site preparation guide
hp visualization center sv6
Manufacturing Part Number: A6062-90004
Edition: E1001
Printed in U.S.A

legal notices
The information in this document is subject to change without notice.
Hewlett-Packard makes no warranty of any kind with regard to this manual,
including, but not limited to, the implied warranties of merchantability and
fitness for a particular purpose. Hewlett-Packard shall not be held liable for
errors contained herein or direct, indirect, special, incidental or consequential
damages in connection with the furnishing, performance, or use of this material.
restricted rights legends. Use, duplication or disclosure by the U.S. Government
is subject to restrictions as set forth in subparagraph (c) (1) (ii) of the Rights in
Technical Data and Computer Software clause at DFARS 252.227-7013 for DOD
agencies, and subparagraphs (c) (1) and (c) (2) of the Commercial Computer
Software Restricted Rights clause at FAR 52.227-19 for other agencies.
HEWLETT-PACKARD COMPANY
3000 Hanover Street
Palo Alto, California 94304 U.S.A.
Use of this manual, CD(s), flexible disk(s) or tape cartridge(s) supplied for this
product is restricted to this product only. Additional copies of the programs may
be made for security and back-up purposes only. Resale of the programs in their
present form or with alterations, is expressly prohibited.
copyright notices
©copyright 1983-2001 Hewlett-Packard Company, all rights reserved.
Reproduction, adaptation, or translation of this document without prior written
permission is prohibited, except as allowed under the copyright laws.
©copyright 1979, 1980, 1983, 1985-93 Regents of the University of California
This software is based in part on the Fourth Berkeley Software Distribution
under license from the Regents of the University of California.
©copyright 1980, 1984, 1986 Novell, Inc.
©copyright 1986-1992 Sun Microsystems, Inc.
©copyright 1985-86, 1988 Massachusetts Institute of Technology. ©copyright
1989-93 The Open Software Foundation, Inc.
©copyright 1986 Digital Equipment Corporation.
©copyright 1990 Motorola, Inc.
©copyright 1990, 1991, 1992 Cornell University
©copyright 1989-1991 The University of Maryland
©copyright 1988 Carnegie Mellon University
trademark notices. UNIX is a registered trademark in the United States and
other countries, licensed exclusively through X/Open Company Limited.
X Window System is a trademark of the Massachusetts Institute of Technology.

MS-DOS and Microsoft are U.S. registered trademarks of Microsoft Corporation.
OSF/Motif is a trademark of the Open Software Foundation, Inc. in the U.S. and
other countries.
printing history
The manual printing date and part number indicate its current edition. The
printing date will change when a new edition is printed. Minor changes may be
made at reprint without changing the printing date. The manual part number
will change when extensive changes are made.
Manual updates may be issued between editions to correct errors or document
product changes. To ensure that you receive the updated or new editions, you
should subscribe to the appropriate product support service. See your HP sales
representative for details.
First Edition: August 2001
Printing Division:
Hewlett-Packard Co.
Technical Computer Division
3404 E. Harmony Rd.
Fort Collins, CO 80525

4

Contents
5
1. safety information
safety warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
rack stability. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
power distribution units (PDUs) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
potential metallic particulate contamination . . . . . . . . . . . . . . . . . . . .11
2. planning your site
the hp workstation j6000 systems rack . . . . . . . . . . . . . . . . . . . . . . . . . .14
space issues. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
location issues. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
power issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
video/audio issues. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
environmental issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
networking issues. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
when your system arrives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
wide field displays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
location issues. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
power issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
lighting issues. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
video/audio issues. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
environmental issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
emergency precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
storage issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
stereoscopic viewing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
space issues. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
power issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
general installation checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

