Horizon Fitness ELITE E4000 User manual

ELLIPTICAL OWNER’S MANUAL
Read the ELLIPTICAL GUIDE before using this OWNER’S MANUAL.

23
ASSEMBLY
There are several areas during the assembly process that special attention must be paid. It is very important to follow the assembly
instructions correctly and to make sure all parts are firmly tightened. If the assembly instructions are not followed correctly, the
elliptical could have frame parts that are not tightened and will seem loose and may cause irritating noises. To prevent damage to
the elliptical, the assembly instructions must be reviewed and corrective actions should be taken.
Before proceeding, find your elliptical’s serial number located on the front stabilizer tube and enter it in the space provided
below. Also locate the model name which is next to the serial number.
ENTER YOUR SERIAL NUMBER AND MODEL NAME IN THE BOXES BELOW:
SERIAL NUMBER:
MODEL NAME: HORIZON ELLIPTICAL
WARNING

4 5
UNPACKING
Unpack the product where you will be using it. Place the elliptical carton on a level flat
surface. It is recommended that you place a protective covering on your floor. Never
open box when it is on its side.
NOTE: During each assembly step, ensure that ALL nuts and bolts are in place and
partially threaded in before completely tightening any ONE bolt.
NOTE: A light application of grease may aid in the installation of hardware. Any grease,
such as lithium bike grease is recommended.
If you have questions or if
there are any missing parts,
contact Customer Tech
Support.
NEED HELP?
PRE ASSEMBLY
TOOLS INCLUDED:
8 mm L-Wrench
5 mm L-Wrench (w/ Screw Driver)
13/15 mm Flat Wrench
PARTS INCLUDED:
1 Main Frame
1 Stabilizer Tube
1 Guide Rail Set
2 Pedal Arms
2 Lower Handlebars
2 Upper Handlebars
2 Lower Link Arms With Footpads
1 Top Cap
1 Console Mast
1 Console Mast Boot
1 Console
2 Handlebar Caps
1 Water Bottle Holder
1 Rear Cover
1 Power Cord
1 Hardware Kit
2 Handlebar Covers
UPPER HANDLEBAR
PULSE GRIPS
WATER BOTTLE HOLDER
TOP CAP
MAIN FRAME
PIVOTING FOOT PADS
REAR COVER
CONSOLE
CONSOLE CONTROLS AND
DISPLAY WINDOWS
CONSOLE MAST
LOWER HANDLEBAR
CRANK
PEDAL ARM
POWER CORD SOCKET
STABILIZER TUBE
LOWER LINK ARM
GUIDE RAIL SET

6 7
FLAT WASHER (D)
Ø10.2xØ20.0xT1.5
Qty:4
SPRING WASHER (E)
Ø10.2xØ18.4xT2.5
Qty:4
BOLT(F)
M10x20 mm
Qty:4
BOLT(A)
M8x30 mm
Qty: 4
SPRING WASHER(B)
Ø8.2xØ15.4xT2.0
Qty:4
ARC WASHER(C)
Ø8.4xØ17.0xT1.0
Qty:4
ASSEMBLY STEP 1 ASSEMBLY STEP 2
A Open HARDWARE FOR STEP 1.
B Attach the STABILIZER TUBE to the MAIN FRAME
using 2 BOLTS (A), 2 SPRING WASHERS (B)
and 2 ARC WASHERS (C ) on each side.
A Open HARDWARE FOR STEP 2.
B Attach the GUIDE RAIL SET to the MAIN FRAME
using 4 BOLTS(F), 4 SPRING WASHERS (E)
and 4 FLAT WASHERS (D).
HARDWARE BAG 1 CONTENTS : HARDWARE BAG 2 CONTENTS :
STABILIZER TUBE
ARC WASHERS(C)
SPRING WASHERS(B)
BOLTS(A)
MAIN FRAME
MAIN FRAME
GUIDE RAIL SET
SPRING WASHERS (E)
FLAT WASHERS (D)
BOLTS (F)

