HP 8719ET User manual

Reference Guide
HP 8719ET/20ET/22ET
HP 8719ES/20ES/22ES
Network Analyzers
HP Part Number 08720-90393
Printed in USA
August 1999
© Copyright 1999
Hewlett-Packard Company

ii
Notice
The information contained in this document is subject to change without notice.
Hewlett-Packard makes no warranty of any kind with regard to this material, including
but not limited to, the implied warranties of merchantability and fitness for a particular
purpose. Hewlett-Packard shall not be liable for errors contained herein or for incidental or
consequential damages in connection with the furnishing, performance, or use of this
material.

iii
Certification
Hewlett-Packard Company certifies that this product met its published specifications at
the time of shipment from the factory. Hewlett-Packard further certifies that its
calibration measurements are traceable to the United States National Institute of
Standards and Technology, to the extent allowed by the Institute's calibration facility, and
to the calibration facilities of other International Standards Organization members.
Regulatory and Warranty Information
The regulatory and warranty information is located in the user’s guide.
Assistance
Product maintenance agreements and other customer assistance agreements are available
for Hewlett-Packard products. For any assistance, contact your nearest Hewlett-Packard
sales or service office. See the user’s guide for the nearest office.
Safety Notes
The following safety notes are used throughout this manual. Familiarize yourself with
each of the notes and its meaning before operating this instrument. All pertinent safety
notes for using this product are located in the user’s guide.
WARNING Warning denotes a hazard. It calls attention to a procedure which, if
not correctly performed or adhered to, could result in injury or loss
of life. Do not proceed beyond a warning note until the indicated
conditions are fully understood and met.
CAUTION Caution denotes a hazard. It calls attention to a procedure that, if not
correctly performed or adhered to, would result in damage to or destruction of
the instrument. Do not proceed beyond a caution sign until the indicated
conditions are fully understood and met.

iv
How to Use This Guide
This guide uses the following conventions:
This represents a key physically located on the
instrument.
This represents a “softkey,” a key whose label is
determined by the instrument’s firmware.
Screen Text This represents text displayed on the instrument’s screen.
Front-Panel Key
SOFTKEY

v
Documentation Map
The Installation and Quick Start Guide provides procedures for
installing, configuring, and verifying the operation of the analyzer. It
also will help you familiarize yourself with the basic operation of the
analyzer.
The User’s Guide shows how to make measurements, explains
commonly-used features, and tells you how to get the most
performance from your analyzer.
The Reference Guide provides reference information, such as
specifications, menu maps, and key definitions.
The Programmer’s Guide provides general HP-IB programming
information, a command reference, and example programs. The
Programmer’s Guide contains a CD-ROM with example programs.
The CD-ROM provides the Installation and Quick Start Guide, the
User’s Guide, the Reference Guide, and the Programmer’s Guide in
PDF format for viewing or printing from a PC.
The Service Guide provides information on calibrating,
troubleshooting, and servicing your analyzer. The Service Guide is not
part of a standard shipment and is available only as Option 0BW, or
by ordering HP part number 08720-90397. A CD-ROM with the
Service Guide in PDF format is included for viewing or printing from
a PC.

vi

Contents
Contents-vii
1. HP 8719/20/22ES Specifications and Characteristics
Definitions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2
Specifications for Instruments with Multiple Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2
Corrected System Performance (HP 8719/20ES) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3
Corrected System Performance (HP 8722ES). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-14
Instrument Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-24
Uncorrected Port Performance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-24
Test Port Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-26
Test Port Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-33
General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-40
Speed Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-46
Power Meter Calibration Accuracy. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-49
2. HP 8719/20/22ET Specifications and Characteristics
Definitions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-2
Corrected System Performance (HP 8719/20ET) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-3
Corrected System Performance (HP 8722ET). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-6
Instrument Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-9
Uncorrected Port Performance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-9
Test Port Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-11
Test Port Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-17
General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-28
Speed Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-34
3. Front/Rear Panel
Front Panel Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2
Analyzer Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-5
Rear Panel Features and Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-10
4. Menu Maps
Menu Maps. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2
5. Hardkey/Softkey Reference
Key Reference. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-2
Where to Look for More Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-3
Guide Terms and Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-3
Analyzer Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-4
6. Error Messages
Error Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-2
Error Messages in Alphabetical Order . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-3
Error Messages in Numerical Order. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-23

