a potentially hazardous situation, which, if not
avoided, could result in serious injury or death.
WARNING symbol on the equipment refers the user to the product
manual for additional information. The symbol appears next to required
information in the manual.
WARNING, Risk of electrical shock: Potential shock hazard where
HAZARDOUS LIVE voltages greater than 30 Vrms, 42.4 Vpeak, or 60
VDC may be accessible.
ESD HAZARD: Danger of an electro-static discharge to which
equipment may be sensitive. Observe precautions for handling
electrostatic sensitive devices.
Protective Earth (PE) terminal: Provided for connection of the
protective earth (green or green/yellow) supply system conductor.
Functional earth terminal: Used for non-safety purposes such as noise
immunity improvement. NOTE: This connection shall be bonded to
Protective Earth at the source of supply in accordance with national local
electrical code requirements.
Earth Ground:Functional earth connection. NOTE: This connection
shall be bonded to Protective Earth at the source of supply in
accordance with national and local electrical code requirements.
Chassis Ground: Identifies a connection to the chassis or frame of the
equipment shall be bonded to Protective Earth at the source of supply in
accordance with national and local electrical code requirements.
continued

About This Document
Symbol Definitions
vi OneWireless XYR 6000 Transmitters Quick Start Guide Revision 12
February 2013
Symbol Definition
The Factory Mutual®Approval mark means the equipment has been
rigorously tested and certified to be reliable.
The Canadian Standards mark means the equipment has been tested
and meets applicable standards for safety and/or performance.
The Ex mark means the equipment complies with the requirements of
the European standards that are harmonised with the 94/9/EC Directive
(ATEX Directive, named after the French "ATmosphere EXplosible").
For radio equipment used in the European Union in accordance with the
R&TTE Directive the CE Mark and the notified body (NB) identification
number is used when the NB is involved in the conformity assessment
procedure. The alert sign must be used when a restriction on use
(output power limit by a country at certain frequencies) applies to the
equipment and must follow the CE marking.
The C-Tick mark is a certification trade mark registered to ACMA
(Australian Communications and Media Authority) in Australia under the
Trade Marks Act 1995 and to RSM in New Zealand under section 47 of
the NZ Trade Marks Act. The mark is only to be used in accordance with
conditions laid down by ACMA and RSM. This mark is equal to the CE
Mark used in the European Union.
N314 directly under the logo is Honeywell’s unique supplier identification
number.
The INMETRO (Brazil) mark means the tested and meets applicable
standards for safety

Contents
Symbol Definitions
Revision 12 OneWireless XYR 6000 Transmitters Quick Start Guide vii
February 2013
Contents
1. INTRODUCTION....................................................................................................1
1.1 Site preparation.............................................................................................................................1
1.2 European Union Usage.................................................................................................................1
1.3 Certifications and Approvals.......................................................................................................2
Hazardous location certifications............................................................................................................................2
Electrical Data: .......................................................................................................................................................6
Battery....................................................................................................................................................................6
DC Supply..............................................................................................................................................................6
1.4 Conditions of Certification...........................................................................................................6
IECEx Conditions of Certification ...........................................................................................................................6
ATEX Conditions for Safe Use ...............................................................................................................................6
1.5 Maximum Working Pressure:.......................................................................................................6
1.6 Radio Certifications ......................................................................................................................7
Radio Frequency (RF) statement ...........................................................................................................................7
European Union restriction.....................................................................................................................................7
Restriction ..............................................................................................................................................................7
Japanese Restrictions............................................................................................................................................7
2. TRANSMITTER MOUNTING .................................................................................9
2.1 Weight ............................................................................................................................................9
2.2 Dimensions..................................................................................................................................10
2.3 Installation drawing number tables...........................................................................................16
2.4 Transmitter location....................................................................................................................17
Pressure models...................................................................................................................................................17
2.5 Conduit / Cable Entries...............................................................................................................17
2.6 Bracket mounting........................................................................................................................18
Attach bracket to pipe...........................................................................................................................................18
Attach transmitter to bracket.................................................................................................................................19
2.7 Remote Seal Transmitter Mounting...........................................................................................20
2.8 Rotate transmitter housing ........................................................................................................21
2.9 Rotate display..............................................................................................................................21
Tools required ......................................................................................................................................................21
Procedure.............................................................................................................................................................21
Display adjustment...............................................................................................................................................22
3. PROCESS INSERTION .......................................................................................23
3.1 Pressure models .........................................................................................................................23
Piping ...................................................................................................................................................................23
Process connections ............................................................................................................................................25
General piping guidelines.....................................................................................................................................26
Insert probe into process......................................................................................................................................27
Integral probe wiring.............................................................................................................................................27
Remote probe wiring ............................................................................................................................................27