6
Contents

Chapter 1 7
1safety information
Proper site preparation and maintenance are vital to the reliability of
any computer hardware component. In order for HP to provide you with
quality service, please ensure that the proper computer room conditions
are maintained. This allows HP to provide support services in

safety information
safety warnings
Chapter 18
accordance with the Customer Support Services Agreement.
For your protection, HP products are tested for conformance to various
national and international regulations and standards. The scope of this
regulatory testing includes electrical and mechanical safety,
electromagnetic emissions, electromagnetic immunity, ESD (electrostatic
discharge), acoustics, and hazardous materials. Where required,
certifications are obtained from third-party test agencies. Certification
marks appear on the product label. In addition, various regulatory
bodies require information to appear in User Manuals.
safety warnings
WARNING An hp visualization center sv6 product rack can weigh 1500 lbs.
(681 kg) when fully loaded with hardware components. Heed all
of the conditions in the WARNING statement under the RACK
STABILITY subsection below when moving and servicing an HP
product rack and its rack-mounted hardware components.
WARNING Your hp visualization center sv6 product may not have been
evaluated for connection to an IT power system (an AC
distribution system having a high impedance connection to
earth according to IEC 950).
rack stability
WARNING To reduce the risk of rack instability:
•Install the heavier hardware components at the bottom of the
rack, below the center of gravity for the rack. Never install
heavier components in the top or upper portion of the rack.

safety information
safety warnings
Chapter 1 9
•Make sure that the anti-tip plate is installed on the rack. Do
not remove the anti-tip foot from the rack.
•Always extend the anti-tip plate before extending a
rack-mounted component for servicing.
•Extend only one rack-mounted component at a time.
•Do not stand or sit on any extended component.
•Have all non-operator servicing done by qualified HP service
personnel.
power distribution units (PDUs)
A Power Distribution Unit (PDU) is equipment located in or near a
computer room which breaks down electric power from a high-voltage
source to appropriate levels of distribution to the central processing unit
and peripheral devices of a computer system. Figure 1-1 shows an
example PDU that is used with the HP product racks. This example is
the HP E7674A 16 Amp 100-240VAC PDU (part number A5137AZ).
CAUTION Some components have been designed to be used with specific electrical
accessories such as PDUs. The use of any accessory other than those
specified is neither recommended nor supported.
Figure 1-1 A Sample Power Distribution Unit (PDU)
IEC320-C13
IEC320-C19
Modular PDU
Qty=7
C20 Inlet

safety information
safety warnings
Chapter 110
Figure 1-2 Cable and Plugs Between the PDU and the Wall Receptacle
PDU leakage current
WARNING Due to the number of components that can be installed on one
Power Distribution Unit (PDU), there may be a risk of high
leakage current (>3.5mA). Reliable ground circuit continuity is
vital for safe operation of such components. To reduce the risk of
electric shock, connect each component to a grounded outlet
only. Never operate any component with its ground pin
disconnected from the socket of a grounded outlet.
L6-20P
IEC309
IEC-320-C19
L6-30P
CEE7/7
Unterminated

safety information
safety warnings
Chapter 1 11
PDU power limitations
CAUTION To reduce the risk of overload, do not exceed the rated load of any single
PDU. In addition, do not load a single NEMA 5-15 (see Fig. 1-3)
receptacle with more than 15 Amperes and any single IEC 320-1/C13
receptacle with more than 10 Amperes. In general, make sure that the
power source circuits are able to safely provide the current that will be
required by all components drawing power from them. This document
assumes that 220V and 240V cables are used.
Figure 1-3 NEMA 5-15 Receptacle
potential metallic particulate contamination
Metallic particulates can be especially harmful around electronic
equipment. This type of contamination may enter the data center
environment from a variety of sources, including, but not limited to,
raised floor tiles, worn air conditioning parts, heating ducts, rotor
brushes in vacuum cleaners or printer component wear. Because metallic
particulates conduct electricity, they have an increased potential for
creating short circuits in electronic equipment. This problem is
exaggerated by the increasingly dense circuitry of electronic equipment.
Over time, very fine whiskers of pure metal can form on electroplated
zinc, cadmium, or tin surfaces. If these whiskers are disturbed, they may
break off and become airborne, possibly causing failures or operational
interruptions. For over 50 years, the electronics industry has been aware
of the relatively rare, but possible, threat posed by metallic particulate
contamination. During recent years, a growing concern has developed in
computer rooms where these conductive contaminants are formed on the
bottom of some raised floor tiles.
Do not load this
connector with
more than 15 Amps