Contents-viii
Contents
7. Options and Accessories
Using This Chapter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
Analyzer Options Available . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
Option 1D5, High Stability Frequency Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
Option 004, Source Attenuator (ET Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
Option 007, Mechanical Transfer Switch (ES Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
Option 010, Time Domain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
Option 012, Direct Access Receiver Configuration (ES Only) . . . . . . . . . . . . . . . . . . . . . . . 7-3
Option 085, High Power System (ES Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-4
Option 089, Frequency Offset Mode (ES Only). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-4
Option 400, Four-Sampler Test Set (ES Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-4
Option 1CM, Rack Mount Flange Kit Without Handles . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-4
Option 1CP, Rack Mount Flange Kit With Handles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-4
Service and Support Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-4
Accessories Available . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-5
Measurement Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-5
Test-Port Cables: 3.5-mm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-5
Test-Port Cables: 7mm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-6
Calibration Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-6
RF Electronic Calibration Modules and PC Software . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-8
Verification Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-9
Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-10
Test Configuration Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-11
Power Meters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-11
Power Sensors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-11
Couplers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-11
Keyboard Template . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-12
8. Preset State and Memory Allocation
Preset State . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
Memory Allocation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-13
Types of Memory and Data Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-13
Volatile Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-13
Non-Volatile Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-13
Determining Memory Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-15
Storing Data to Disk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-17
Conserving Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-19
Using Saved Calibration Sets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-19
9. Understanding the CITIfile Data Format
Using This Chapter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-2
The CITIfile Data Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-3
Description and Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-3
Data Formats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-3
File and Operating System Formats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-3
Definition of CITIfile Terms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-4
A CITIfile Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-4
The CITIfile Header . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-5

Contents
Contents-ix
An Array of Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-5
CITIfile Keyword. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-5
CITIfile Examples. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-6
Example 2, An 8510 Display Memory File. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-6
Example 3, 8510 Data file. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-7
Example 4, 8510 3-Term Frequency List Cal Set File. . . . . . . . . . . . . . . . . . . . . . . . . . . .9-8
CITIfile Keywords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-10
Useful Calculations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-13
Computing Frequency Points . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-13
Expressing CITIfile Data in Other Data Formats. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-14
Example Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-15
10. Determining System Measurement Uncertainties
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10-2
Sources of Measurement Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10-3
Sources of Systematic Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10-3
Sources of Random Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10-4
Determining Expected System Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10-5
Determining Cable Stability Terms (CR1, CR2, CTM1, CTM2, CTP1, CTP2). . . . . . . . . . . . . . .10-6
Measurement Uncertainty Equations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10-8
Forward Reflection Uncertainty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10-8
Forward Transmission Uncertainty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10-9
Reverse Reflection Uncertainty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10-10
Reverse Transmission Uncertainty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10-11

Contents-x
Contents

1-1
1HP 8719/20/22ES
Specifications and Characteristics

1-2
HP 8719/20/22ES Specifications and Characteristics
Definitions
Definitions
All specifications and characteristics apply over a 23 °C±3°C range (unless otherwise
stated) and 1/2 hour after the instrument has been turned on.
Specification (spec.): Warranted performance. Specifications include guardbands to
account for the expected statistical performance distribution, measurement uncertainties,
and changes in performance due to environmental conditions.
Characteristic (char.): A performance parameter that the product is expected to meet
before it leaves the factory, but that is not verified in the field and is not covered by the
product warranty. A characteristic includes the same guardbands as a specification.
Typical (typ.): Expected performance of an average unit which does not include
guardbands. It is not covered by the product warranty.
Nominal (nom.): A general, descriptive term that does not imply a level of performance. It
is not covered by the product warranty.
Calibration: The process of measuring known standards from a calibration kit to
characterize a network analyzer’s systematic (repeatable) errors.
Corrected (residual) Performance: Indicates performance after error correction
(calibration). It is determined by the quality of calibration standards and how well
“known” they are, plus system repeatability, stability, and noise.
Uncorrected (raw) Performance: Indicates instrument performance without error
correction. The uncorrected performance affects the stability of a calibration.
Standard: When referring to the analyzer, this includes all options unless noted otherwise.
Specifications for Instruments with Multiple Options
For instruments with any or all of the following options, standard instrument
specifications apply:
• Option 400
• Option 089
• Option 012 (except where noted)
For instruments with Option 089 and Option 007, Option 007 specifications apply.
For instruments with Option 089 and Option 085, Option 085 measurement uncertainties
apply, Option 089 R input specifications apply, and all other standard instrument
specifications apply.
For preconfigured analyzers, standard instrument specifications apply, except for
frequency stability; Option 1D5 specifications apply.