Contents
Symbol Definitions
viii OneWireless XYR 6000 Transmitters Quick Start Guide Revision 12
February 2013
3.2 HLAI models ................................................................................................................................28
Connect wiring.....................................................................................................................................................28
3.3 Universal I/O ................................................................................................................................29
Connect wiring.....................................................................................................................................................29
Wiring for calibration – XYR6000 Universal I/O Wiring Diagrams for AI/DI (Model STUW700) ...........................30
Wiring for calibration – XYR 6000 Universal I/O Wiring Diagrams for AI/DI/DO (Model STUW701)....................31
3.4 Corrosion models .......................................................................................................................33
Probe mounting locations.....................................................................................................................................33
Probe installation .................................................................................................................................................36
Connect wiring.....................................................................................................................................................37
4. ANTENNA ADJUSTMENT AND MOUNTING ..................................................... 38
4.1 Requirements ..............................................................................................................................38
Radio installation requirements............................................................................................................................38
4.2 Integral antenna...........................................................................................................................38
Elbow...................................................................................................................................................................39
Straight.................................................................................................................................................................39
4.3 Remote antenna ..........................................................................................................................40
Outdoor installation warnings...............................................................................................................................40
Choosing a Mounting Location.............................................................................................................................41
Site Selection.......................................................................................................................................................41
Mounting the Antenna..........................................................................................................................................42
Directional mounting procedure...........................................................................................................................44
Omnidirectional mounting procedure ...................................................................................................................45
Grounding the antenna ........................................................................................................................................45
5. START UP ...........................................................................................................47
5.1 Battery Power Option .................................................................................................................47
Connect batteries.................................................................................................................................................47
IS Battery Holder, 50025288-502.........................................................................................................................48
Battery replacement procedure............................................................................................................................49
IS Battery Pack, 50047517-501...........................................................................................................................50
IS Battery Pack replacement procedure ..............................................................................................................50
24 Vdc Power Supply Option (DC) System Diagram ...........................................................................................52
5.2 Display sequence........................................................................................................................53
5.3 Provisioning.................................................................................................................................53
6. CERTIFICATION INSTALLATION REQUIREMENTS......................................... 55
6.1 Certification Drawings................................................................................................................55
EC Declaration of Conformity...............................................................................................................................55
Schedule..............................................................................................................................................................56
CSA Installation Drawings....................................................................................................................................58
ATEX Control Drawings.......................................................................................................................................81
IECEx Control Drawings ......................................................................................................................................93

Tables
Revision 12 OneWireless XYR 6000 Transmitters Quick Start Guide ix
February 2013
Tables
Table 1-1 European Union.............................................................................................................................1
Table 1-2 Certifications and Approvals..........................................................................................................2
Table 1-3 Radio Certifications .......................................................................................................................7
Table 2-1 Weights..........................................................................................................................................9
Table 2-2 Installation Drawing Numbers for Flush, Extended and Pseudo Flanged Models......................16
Table 2-3 Installation Drawing Numbers for DP Remote Seal Models STRW1xD, STRW9xD..................16
Table 2-4 Installation Drawing Numbers for GP/AP Remote Seal Models STRW1xG, STRW9xG,
STRW1xA, STRW9xA..........................................................................................................................16
Table 2-5 Pressure models..........................................................................................................................17
Table 2-6 Conduit entry plugs and cable glands for your XYR 6000 transmitter........................................17
Table 2-7 Bracket Attacment.......................................................................................................................19
Table 2-8 Remote Seal Transmitter Mounting.............................................................................................20
Table 3-1 Process connections ...................................................................................................................25

