CLUB SERIES
TREADMILL USER’S GUIDE
FOR MODELS:
CST3.6
CST4.6
PERFORMANCETRACKI N G
IN CLI N E
1%
2%
3%
4%
5%
6%
7%
8%
9%
10%
11%
12%
1
MPH
2
MPH
3
MPH
4
MPH
5
MPH
6
MPH
7
MPH
8
MPH
9
MPH
10
MPH
11
MPH
12
MPH
SELECTPROGRAM
S T A R T
PROGRAM
PRESSTOBEGIN
USER USER
SELECTUSER
(OPTIONAL)
ADJUSTPROGRAMSETTINGS
EN T E R
MOUNTAIN
CLIMB
WEIGHT
LOSS5K
SPEED
+0.5
INCLIN E
+0.5
SPEED
PRESS
TOSET
INCLINE
PRESS
TOSET
SPEED
QUI C K
ST A RT
STOP/ P AUSE
HOLD T O RESE T
CAUTION!
Consultaphysicianbeforeusingthis
equipment.Stopexercisingifyoufeel
pain,faint,dizzyorshortofbreath.
WARNING!
Attachsafetykeycliptoclothingbeforestarting.Toavoidinjury,standonthesiderails before
startingtreadmill.Readandfollowallinstructionsbefore operating.Keepchildenawayfrom
thisequipment.Removesafetykeywhennotinuseandstoreoutofreachofchildren.
DATECLOCK
PRESSTOSWITCH
CURRENTWORKOUT
AVERAGEWORKOUT
LASTWORKOUT
DISTANCE
TIMEPACE
CALORIES/ PULSE
INCLI NESPEED
WEEKLYTOTAL
MONTLYTOTAL
LIFETIMETOTAL

3
INTRODUCTION
IMPORTANT
PRECAUTIONS
ASSEMBLY
BEFORE
YOU BEGIN
TREADMILL
OPERATION
CONDITIONING
GUIDELINES
TROUBLESHOOTING
& MAINTENANCE
LIMITED
WARRANTY
CONGRATULATIONS and THANK YOU for your purchase of this Freespirit treadmill!
Whether your goal is to win races or simply enjoy a fuller, healthier lifestyle, a Freespirit treadmill can
help you attain it – adding club-quality performance to your at-home workouts, with the ergonomics
and innovative features you need to get stronger and healthier, faster. Because we're committed to
designing fitness equipment from the inside out, we use only the highest quality components. It's a
commitment we back with one of the strongest frame-to-motor warranty packages in the industry.
You want exercise equipment that offers the most comfort, the best reliability and the highest quality
in its class.
Freespirit Treadmils deliver.
INTRODUCTION
Important Precautions
Assembly
Before You Begin
Treadmill Operation
Conditioning Guidelines
Troubleshooting & Maintenance
Limited Warranty
CONTACT INFORMATION
4
6
13
16
27
35
38
Back Panel
TABLE OF CONTENTS

4
INTRODUCTION IMPORTANT
PRECAUTIONS ASSEMBLY BEFORE
YOU BEGIN TREADMILL
OPERATION LIMITED
WARRANTY
TROUBLESHOOTING
& MAINTENANCE
CONDITIONING
GUIDELINES
SAVE THESE INSTRUCTIONS
Read all instructions before using this treadmill. When using an electrical product, basic precautions
should always be followed, including the following: Read all instructions before using this treadmill. It is the
responsibility of the owner to ensure that all users of this treadmill are adequately informed of all warnings
and precautions. If you have any questions after reading this manual, contact Customer Tech Support at the
number listed on the back panel of this manual.
Connect this exercise product to a properly grounded outlet only. See grounding
instructions.
GROUNDING INSTRUCTIONS
This product must be grounded. If a treadmill should malfunction or breakdown, grounding provides a path
of least resistance for electrical current to reduce the risk of electrical shock. This product is equipped with
a cord having an equipment-grounding conductor and a grounding plug. The plug must be plugged into an
appropriate outlet that is properly installed and grounded in accordance with local codes and ordinances.
Improper connection of the equipment-grounding conductor can result in a risk of
electric shock. Check with a qualified electrician or serviceman if you are in doubt
as to whether the product is properly grounded. Do not modify the plug provided
with the product. If it will not fit the outlet, have a proper outlet installed by a
qualified electrician.
This product is for use on a nominal 110-volt circuit
and has a grounding plug that looks like the illustration
to the right. This product must be used on a dedicated
circuit. To determine if you are on a dedicated circuit,
shut off the power to that circuit and observe if any other
devices lose power. If so, move devices to a different
circuit. Note: There are usually multiple outlets on one
circuit. It is recommended that the treadmill be used
with a 20 amp circuit for optimal performance.
IMPORTANT PRECAUTIONS
WARNING
WARNING
3-Pole Grounded Outlet
GROUNDED
TREADMILL
POWER CORD

