Honeywell oneWireless XYR 6000 User manual

OneWireless
XYR 6000 ISA100.11a Compliant
Universal I/O Transmitter
User's Manual
34-XY-25-46
Revision 1
January 2011

ii XYR 6000 ISA100.11a Compliant Universal I/O Transmitter User's Manual Revision 1
January 2011
Notices and Trademarks
Copyright 2011 by Honeywell International Inc.
Revision 1 January 2011
While this information is presented in good faith and believed to be accurate, Honeywell disclaims the implied
warranties of merchantability and fitness for a particular purpose and makes no express warranties except as may
be stated in its written agreement with and for its customers.
In no event is Honeywell liable to anyone for any indirect, special or consequential damages. The information and
specifications in this document are subject to change without notice.
Honeywell, PlantScape, Experion PKS, and TotalPlant are registered trademarks of Honeywell International Inc.
Other brand or product names are trademarks of their respective owners.
Honeywell Process Solutions
1860 West Rose Garden Lane
Phoenix, Arizona 85027

Revision 1 XYR 6000 ISA100.11a Compliant Universal I/O Transmitter User's Manual iii
January 2011
About This Document
This document describes preparation, operation and maintenance of the XYR 6000 Wireless Universal I/O
Transmitters. Mounting, installation and wiring are covered in other documents.
Honeywell does not recommend using devices for critical control where there is a single point of failure or where
single points of failure result in unsafe conditions. OneWireless is targeted at open loop control, supervisory
control, and controls that do not have environmental or safety consequences. As with any process control solution,
the end-user must weigh the risks and benefits to determine if the products used are the right match for the
application based on security, safety, and performance. Additionally, it is up to the end-user to ensure that the
control strategy sheds to a safe operating condition if any crucial segment of the control solution fails.
Revision Information
Document Name
Document ID Revision
Number Publication Date
XYR 6000 ISA100.11a Compliant Universal I/O Transmitter
User's Manual
34-XY-25-46 1 January 2011
References
The following list identifies all documents that may be sources of reference for material discussed in this
publication.
Document Title
XYR 6000 Transmitters Quick Start Guide
Getting Started with Honeywell OneWireless Solutions
OneWireless User’s Guide
OneWireless Builder Parameter Reference

iv XYR 6000 ISA100.11a Compliant Universal I/O Transmitter User's Manual Revision 1
January 2011
Support and contact info
United States and Canada
Contact: Honeywell Process Solution
Global Technical Support - Phone: [phone]
Customer Service (HFS) - Phone: [phone]
Outside United States - Phone: [phone]
Calls are answered by dispatcher between 6:00 am and 4:00 pm Mountain Standard
Time. Emergency calls outside normal working hours are received by an answering
service and returned within one hour.
Email support: [email protected]
Mail: Honeywell Process Solutions
1860 West Rose Garden Lane,
Phoenix, Arizona 85027
EuropeContact: Honeywell TAC-EMEA
Phone: [phone]
Facsimile: [phone]
Mail: TAC-BE02
Hermes Plaza
Hermeslaan, 1H
B-1831 Diegem, Belgium
Pacific Contact: Honeywell Global TAC – Pacific
Phone: [phone] (toll free within Australia)
[phone] (outside Australia)
Facsimile: [phone]
Mail: Honeywell Limited Australia
5 Kitchener Way
Burswood 6100, Western Australia
Email: [email protected]
India Contact: Honeywell Global TAC – India
Phone: [phone]
Facsimile: [phone]
Mail: Honeywell Automation India Ltd.
56 and 57, Hadapsar Industrial Estate
Hadapsar, Pune –411 013, India
Email: [email protected]
Korea Contact: Honeywell Global TAC – Korea
Phone: [phone]
[phone]
Facsimile: [phone]
Mail: Honeywell Co., Ltd
17F, Kikje Center B/D,
191, Hangangro-2Ga
Yongsan-gu, Seoul, 140-702, Korea
Email: [email protected]