Figures
x OneWireless XYR 6000 Transmitters Quick Start Guide Revision 12
February 2013
Figures
Figure 2-1 Temperature/DI/Multi DI/HLAI/Corrosion transmitter dimensions..............................................10
Figure 2-2 Universal I/O Temperature/DI/Multi DI/HLAI/Corrosion antenna dimensions............................11
Figure 2-3 DP/DHGP Pressure transmitter dimensions..............................................................................12
Figure 2-4 DP/DHGP Pressure antenna dimensions..................................................................................13
Figure 2-5 GP/AP Pressure transmitter dimensions ...................................................................................14
Figure 2-6 GP/AP Pressure antenna dimensions........................................................................................15
Figure 2-7 Common bracket orientations....................................................................................................18
Figure 2-8 Remote Seal mounting...............................................................................................................20
Figure 2-9 Rotating transmitter housing......................................................................................................21
Figure 2-10 Display rotation.........................................................................................................................22
Figure 3-1 Typical 3-valve manifold and blow-down piping arrangement...................................................23
Figure 3-2 Typical Arrangement for ½” NPT Process Connection Piping...................................................24
Figure 3-3 Flange Mounting.........................................................................................................................26
Figure 3-4 Temperature probes...................................................................................................................27
Figure 3-5 HLAI connection.........................................................................................................................28
Figure 3-6 Voltage input wiring....................................................................................................................28
Figure 3-7 Current input wiring....................................................................................................................28
Figure 3-8 Universal I/O Connection ...........................................................................................................29
Figure 3-9 Corrosion transmitter with remote probe....................................................................................37
Figure 4-1 Elbow antenna adjustment.........................................................................................................39
Figure 4-2 Integral straight antenna ............................................................................................................39
Figure 4-3 Directional antenna mounting ....................................................................................................44
Figure 4-4 Omnidirection antenna mounting...............................................................................................45
Figure 5-1: Battery assembly.......................................................................................................................48
Figure 5-2: IS Battery Pack..........................................................................................................................50
Figure 5-3 Power Option 24V......................................................................................................................51
Figure 5-4 External 24V Power Module.......................................................................................................51
Figure 5-5 Power Supply 24 Vdc Option (DC) System Diagram.................................................................52

Introduction
Site preparation
Revision 12 OneWireless XYR 6000 Transmitters Quick Start Guide 1
February 2013
1. Introduction
1.1 Site preparation
Wireless devices require proper site preparation to ensure optimum performance and safety compliance.
Do not proceed until you have done the proper planning described in the Wireless Planning Guide.
1.2 European Union Usage
This product may be used in any of the following European Union nations.
Table 1-1 European Union
Country ISO 3166
2 letter code Country ISO 3166 2 letter code
Austria AT Latvia LV
Belgium BE Liechtenstein LI
Bulgaria BG Lithuania LT
Cyprus CY Malta MT
Czech Republic CZ Netherlands NL
Denmark DK Norway NO
Estonia EE Poland PL
Finland FI Portugal PT
France FR Romania RO
Germany DE Slovakia SK
Greece GR Slovenia SI
Hungary HU Spain ES
Iceland IS Sweden SE
Ireland IE Switzerland CH
Italy IT United Kingdom BG