5
INTRODUCTION
IMPORTANT
PRECAUTIONS
ASSEMBLY
BEFORE
YOU BEGIN
TREADMILL
OPERATION
CONDITIONING
GUIDELINES
TROUBLESHOOTING
& MAINTENANCE
LIMITED
WARRANTY
At NO time should pets or children under the age of 12 be closer to the treadmill than 10 feet.
At NO time should children under the age of 12 use the treadmill.
Children over the age of 12 should not use the treadmill without adult supervision.
To reduce the risk of burns, fire, electrical shock or injury to persons:
• Never use the treadmill before securing the safety tether clip to your clothing.
• If you experience any kind of pain, including but not limited to chest pains, nausea, dizziness, or shortness
of breath, stop exercising immediately and consult your physician before continuing.
• Do not wear clothes that might catch on any part of the treadmill.
• Always wear athletic shoes while using this equipment.
• Do not jump on the treadmill.
• Keep power cord away from heated surfaces.
• Do not insert or drop any object into any opening.
• Unplug treadmill before moving or cleaning it. To clean, wipe surfaces down with soap and slightly damp
cloth only; never use solvents. (See MAINTENANCE)
• At no time should more than one person be on treadmill while in operation.
• The treadmills should not be used by persons weighing more than 325 pounds. Failure to comply will
void the warranty.
• The treadmill is intended for in-home use only. Do not use this treadmill in any commercial, rental, school
or institutional setting. Failure to comply will void the warranty.
• Do not use treadmill in any location that is not temperature controlled, such as but not limited to garages,
porches, pool rooms, bathrooms, car ports or outdoors. Failure to comply may void the warranty.
• Use the treadmill only as described in this manual.
OTHER SAFETY TIPS FOR YOUR TREADMILL
OPERATION
To reduce the risk of damaging important components on your treadmill, it is strongly
recommended that your treadmill is plugged into a dedicated 20 amp circuit, without
the use of an additional extension cord and/or power strip. Failure to comply may void
the warranty.
IMPORTANT: The treadmill is not compatible with GFCI-equipped outlets.
It is essential that your treadmill is used only indoors, in a climate controlled room. If your treadmill has been
exposed to colder temperatures or high moisture climates, it is strongly recommended that the treadmill is
warmed up to room temperature before first time use. Failure to do so may cause premature electronic failure.
WARNING
WARNING

6
INTRODUCTION IMPORTANT
PRECAUTIONS ASSEMBLY BEFORE
YOU BEGIN TREADMILL
OPERATION LIMITED
WARRANTY
TROUBLESHOOTING
& MAINTENANCE
CONDITIONING
GUIDELINES
ASSEMBLY
IMPORTANT: READ THESE SAFETY INSTRUCTIONS BEFORE USE!
During the assembly process of the treadmill there are several areas that special attention must be paid.
It is very important to follow the assembly instructions correctly and to make sure all parts are firmly
tightened. If the assembly instructions are not followed correctly, the treadmill could have frame parts that
are not tightened and will seem loose and may cause irritating noises. There should be no side-to-side play
in the console masts or any forward and back play in the console assembly or handlebars. If there is any
play in these areas, the treadmill has not been properly assembled. To prevent damage to the treadmill, the
assembly instructions must be reviewed and corrective actions should be taken.
UNPACKING
Place the treadmill carton on a level flat surface. It is recommended that you place a protective covering on
your floor. Take CAUTION when handling and transporting this unit. Never open box when it is on its side.
Once the banding straps have been removed, do not lift or transport this unit unless it is fully assembled
and in the upright folded position, with the lock latch secure. Unpack the unit where it will be used. Never
grab hold of any portion of the incline frame and attempt to lift or move the treadmill. FAILURE TO FOLLOW
THESE INSTRUCTIONS COULD RESULT IN INJURY!
Before proceeding, find your treadmill’s serial number
and model name located under the deck on the frame
crossbar and enter it in the space provided below.
ENTER YOUR SERIAL NUMBER AND
MODEL NAME IN THE BOxES BELOW:
SERIAL NUMBER:
MODEL NAME:
* Refer to the SERIAL NUMBER and MODEL NAME when calling for service.
* Also enter this serial number on your Warranty Card.
WARNING

