Hoshizaki F-1500MAH(-C) User manual

Hoshizaki
©HOSHIZAKI AMERICA, INC.
618 Hwy. 74 S., Peachtree City, GA 30269 TEL [phone] FAX [phone] www.hoshizaki.com
CUBELE DIMENSIONS
WxDxH
F-1500M_H-C
4/08
Item # 13162
MODULAR CUBELE ICE MACHINE
Warranty
Valid in United States, Canada, uerto Rico, & U.S.Territories. Contact factory for warranty in
other countries.
wo Year - arts & Labor on entire machine.
Five Year - arts on: Compressor, air-cooled condenser coil.
F-1500M_H-C
Item #
Project:
Qty:
Hoshizaki reserves the right to change specifications without notice.
F-1500M_H-C
30 x 271/2 x 347/16
*AutoCad available on KCL
•Up to 1335 lbs. of ice p oduction pe 24 hou s
•Du able stainless steel exte io
•CleanCycle12®Design
•15 minute flush cycle eve y 12 hou s
•Removes sediment
•Cleane ice
•Longe life and easy maintenance
•Removable ai filte s (Ai -cooled model only)
•R-404A Ref ige ant
®
F-1500MAH-C
Air-Cooled
Shown on an optional
B-900
F-1500MWH-C
Water-Cooled
F-1500MRH-C
Remote Air-Cooled
B-900
B-800
B-700B-500
Also availa le on Large Bins:
B-1150SS
B-1300SS
B-1500SS
B-1650SS

Hoshizaki
DIMENSIONS
WxDxH
F-1500M_H-C
30 x 271/2 x 347/16
©HOSHIZAKI AMERICA, INC.
F-1500M_H-C
MODULAR CUBELE ICE MACHINE
U ILI Y C O N S U M P I O N
AIR-COOLED
Model Number
70˚
50˚ 70˚
1300
90˚
80˚
90˚
KWH per
100 LBS.
F-1500MAH-C
Air Temp˚ F.
Water Temp˚ F.
SPECIFICA IONS
Model Number Condenser Amperage Min. Circuit
Ampacity Shipping
Weight
16.3 20 325 lbs.
Air-Cooled
F-1500MAH-C
4.5 12.0
1145
1011
1245
1099
1194
1054
930
F-1500MWH-C Water-Cooled 15.9 20 325 lbs.
990
90/70
Potable
Water Gal.
per 100 lbs.
O P E R A I N G L I M I S
• Ambient Temp Range 45 - 100˚F
• Water Temp Range 45 - 90˚F
• Water ressure 10 - 113psig
• Voltage Range 187 - 253V
ELEC RICAL&PLUMBING/F-1500M_H-C
• 208-230V/60/1 (3 wire dedicated neutral for 115V)
• 20 amp Max Fuse/HACR Breaker Size
• 1/2” OD copper or equivalent independent water supply
• 3/4” F T independent drain connection
SERVICE
• anels easily removed and all components
accessible for service.
• Removable/cleanable air filter
(Air-Cooled models only)
618 Hwy. 74 S., Peachtree City, GA 30269 TEL [phone] FAX [phone] www.hoshizaki.com Printe in U.S.A.
• Air-cooled
• Water-cooled
• Remote Air-cooled
WA E R - C O O L E D
70˚
50˚ 70˚
1125
90˚
80˚
90˚
Air Temp˚ F.
Water Temp˚ F.
1050
1015
1075
1040
1060
1025
990
975
F-1500MWH-C 4.3 12.0
S O R AGE BINS
Model Number Application Capacity ARI-Rated Capacity
B-500 500 lbs. 360 lbs.
B-700 700 lbs. 550 lbs.
B-900 900 lbs. 660 lbs.
B-1150 1150 lbs. N/A
B-800 800 lbs. 600 lbs.
B-1500 1490 lbs. N/A
B-1650 1605 lbs. N/A
B-1300 1275 lbs. N/A
REMO E A I R - C O O L E D
70˚
50˚ 70˚
1335
90˚
80˚
90˚
Air Temp˚ F.
Water Temp˚ F.
1223
1123
1294
1188
1258
1155
1060
1120
F-1500MRH-C 4.18 12.0
F-1500MRH-C Remote
Air-Cooled 18.9 20 325 lbs.
FRONT IEW
1-11/16" (43mm)
28-21/32"
(728mm)
Drain Outlet
Electrical Supply
7/8"Opening
(22mm)
1-3/4"
(45mm)
23-11/16"
(602mm)
5-1/4"
(133mm)
3-3/8"
(86mm)
IceMakingWater
Inlet 1/2"FPT
3/4" FPT
AIR-COOLED UNIT
Ice Making Water
Inlet 1/2" FPT
Fan MotorConnection
7/8"Opening
(22mm)
Electrical Supply
7/8"Opening
(22mm)
Drain Outlet
3/4" FPT
Liquid Refrig. Line
5/8"-18UNF Fitting
Discharge Refrig. Line
1-1/16"-12UNF Fitting
3-3/8"
(86mm)
5-1/4"
(133mm)
23-11/16"
(602mm)
3-7/16"
(36mm)
3-7/8"
(98mm)
20-5/8"
(524mm)
27-3/4"
(736mm)
31-15/16"
(811mm)
1-15/16"
(50mm)
1-13/16"
(46mm)
28-3/4"
(730mm)
REMOTE AIR-COOLED UNIT
ICE DROP ZONE SIDE IEW
WATER COOLED UNIT
35 11/16
14 1/16
36 7/8
URC-12F
Air Flow
211/16
23/4 215/16
18 1/8
2115/16
Liqui
Refrigerant
Line
Discharge Line
Electrical Con uit
Access
Pre-Charged ubing Kits
(Sold Separately)
20’ R404-2068-2
35’ R404-3568-2
55’ R404-5568-2
URC-12F Remote Condenser (Sold Separately)
For Use with F-1500MRH-C
Voltage supply for the URC Remote
Condenser is supplied from the Ice Maker.
No additional circuit is required.
37 13/16