8 9
PRE-INSTALLED BOLTS
WAVY WASHER(G)
FLAT WASHER(H)
SPRING WASHER(B)
BOLT(I)
PRE-INSTALLED
FLAT WASHERS
CONSOLE MAST
CONSOLE CABLE
GUIDE RAIL SET
PEDAL ARM
PEDAL ARM WHEEL
CRANK
WAVY WASHER (G)
Φ17.2xΦ22.5xT0.5
Qty:2
FLAT WASHER (H)
Φ8.2xΦ20.0xT1.5
Qty: 2
SPRING WASHER (B)
Φ8.2xΦ15.4xT2.0
Qty:2
BOLT(I)
M8x20 mm
Qty:2
FLAT WASHER(J)
Φ20.2xΦ27.2xT1.5
Qty:4
WAVY WASHER(K)
Φ20.7xΦ29.1xT0.5
Qty:2
FLAT WASHER(H)
Φ8.2xΦ20.0xT1.5
Qty:2
SPRING WASHER (B)
Φ8.2xΦ15.4xT2.0
Qty:2
BOLT (I)
M8x20mm
Qty:2
ASSEMBLY STEP 3 ASSEMBLY STEP 4
A Open HARDWARE FOR STEP 3.
B Carefully pull the CONSOLE CABLE through the
CONSOLE MAST using the twist tie located inside
the CONSOLE MAST.
C Attach CONSOLE MAST to MAIN FRAME using
4 PRE-INSTALLED FLAT WASHERS and 4
PRE-INSTALLED BOLTS.
D Silde WAVY WASHER (G) over CRANK followed
by PEDAL ARM as shown. Rest PEDAL ARM WHEEL
on GUIDE RAIL SET.
E Attach the PEDAL ARM to CRANK using 1 FLAT
WASHER (H), 1 SPRING WASHER (B) and
1 BOLT (I).
F Repeat steps D-E on the opposite side of the elliptical.
A Open HARDWARE FOR STEP 4.
B Slide 1 FLAT WASHER (J), 1 WAVY WASHER
(K) and another 1 FLAT WASHER (J) onto the
LOWER LINK ARM.
C Slide the LOWER LINK ARM into the PEDAL ARM
BRACKET.
D Attach the LOWER LINK ARM to the PEDAL ARM
BRACKET using 1 FLAT WASHER (H), 1 SPRING
WASHER (B) and 1 BOLT (I).
E Repeat steps B-D on the opposite side of the
elliptical.
HARDWARE BAG 3 CONTENTS HARDWARE BAG 4 CONTENTS
NOTE: Be careful not to pinch any
wires while attaching the console
mast
FLAT WASHER (J)
WAVY WASHER (K)
FLAT WASHER (J)
LOWER LINK ARM
PEDAL ARM BRACKET
BOLT (I)
SPRING WASHER (B)
FLAT WASHER (H)

10 11
TEFLON WASHER(O)
Φ15.9xΦ28.4x1.0T
Qty:4
FLAT WASHER(P)
Φ8.4xΦ17.0x1.0T
Qty:2
BOLT(Q)
M8x70 mm
Qty:2
NUT(R)
M8X1.25P
Qty:2
SPRING WASHER (B)
Φ8.2xΦ15.4x2.0T
Qty:2
RUBBER WASHER(L)
Φ16.2xΦ26.2x11.5T
Qty:2
FLAT WASHER(M)
Φ16.0xΦ25.0x1.5T
Qty:4
SPRING WASHER (B)
Φ8.2xΦ15.4x2.0T
Qty:2
BOLT(I)
M8x20 mm
Qty:2
FLAT WASHER(N)
Φ8.6xΦ26.0x2.0T
Qty:4
ASSEMBLY STEP 5 ASSEMBLY STEP 6
A Open HARDWARE FOR STEP 6. Remove zip tie
securing axle in LOWER LINK ARM.
B Align end of LOWER LINK ARM with bracket on
bottom of LOWER HANDLEBAR.
C Place TEFLON WASHERS (O) on both sides of
the LOWER LINK ARM. While holding TEFLON
WASHER (O) slide LOWER LINK ARM into bottom
end of LOWER HANDBAR.
D Secure the joint with 1 FLAT WASHER (P), 1
SPRING WASHER (B), 1 BOLT (Q) and secure
with 1 NUT (R).
E Repeat steps B-D on the opposite side of the
elliptical.
HARDWARE BAG 6 CONTENTS :
A Open HARDWARE FOR STEP 5.
B Slide 1 RUBBER WASHER (L) and 1 FLAT WASHER
(M) onto the CONSOLE MAST.
C Slide LOWER HANDLEBAR onto CONSOLE
MAST and attach using 1 FLAT WASHER (M),
1 FLAT WASHER (N), 1 HANDLEBAR CAP, 1
FLAT WASHER (N), 1 SPRING WASHER (B)
and 1 BOLT (I).
D Repeat steps B-C on the opposite side of the
elliptical.
HARDWARE BAG 5 CONTENTS :
CONSOLE MAST
RUBBER WASHER(L)
FLAT WASHER (M)
FLAT WASHER (N)
BOLT (I)
SPRING WASHER (B)
LOWER HANDLEBAR
LOWER HANDLEBAR
NUT (R)
TEFLON WASHER (O)
FLAT WASHER (P)
SPRING WASHER (B)
BOLT (Q)
LOWER LINK ARM