7
INTRODUCTION
IMPORTANT
PRECAUTIONS
ASSEMBLY
BEFORE
YOU BEGIN
TREADMILL
OPERATION
CONDITIONING
GUIDELINES
TROUBLESHOOTING
& MAINTENANCE
LIMITED
WARRANTY
TOOLS INCLUDED
PARTS INCLUDED
1 Safety Key
1 Console Assembly (located under treadmill deck)
1 Power Cord
4 Hardware Bags
2 Handlebar Extensions
2 End Caps
2 Console Masts
1 Heartrate Chest Strap
DISPLAY AREA
WATER BOTTLE HOLDER
GRIP PULSE HANDRAILS
ON/OFF SWITCH
CIRCUIT BREAKER
TRANSPORT WHEEL
POWER CORD
CONSOLE
HANDLEBAR EXTENTIONS
SAFETY KEY PLACEMENT
MOTOR COVER
RUNNING BELT / RUNNING DECK
SIDE RAIL
ROLLER END CAP
CONSOLE MAST
REAR ROLLER
ADJUSTMENT BOLTS
FOOT LOCK LATCH
If you have questions or if there are any missing parts, contact Customer Tech Support.
contact information is located on the back panel of this manual.
5 mm Allen Wrench
6 mm T-wrench
Screwdriver
READING RACK
PERFORMANCE TRACKING
INCLINE
1%
2%
3%
4%
5%
6%
7%
8%
9%
10%
11%
12%
1
MPH
2
MPH
3
MPH
4
MPH
5
MPH
6
MPH
7
MPH
8
MPH
9
MPH
10
MPH
11
MPH
12
MPH
SELECT PROGRAM
S T A R T
PROGRAM
PRESS TO BEGIN
USER USER
SELECT USER
(OPTIONAL)
ADJUST PROGRAM SETTINGS
ENTER
MOUNTAIN
CLIMB
WEIGHT
LOSS5K
SPEED
+0.5
INCLINE
+0.5
SPEED
PRESS
TO SET
INCLIN E
PRESS
TO SET
SPEED
QUICK
S T A R T
STOP/PAUSE
HOLD TO RESET
CAUTION!
Consulta physician before usingthis
equipment.Stop exercising if you feel
pain,faint,dizzyor short of breath.
WARNING!
Attachsafety key clip to clothing before starting. Toavoid injury, stand on theside rails before
startingtreadmill. Read and follow allinstructions before operating. Keep childen away from
thisequipment. Remove safety key when not in use and store out of reach of children.
DATE CLOCK
PRESS TO S W I TCH
CURRENT WORKOUT
AVERAGEWORKOUT
LAST WORKOUT
DISTANCE
TIME PAC E
CALORIES / PULSE
INCLINE SPEED
WEEKLYTOTAL
MONTLYTOTAL
LIFETIME TOTAL
(CST 4.6 SHOWN)

8
INTRODUCTION IMPORTANT
PRECAUTIONS ASSEMBLY BEFORE
YOU BEGIN TREADMILL
OPERATION LIMITED
WARRANTY
TROUBLESHOOTING
& MAINTENANCE
CONDITIONING
GUIDELINES
Disassemble box and remove the cardboard packaging that is not beneath the treadmill. Do not attempt to
lift the treadmill at this time. Remove plastic wrap from console masts.
NOTE: During each assembly step, ensure that ALL nuts and bolts are in place and partially threaded in before
completely tightening any ONE bolt. NOTE: A light application of grease may aid in the installation of hardware.
Any grease, such as lithium bike grease is recommended.
Open HARDWARE BAG 1.
Pull LEAD WIRE through RIGHT
CONSOLE MAST to drag upward.
Place RIGHT CONSOLE MAST
into upright position using 2
BOLTS (A) and 2 WASHERS (B)
and tighten. Be sure to hold the
console mast firmly, as it will
not stay in the upright
position on its own.
Repeat on the left side. Note:
There is no wire in the LEFT
CONSOLE MAST.
PRE-ASSEMBLY
ASSEMBLY STEP 1
A
B
C
D
BOLT (A)
65 mm
Qty: 4
FLAT WASHER (B)
8 mm
Qty: 4
HARDWARE BAG 1 CONTENTS :
Z01
BOLT (A)
FLAT WASHER (B)
CONSOLE CABLE
LEAD WIRE

9
INTRODUCTION
IMPORTANT
PRECAUTIONS
ASSEMBLY
BEFORE
YOU BEGIN
TREADMILL
OPERATION
CONDITIONING
GUIDELINES
TROUBLESHOOTING
& MAINTENANCE
LIMITED
WARRANTY
ASSEMBLY STEP 2
NOTE: There is no hardware bag for this step.
Lift the RUNNING DECK until
lock latch on side of treadmill is
fully engaged.
Remove CONSOLE from box
and place out of the way.
Lower the treadmill RUNNING
DECK from the folded position
by stepping on LOCK LATCH on
the bottom left side of the deck.
A
B
C
1
3
2

10
INTRODUCTION IMPORTANT
PRECAUTIONS ASSEMBLY BEFORE
YOU BEGIN TREADMILL
OPERATION LIMITED
WARRANTY
TROUBLESHOOTING
& MAINTENANCE
CONDITIONING
GUIDELINES
SCREW (C)
ROLLER END CAP
MAIN FRAME
ASSEMBLY STEP 3
SCREW (C)
12 mm
Qty: 2
HARDWARE BAG 3 CONTENTS :
A Open HARDWARE BAG 3.
B Slide left ROLLER END CAP onto MAIN FRAME and attach with SCREW (C).
C. Repeat on other side.