1-3
HP 8719/20/22ES Specifications and Characteristics
Corrected System Performance (HP 8719/20ES)
Corrected System Performance (HP 8719/20ES)
The specifications in this section apply for measurements made using 10 Hz IF bandwidth,
no averaging, and at an environmental temperature of 23 ±3°C, with less than 1 °C
deviation from the calibration temperature. Assumes that an isolation calibration was
performed with an averaging factor of 8.
Table 1-1 System Dynamic Range, All Device Connector Types
HP 8719/20ES, All Cal Kits, All Cables, 10 Hz IF BW
Description Specification Supplemental
Information
System Transmission Dynamic Range
HP 8719/20ES (Standard)a
a. The System Transmission Dynamic Range is calculated as the difference
between the receiver noise floor and the lesser of either: the source maximum
output or the receiver maximum input. The receiver noise floor is specified as 3
standard deviations above the mean of the linear magnitude noise floor trace
over the specified frequency band.
50 MHz to 840 MHz 77 dB
840 MHz to 8 GHz 100 dB
8 GHz to 20 GHz 100 dB
HP 8719/20ES (Option 007)a
50 MHz to 840 MHz 82 dB
840 MHz to 20 GHz 105 dB
HP 8719/20ES (Option 012 with test set bypassed)b
b. The System Transmission Dynamic Range is calculated as the difference
between the receiver noise floor and the lesser of either: the source maximum
output or the receiver maximum input. The receiver noise floor is specified as
the mean of the linear magnitude noise floor trace over the specified frequency
band.
50 MHz to 500 MHz 115 dB, typ.
500 MHz to 2 GHz 115 dB, typ.
2 GHz to 8 GHz 115 dB, typ.
8 GHz to 13.5 GHz 113 dB, typ.
13.5 GHz to 20 GHz 113 dB, typ.

1-4
HP 8719/20/22ES Specifications and Characteristics
Corrected System Performance (HP 8719/20ES)
Table 1-2 System Dynamic Range, All Device Connector Types
HP 8722ES, All Cal Kits, All Cables, 10 Hz IF BW
Description Specification Supplemental
Information
System Transmission Dynamic Range
HP 8722ES (Standard)a
50 MHz to 840 MHz 67 dB
840 MHz to 8 GHz 93 dB
8 GHz to 20 GHz 91 dB
20 GHz to 40 GHz 80 dBb
HP 8722ES (Option 007)a
50 MHz to 840 MHz 72 dB
840 MHz to 8 GHz 98 dB
8 GHz to 20 GHz 96 dB
20 GHz to 40 GHz 85 dBb
HP 8722ES (Option 012 with test set bypassed)c
50 MHz to 500 MHz 115 dB, typ.
50 Hz to 8 GHz 115 dB, typ.
8 GHz to 20 GHz 113 dB, typ.
20 GHz to 40 GHz 108 dB, typ.
a. The System Transmission Dynamic Range is calculated as the difference
between the receiver noise floor and the lesser of either: the source maximum
output or the receiver maximum input. The receiver noise floor is specified as 3
standard deviations above the mean of the linear magnitude noise floor trace
over the specified frequency band.
b. 3 dB less for Option 085 or Option 012.
c. The System Transmission Dynamic Range is calculated as the difference
between the receiver noise floor and the lesser of either: the source maximum
output or the receiver maximum input. The receiver noise floor is specified as
the mean of the linear magnitude noise floor trace over the specified frequency
band.