12 13
SCREW(S)
Φ5x20mm
Qty:2
BOLT(T)
M5x10 mm
Qty:4
ASSEMBLY STEP 7 ASSEMBLY STEP 8
A Open HARDWARE FOR STEP7.
B Slide TOP CAP and TOP CAP REAR COVER over
CONSOLE MAST and snap into place.
C Insert CONSOLE MAST BOOT over TOP CAP
and snap into place.
D Slide WATER BOTTLE HOLDER over CONSOLE
MAST and attached using 2 SCREWS (S).
HARDWARE BAG 7 CONTENTS :
A Open HARDWARE FOR STEP 8.
B Attach the 5 CONSOLE CABLES to the CONSOLE.
C Carefully tuck the CONSOLE CABLES into the
CONSOLE MAST into the CONSOLE MAST
before attaching the CONSOLE. Attach CONSOLE
to CONSOLE MAST using 4 BOLTS (T).
D Slide HANDLEBAR BOOTS over upper handlebars.
E Slide UPPER HANDLEBARS onto LOWER
HANDLEBARS making sure handlebars are joined
togeter completely. Secure UPPER HANDLEBARS
to LOWER HANDLEBARS using PRE-INSTALLED
SET SCREWS.
* Make sure upper handlebars are as far down as
possible. Handlebars can be damaged If not
secured correctly.
F Slide HANDLEBAR BOOTS down to cover
handlebar attachments.
G Insert HANDLEBAR CAPS into UPPER
HANDLEBARS.
HARDWARE BAG 8 CONTENTS :
NOTE: Be careful not to pinch any
wires while attaching the console or
handlebars.
WATER BOTTLE HOLDER
CONSOLE MAST
CONSOLE MAST BOOT
TOP CAP REAR COVER
SCREW (S)
TOP CAP
HANDLEBAR CAP
UPPER HANDLEBAR
CONSOLE MAST
CONSOLE CABLES
CONSOLE
BOLT (T)
PRE-INSTALLED SET SCREWS
HANDLEBAR BOOT
LOWER HANDLEBAR

14 15
ASSEMBLY COMPLETE!
ELITE E4000
Max. User Weight: 159 kg / 350 lbs
Product Weight: 80 kg / 176 lbs.
Overall Dimension: 187 x 167 x 62 cm / 74” x 66” x 24”
ELLIPTICAL OPERATION
This section explains how to use your elliptical’s console and programming.
The BASIC OPERATION section in the ELLIPTICAL GUIDE has instructions for the following:
• LOCATION OF THE ELLIPTICAL
• POWER/GROUNDING INSTRUCTIONS
• FOOT POSITIONING
• MOVING THE ELLIPTICAL
• LEVELING THE ELLIPTICAL
• POWER/MANUAL INCLINE OPERATION
• USING THE HEART RATE FUNCTION

16 17
CONSOLE OPERATION
Note: There is a thin protective sheet of clear plastic on the overlay of the console that should be removed before use.
A) LED DISPLAY WINDOWS: time, distance, date and clock.
B) ALPHANUMERIC DISPLAY WINDOW: displays watts, calories, rpm, heart rate, speed and PROFILE™ display information.
C) WORKOUT PROFILE DISPLAY: displays workout level and progress.
D) PROFILE™ BUTTON: used to scroll through PROFILE™ display modes. User must be selected before pressing.
E) CHANGE DISPLAY BUTTON: used to scroll through display modes. Press to change display feedback during workout.
F) IPOD® CONTROLS: press to adjust your attached iPod® audio settings.
G) START: press to begin exercising, start your workout or resume exercising after pause.
H) STOP: press to pause/end your workout. Hold for 3 seconds to reset the console.
I) IPOD®/ PROGRAMMING BUTTON: used to select program, level and time, and other options. Used to control iPod®
(during workout only).
J) QUICK ADJUST KEYPAD: used to reach desired resistance more quickly.
K) RESISTANCE KEY: press to adjust resistance.
L) AUDIO IN: plug your cd / mp3 player into the console using the included audio adaptor cable.
M) AUDIO OUT/HEADPHONE JACK: plug your headphones into this jack to listen to your music through the headphones.
N) IPOD® DOCKING STATION: used to dock and charge your iPod® (not included).
O) SPEAKERS: music plays through speakers when your cd/mp3 player is connected to the console.
P) USB PORT: used for software updates.
W a t ts
Date
Datum
Distance Entfernung
Time
Zeit
Cloc k Uhrzeit
Calor ies
Kalorien
Watt
Hear t R a t e Herzfrequenz
Spee d Geschwindigkeit
pre ss to s witch
Für Anzeigenwechsel drücken
Change
Display
Anzeigenwechsel
RPM UPM
EnergySaver
ENERGIESPARMODUS
SCHNE LLSTAR T
FÜR NUL LSTELL UNG
GEDRÜ CKT HALTE N
LE VEL
WIDERSTANDSEINSTELLUNG
LE VEL
WIDERSTANDSEINSTELLUNG
Programmbedienung
ZURÜCK EINGABE
iPo d Bedie nung
iP od C on tr olsiP od C on tr ols
iPo d Bedie nung
Programmbedienung
C
P
E
H
K
K
J
M
A
B
G
J
K
L
I
D
F
NO O