11
INTRODUCTION
IMPORTANT
PRECAUTIONS
ASSEMBLY
BEFORE
YOU BEGIN
TREADMILL
OPERATION
CONDITIONING
GUIDELINES
TROUBLESHOOTING
& MAINTENANCE
LIMITED
WARRANTY
A. Open HARDWARE BAG 4
B. With running deck in lowered position,
place CONSOLE on upright masts.
C. Secure console by partially inserting
3 BOLTS (D) and 3 FLAT WASHERS
(E) into side of LEFT upright MAST.
Remember to partially install
these bolts.
D. Gently lift right side of the CONSOLE
to connect the CONSOLE CABLE.
Carefully tuck wires in mast to avoid
damage. NOTE: Do not pinch console
cable. Be sure the console cable
prongs are aligned and the ends are
tightly seated into each other.
E. Repeat step C above to assemble the
right side upright mast and console.
F. Tighten all bolts completely.*
G. Once BOLTS (D) have been
completely tightened, insert BOLTS
(F) into the back of the mast and
completely tighten.
BOLT (D)
15 mm
Qty: 6
FLAT WASHER (E)
8 mm
Qty: 6
top view
BOLT (F)
25 mm
Qty: 2
top view
* NOTE: Be careful not to pinch any
wires while assembling the masts.
* Be sure to tighten bolts after all are lined up.
Z01
BOLT (D)
MAST
FLAT WASHER (E)
BOLT (F)
ASSEMBLED IN STEP 4-C
HARDWARE BAG 4 CONTENTS :
ASSEMBLY STEP 4

12
INTRODUCTION IMPORTANT
PRECAUTIONS ASSEMBLY BEFORE
YOU BEGIN TREADMILL
OPERATION LIMITED
WARRANTY
TROUBLESHOOTING
& MAINTENANCE
CONDITIONING
GUIDELINES
YOU’RE FINISHED!
A Open HARDWARE BAG 5.
B Slide left HANDLEBAR ExTENSION onto CONSOLE FRAME. Attach using BOLT (G).
C Connect bottom of HANDLEBAR ExTENSION to the CONSOLE MAST using 2 BOLTS (I) and
2ARC WASHERS (H). Note: CST3.6 skips this step.
D Repeat on other side.
E. Connect power plug to the treadmill and connect the cord to a power outlet. The on/off switch
is located next to the power cord. Flip this switch to the 'ON' position, so that the switch is lit.
You will hear a beep and the console will light up.
ASSEMBLY STEP 5
PERFORMANC E TRACKIN G
INCLINE
1%
2%
3%
4%
5%
6%
7%
8%
9%
10%
11%
12%
1
MPH
2
MPH
3
MPH
4
MPH
5
MPH
6
MPH
7
MPH
8
MPH
9
MPH
10
MPH
11
MPH
12
MPH
SELECT PROGRAM
S T A R T
PROGRAM
PRESS TO BEGIN
USER USER
SELECT USER
(OPTIONAL)
ADJUST PROGRAM SETTINGS
ENTER
MOUNTAIN
CLIMB
WEIGHT
LOSS 5K
SPEED
+0.5
INCLINE
+0.5
SPEED
PRESS
TO SET
INCLINE
PRESS
TO SET
SPEED
QUICK
S T A R T
STOP/PAUSE
HOLD TO RESET
CAUTION!
Consulta physician before using this
equipment.Stop exercising if you feel
pain,faint, dizzy or short of breath.
WARNING!
Attachsafety key clip to clothing before starting. Toavoid injury,stand on the side rails before
startingtreadmill. Read and follow all instructions before operating. Keep childen away from
thisequipment. Remove safety key when not in use and store out of reach of children.
DAT E CLOCK
PRESS TO SWITCH
CURRENT WORKOUT
AVERAGE WORKOUT
LAST WORKOUT
DISTANCE
TIME PA CE
CALORIES / PULSE
INCLINE SPEED
WEEKLYTOTAL
MONTLYTOTAL
LIFETIME TOTAL
BOLT (I)
BOLT (G)
CONSOLE FRAME
HANDLEBAR EXTENSION
ARC WASHER (H)
BOLT (G)
12 mm
Qty: 2
top view
BOLT (I)
115 mm
Qty: 2
BOLT (G)
12 mm
Qty: 4
top view
ARC
WASHER (H)
Qty: 2
HARDWARE BAG 5 CONTENTS FOR CST3.6:
BOLT (G)
CONSOLE FRAME HANDLEBAR EXTENSION
CST3.6 CST4.6
BOLT (G)
12 mm
Qty: 2
top view
BOLT (I)
115 mm
Qty: 2
BOLT (G)
12 mm
Qty: 4
top view
ARC
WASHER (H)
Qty: 2
HARDWARE BAG 5 CONTENTS FOR CST4.6:

