HP NetServer LXr Pro8
200 MHz/1 MB Processor
Board
Upgrade Guide
HP Part Number 5967-2101
Printed in January 1998

ii
Notice
The information contained in this document is subject to change without notice.
Hewlett-Packard makes no warranty of any kind with regard to this
material, including, but not limited to, the implied warranties of
merchantability and fitness for a particular purpose. Hewlett-Packard shall
not be liable for errors contained herein or for incidental or consequential
damages in connection with the furnishing, performance, or use of this material.
Hewlett-Packard assumes no responsibility for the use or reliability of its software
on equipment that is not furnished by Hewlett-Packard.
This document contains proprietary information that is protected by copyright.
All rights are reserved. No part of this document may be photocopied,
reproduced, or translated to another language without the prior written consent of
Hewlett-Packard Company.
Hewlett-Packard Company
Network Server Division
Technical Marketing Department / MS 53U-FJ
5301 Stevens Creek Boulevard
P.O. Box 58059
Santa Clara, CA 95052-8059 USA
© Copyright 1998, Hewlett-Packard Company.
Audience Assumptions
This guide is for the person who installs, administers, and troubleshoots LAN
servers. Hewlett-Packard Company assumes you are qualified in the servicing of
computer equipment and trained in recognizing hazards in products with
hazardous energy levels.

iii
Contents
1 Overview.......................................................................................................1
About This Guide...........................................................................................1
Additional Information................................................................................1
Verify Contents..............................................................................................1
Tools Required...............................................................................................3
2 Plan the Upgrade..........................................................................................5
Determine Where to Place the Processor Board............................................5
3 Perform the Upgrade....................................................................................7
Power Down the HP NetServer......................................................................7
Slide Out the Satellite Chassis.......................................................................9
Lift and Remove Top Cover of Satellite Chassis..........................................11
Remove the Terminator Board.....................................................................12
Install the Processor Board ..........................................................................15
Slide the Satellite Chassis Back Into Place ..................................................15
A Warranty and Support...............................................................................19
Hardware Warranty......................................................................................19
HP Repair and Telephone Support...............................................................19
B Regulatory Information.............................................................................21
Notice for USA: FCC Radio Frequency Emissions Statements.....................21
Class A Product Statement......................................................................21
Notice for EU...............................................................................................22
Index...............................................................................................................23

1
1Overview
About This Guide
This guide describes the installation of the 200 MHz/1 MB Processor Board
Accessory Kit in HP NetServer LXr Pro8 systems. The processor board includes
two 200 MHz/1 MB CPU chips, on which two heat pipes are mounted for
efficient cooling.
Use this guide to install up to three additional processor boards in a system that
already has one 200 MHz/1MB processor board installed.
In addition to the installation instructions, this guide contains regulatory
information.
Additional Information
For other information about your HP NetServer LXr Pro8, refer to the HP
NetServer LXr Pro8 User Guide.
Verify Contents
CAUTION Do not remove the processor board from its bag until you are
ready to install it. Make sure the bag remains sealed. The
CPU chips are sensitive to humidity, so desiccant has been
packed in the bag containing the processor board. When the
processor board has been installed and the HP NetServer is
running, the chips are no longer sensitive to humidity.
Unpack the shipping box and verify that you received the contents listed on the
next page for the 200 MHz/1 MB Processor Board Accessory Kit. If anything is
missing or damaged, or if the bag around the processor board is not sealed, call
your reseller.

Chapter 1 Overview
2
1. Processor board, shown in Figure 1-1, has the following parts mounted on
it:
• Two 200 MHz/1 MB CPU chips
• Two heat pipes
• Two VRMs (voltage regulator modules)
Be sure to keep the bag around the processor board sealed until you are
ready to install the board.
2. HP NetServer LXr Pro8 200 MHz/1 MB Processor Board Upgrade Guide
(this guide).
3. Update Return Kit that explains how to return unused terminator boards
to HP for environmentally safe disposal.
4. HP Navigator CD-ROM. You are not required to use the HP Navigator
CD-ROM to reconfigure your system after installing the new processor
board. However, we recommend that you use it to ensure that you have the
latest drivers and information.
Figure 1-1. 200 MHz/1MB Processor Board

Chapter 1 Overview
3
Tools Required
• An antistatic service kit (3MTM 8501/8502/8503 or equivalent). This kit
includes a static-dissipating work surface, a chassis clip lead, and a wrist
strap.
• Number 2 Phillips head screwdriver.