18 19
A) QUICK START
1) Simply press START to begin working out. Time will count up from
0:00. The resistance level will default to level 1. OR...
B) SELECT A PROGRAM
1) Select GUEST, USER 1 or USER 2 using on the
PROGRAMMING BUTTON and press ENTER to confirm.
2) Select weight and press ENTER.
3) Select a program using on the PROGRAMMING BUTTON
and press ENTER to confirm.
NOTE: if you press START before pressing
ENTER, the program will begin and counts
up from 0:00 for the Manual program,
and counts down from 30:00 for all other
programs. The level defaults to 1.
4) Complete the program setup using on
the PROGRAMMING BUTTON and press
ENTER to confirm after each step.
5) When setup is complete, press START to
begin your workout.
DATE AND CLOCK SETUP
1) Enter Setup mode: Press and hold the 2 and 4 buttons
for 3 seconds.
2) Use on the PROGRAMMING BUTTON to
change settings and press ENTER to confirm.
3) Settings include: Month, Day, Year, Hour, Minute, and
AM/PM.
4) Review settings: You can review your settings at any
time while in setup mode. Press ENTER to scroll
through settings.
5) Exit setup mode: To confirm the date and time, press
and hold ENTER for 3 seconds.
TO CLEAR SELECTION/RESET THE CONSOlE
Hold STOP key for 3 seconds.
FINISHING YOUR WORKOUT
When your workout is complete, the display will flash
“WORKOUT COMPLETE” and beep. Your workout
information will stay displayed on the console for 30
seconds and then reset.
DISPLAY WINDOWS
• TIME: Shown as minutes : seconds. View the time remaining
or the time elapsed in your workout.
• DISTANCE : Shown as miles or kilometer. Indicates distance
traveled or distance remaining during your workout.
• SPEED: Calories burned during your workout.
• CALORIE S: Total calories burned or calories remaining left
to burn during your workout.
• HEART RATE(HR) : Shown as BPM (beats per minute).
Used to monitor your heart rate (displayed when contact
is made with both pulse grips or when wearing Polar chest
strap).
• SPEED: Shown as MPH. Indicates how fast the foot pads
are moving.
• DATE/CLOCK: Displays date and time.
1) GETTING STARTED
2) Check to make sure no objects are nearby that will hinder the
movement of the elliptical.
3) Plug in the power cord and make sure the power is ON.
4) You have the following options to start your workout:
• WATTS: Displays current user power output.
• RPM: Rotations Per Minute.
• RESISTANCE: Shows the current level of resistance. Will be
displayed in the alphanumeric window.
• PROFILE™ DISPLAY: When PROFILE™ is activated, the
PROFILE™ information is displayed in the LED windows. Use
the PROFILE™ button to change display information. More
information is on PROFILE PERFORMANCE TRACKER
SECTION.
• ENERGYSAVER: If the machine is unused for 15 minutes,
the console will automatically enter into power save mode
and could be quickly waken up with a touch of a button or
pedal movement.
Programming Button
BACK ENTER
ZURÜCK EINGABE
EnergySaver
ENERGIESPARMODUS
Wa t t s Watt
Da t e Datum
Di s t an c e Entfernung
Ti m e Zeit
Cl oc k Uhrzeit
Ca lor i e s
Kalorien
He ar t R ate Herzfrequenz
Sp ee d Geschwindigkeit
RP M UPM