1. Introduction
Certifications and Approvals
2 OneWireless XYR 6000 Transmitters Quick Start Guide Revision 12
February 2013
1.3 Certifications and Approvals
Hazardous location certifications
Refer to product label for applicable approvals.
Table 1-2 Certifications and Approvals
AGENCY TYPE OF PROTECTION Ambient
Temperature Product Applicability*
CSA
1903673
(USA and
Canada)
Intrinsically Safe:
Class I; Division 1; Groups A, B, C, D;
Class II, Division 1, Groups E, F, G;
Class III, Division 1; T4
Class I, Zone 0 Ex ia IIC T4
Class I, Zone 0 AEx ia IIC T4
-40 oC to +85 oC : Battery
-40 oC to +80 oC : DC
Supply
Pressure
Temperature/ Discrete
Inputs
Corrosion
High Level INPUT (HLAI)
Universal I/O
Nonincendive:
Class I; Division 2; Groups A, B, C, D;
Class II, Division 2, Groups F, G;
Class III, Division 2, T4
Class I, Zone 2 Ex nA IIC, T4
Class I, Zone 2 AEx nA IIC, T4
-40 oC to +85 oC : Battery
-40 oC to +80 oC : DC
Supply
Pressure
Temperature/ Discrete
Inputs
High Level INPUT (HLAI)
Universal I/O
Explosion-Proof/ Flameproof:
Class I, Division 1; Groups A, B, C, D;
Class II, Division 1, Groups E, F, G;
Class III, Division 1; T4
Class I, Zone 1 Ex d IIC T4
Class I, Zone 1 AEx d IIC, T4
40 oC to +85 oC : Battery
-40 oC to +80 oC : DC
Supply
Pressure
Temperature/ Discrete
Inputs
Corrosion
High Level INPUT (HLAI)
Universal I/O
Enclosure: Type 4X/ IP66
Standards Used:
CSA-C22.2 No. 30:M1986
CSA-C22.2 No. 94:M1991
CSA E60079-0: 2002
CSA E60079-15: 2002
FM 3600: 1998
FM 3615: 2006
UL 916:1998
CSA-C22.2 No. 142:M1987
CSA-C22.2 No. 157:M1992
CSA E60079-1: 2002
CSA E61241-0: 2002
FM 3610: 1999
ANSI/ ISA 12.12.02: 2003
CSA-C22.2 No. 213:M1987
CSA-C22.2 No. 60529:2005
CSA E60079-11: 2002
CSA E61241-1: 2002
FM 3611: 2004
UL 50:2003

Introduction
Certifications and Approvals
Revision 12 OneWireless XYR 6000 Transmitters Quick Start Guide 3
February 2013
AGENCY TYPE OF PROTECTION Ambient
Temperature Product Applicability*
FM
ApprovalsTM
3032450
(USA)
Intrinsically Safe:
Class I; Division 1; Groups A, B, C, D;
Class II, Division 1, Groups E, F, G;
Class III, Division 1; T4
Class I, Zone 0 AEx ia IIC T4
-40 oC to +85 oC : Battery
-40 oC to +80 oC : DC
Supply
Pressure
Temperature/ Discrete
Inputs
Corrosion
High Level INPUT (HLAI)
Universal I/O
Nonincendive:
Class I; Division 2; Groups A, B, C, D;
Class II, Division 2, Groups F, G;
Class III, Division 2, T4
Class I, Zone 2 AEx nA IIC, T4
-40 oC to +85 oC : Battery
-40 oC to +80 oC : DC
Supply
Pressure
Temperature/ Discrete
Inputs
High Level INPUT (HLAI)
Universal I/O
Explosion-Proof/ Flameproof:
Class I, Division 1; Groups A, B, C, D;
Class II, Division 1, Groups E, F, G;
Class III, Division 1; T4
Class I, Zone 1 AEx d IIC, T4
-40 oC to +85 oC : Battery
-40 oC to +80 oC : DC
Supply
Pressure
Temperature/ Discrete
Inputs
Corrosion
High Level INPUT (HLAI)
Universal I/O
Enclosure: Type 4X/ IP66
Standards Used:
FM 3600:1998
FM 3615:2006
ANSI/ ISA 12.02.01: 2002
ANSI/ IEC 60529: 2004
FM 3610: 2007
FM 3810: 2005
ANSI/ ISA 12.12.02: 2003
ANSI/ NEMA 250: 2003
FM 3611: 2004
ANSI/ ISA 12.00.01: 2002
ANSI/ ISA 12.22.01: 2005
AGENCY TYPE OF PROTECTION Ambient
Temperature Product Applicability*
ATEX- KEMA
08ATEX0062X
Intrinsically Safe:
II 1 G Ex ia IIB T4
II 1 D Ex tD A20 IP66 T90 oC -40 oC to +70 oC: Battery
-40 oC to +80 oC : DC
Supply
Pressure
Temperature/ Discrete
Inputs
Corrosion
High Level INPUT (HLAI)
Universal I/O
Flameproof:
II 2 G Ex d [ia] IIB T4
II 2 D Ex tD A21 IP66 T90 oC
-40 oC to +70 oC: Battery
-40 oC to +80 oC : DC
Supply
Pressure
Corrosion
High Level INPUT (HLAI)
Universal I/O
Enclosure: IP66
Standards Used:
EN 60079-0 : 2006
EN 60079-26 : 2007
EN 60079-1 : 2004
EN 61241-0 : 2006
EN 60079-11 : 2007
EN 61241-1 : 2004