Revision 1 XYR 6000 ISA100.11a Compliant Universal I/O Transmitter User's Manual v
January 2011
People’s Republic of China
Contact: Honeywell Global TAC – China
Phone: [phone]
Mail: Honeywell (China) Co., Ltd
33/F, Tower A, City Center, 100 Zunyi Rd.
Shanghai 200051, People’s Republic of China
Email: [email protected]
Singapore
Contact: Honeywell Global TAC – South East Asia
Phone: [phone]
Facsimile: [phone]
[phone]
Mail: Honeywell Private Limited
Honeywell Building
17, Changi Business Park Central 1
Singapore 486073
Email: [e-mail]
Taiwan Contact: Honeywell Global TAC – Taiwan
Phone: [phone]
Facsimile: [phone]
Mail: Honeywell Taiwan Ltd.
17F-1, No. 260, Jhongshan 2nd Road.
Cianjhen District
Kaohsiung, Taiwan, ROC
Email: [email protected]
Japan Contact: Honeywell Global TAC – Japan
Phone: [phone]
Facsimile: [phone]
Mail: Honeywell Japan Inc.
New Pier Takeshiba, South Tower Building,
20th Floor, 1-16-1 Kaigan, Minato-ku,
Tokyo 105-0022, Japan
Email: Global-TAC-Jap[email protected]
World Wide Web
Honeywell Solution Support Online:
www.honeywell.com/ps/hfs
Elsewhere
Call your nearest Honeywell office.
Training Classes
Honeywell Automation College:
http://www.automationcollege.com

vi XYR 6000 ISA100.11a Compliant Universal I/O Transmitter User's Manual Revision 1
January 2011
Symbol Definitions
The following table lists those symbols used in this document to denote certain conditions.
Symbol Definition
ATTENTION: Identifies information that requires special consideration.
TIP: Identifies advice or hints for the user, often in terms of performing a task.
CAUTION
Indicates a situation which, if not avoided, may result in equipment or work (data) on
the system being damaged or lost, or may result in the inability to properly operate
the process.
CAUTION: Indicates a potentially hazardous situation which, if not avoided, may
result in minor or moderate injury. It may also be used to alert against unsafe
practices.
CAUTION symbol on the equipment refers the user to the product manual for
additional information. The symbol appears next to required information in the
manual.
WARNING: Indicates a potentially hazardous situation, which, if not avoided, could
result in serious injury or death.
WARNING symbol on the equipment refers the user to the product manual for
additional information. The symbol appears next to required information in the
manual.
WARNING, Risk of electrical shock: Potential shock hazard where HAZARDOUS
LIVE voltages greater than 30 Vrms, 42.4 Vpeak, or 60 VDC may be accessible.
ESD HAZARD: Danger of an electro-static discharge to which equipment may be
sensitive. Observe precautions for handling electrostatic sensitive devices.
Protective Earth (PE) terminal: Provided for connection of the protective earth
(green or green/yellow) supply system conductor.
Functional earth terminal: Used for non-safety purposes such as noise immunity
improvement. NOTE: This connection shall be bonded to Protective Earth at the
source of supply in accordance with national local electrical code requirements.
Earth Ground:Functional earth connection. NOTE: This connection shall be
bonded to Protective Earth at the source of supply in accordance with national and
local electrical code requirements.
Chassis Ground: Identifies a connection to the chassis or frame of the equipment
shall be bonded to Protective Earth at the source of supply in accordance with
national and local electrical code requirements.
continued

Revision 1 XYR 6000 ISA100.11a Compliant Universal I/O Transmitter User's Manual vii
January 2011
Symbol Description
The Factory Mutual®Approval mark means the equipment has
been rigorously tested and certified to be reliable.
The Canadian Standards mark means the equipment has been
tested and meets applicable standards for safety and/or
performance.
The Ex mark means the equipment complies with the requirements
of the European standards that are harmonised with the 94/9/EC
Directive (ATEX Directive, named after the French "ATmosphere
EXplosible").
For radio equipment used in the European Union in accordance
with the R&TTE Directive the CE Mark and the notified body (NB)
identification number is used when the NB is involved in the
conformity assessment procedure. The alert sign must be used
when a restriction on use (output power limit by a country at certain
frequencies) applies to the equipment and must follow the CE
marking.
The C-Tick mark is a certification trade mark registered to ACMA
(Australian Communications and Media Authority) in Australia under
the Trade Marks Act 1995 and to RSM in New Zealand under
section 47 of the NZ Trade Marks Act. The mark is only to be used
in accordance with conditions laid down by ACMA and RSM. This
mark is equal to the CE Mark used in the European Union.
N314 directly under the logo is Honeywell’s unique supplier
identification number.
The ISA100 Wireless Compliant logo indicates the device has
received ISA100.11a conformance certification and is registered
with the Wireless Compliance Institute, assuring device
interoperability.
CRN Canadian Registration Number