safety information
safety warnings
Chapter 112
Although this problem is relatively rare, it may be an issue within your
computer room. Since metallic contamination can cause permanent or
intermittent failures on your electronic equipment, Hewlett-Packard
strongly recommends that your site be evaluated for metallic particulate
contamination before installation of electronic equipment.

Chapter 2 13
2planning your site
This chapter covers site and installation planning for hp visualization
center sv6 solutions. It can help you anticipate issues before installation
and operation. It assumes you are familiar with local regulatory codes
(e.g. building, fire, power, safety, etc.) which might affect installation.

planning your site
the hp workstation j6000 systems rack
Chapter 214
the hp workstation j6000 systems rack
This section will explain the site preparation requirements for the hp
workstation j6000 systems rack (see Fig. 2-1) that is at the heart of your
hp visualization center solution. All other standard HP computer
considerations for space, safety, power, environmental conditions
(temperature, humidity, dust, ventilation, clearances, etc.), delivery,
servicing, and supply apply to systems discussed here. Consult your local
HP Service Representatives for additional information on HP system
components.
Use this checklist to determine if your site is ready for your hp
visualization center product. Place a check mark in the ❑box located to
the left of each question when you meet that section’s requirements.
When all of the boxes are checked, your site is ready for your hp
visualization center sv6. A General Installation Checklist is also
provided on page 27.
Figure 2-1 Typical j6000 Systems Rack
8-Pipe sv6
System

planning your site
the hp workstation j6000 systems rack
Chapter 2 15
space issues
Figure 2-2 Rack Floor Space/Service Space Requirements
Table 2-1 Dimensions for j6000 Rack (max. 20 systems per rack)
Component A (Depth) B (Width) C (Height) D (Service
Area)
E (Extended
Component
on Rails)
F (anti-tip
plate)
41U Rack
alone 36.5 in (.9m) 23.5 in (.6m) 77.5 in (1.96m) 36 in (.92m) Total=72in
(1.83m)
27 in (.68m) 13in
(.33m)
Rack
packaged 48 in (1.22m) 40 in (1.02m) 86.5 in (2.2m) 36 in (.92m) Total=72in
(1.83m)
not applicable not applicable
Table 2-2 Weight of j6000 Racked Systems
System Weight
Single hp workstation j6000 39.9 lbs. (18.09 Kg.)
hp workstation j6000 Rack-mount Kit 9.6 lbs. (4.35 Kg.)
41U Rack w/out systems installed 250 lbs. (113.64 Kg.)
Fully loaded rack (max. 20 hp j6000 systems) 1240 lbs. (563.64 Kg.)

planning your site
the hp workstation j6000 systems rack
Chapter 216
Footprint ❑Do you have the required floor and service space
for the hp j6000 systems rack? See Figure 2-2 and
Table 2-1 and 2-2 for specifications.
Delivery ❑Do you have the means to get the rack product
from the loading dock to the room where it will be
installed? For example:
• Pallet jack (a fork lift is NOT recommended)
• Electric transport cart
• Electrical lifting device
• Manpower
• Elevators
❑Are doorways at least 86.5 in (2.2m)tall and 48 in
(1.22m) wide in order to safely move the rack(s)?
Remember to increase these dimensions to include
the means of moving the product (pallets, etc.).
hp j6000 systems racks are very top heavy and easily
tipped over. Make sure you have sufficient help to
steady the load as you transport it.
Typical systems rack (as shipped)