1. Introduction
Certifications and Approvals
4 OneWireless XYR 6000 Transmitters Quick Start Guide Revision 12
February 2013
AGENCY TYPE OF PROTECTION Ambient
Temperature Product Applicability*
ATEX-
DEKRA
08ATEX0074
Nonincendive:
II 3 G Ex nA [nL] IIC T4
II 3 D Ex tD A22 IP66 T90 oC -40 oC to +84 oC
Pressure
Temperature/ Discrete
Inputs
Corrosion
High Level INPUT (HLAI)
Universal I/O
Enclosure: IP66
Standards Used:
EN 60079-0 : 2006
EN 61241-1 : 2004
EN 60079-15 : 2005 EN 61241-0 : 2006
AGENCY TYPE OF PROTECTION Ambient
Temperature Product Applicability*
IECEx- CSA
09.0001X
Intrinsically Safe:
Ex ia IIB T4
Ex tD A20 IP66 T90 oC -40 oC to +70 oC: Battery
-40 oC to +80 oC : DC
Supply
Pressure
Temperature/ Discrete
Inputs
Corrosion
High Level INPUT (HLAI)
Universal I/O
Flameproof:
Ex d [ia] IIB T4
Ex tD A21 IP66 T90 oC
-40 oC to +70 oC: Battery
-40 oC to +80 oC : DC
Supply
Pressure
Corrosion
High Level INPUT (HLAI)
Universal I/O
Nonincendive:
Ex nA [nL] IIC T4
Ex tD A22 IP66 T90 oC -40 oC to +84 oC: Battery
-40 oC to +80 oC : DC
Supply
Pressure
Temperature/ Discrete
Inputs
Corrosion
High Level INPUT (HLAI)
Universal I/O
Enclosure: IP66
Standards Used:
IEC 60079-0 : 2004
IEC 60079-26 : 2007
IEC 60079-15 : 2001
IEC 60079-1 : 2003
IEC 61241-0 : 1999 IEC 60079-11 : 1999 IEC 61241-1 : 1999