13
INTRODUCTION
IMPORTANT
PRECAUTIONS
ASSEMBLY
BEFORE
YOU BEGIN
TREADMILL
OPERATION
CONDITIONING
GUIDELINES
TROUBLESHOOTING
& MAINTENANCE
LIMITED
WARRANTY
BEFORE YOU BEGIN
CONGRATULATIONS! on choosing your treadmill. You’ve taken an important step in developing and
sustaining an exercise program! Your treadmill is a tremendously effective tool for achieving your personal
fitness goals. Regular use of your treadmill can improve the quality of your life in so many ways.
HERE ARE JUST A FEW OF THE HEALTH BENEFITS OF EXERCISE:
• Weight Loss
• A Healthier Heart
• Improved Muscle Tone
• Increased Daily Energy Levels
The key to reaping these benefits is to develop an exercise habit. Your new treadmill will help you eliminate
obstacles that prevent you from exercising. Inclement weather and darkness won't interfere with your
workout when you use your treadmill in the comfort of your home. This guide provides you with basic
information for using and enjoying your new machine.
LOCATION OF THE TREADMILL
Place the treadmill on a level surface. There should be 6 feet of clearance
behind the treadmill, 3 feet on each side and one foot in front for folding
and the power cord. Do not place the treadmill in any area that will block
any vent or air openings. The treadmill should not be located in a garage,
covered patio, near water or outdoors.
DO NOT STAND ON THE BELT
While you are preparing to use the treadmill, do not stand on the belt.
Place your feet on the side rails before starting the treadmill. Start
walking on the belt only after the belt has begun to move. Never start the
treadmill at a fast running speed and attempt to jump on!
SAFETY KEY
Your treadmill will not start unless the safety key is placed in position. Attach the clip end securely to your
clothing. This safety key is designed to cut the power to the treadmill if you should fall. Check the operation
of the safety key every 2 weeks.
NEVER USE THE TREADMILL WITHOUT SECURING THE SAFETY KEY CLIP TO YOUR
CLOTHING. PULL ON THE SAFETY KEY CLIP FIRST TO MAKE SURE IT WILL NOT
COME OFF YOUR CLOTHING.
WARNING
3 feet
6 feet
3 feet
1 foot
WARNING

14
INTRODUCTION IMPORTANT
PRECAUTIONS ASSEMBLY BEFORE
YOU BEGIN TREADMILL
OPERATION LIMITED
WARRANTY
TROUBLESHOOTING
& MAINTENANCE
CONDITIONING
GUIDELINES
PROPER USAGE
Your treadmill is capable of reaching high speeds. Always start off using a slower speed and adjust the speed in
small increments to reach a higher speed level. Never leave the treadmill unattended while it is running. When
not in use, remove the safety key, turn the on/off switch to off and unplug the power cord. Make sure to follow
the MAINTENANCE schedule in this manual. Keep your body and head facing forward. Do not attempt to turn
around or look backwards while the treadmill is running. Stop your workout immediately if you feel pain, faint,
dizzy or are short of breath.
Do not operate the treadmill if the power cord or plug is damaged.
If the treadmill appears to not be working properly, do not use the treadmill.
FOLDING
Firmly grasp the back end of the treadmill. Carefully
lift the end of the treadmill deck into the upright
position until the foot lock latch engages and
securely locks the deck into position. Make sure the
deck is securely latched before letting go. To unfold,
firmly grasp the back end of the treadmill. Gently
press down on the foot lock latch with your foot until
the lock latch disengages. Carefully lower the deck
to the ground. NOTE: The foot lock latch is located
on the bottom left side of the deck.
MOVING
Your treadmill has a pair of transport wheels built
into the frame. To move, make sure the treadmill is
folded and securely latched. Then firmly grasp the
handlebars, tilt the treadmill back and roll.
Our Treadmills are heavy, use care and additional help if necessary when moving.
Do not attempt to move or transport treadmill unless it is in the upright, folded
position with the lock latch secured. Failure to follow these instructions could
result in injury.
WARNING
WARNING