viii XYR 6000 ISA100.11a Compliant Universal I/O Transmitter User's Manual Revision 1
January 2011

Revision 1 XYR 6000 ISA100.11a Compliant Universal I/O Transmitter User's Manual ix
January 2011
Contents
Support and contact info........................................................................................................................iv
1. INTRODUCTION....................................................................................................1
1.1 Purpose..........................................................................................................................................1
1.2 Scope..............................................................................................................................................1
1.3 OneWireless network overview...................................................................................................1
1.4 About the transmitter....................................................................................................................1
Inputs/Outputs ........................................................................................................................................................1
2. SPECIFICATIONS .................................................................................................4
2.1 European Union Usage.................................................................................................................4
2.2 Certifications and approvals........................................................................................................5
Transmitter .............................................................................................................................................................5
Provisioning Device................................................................................................................................................6
2.3 Agency compliance information..................................................................................................6
FCC compliance statements ..................................................................................................................................6
IC compliance statements ......................................................................................................................................6
Radio Frequency (RF) statement ...........................................................................................................................7
European Union restriction .....................................................................................................................................7
Restriction ..............................................................................................................................................................7
Japanese Restrictions ............................................................................................................................................7
2.4 Honeywell European (CE) Declaration of Conformity (DoC)....................................................8
European Declaration of Conformity statements ....................................................................................................9
For more information about the R&TTE Directive.................................................................................................10
2.5 IECEx Conditions of Certification..............................................................................................10
ATEX Conditions for Safe Use .............................................................................................................................10
3. PREPARATION ...................................................................................................11
3.1 Installation ...................................................................................................................................11
3.2 Configuration...............................................................................................................................11
3.3 Connecting to network ...............................................................................................................11
3.4 Calibrating the transmitter .........................................................................................................11
Methods of calibration ..........................................................................................................................................11
User calibration ....................................................................................................................................................12
Wiring for calibration – XYR 6000 Universal I/O Wiring Diagrams for AI/DI (Model STUW700)...........................13
Wiring for calibration – XYR 6000 Universal I/O Wiring Diagrams for AI/DI/DO (Model STUW701).....................14
Restore calibration................................................................................................................................................16
Clear calibration....................................................................................................................................................16

Contents
x XYR 6000 ISA100.11a Compliant Universal I/O Transmitter User's Manual Revision 1
January 2011
4. FUNCTION BLOCKS...........................................................................................17
4.1 Introduction .................................................................................................................................17
4.2 Block description........................................................................................................................17
Block types...........................................................................................................................................................17
Block diagram ......................................................................................................................................................17
4.3 Parameter details ........................................................................................................................18
5. OPERATION........................................................................................................19
5.1 Overview ......................................................................................................................................19
Transmitter display modes ...................................................................................................................................19
Provisioning Device..............................................................................................................................................19
5.2 Transmitter connection status...................................................................................................20
5.3 Transmitter PV display ...............................................................................................................21
5.4 Transmitter quick view of parameters ......................................................................................25
5.5 Transmitter menu........................................................................................................................27
Menu tree.............................................................................................................................................................27
5.6 Provisioning device menus........................................................................................................28
Overview..............................................................................................................................................................28
Main menu ...........................................................................................................................................................28
Security and Node Deployment ...........................................................................................................................29
Device Local Configuration ..................................................................................................................................31
Read Device Information......................................................................................................................................32
Advanced Options................................................................................................................................................34
6. MAINTENANCE/REPAIR ....................................................................................35
6.1 Parts .............................................................................................................................................35
6.2 Replacing batteries.....................................................................................................................36
When to replace...................................................................................................................................................36
Tools required ......................................................................................................................................................36
Procedure ............................................................................................................................................................36
6.3 Replacing 24V external power module .....................................................................................38
When to replace...................................................................................................................................................38
Tools required ......................................................................................................................................................38
Procedure ............................................................................................................................................................38
6.4 Replacing sensor module ..........................................................................................................41
When to replace...................................................................................................................................................41
Tools required ......................................................................................................................................................41
Procedure ............................................................................................................................................................41
6.5 Replacing antenna ......................................................................................................................43
Tools required ......................................................................................................................................................43
Procedure ............................................................................................................................................................43
6.6 Replacing terminal board...........................................................................................................46
When to replace...................................................................................................................................................46
Tools required ......................................................................................................................................................46
Procedure ............................................................................................................................................................46