1-5
HP 8719/20/22ES Specifications and Characteristics
Corrected System Performance (HP 8719/20ES)
Table 1-3 3.5-mm Device Connector Type
Network Analyzer: HP 8719ES/20ES, Standard
Calibration Kit: HP 85052D (3.5-mm, 50 Ω)
Cables: HP 85131F
Calibration: Full 2-Port
IF BW = 10 Hz, Avg off, Temp = 23 ±3°Cwith < 1°Cdeviation from cal temp, Isol cal with avg = 8
Description Specification
50 to 500 MHz 0.5 to 2 GHz 2 to 8 GHz 8 to 20 GHz
Directivity (dB) 42 42 38 36
Source Match (dB) 37 37 31 28
Load Match (dB) 42 42 38 36
Refl. Tracking
Magnitude (dB) ±(0.006 + .02/°C) ±(0.006 + .03/°C) ±(0.006 + .03/°C) ±(0.009 + .04/°C)
Phase (deg) ±(0.040 + 0.1/°C) ±(0.040 + 0.1/°C) ±(0.040 + 0.3/°C) ±(0.059 + 0.5/°C)
Trans. Tracking
Magnitude (dB) ±(0.028 + .02/°C) ±(0.03 + .03/°C) ±(0.096 + .03/°C) ±(0.158 + .04/°C)
Phase (deg) ±(0.185 + 0.1/°C) ±(0.198 + 0.1/°C) ±(0.634 + 0.3/°C) ±(1.04 + 0.5/°C)
Transmission Uncertainty (Specification)
Reflection Uncertainty (Specification)

1-6
HP 8719/20/22ES Specifications and Characteristics
Corrected System Performance (HP 8719/20ES)
Table 1-4 3.5-mm Device Connector Type
Network Analyzer: HP 8719ES/20ES, Standard
Calibration Kit: HP 85052B (3.5-mm, 50 Ω)
Cables: HP 85131F
Calibration: Full 2-Port
IF BW = 10 Hz, Avg off, Temp = 23 ±3°Cwith < 1°Cdeviation from cal temp, Isol cal with avg = 8
Description Specification
50 to 500 MHz 0.5 to 2 GHz 2 to 8 GHz 8 to 20 GHz
Directivity (dB) 48 48 44 44
Source Match (dB) 40 40 33 31
Load Match (dB) 48 48 44 44
Refl. Tracking
Magnitude (dB) ±(0.006 + .02/°C) ±(0.006 + .03/°C) ±(0.006 + .03/°C) ±(0.008 + .04/°C)
Phase (deg) ±(0.040 + 0.1/°C) ±(0.040 + 0.1/°C) ±(0.040 + 0.3/°C) ±(0.053 + 0.5/°C)
Trans. Tracking
Magnitude (dB) ±(0.017 + .02/°C) ±(0.018 + .03/°C) ±(0.066 + .03/°C) ±(0.099 + .04/°C)
Phase (deg) ±(0.112 + 0.1/°C) ±(0.119 + 0.1/°C) ±(0.436 + 0.3/°C) ±(0.653 + 0.5/°C)
Transmission Uncertainty (Specification)
Reflection Uncertainty (Specification)

1-7
HP 8719/20/22ES Specifications and Characteristics
Corrected System Performance (HP 8719/20ES)
Table 1-5 3.5-mm Device Connector Type
Network Analyzer: HP 8719ES/20ES, Option 400
Calibration Kit: HP 85052C (3.5-mm, 50 Ω)
Cables: HP 85131F
Calibration: TRL
IF BW = 10 Hz, Avg off, Temp = 23 ±3°Cwith < 1°Cdeviation from cal temp, Isol cal with avg = 8
Description Specification
50 to 500 MHz 0.5 to 2 GHz 2 to 8 GHz 8 to 20 GHz
Directivity (dB) 48 48 50 50
Source Match (dB) 40 40 50 50
Load Match (dB) 48 48 50 50
Refl. Tracking
Magnitude (dB) ±(0.006 + .02/°C) ±(0.006 + .03/°C) ±(0.005 + .03/°C) ±(0.005 + .04/°C)
Phase (deg) ±(0.040 + 0.1/°C) ±(0.040 + 0.1/°C) ±(0.033 + 0.3/°C) ±(0.033 + 0.5/°C)
Trans. Tracking
Magnitude (dB) ±(0.013 + .02/°C) ±(0.017 + .03/°C) ±(0.016 + .03/°C) ±(0.019 + .04/°C)
Phase (deg) ±(0.086 + 0.1/°C) ±(0.112 + 0.1/°C) ±(0.107 + 0.3/°C) ±(0.125 + 0.5/°C)
Transmission Uncertainty (Specification)
Reflection Uncertainty (Specification)