15
INTRODUCTION
IMPORTANT
PRECAUTIONS
ASSEMBLY
BEFORE
YOU BEGIN
TREADMILL
OPERATION
CONDITIONING
GUIDELINES
TROUBLESHOOTING
& MAINTENANCE
LIMITED
WARRANTY
CENTERING THE RUNNING BELT
The running belt has been properly adjusted at the
factory before it was shipped. At times the belt can
move off-center during shipment. Before operating the
treadmill, make sure the belt is centered and remains
centered to maintain smooth operation.
CAUTION: Do not run belt faster than 1/2 mph while
centering. Keep fingers, hair and clothing away from
belt at all times.
If the running belt is too far to the right side:
With the treadmill running at 1/2 mph, turn the right
adjustment bolt clockwise 1/4 TURN at a time (using
the supplied Allen wrench). Check the belt alignment.
Allow belt to run a full cycle to gauge if more adjustment
is needed. Repeat if necessary, until the belt remains
centered during use.
If the running belt is too far to the left side:
With the treadmill running at 1/2 mph, turn the right
adjustment bolt counter-clockwise 1/4 TURN at a time
(using the supplied Allen wrench). Check the belt
alignment. Allow belt to run a full cycle to gauge if more
adjustment is needed. Repeat if necessary, until the
belt remains centered during use.
Belt is too far to the right side
Belt is too far to the left side
TENSIONING THE RUNNING BELT
The running belt has been properly adjusted at the
factory before it was shipped. At times the belt can
move off-center during shipment.
CAUTION: Running belt should NOT be moving during
tensioning. Over-tightening the running belt can
cause excessive wear on the treadmill as well as its
components. Never over-tighten the belt.
If you can feel a slipping sensation when running on the
treadmill, the running belt must be tightened. In most
cases, the belt has stretched from use, causing the
belt to slip. This is a normal and common adjustment.
To eliminate this slipping, TURN THE TREADMILL OFF
and tension BOTH THE REAR ROLLER BOLTS using the
supplied Allen wrench, turning them 1/4 TURN to the
right as shown. Turn the treadmill on and check for
slipping. Repeat if necessary, but NEVER TURN the
roller bolts more than 1/4 turn at a time. Belt is properly
tensioned when the slipping sensation is gone.

16
INTRODUCTION IMPORTANT
PRECAUTIONS ASSEMBLY BEFORE
YOU BEGIN TREADMILL
OPERATION LIMITED
WARRANTY
TROUBLESHOOTING
& MAINTENANCE
CONDITIONING
GUIDELINES
Note: A thin protective sheet of clear plastic is on the overlay of the console and should be removed.
A) eTRAK™ BUTTON: Used to scroll through eTRAK™ display modes.
B) eTRAK™ DISPLAY MODES: Light indicates active eTRAK™ display mode (CST3.6 has fewer modes).
C) LED DISPLAYS: Incline, Time, Calories, Pulse, Pace, Distance, Speed, Date, and Clock (Pace, Date, and Clock on
CST4.6 only).
D) MONITOR DISPLAY: Shows Program Profiles.
E) QUICK START: Simply press to begin exercising.
F) STOP: Press to pause/end your workout. Hold for 3 seconds to reset the treadmill.
G) USER KEYS: Press to select user (CST4.6 only).
H) QUICK PROGRAM KEYS: Press to select program. Press enter to confirm selection.
I) PROGRAM SETTING KEYS: Press to adjust Time, Incline, Speed, and Level.
j) ENTER: Press to set Time, Incline, Speed, and Level.
K) START PROGRAM: Press to begin program.
L) QUICK INCLINE KEYS: Press to reach desired incline more quickly. Select before pressing SET INCLINE key.
TREADMILL OPERATION
PERFORMANCE TRACKING
INCLINE
1%
2%
3%
4%
5%
6%
7%
8%
9%
10%
11%
12%
1MPH
2MPH
3MPH
4MPH
5MPH
6MPH
7MPH
8MPH
9MPH
10 M P H
11 M P H
12 M P H
SELECT PROGRAM
S T A R T
PROGRAM
PRESS TO BEGIN
USERUSER
SELECT USER (OPTIONAL) ADJUST PROGRAM SETTINGS
ENTER
MOUNTAIN
CLIMB
WEIGHT
LOSS 5K
SPEED
+0.5
INCLINE
+0 . 5
SPEED
PRESS
TO SET
INCLINE
PRESS
TO SET
SPEED
QUICK
S T A R T
STOP/PAUSE
HOLD TO RESET
CAUTION!
Consult a physician before using this
equipment. Stop exercising if you feel
pain, faint, dizzy or short of breath.
WARNING!
Attach safety key clip to clothing before starting. To avoid injury,stand on the side rails before
starting treadmill. Read and follow all instructions before operating. Keep childen away from
this equipment. Remove safety key when not in use and store out of reach of children.
DAT E C L OCK
PRESSTOS WI T CH
CURRENT WORKOUT
AVERAGE WORKOUT
LAST WORKOUT
DI ST A N C E
TI M E PA CE
CALORIES /PULSE
INC LINE S P EED
WEEKLY TOTAL
MONTLY TOTAL
LIFETIME TOTAL
DL PCW BAM Q
E
UTGN O S RH I J KF