Introduction
Certifications and Approvals
Revision 12 OneWireless XYR 6000 Transmitters Quick Start Guide 5
February 2013
AGENCY TYPE OF PROTECTION Ambient
Temperature Product Applicability*
SAEx
S/09-036X
(South
Africa)
Intrinsically Safe:
Ex ia IIB T4
Ex tD A20 IP66 T90 oC -40 oC to +70 oC: Battery
-40 oC to +80 oC : DC
Supply
Pressure
Temperature/ Discrete
Inputs
Corrosion
High Level INPUT (HLAI)
Universal I/O
Flameproof:
Ex d [ia] IIB T4
Ex tD A21 IP66 T90 oC
-40 oC to +70 oC: Battery
-40 oC to +80 oC : DC
Supply
Pressure
Corrosion
High Level INPUT (HLAI)
Universal I/O
Nonincendive:
Ex nA [nL] IIC T4
Ex tD A22 IP66 T90 oC -40 oC to +84 oC: Battery
-40 oC to +80 oC : DC
Supply
Pressure
Temperature/ Discrete
Inputs
Corrosion
High Level INPUT (HLAI)
Universal I/O
Enclosure: IP66
Standards Used:
SANS (IEC) 60079-0 : 2005
IEC 60079-1 : 2003
IEC 61241-0 : 1999
SANS (IEC) 60079-15 : 2006
IEC 60079-11 : 1999
IEC 61241-1 : 1999
ARP 0108 (Edition 1.1)
IEC 60079-26 : 2007
AGENCY TYPE OF PROTECTION Ambient
Temperature Product Applicability*
INMETRO**
NCC 11.0331
X
(BRAZIL)
Intrinsically Safe:
Ex ia IIB T4 Ga -40 oC to +70 oC: Battery
-40 oC to +80 oC : DC
Supply
Pressure
Temperature/ Discrete
Inputs
Corrosion
High Level INPUT (HLAI)
Universal I/O
Flameproof:
Ex d [ia] IIB T4
Ex tb IIIC T90 oC IP66
-40 oC to +70 oC: Battery
-40 oC to +80 oC : DC
Supply
Pressure
Corrosion
High Level INPUT (HLAI)
Universal I/O
Nonincendive:
Ex nA [ic] IIC T4
Ex tc IIIC T90 oC IP66
-40 oC to +84 oC: Battery
-40 oC to +80 oC : DC
Supply
Pressure
Temperature/ Discrete
Inputs
Corrosion
High Level INPUT (HLAI)
Universal I/O
Enclosure: IP66
Standards Used:
ABNT NBR IEC 60079-0:2008
IEC 60079-15:2010
ABNT NBR IEC 60529:2009
ABNT NBR IEC 60079-1:2009
ABNT NBR IEC 60079-
26:2008
IEC 61241-0 : 1999
ABNT NBR IEC 60079-11:2009
IEC 60079-31:2008
IEC 61241-1 : 1999
*See individual Product manuals as defined on page iii for exact Models
** At time of Printing Certification was pending.

1. Introduction
Conditions of Certification
6 OneWireless XYR 6000 Transmitters Quick Start Guide Revision 12
February 2013
Electrical Data:
Battery
Two in series connected (D size) Lithium batteries, type 5930 manufactured by Tadiran, type XL-205F
manufactured by Zeno Energy or type PT-2300H manufactured by Eagle Picher.
Additionally for ATEX and IECEx certifications, Lithium Battery SL-2780, manufactured by Tadiran,
GmbH may be used.
DC Supply
For Ordinary Locations, Explosion-proof and Non Incendive:
16.0 V min to 28.0 V max, Current = 100 mA
For Intrinsically Safe:
A Barrier, MTL 728P+ or MTL 7728P+ mounted in a suitable enclosure, or in a non-hazardous
location is needed, see Agency Certification drawings in Section 6.
For Output parameters associated with Temperature/ Discrete Inputs, Corrosion, High Level INPUT
(HLAI) or Universal I/O, see Agency Certification drawings in Section 6.
1.4 Conditions of Certification
IECEx Conditions of Certification
Parts of the antenna are non-conducting and the area of the non-conducting part exceeds the maximum
permissible areas for Category ll 1 G (Zone 0) according to IEC 60079-0. Therefore when the antenna is
used within a potentially explosive atmosphere, appropriate measures must be taken to prevent
electrostatic discharge.
Impact and friction hazards need to be considered according to IEC 600079-0 when the transmitter that is
exposed to the exterior atmosphere is made of light metal alloys, and used in Category ll 1 G (Zone 0).
ATEX Conditions for Safe Use
Because the enclosure of the XYR 6000 Wireless Transmitter is made from aluminum, if it is mounted in
an area where the use of category 1G apparatus is required, it must be installed such that even in the event
of rare incidents, ignition sources due to impact and friction sparks are excluded.
Special precautions shall be taken to prevent the surface of the antenna of the XYR 6000 Wireless
Transmitter from being electrostatically charged.
1.5 Maximum Working Pressure:
See individual Product manuals as defined on page iii