Contents
Tables
Revision 1 XYR 6000 ISA100.11a Compliant Universal I/O Transmitter User's Manual xi
January 2011
Tables
Table 1 User calibration: T/C, mV or HLAI ..................................................................................................12
Table 2 Calibration error messages ............................................................................................................15
Table 3 Transmitter connection status ........................................................................................................20
Table 4 Transmitter PV Display...................................................................................................................21
Table 5 PV engineering units ......................................................................................................................21
Table 6 PV status ........................................................................................................................................23
Table 7 Device status ..................................................................................................................................23
Table 8 Menu tree........................................................................................................................................27
Table 9 Buttons for Device Local Configuration ..........................................................................................31
Table 10 Read Device Information ..............................................................................................................32
Table 11 Advanced Options ........................................................................................................................34
Table 12: IS Battery Pack replacement procedure......................................................................................37
Table 13 24V External power module .........................................................................................................40
Table 14 Sensor module replacement.........................................................................................................42
Table 15 Antenna replacement procedure ..................................................................................................44
Table 16 Terminal board replacement procedure .......................................................................................46

Contents
Figures
xii XYR 6000 ISA100.11a Compliant Universal I/O Transmitter User's Manual Revision 1
January 2011
Figures
Figure 1 XYR 6000 Universal I/O Functional Diagram.................................................................................4
Figure 2 Block Diagram ...............................................................................................................................17
Figure 3 Main menu.....................................................................................................................................28
Figure 4 Security and Node Deployment.....................................................................................................29
Figure 5 Device Local Configuration screen................................................................................................31
Figure 6 Read Device Information...............................................................................................................32
Figure 7 Advanced Options .........................................................................................................................34
Figure 8: IS Battery Pack.............................................................................................................................37
Figure 9 24V Power Supply Module Assembly ..........................................................................................39
Figure 10 Sensor module removal and replacement ..................................................................................42
Figure 11 Antenna replacement ..................................................................................................................45
Figure 12 Terminal board replacement .......................................................................................................47

Contents
Figures
Revision 1 XYR 6000 ISA100.11a Compliant Universal I/O Transmitter User's Manual 1
January 2011
1. Introduction
1.1 Purpose
This manual describes the Honeywell OneWireless XYR 6000 Universal I/O Transmitter function,
operation and maintenance.
1.2 Scope
The manual includes:
Details of topics that relate uniquely to the Honeywell XYR 6000 Universal I/O Transmitter,
This manual does not cover installation, mounting, or wiring. See XYR 6000 Transmitter Quick Start
Guide (document 34-XY-25-21).
1.3 OneWireless network overview
OneWireless is an all digital, serial, two-way communication mesh network that interconnects industrial
field sensors to a central system.
OneWireless has defined standards to which field devices and operator stations communicate with one
another. The communications protocol is built as an "open system" to allow all field devices and
equipment that are built to OneWireless standard to be integrated into a system, regardless of the device
manufacturer. This interoperability of devices using OneWireless technology is to become an industry
standard for automation systems.
1.4 About the transmitter
The XYR 6000 Universal I/O Transmitter is furnished with an ISA100.11a-compliant wireless interface to
operate in a compatible distributed ISA100.11a wireless system. The transmitter will interoperate with any
ISA100.11a wireless network.
The transmitter includes ISA100.11a-compliant electronics for operating in a 2.4GHz wireless network. It
features function block architecture and instantiable input channels.
Inputs/Outputs
The transmitter supports three input/output channels in various configurations depending on model.
Supports up to 4 I/O types:
1. T/C (thermocouple) or mV (millivolts)
2. HLAI (high level analog input)
3. DI (discrete input) (contact closure)
4. DO (discrete output) (STUW701 only)