5
2 Plan the Upgrade
Up to four processor boards, each with two 200 MHz/1 MB CPU chips, can be
installed in the HP NetServer LXr Pro8 system. All four processor board slots on
the system board must be filled, even when fewer than four processor boards
(eight CPUs) are installed. Each processor board slot must contain one of two
kinds of boards:
• Processor board. The processor board contains two 200 MHz/1MB CPU
chips with two heat pipes and two VRMs (voltage regulator modules).
or
• Terminator board. The terminator board uses the same board blank as
the processor board, but it does not contain the CPU chips, heat pipes, or
VRMs. Each terminator board contains just the components necessary to
terminate the bus.
During start up, the control panel of the HP NetServer LXr Pro8 displays how
many CPUs the system detects.
Determine Where to Place the Processor Board
The system comes standard with one processor board and three terminator
boards. Before you can add a processor board, you must remove a terminator
board.
The HP NetServer LXr Pro8 has two CPU buses: A and B. Bus A, containing
slots A1 and A2, is the primary bus. Bus B, containing slots B1 and B2, is the
secondary bus. Table 2-1 shows how processor boards can be added to the HP
NetServer LXr Pro8 to keep the two buses balanced.

Chapter 2 Plan the Upgrade
6
Table 2-1. Processor Board Configurations
Total Number of CPU
Chips in System Board in Slot A1 Board in Slot A2 Board in Slot B1 Board in Slot B2
2 CPUs Processor
board Terminator board Terminator board Terminator board
4 CPUs Processor
board Terminator board Processor board Terminator board
6 CPUs Processor
board Processor board Processor board Terminator board
8 CPUs Processor
board Processor board Processor board Processor board
Figure 2-1 shows a diagram of a system board which labels the processor board
slots. You might want to use this diagram to mark or highlight the slot (or slots)
on the system board where you will remove a terminator board to install a
200 MHz/1 MB processor board.
Figure 2-1. System Board of HP NetServer LXr Pro8

7
3 Perform the Upgrade
The installation steps are as follows:
1. Power down the HP NetServer.
2. Slide out the satellite chassis.
3. Lift and remove the cover of the satellite chassis.
4. Remove the terminator board.
5. Install the processor board.
6. Slide the satellite chassis back into place.
CAUTION The processor board and CPU chips are sensitive to static
electricity, and can be easily damaged by improper handling.
Do the following when handling the accessory kit:
•Leave the processor board in the antistatic container until
you are ready to install it.
•Use an antistatic wrist strap and a grounding mat.
•Before you remove a processor board from the antistatic
container, touch a grounded, unpainted metal surface on
the HP NetServer to discharge static electricity.
Power Down the HP NetServer
1. Log off all users and shut down all networking software and applications.
2. Press the DC power switch on the HP NetServer's control panel as shown
in Figure 3-1.

Chapter 3 Perform the Upgrade
8
Figure 3-1. HP NetServer Control Panel
3. Unlock the power interlock switch at the back of the HP NetServer by
turning it clockwise as shown in Figure 3-2. This turns off DC power to
the satellite and unlatches the satellite chassis.
Figure 3-2. HP NetServer Power Interlock Switch

Chapter 3 Perform the Upgrade
9
NOTE After you unlock the power interlock switch, there is no power
present at any internal or externally accessible area of the
satellite chassis. However, five volts of power are present at
the power supply pins on the base chassis where the satellite
attaches. To remove all power, unplug the AC power cord.
Slide Out the Satellite Chassis
CAUTION Wear a wrist strap and use a static-dissipating work surface
connected to the chassis when handling components. Ensure
that the metal of the wrist strap contacts your skin.
1. Put on the antistatic wrist strap and place the antistatic mat on a firm
surface near the system. Connect the strap and mat to an unpainted metal
surface on the system chassis.
2. Look at any cables you might have connected to PCI cards. If there is not
enough slack in one or more cables to pull out the satellite chassis,
disconnect the cables as necessary.
3. Remove the retention bracket from the lower rear of the NetServer and set
it aside. See Figure 3-3.
CAUTION You will need to replace the retention bracket when
redocking the Satellite Chassis. The bracket ensures correct
mechanical connection.