17
INTRODUCTION
IMPORTANT
PRECAUTIONS
ASSEMBLY
BEFORE
YOU BEGIN
TREADMILL
OPERATION
CONDITIONING
GUIDELINES
TROUBLESHOOTING
& MAINTENANCE
LIMITED
WARRANTY
DATE • Date format is month: day (CST4.6 only).
PROGRAM PROFILES • Represents the profile of the program being used (speed during speed based
programs and incline during incline based programs).
CLOCK • The clock displays the time in the 12-hour system (CST4.6 only).
MONITOR DISPLAY
M) SET INCLINE: Press to accept incline selected with quick incline keys.
N) INCLINE ARROW KEYS: Press to adjust incline (0.25% increments).
O) +0.5 INCLINE: Press to increase incline by 0.5%.
P) QUICK SPEED KEYS: Press to reach desired speed more quickly. Select before pressing SET SPEED key.
Q) SET SPEED: Press to accept speed selected with quick speed keys.
R) SPEED ARROW KEYS: Press to adjust speed (0.1mph increments).
S) +0.5 SPEED: Press to increase speed by 0.5%.
T) SAFETY KEY POSITION: Enables treadmill operation when safety key is in place.
U) WATER BOTTLE / CD / MP3 HOLDER: Holds personal workout equipment.
V) TRIP (not shown): Functions similar to a vehicle trip odometer. Hold for 5 seconds to reset trip (CST3.6 only).
W) READING RACK: Holds reading material.
DATE CLOCK
DISTANCE
TIME PACE
CALORIES / PULSE
INCLINE SPEED

18
INTRODUCTION IMPORTANT
PRECAUTIONS ASSEMBLY BEFORE
YOU BEGIN TREADMILL
OPERATION LIMITED
WARRANTY
TROUBLESHOOTING
& MAINTENANCE
CONDITIONING
GUIDELINES
PULSE GRIPS
Place the palm of your hands directly on the grip pulse handlebars. Both hands must grip the bars for your
heart rate to register. It takes 5 consecutive heart beats (15-20 seconds) for your heart rate to register. When
gripping the pulse handlebars, do not grip tightly. Holding the grips tightly may elevate your blood pressure.
Keep a loose, cupping hold. You may experience an erratic readout if consistently holding the grip pulse
handlebars. Make sure to clean the pulse sensors to ensure proper contact can be maintained.
HEART RATE
DAT E CLOCK
DISTANCE
TIME PACE
CALORIES / PULSE
INCLINE SPEED
INCLINE • Shown as Percent. Indicates the incline of your walking or running surface.
TIME • Shown as Minutes:Seconds. View the time remaining or the time elapsed in your workout.
CALORIES • Total Calories burned during your workout.
PULSE • Shown as Beats Per Minute. Used to monitor your heart rate (displayed when contact is made with
both pulse grips).
DAT E CLOCK
DISTANCE
TIME PACE
CALORIES / PULSE
INCLINE SPEED
PACE • Shown as Minutes. Tenths of a Minute. Indicates the time to run a mile at the current speed
(CST4.6 only).
DISTANCE • Shown as Miles. Indicates distance traveled during your workout.
SPEED • Shown as MPH. Indicates how fast your walking or running surface is moving.

19
INTRODUCTION
IMPORTANT
PRECAUTIONS
ASSEMBLY
BEFORE
YOU BEGIN
TREADMILL
OPERATION
CONDITIONING
GUIDELINES
TROUBLESHOOTING
& MAINTENANCE
LIMITED
WARRANTY
Check to make sure nothing is on or will hinder the movement of the treadmill.
Plug in the power cord and turn the treadmill ON.
Stand on the side rails of the treadmill.
Attach the safety key clip to part of your clothing.
Insert the safety key into the safety keyhole in the console.
You have two options to start your workout:
QUICK START UP
Simply press the START key to begin working out. OR...
SELECT A PROGRAM
Select a PROGRAM using the PROGRAM +/- or QUICK PROGRAM keys.
Once a PROGRAM has been chosen, press ENTER.
SELECT A LEVEL
Select a PROGRAM LEVEL using the PROGRAM +/- keys.
Once a PROGRAM LEVEL has been chosen, press ENTER.
SELECT A TIME
Select a Time using the PROGRAM +/- keys or use the default time.
Once a TIME has been chosen, press START.
FINISHING YOUR WORKOUT
When your workout is complete, the MONITOR DISPLAY will flash and beep. Your workout information will stay
displayed on the console for 30 seconds and then reset.
CLEAR CURRENT SELECTION
To clear the current program selection or screen, hold the STOP button for 4-5 seconds.
GETTING STARTED / SELECTING A PROGRAM
1)
2)
3)
4)
5)
6)
A)
B)