Contents
Figures
2 XYR 6000 ISA100.11a Compliant Universal I/O Transmitter User's Manual Revision 1
January 2011
The Universal I/O transmitter can be configured, using channel instantiation, for the following channel I/O
combinations, according to model number.
The input channels can be configured for the following input types by using the wireless system’s user
interface to assign temperature, HLAI or discrete input types to each channel on OneWireless systems or
other wireless systems that support channel instantiation. Wireless systems which do not support channel
instantiation are supported with an available PC software tool to preinstantiate specific transmitter channel
IO combinations before provisioning via the infrared interface. Alternate device descriptor (DD) files
matching the specific channel combinations are then used with the device, as indicated below.
STUW700
Channel 1 Channel 2 Channel 3 Alternate DDs
Available
DI DI HLAI Yes
DI HLAI HLAI
DI T/C or mV HLAI
HLAI DI HLAI Yes
HLAI HLAI HLAI Yes
HLAI T/C or mV HLAI
T/C or mV DI HLAI Yes
(Factory default)
T/C or mV HLAI HLAI Yes
T/C or mV T/C or mV HLAI Yes
STUW701
Channel 1 Channel 2 Channel 3 Alternate DDs
Available
DI DI DO Yes
DI HLAI DO
DI T/C or mV DO
HLAI DI DO Yes
HLAI HLAI DO Yes
HLAI T/C or mV DO
T/C or mV HLAI DO Yes
T/C or mV DI DO Yes
(Factory default)
T/C or mV T/C or mV DO Yes
Up to 2 T/C, millivolt or DI (contact closure) channels

Contents
Figures
Revision 1 XYR 6000 ISA100.11a Compliant Universal I/O Transmitter User's Manual 3
January 2011
Channel 3 fixed as HLAI (STUW700) or DO (STUW701)
T/C and millivolt ranges
Thermocouple (B ,E, J, K, N, R, S, T) (all models)
mV (0 to 10, 0 to 50, 0 to 100) (all models)
HLAI input ranges
Current only (0-20mA, 4-20mA) (all models)
The transmitter measures the analog signal from temperature sensors, discrete inputs, millivolt or high-
level analog inputs and transmits a digital output signal proportional to the measured value for direct
digital communications with systems.
The discrete input channels support voltage-free floating contacts. Maximum ON contact resistance is 300
ohms. Minimum OFF contact resistance is 100k ohms.
The STUW701 provides one discrete output.
The Process Variable (PV) is available for monitoring and alarm purposes. Available PV update rates are
1, 5, 10, 30 seconds and are set on OneWireless User Interface. Slower update rates extend battery life.
Figure 1 shows a block diagram of a XYR 6000 Universal I/O transmitter’s operating functions.

Contents
Figures
4 XYR 6000 ISA100.11a Compliant Universal I/O Transmitter User's Manual Revision 1
January 2011
Figure 1 XYR 6000 Universal I/O Functional Diagram
2. Specifications
2.1 European Union Usage
This product may be used in any of the following European Union nations.
Country ISO 3166
2 letter code Country ISO 3166 2 letter code
Austria AT Latvia LV
Belgium BE Liechtenstein LI
Bulgaria BG Lithuania LT
Cyprus CY Malta MT
Czech Republic CZ Netherlands NL
Denmark DK Norway NO
Estonia EE Poland PL
Finland FI Portugal PT
France FR Romania RO
Germany DE Slovakia SK
Greece GR Slovenia SI
Hungary HU Spain ES
Iceland IS Sweden SE
Ireland IE Switzerland CH
Italy IT United Kingdom BG