Introduction
Radio Certifications
Revision 12 OneWireless XYR 6000 Transmitters Quick Start Guide 7
February 2013
1.6 Radio Certifications
Table 1-3 Radio Certifications
Agency Certification Description
Federal Communications
Commission (FCC)
FCC ID:
S5750016517
or
FCC ID:
S5750025034
The XYR 6000 Wireless Transmitters comply with part 15 of the
FCC rules. Operation is subject to the following two conditions.
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
Industry Canada (IC)
IC: 573I-50016517
or
IC: 5731-50025034
The installer of this radio equipment must ensure that the
antenna is located or pointed such that it does not emit RF fields
in excess of Health Canada limits for the general population;
consult Safety Code 6, obtainable from Health Canada’s web
site www.hc-sc.gc.ca/rpb.
0981 For radio equipment used in the European Union in accordance
with the R&TTE Directive the CE Mark and the notified body
(NB) identification number is used when the NB is involved in
the conformity assessment procedure. The alert sign must be
used when a restriction on use (output power limit by a country
at certain frequencies) applies to the equipment and must follow
the CE marking.
Radio certification by the Brazilian National telecom Agency.
Radio Frequency (RF) statement
To comply with FCC’s and Industry Canada’s RF exposure requirements, the following antenna
installation and device operating configurations must be satisfied.
•Remote Point-to-Multi-Point antenna(s) for this unit must be fixed and mounted on outdoor permanent
structures with a separation distance between the antenna(s) of greater than 20cm and a separation
distance of at least 20cm from all persons.
•Remote Fixed Point–to-Point antenna(s) for this unit must be fixed and mounted on outdoor
permanent structures with a separation distance between the antenna(s) of greater than 20cm and a
separation distance of at least 100cm from all persons.
•Furthermore, when using integral antenna(s) the XYR 6000 Wireless Transmitter unit must not be co-
located with any other antenna or transmitter device and have a separation distance of at least 20cm
from all persons.
European Union restriction
The XYR 6000 Wireless Transmitters are in conformity with the applicable portions of the ETSI standards
as required by the R&TTE Directive 1999/5/EC.
Restriction
France restricts outdoor use to 10mW (10dBm) EIRP in the frequency range of 2,454-2,483.5 MHz.
Installations in France must limit EIRP to 10dBm, for operating modes utilizing frequencies in the range of
2,454 – 2,483.5MHz.
Japanese Restrictions
For locations in Japan the transmitter power is restricted to 12.14dBm/Mhz {(32mW (15.4 dBm)]
maximum EIRP including the antenna.

1. Introduction
Radio Certifications
8 OneWireless XYR 6000 Transmitters Quick Start Guide Revision 12
February 2013

Transmitter Mounting
Weight
Revision 12 OneWireless XYR 6000 Transmitters Quick Start Guide 9
February 2013
2. Transmitter Mounting
2.1 Weight
Table 2-1 Weights
Transmitter Model Weight
STDW1xx
STDW9xx
STGW9x4
STRW1xD
STRW9xD
11 lbs (5 kg)
STAW14L
STRW14A
STRW1xG
STRW9xG
STGW1xL
STGW9xL
7 lbs (3.2 kg)
STFW1xF
STFW9xF 17 lbs (7.7 kg) for 2” 150# flanged head 21 lbs (9.5 kg) for 3” 150# flanged head
STFW1xx
STFW9xx 23 to 36 lbs (10.5 kg to 16.4 kg) depending on flange size
STIW400
STTW40x
STTW500
STIW600
STUW700
STUW701
STTW8x0
CETW6000M
6 lbs (2.7 kg)
Note: Add 8.0 pounds (3.6 kg) to any model equipped with the stainless steel housing option (Model Selection Guide Table IV
selections A3 or SH)

2. Transmitter Mounting
Dimensions
10 OneWireless XYR 6000 Transmitters Quick Start Guide Revision 12
February 2013
2.2 Dimensions
For Flange and Remote Seal transmitter dimensions, obtain appropriate installation drawing using
Installation drawing number tables on page 16 as a guide.
Figure 2-1 Temperature/DI/Multi DI/HLAI/Corrosion transmitter dimensions