planning your site
the hp workstation j6000 systems rack
Chapter 2 17
location issues
Additional
devices ❑Multi-channel configurations may require workstation consoles to be located next to each other
- does your space plan accommodate this?
❑Does your space plan anticipate future needs for
additional equipment?
❑If a projection display used, is space for its control
console anticipated?
Ergonomics ❑Does your space plan abide by proper ergonomic
rules and considerations?
❑Is ambient glare on console screens properly
controlled?
Proximity ❑If a projection display is used, can the operator see
console and display simultaneously? (Sometimes
demonstration rooms may require a console placed at
right angles to screen.)
❑Is telephone service conveniently close to system for
troubleshooting?
Access ❑Are all areas of the system accessible for easy
reconfiguration, upgrade, maintenance, and trouble
shooting?
❑Is system security an issue?
❑Is mobility of systems a consideration?

planning your site
the hp workstation j6000 systems rack
Chapter 218
power issues
video/audio issues
Supply ❑Is there adequate power for each system in the
configuration? See Table 2-3.
❑If a projection display is used, are its circuits kept
separate from the workstation circuits?
❑Is surge protection and line filtering adequate for
all powered systems?
❑Does the power supply meet local fire safety and
emergency shut-off requirements?
❑Are extension cords and power strips properly
excluded from your power supply plan? (These
temporary forms of supply are not recommended for
any installation.)
Table 2-3 HP visualization center Power Requirements
Parameter Total Rating
Voltage 100-120 V 220-240 V
Current (Max) 120.22 A 60.22 A
Power
j6000 System (single)
Gigabit Switch
100BaseT Switch
Compositor
DigiSwitch
530 Watts/ea. (max.)
200 Watts (max.)
240 Watts (max.)
325 Watts (max.)
22 Watts (max.)
Video ❑If a projection display is used, can workstations
be easily disconnected from projector system to
troubleshoot?
Audio ❑If a projection display is used, does audio system
disrupt people in the surrounding environment?

planning your site
the hp workstation j6000 systems rack
Chapter 2 19
environmental issues
networking issues
Air Conditioning
and Ventilation ❑Does your site air conditioning system meet these requirements?
• Can cooling be maintained between 41oF and
86oF (5oC and 30oC)? NOTE: Inlet
temperature must not exceed 86oF (30oC).
• Can temperature rate of change be held at less
than 10oC per hour?
• Can the humidity level be maintained between
15% and 80%?
• Are air conditioning filters installed?
• Is your air conditioning sized properly for the
load?
The following estimates are average values for
loaded computers, compositors and switches only.
Units are in approximate BTUs per hour per
system. Figures are based on: 1 Watt = 3.41214
BTU/hr.
System BTUs
j6000 System (single) 1808.4
Compositor 1108.9
Gigabit switch 682.4
100BaseT switch 818.9
DigiSwitch 75.1
Connectivity ❑Because systems often use data on remote servers,
is the network bandwidth sufficient, both to and from
the system?
❑Are the workstations isolated from high traffic
network paths?

planning your site
when your system arrives
Chapter 220
when your system arrives
See the hp visualization center sv6 Installation and User’s Guide for
more installation details. See
/opt/graphics/OpenGL/doc/sv/Troubleshoot.pdf for additional help.
These files are also available on the Recovery CD under /Docs/*.pdf.
1. Verify Your Hardware Setup
The systems will arrive fully configured. There are just a few physical
connections that have to be made after unpacking.
•Unpack racks
— Verify that boxes are undamaged before opening.
— Check the packing slip and verify that you received all
equipment on the list.
— Position the racks.
WARNING Before doing any further configuration, pull out or bolt on
the anti-tip plate at the bottom of each rack. Failure to do
so will pose a serious safety risk, as the rack could tip over.
•Connect Extras
— If you have multiple racks, connect them as indicated by the
labels on the disconnected cables.
—Power & I/O devices:
❏See power, space, and cooling requirements in this
document.
❏Plug in power for each rack.
❏Attach keyboard and mouse to the system labeled Master.
❏Attach the stereo emitter to the controller card of the
compositor (optional)
❏Attach your display device to the output card of the
compositor via a standard analog monitor cable.
—Network