Contents
Figures
Revision 1 XYR 6000 ISA100.11a Compliant Universal I/O Transmitter User's Manual 5
January 2011
2.2 Certifications and approvals
Transmitter
See the product label for applicable approvals and ratings.
Approval / Item Ratings / Description
CSAcus Intrinsically
Safe
CL I, Div 1, Groups A, B, C, & D; CL II, Div 1, Groups E, F & G; CL III, T4
CL I, Zone 0: Ex ia IIC, T4; CL I, Zone 0: AEx ia IIC, T4
CSAcus Explosionproof CL I, Div 1, Groups A, B, C, & D; CL II, Div 1, Groups E, F & G; CL III, T4
CL I, Zone 1: Ex d IIC, T4; CL I, Zone 1: AEx d IIC, T4
CSAcus Nonincendive CL I, Div 2, Groups A, B, C & D; CL II, Div 2, Groups F & G; CL III, Div 2, T4
CL I, Zone 2: Ex nA IIC, T4; CL I, Zone 2: AEx nA IIC, T4
FM Approvals
Intrinsically Safe
CL I, Div 1, Groups A, B, C, & D; CL II, Div 1, Groups E, F & G; CL III, T4
CL I, Zone 0: AEx ia IIC, T4
FM Approvals
Explosionproof
CL I, Div 1, Groups A, B, C, & D; CL II, Div 1, Groups E, F & G; CL III, T4
CL I, Zone 1: AEx d IIC, T4
FM Approvals
Nonincendive
CL I, Div 2, Groups A, B, C & D; CL II, Div 2, Groups F & G; CL III, Div 2, T4
CL I, Zone 2: AEx nA IIC, T4
KEMA 08 ATEX0062X
Intrinsically Safe
Flameproof
KEMA 08 ATEX0074
Non-Sparking
Ex ia IIB; T4 Ta = 70ºC; Ex tD A20 IP66 T90ºC
Ex d [ia] IIB; T4 Ta = 70ºC; Ex tD A21 IP66 T90ºC
Ex nA [nL] IIC; T4 Ta = 84ºC; Ex tD A22 IP66 T90ºC
IECEx CSA 09.0001X
Intrinsically Safe
Flameproof
Non-Sparking
Ex ia IIB; T4 Ta = 70ºC; DIP A20 IP66 T90ºC
Ex d [ia] IIB; T4 Ta = 70ºC; DIP A21 IP66 T90ºC
Ex nA [nL] IIC; T4 Ta = 84ºC; DIP A22 IP66 T90ºC
Process Connections in
Division 2 / Zone 2
Division 2 / Zone 2 apparatus may only be connected to processes classified
as non-hazardous or Division 2 / Zone 2. Connection to hazardous (flammable
or ignition capable) Division 1 / Zone 0, or 1 process is not permitted.
Enclosure Type Type 4X, IP 66
Class II and III installations and Type 4X/IP66 applications require that all cable and unused entries be
sealed with a NRTL (National Recognized Testing Laboratory) listed cable gland or conduit plug. Cable
glands and conduit plugs are not supplied with the product.

Contents
Figures
6 XYR 6000 ISA100.11a Compliant Universal I/O Transmitter User's Manual Revision 1
January 2011
For detailed transmitter specifications see the following Specification and Model Selection Guide.
XYR 6000 Wireless Transmitter Universal I/O (document 34-XY-03-29)
Provisioning Device
Install the Provisioning Device application on any PDA having
Windows Mobile version 4.2+
infrared port.
2.3 Agency compliance information
This section contains the Federal Communications Commission (FCC), Industry Canada (IC) and Radio
Frequency compliance statements for the OneWireless Multinode device.
ATTENTION
XYR 6000 units must be professionally installed in accordance with the
requirements specified in the OneWireless XYR 6000 Agency Compliance
Professional Installation Guide.
FCC compliance statements
This device complies with Part 15 of FCC Rules and Regulations. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference and (2) this device must
accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radiofrequency energy and, if not installed and used in accordance with these instructions, may
cause harmful interference to radio communications. Operation of this equipment in a residential area
is likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
Intentional or unintentional changes or modifications must not be made to the Multinode unless under
the express consent of the party responsible for compliance. Any such modifications could void the
user’s authority to operate the equipment and will void the manufacturer’s warranty.
IC compliance statements
To reduce potential radio interference to other users, the antenna type and its gain should be so chosen
that the equivalent isotropic radiated power (EIRP) is not more than that permitted for successful
communication.
Operation is subject to the following two conditions: (1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired operation
of the device.
This Class A digital apparatus complies with Canadian ICES-003.
French: Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.