20
INTRODUCTION IMPORTANT
PRECAUTIONS ASSEMBLY BEFORE
YOU BEGIN TREADMILL
OPERATION LIMITED
WARRANTY
TROUBLESHOOTING
& MAINTENANCE
CONDITIONING
GUIDELINES
Walk or run a series of alternating SPEED levels. Time-based goal with 10 difficulty levels to choose from.
INTERVALS PROGRAM SEGMENTS
(peak segments last 30 seconds, valley segments last 90 seconds)
MPH WARM-UP 1234
SEGMENTS ARE REPEATED UNTIL SELECTED
TIME IS REACHED
COOL DOWN
Level 1 1.0 1.5 2.0 4.0 2.0 4.0 1.5 1.0
Level 2 1.0 1.5 2.0 4.5 2.0 4.5 1.5 1.0
Level 3 1.3 1.9 2.5 5.0 2.5 5.0 1.9 1.3
Level 4 1.3 1.9 2.5 5.5 2.5 5.5 1.9 1.3
Level 5 1.5 2.3 3.0 6.0 3.0 6.0 2.3 1.5
Level 6 1.5 2.3 3.0 6.5 3.0 6.5 2.3 1.5
Level 7 1.8 2.6 3.5 7.0 3.5 7.0 2.6 1.8
Level 8 1.8 2.6 3.5 7.5 3.5 7.5 2.6 1.8
Level 9 2.0 3.0 4.0 8.0 4.0 8.0 3.0 2.0
Level 10 2.0 3.0 4.0 8.5 4.0 8.5 3.0 2.0
(WARM-UP and COOL-DOWN last 4:00 minutes each and are included in program times)
PROGRAM: INTERVALS
MANUAL
INTERVALS
ROLLING
WEIGHT LOSS
GOLF COURSE
RACE
CUSTOM 1
CUSTOM 2
THR ZONE 1
THR ZONE 2
VALLEY
TOUR
PEAK
INTERVALS
MOUNTAIN
CLIMB
Motivates with different combinations of SPEED. Time-based goal with 10 difficulty levels to choose from.
ROLLING PROGRAM SEGMENTS (all segments last 30 seconds)
MPH WARM-UP 12345678
SEGMENTS ARE REPEATED UNTIL SELECTED
TIME IS REACHED
COOL-DOWN
Level 1 1.0 1.5 2.0 2.5 3.0 3.5 4.0 3.5 3.0 2.5 2.3 1.5
Level 2 1.3 1.9 2.5 3.0 3.5 4.0 4.5 4.0 3.5 3.0 2.6 1.8
Level 3 1.5 2.3 3.0 3.5 4.0 4.5 5.0 4.5 4.0 3.5 3.0 2.0
Level 4 1.8 2.6 3.5 4.0 4.5 5.0 5.5 5.0 4.5 4.0 3.4 2.3
Level 5 2.0 3.0 4.0 4.5 5.0 5.5 6.0 5.5 5.0 4.5 3.8 2.5
Level 6 2.3 3.4 4.5 5.0 5.5 6.0 6.5 6.0 5.5 5.0 4.1 2.8
Level 7 2.5 3.8 5.0 5.5 6.0 6.5 7.0 6.5 6.0 5.5 4.5 3.0
Level 8 2.8 4.1 5.5 6.0 6.5 7.0 7.5 7.0 6.5 6.0 4.9 3.3
Level 9 3.0 4.5 6.0 6.5 7.0 7.5 8.0 7.5 7.0 6.5 5.3 3.5
Level 10 3.3 4.9 6.5 7.5 7.5 8.0 8.5 8.0 7.5 7.0 5.6 3.8
(WARM-UP and COOL-DOWN last 4:00 minutes each and are included in program times)
PROGRAM: ROLLING HILLS
MANUAL
INTERVALS
ROLLING
WEIGHT LOSS
GOLF COURSE
RACE
CUSTOM 1
CUSTOM 2
THR ZONE 1
THR ZONE 2
VALLEY
TOUR
PEAK
INTERVALS
MOUNTAIN
CLIMB
PROGRAM: MANUAL
MANUAL
INTERVALS
ROLLING
WEIGHT LOSS
GOLF COURSE
RACE
CUSTOM 1
CUSTOM 2
THR ZONE 1
THR ZONE 2
VALLEY
TOUR
PEAK
INTERVALS
MOUNTAIN
CLIMB
Allows ‘On The Fly’ manual SPEED and INCLINE changes. Time-based goal.
PROGRAM INFORMATION