Chapter 3 Perform the Upgrade
10
Figure 3-3. Location of the Retention Bracket
4. Stand behind the HP NetServer and grasp the two ejector handles on the
rear panel. Pull both handles down firmly, and then pull the satellite
chassis toward you. Pull it out until its slides are fully extended as shown
in Figure 3-4. The slides lock in the extended position so that the satellite
chassis cannot move.

Chapter 3 Perform the Upgrade
11
Figure 3-4. Slide Out Satellite Chassis
Lift and Remove Top Cover of Satellite Chassis
1. Find the fingerholds on the cover of the satellite chassis.
2. Place a finger in each of the two fingerholds and push both fingerholds
toward each other.
3. Maintain pressure with your fingers and slide the cover away from you.
The cover slides about one-half inch before stopping.
4. Lift the cover by the fingerholds until it is fully open.

Chapter 3 Perform the Upgrade
12
Figure 3-5. Satellite Chassis with Open Cover
5. Pull back one of the spring-loaded hinge pins on the underside of the
cover and lift the cover off.
6. Set the cover aside.
Looking down into the satellite chassis, you can see the processor and
terminator boards on the system board.
Remove the Terminator Board
1. Determine which terminator board (or boards) you will be removing from
your system.
You must remove one terminator board for each 200 MHz/1 MB processor
board you are adding. Refer to Table 2-1 in "Plan the Upgrade" and to
Figure 3-6 that follows to determine which terminator board (or boards)
you need to remove from your system.

Chapter 3 Perform the Upgrade
13
Figure 3-6. Processor and Terminator Boards on the System Board
2. Using a Phillips head screwdriver, unscrew the two mounting screws that
secure the terminator board in place.
3. Grasp the board you are removing, and lift firmly. Place it on the
antistatic mat.
4. If you are installing more than one 200 MHz/1MB processor board,
remove additional terminator boards as necessary.

Chapter 3 Perform the Upgrade
14
Figure 3-7. Remove the Terminator Board
5. You may return the terminator boards you removed to Hewlett-Packard
for environmentally safe disposal. To return used boards, see the Update
Return Kit.

Chapter 3 Perform the Upgrade
15
Install the Processor Board
1. Remove the processor board from the sealed bag.
NOTE Do not change the jumper settings on the processor board.
These settings are factory set.
2. Install the processor board in the slot from which you removed the
terminator board. Gently, but firmly push the board into place.
You must install one processor board for every terminator board that you
removed.
3. Using a Phillips head screwdriver, secure the mounting screws in place.
NOTE You are not required to use the HP Navigator CD-ROM to
reconfigure your system after installing the new processor
board. The system detects the additional processors
automatically. However, we recommend that you use the HP
Navigator CD-ROM to ensure that you have the latest drivers
and information.
Slide the Satellite Chassis Back Into Place
1. Replace the cover of the satellite chassis.
2. When you finish servicing the HP NetServer, move to the front of the
server and unlatch all four power supplies. (If the front bezel is in place,
remove it.)
3. At the rear, insert the satellite chassis. To do so, press the release latch on
each slide as shown in Figure 3-8 and push the satellite chassis about one
inch back onto the base.

Chapter 3 Perform the Upgrade
16
Figure 3-8. Unlock the Slides
4. Grasp the ejector handles and push the satellite chassis all the way
forward until it locks into position against the base chassis. Be careful to
keep the ejector handles in the "down" position.
5. Push the ejector handles up until they stop. You should hear a click.
6. Replace the retention bracket as shown in Figure 3-3.
7. Reconnect any cables to PCI cards you might have disconnected earlier.
Reconnect the AC power cord if you disconnected it earlier.
8. Lock the power interlock switch by turning it counterclockwise as shown
in Figure 3-9.
9. At the front, relatch the power supplies. Ensure the indicator lights come
up correctly. See "Power Supply Indicators" in the HP NetServer LXr
Pro8 User Guide.