Contents
Figures
Revision 1 XYR 6000 ISA100.11a Compliant Universal I/O Transmitter User's Manual 7
January 2011
Radio Frequency (RF) statement
To comply with FCC’s and Industry Canada’s RF exposure requirements, the following antenna
installation and device operating configurations must be satisfied.
Remote Point-to-Multi-Point antenna(s) for this unit must be fixed and mounted on outdoor permanent
structures with a separation distance between the antenna(s) of greater than 20cm and a separation
distance of at least 20cm from all persons.
Remote Fixed Point–to-Point antenna(s) for this unit must be fixed and mounted on outdoor
permanent structures with a separation distance between the antenna(s) of greater than 20cm and a
separation distance of at least 100cm from all persons.
Furthermore, when using integral antenna(s) the Multinode unit must not be co-located with any other
antenna or transmitter device and have a separation distance of at least 20cm from all persons.
European Union restriction
The XYR 6000 Wireless Transmitters are in conformity with the applicable portions of the ETSI standards
as required by the R&TTE Directive 1999/5/EC.
Restriction
France restricts outdoor use to 10mW (10dBm) EIRP in the frequency range of 2,454-2,483.5 MHz.
Installations in France must limit EIRP to 10dBm, for operating modes utilizing frequencies in the range of
2,454 – 2,483.5MHz.
Japanese Restrictions
For locations in Japan the transmitter power is restricted to 12.14dBm/Mhz {(32mW (15.4 dBm)]
maximum EIRP including the antenna.

Contents
Figures
8 XYR 6000 ISA100.11a Compliant Universal I/O Transmitter User's Manual Revision 1
January 2011
2.4 Honeywell European (CE) Declaration of Conformity (DoC)
This section contains the European Declaration of Conformity (DoC) statement, for the XYR6000 OneWireless
products.
R&TTE
Directive 1999/5/EC LVD Directive 73/23/EEC EMC Directive 2004/108/EC ATEX Directive 94/9/EC
Harmonized Standards
EN 300 328 V1.7.1
EN 301 893 V1.4.1
EN 301 489-17 V1.2.1
EN 301 489-1 V1.6.1
IEC 61326-1 : 2006
EN 60079-0 : 2006
EN 60079-1 : 2004
EN 60079-11 : 2007
EN 60079-15 : 2005
EN 61241-0 : 2007
EN 61241-1 : 2004
Emissions Specification and Method
Emissions Spec and Method
Immunity Specification
Immunity Method
Electrical equipment for measurement, control and laboratory use – EMC
requirements – Part 1: General requirements
Electrical apparatus for explosive gas atmospheres – Part 0: General
requirements.
Electrical apparatus for explosive gas atmospheres – Part 1: Flameproof
enclosure ‘d’.
Electrical apparatus for explosive gas atmospheres – Part 11: Intrinsic
safety ‘i’
Electrical apparatus for explosive gas atmospheres – Part 15: Type of
protection ‘n’
Electrical apparatus for use in the presence of combustable dust – Part 0:
General requirements
Electrical apparatus for use in the presence of combustable dust – Part 1-1:
Electrical apparatus for use in the presence of combustable dust – Part 1:
Protection by enclosures “tD”
Manufacturer’s Name and
Address
Honeywell Process Solutions
525 East Market Street, York, PA 17403 USA
Compliance Statement The products listed here comply with the harmonized standards listed
above. Typical product line systems and configurations have been tested,
for compliance.
