8
X1 PM10 017
X1 PM10 090
X2 PM2.5 065
X3 L3GAS
X4 16TEMP
X5 36
HUMIDITY
X6 -
FILTER LIFE
USING YOUR H-PURIFIER
Plug in the Product [Fig. 4]:
Pull out the power cord from the cord reel and plug into a power supply.
All lights on the Control Panel / Display will fully illuminate for approximately 1 second to indicate a
succesful plug in.
The POWER button will be dimly lit and the CO sensor light will be ON to indicate that the Multi Sensor
Monitoring System has started working to monitor the indoor Carbon Monoxide level.
Switching on the Product [Fig. 5]:
To switch on your product, press the POWER button on the display.
The Air Quality LED Ring will illuminate through all colours in sequence whilst the sensors are analysing
the realtime air condition. After a few seconds, the Air Quality LED ring will select the appropriate colour
for the air quality at that time.
The AUTO MODE button, INFORMATION button, LIGHT CONTROL button and PM10 information on
the Display will illuminate.
The following functions are available via the Display buttons:
Press the Wi-Fi button to turn on/off remote access.
Press the INFORMATION button to see all the monitored data.
Press the AUTO, MAX or SLEEP buttons to select a purifying mode.
Press the LIGHT CONTROL button to set the brightness of the display lights.
Press the CHILD LOCK button to inactivate all the buttons on the Control Panel / Display.
Press the DIFFUSER button to activate the function.
Press the HUMIDIFIER button to activate the function.
Pairing to Wi-Fi:
Instructions:
1. Download the hOn application from the App Store or Google Play. [Fig. 6]
2. Open the APP, create an account with your e-mail and a password.
3.
4. Ensure your mobile device is connected to Wi-Fi.
5. Log into the hOn APP.
6. Press and hold the Wi-Fi button on the display for 5 seconds, there will an audible beep and the
[Fig. 7]
7. Follow the in app instructions to connect your mobile device to your product.
8. When successfully paired, the Wi-Fi button on the product will remain illuminated.
9. To reset the Wi-Fi, press & hold the Wi-Fi button for 5 Secs.
Wireless Parameters for Pairing
INFORMATION Function [Fig. 8]:
There are 6 different data sets available to monitor:
PM10, PM2.5, GAS, Temperature, Humidity, and Filter Status.
To monitor each value simply press consecutively the INFORMATION button.
By default the display will show the PM10 data, the machine will remember user’s last selection and
maintain this selection the next time the product is switched on.
The GAS data will show spinning cursor during the initial 3 minutes after product is switched on, while
the GAS sensor is performing a calibration cycle.
More info on PM 2.5, PM 10 and GAS:
vehicles and industrial emissions and potentially dangerous to our health in case of prolonged exposure.
PM 10 have a size up to 10 µm and are capable of penetrating the upper respiratory tract (nose,
PM 2.5 have a size up to 2.5 µm and, given their small dimension, they can reach our lungs, thus
Technology Wi-Fi Bluetooth
Standard IEE 802.11 b/g/n Bluetooth v4.2, BR/EDR, BLE
100 10
GB
Fig. 4
Fig. 5
Fig. 7
Fig. 6
Fig. 8