1-8
HP 8719/20/22ES Specifications and Characteristics
Corrected System Performance (HP 8719/20ES)
Table 1-6 3.5-mm Device Connector Type
Network Analyzer: HP 8719ES/20ES, Option 007
Calibration Kit: HP 85052B (3.5-mm with Sliding Loads, 50 Ω)
Cables: HP 85132F
Calibration: Full 2-Port
IF BW = 10 Hz, Avg off, Temp = 23 ±3°Cwith < 1°Cdeviation from cal temp, Isol cal with avg = 8
Description Specification
0.05 to 0.5 GHz 0.5 to 2 GHz 2 t0 8GHz 8 to 20 GHz
Directivity (dB) 48 48 44 44
Source Match (dB) 40 39 32 30
Load Match (dB) 48 45 38 37
Refl. Tracking
Magnitude (dB) ±(0.006 + .02/°C) ±(0.010 + .03/°C) ±(0.030 + .03/°C) ±(0.031 + .04/°C)
Phase (deg) ±(0.040 + 0.1/°C) ±(0.066 + 0.1/°C) ±(0.198 + 0.3/°C) ±(0.205 + 0.5/°C)
Trans. Tracking
Magnitude (dB) ±(0.011 + .02/°C) ±(0.016 + .03/°C) ±(0.066 + .03/°C) ±(0.108 + .04/°C)
Phase (deg) ±(0.073 + 0.1/°C) ±(0.106 + 0.1/°C) ±(0.436 + 0.3/°C) ±(0.713 + 0.5/°C)
Transmission Uncertainty (Specification)
Reflection Uncertainty (Specification)

1-9
HP 8719/20/22ES Specifications and Characteristics
Corrected System Performance (HP 8719/20ES)
Table 1-7 3.5-mm Device Connector Type
Network Analyzer: HP 8719ES/20ES, Option 007
Calibration Kit: HP 85052D (3.5-mm 50 Ω)
Cables: HP 85132F
Calibration: Full 2-Port
IF BW = 10 Hz, Avg off, Temp = 23 ±3°Cwith < 1°Cdeviation from cal temp, Isol cal with avg = 8
Description Specification
0.05 to 0.5 GHz 0.5 to 2 GHz 2 t0 8GHz 8 to 20 GHz
Directivity (dB) 42 42 38 36
Source Match (dB) 37 37 30 28
Load Match (dB) 42 41 36 34
Refl. Tracking
Magnitude (dB) ±(0.006 + .02/°C) ±(0.010 + .03/°C) ±(0.030 + .03/°C) ±(0.031 + .04/°C)
Phase (deg) ±(0.038 + 0.1/°C) ±(0.069 + 0.1/°C) ±(0.200 + 0.3/°C) ±(0.205 + 0.5/°C)
Trans. Tracking
Magnitude (dB) ±(0.018 + .02/°C) ±(0.019 + .03/°C) ±(0.080 + .03/°C) ±(0.141 + .04/°C)
Phase (deg) ±(0.118 + 0.1/°C) ±(0.123 + 0.1/°C) ±(0.531 + 0.3/°C) ±(0.928 + 0.5/°C)
Transmission Uncertainty (Specification)
Reflection Uncertainty (Specification)

1-10
HP 8719/20/22ES Specifications and Characteristics
Corrected System Performance (HP 8719/20ES)
Table 1-8 7-mm Device Connector Type
Network Analyzer: HP 8719ES/20ES, Standard
Calibration Kit: HP 85050B (7-mm, 50 Ω)
Cables: HP 85132F
Calibration: Full 2-Port
IF BW = 10 Hz, Avg off, Temp = 23 ±3°Cwith < 1°Cdeviation from cal temp, Isol cal with avg = 8
Description Specification
50 to 500 MHz 0.5 to 2 GHz 2 to 8 GHz 8 to 18 GHz
Directivity (dB) 52 52 52 52
Source Match (dB) 48 48 44 41
Load Match (dB) 51 51 51 51
Refl. Tracking
Magnitude (dB) ±(0.006 + .02/°C) ±(0.006 + .03/°C) ±(0.017 + .03/°C) ±(0.047 + .04/°C)
Phase (deg) ±(0.040 + 0.1/°C) ±(0.040 + 0.1/°C) ±(0.112 + 0.3/°C) ±(0.310 + 0.5/°C)
Trans. Tracking
Magnitude (dB) ±(0.01 + .02/°C) ±(0.011 + .03/°C) ±(0.022 + .03/°C) ±(0.034 + .04/°C)
Phase (deg) ±(0.066 + 0.1/°C) ±(0.073 + 0.1/°C) ±(0.145 + 0.3/°C) ±(0.224 + 0.5/°C)
Transmission Uncertainty (Specification)
Reflection Uncertainty (Specification)
