Hoover HV-C90CG User manual

Controls
• The control panel at the front of the cooktop has five control knobs, one for
each burner; the small diagram to the left of each knob illustrates which
burner it controls.
• The black circle above each knob indicates that the gas is OFF.
• The large circle at the left of each control knob indicates the HIGH
(maximum) setting.
• The small circle at the bottom right of each control knob indicates the LOW
(minimum) setting.
Welcome to your new Hoover cooktop! We hope that this product brings you many years of enjoyment.
NOTE: This cooktop must be installed by a licensed plumber/gasfitter. You are not allowed to do this
yourself. Installation involves cutting out an appropriate opening in your benchtop, applying a seal to the
cooktop, fixing it in place and connecting it to your electricity and gas supply.
This cooktop is fitted out for use with Natural Gas (NG). If you want to use it with Universal Liquefied
Petroleum Gas (ULPG), the burners have to be converted. Your licensed gasfitter/plumber will be able to do
this. Please pass on the supplied instruction manual to your professional installer.
For detailed installation instructions, please consult the supplied instruction manual, which also has
comprehensive usage instructions and important safety advice.
Let’s get your cooktop
up and running!
Cooktop
• The cooktop has five burners: one wok (W), one
auxiliary (A), one rapid (R) and two semirapid (SR),
each fitted with a flame failure safety device which
stops the flow of gas if the flame goes out. Three
cast iron trivets fit over the burners.
• To light a burner, press down the knob, turn it
anticlockwise to the maximum position and keep it
depressed for around 15 seconds to ensure it stays
lit. Turn the knob to a position between HIGH and
LOW, not between OFF and HIGH.
• After use, always turn the control knob back to the
OFF position.
• Press and hold a button, as instructed on the panel,
to activate the child lock, or to mute the alert sound.
Version #:
After Sales Support
Model #:
V1.0
1300 886 649
HV-C90CG
90 cm Glass Gas
Cooktop
Hoover’s quick
& snappy start
up guide.
12566200A18619
A
A3
郭志文
杨道平
韦辉亮
2021/12/14
2021/12/14
2021/12/14
钢化玻璃/T=8mm
90GP095
900
510
90G50ME503-GFL_01-02A
3.面板颜色：杏色；丝印颜色：黑色
63.9
28.21
27.7
Pantone coolgray 3c
1
W
R
A
SR
SR
2
90 cm Glass Gas
Cooktop
HV-C90CG

Appropriate pan size:
W: Wok burner 20–24 cm ∅
R: Rapid burner 20-24 cm ∅
SR: Semirapid burner 16–18 cm ∅
A: Auxiliary burner 12–16 cm ∅
Hope you enjoy your new Hoover
cooktop!
90 cm Glass Gas
Cooktop
HV-C90CG
Cookware
• In order to avoid unnecessary energy use, it is important
to use appropriately sized pots and pans for each burner
(Fig. 3a).
3B3A
4A 4B
3D
4C
3C
• Only use cookware with a thick, flat base so that it sits on
the trivet properly and does not rock. Do not use a pan
with a convex or concave base (Fig. 3b).
• Position your pot/pan properly on the trivet above the burners. Do not place cookware on one side of a
burner as it could tip over (Fig. 3c).
• Adjust the flame height so it evenly heats the underside of the pot/pan (Fig. 3d). The flame should never
come up the sides of the cookware as this will waste gas and possibly cause damage to the cookware
handle.
• Do not use saucepans that overlap the boundaries of the cooktop, otherwise heat may get deflected
towards the cooktop or benchtop, which could deteriorate these surfaces.
• The three symbols on the glass cooktop surface warn
you:
* NOT to place anything, for example a flame tamer or
asbestos mat, between the pan and trivet (Fig. 4a).
* NOT to remove the trivet and enclose the burner with
a wok stand (Fig. 4b)
* NOT to use large, heavy pots or place heavy weights
on the cooktop (Fig. 4c).
