HP 705 Workstation User manual

HP DDS-DC T ape Drive
User’s Guide

Workstation Systems Group
Order No. A1658–90696
Edition E0796
Printed in U.S.A.

Hewlett-Packard Co. 1996
First Printing: July 1996
UNIX
is a registered trademark in the United States and other countries, licensed exclusively through
X/Open Company Limited.
NOTICE
The information contained in this document is subject to change without notice.
HEWLETT–PACKARD MAKES NO WARRANTY OF ANY KIND WITH REGARD TO THIS
MATERIAL INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Hewlett-Packard shall
not
be liable for errors contained herein or for incidental or consequential damages in connection with
the furnishing, performance or use of this material.
Hewlett-Packard
assumes no responsibility for the use or reliability of its software on equipment that is
not furnished by Hewlett-Packard.
This
document contains proprietary information which is protected by copyright. All rights reserved.
No part of this document may be photocopied, reproduced or translated to another language without the
prior written consent of Hewlett-Packard Company.
RESTRICTED RIGHTS LEGEND. Use, duplication, or disclosure by government is subject to
restrictions
as set forth in subdivision (c) (1) (ii) of the Rights in T echnical Data and Computer Software
Clause at DFARS 252.227.7013. Hewlett-Packard Co., 3000 Hanover St., Palo Alto, CA 94304.
10 9 8 7 6 5 4 3 2 1

iii
Contents
Preface
Audience vii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety and Regulatory Statements viii . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation Notice ix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Related Manuals x . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Revision History x . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Questions, Suggestions, or Problems xi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Documentation Conventions xi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 1 Introduction
General Description 1–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DDS-DC Drive Environmental Requirements 1–3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DDS-DC Drive Physical Specifications 1–5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Preparing to Install the DDS-DC Drive 1–6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
T ools Required 1–6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Verifying Kit Contents 1–6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operating System Support 1–6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setting the SCSI-2 Address 1–7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Address Jumpers 1–8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Preparing the System 1–11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SCSI-2 Connection and Termination 1–13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Powering Off the Workstation and Any Peripherals 1–14 . . . . . . . . . . . . . . . . . . . . . . . . . .
Adding or Removing the DDS-DC Drive Bezels or Expansion Brackets 1–15 . . . . . . . . . .

Contents
iv
Chapter 2 Using the DDS-DC Drive
Your DDS-DC Drive Configuration 2–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Controls and Features of the DDS-DC Drive 2–2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
LEDs 2–3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Data Cassettes 2–3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Media Life 2–3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning the T ape Heads 2–4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Media Restrictions 2–4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setting the Write-Protect T ab on a Data Cassette 2–4 . . . . . . . . . . . . . . . . . . . . . . .
Using the DDS-DC Drive 2–6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Loading and Unloading a Data Cassette 2–6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Verifying the DDS-DC Tape Drive Operation 2–7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Media Interchangeability Restrictions 2–8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ordering Information 2–8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 3 Troubleshooting and Removal/Replacement Procedures
Troubleshooting 3–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the Address Settings for Single-Ended Drives 3–2 . . . . . . . . . . . . . . . . . . . .
Checking the Hardware Installation 3–4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rechecking the Address Settings 3–6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Verifying the System Operation Using the Support T ools Manager 3–6 . . . . . . . . . . . .
Removal/Replacement Procedures 3–9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Field Replaceable Units 3–9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Powering Off the System 3–9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Removing and Replacing the DDS-DC Drive 3–10 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Adding or Removing the DDS-DC Drive Bezels and Expansion Brackets 3–10 . . . . . .
Appendix A SCSI Connector Pinouts

Contents
v
Figures
1–1. HP DDS-DC Drive 1–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1–2. HP DDS-DC Drive Physical Specifications 1–5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1–3. Rear View of DDS-DC Drive and SCSI Address/Jumper Settings 1–9 . . . . . . . . . . .
1–4. Switch Settings for Data Compression Mode 1–10 . . . . . . . . . . . . . . . . . . . . . . . . . .
1–5. Adding a Bezel to the DDS-DC Drive 1–15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1–6. Removing a Bezel from the DDS-DC Drive 1–16 . . . . . . . . . . . . . . . . . . . . . . . . . . .
1–7 Adding or Removing Expansion Brackets 1–16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2–1. DDS-DC Drive Controls and Indicators 2–2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2–2. Setting the Write-Protect Tab on a DDS Tape 2–5 . . . . . . . . . . . . . . . . . . . . . . . . . . .
2–3. Loading a Data Cassette 2–6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3–1. Adding a Bezel to the DDS-DC Drive 3–15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3–2. Removing a Bezel from the DDS-DC Drive 3–15 . . . . . . . . . . . . . . . . . . . . . . . . . . .
3–3. Adding or Removing Expansion Brackets 3–16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tables
2–1. LED Display Codes 2–3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2–2. HP DDS Drive Compatibility 2–8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
A–1. SCSI Connector Pinouts A–1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

vii
Preface
The HP DDS-DC T ape Drive User ’ s Guide describes how to install, configure, and use
the DDS-DC drive.
We’ve organized this guide as follows:
Chapter 1 Provides a general description of the DDS-DC drive and the procedures
for installing it into a system.
Chapter 2 Describes the DDS-DC drive configurations, its controls and features, and
provides directions for using it.
Chapter 3 Provides information on caring for DDS tapes, troubleshooting
information, and removal/replacement procedures for the DDS-DC drive.
Appendix A Lists the pinouts for the SCSI connector on the DDS-DC drive.
Audience
This guide is intended for use by anyone familiar with the the HP workstations who
wants to install and configure the DDS drive.

Preface
viii
Safety and Regulatory Statements
See the Owner’s Guide that came with your system for safety informtion.
Emissions Regulations
Federal Communications Commission (FCC)
The Federal Communications Commission of the U.S. government regulates the radio
frequency energy emanated by computing devices through published regulations. These
regulations specify the limits of radio frequency emission to protect radio and television
reception. All HP Apollo nodes and peripherals have been tested and comply with these
limits. The FCC regulations also require that computing devices used in the U.S. display
the agency’s label and that the related documentation include the following statement:
NOTICE: This equipment has been tested and found to comply with the limits
for a Class A digital device, pursuant to part 15 of the FCC rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment
in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at his own
expense.
Canadian Department of Communications (CDC)
This digital apparatus does not exceed the Class A limits for radio noise emissions from
digital apparatus as set out in the Radio Interference Requirements of the Canadian
Department of Communications.

Preface
ix
Emissions Regulations Compliance
Any third-party I/O device installed in HP system(s) must be in accordance with the
requirements set forth in the preceding Emissions Regulations statements. In the event
that a third-party noncompliant I/O device is installed, the customer assumes all
responsibility and liability arising therefrom.
Electrostatic Discharge (ESD) Precautions
Electrostatic charges can damage the integrated circuits on printed circuit boards. To
prevent such damage from occurring, observe the following precautions during board
unpacking and installation:
•Stand on a static-free mat.
•Wear a static strap to ensure that any accumulated electrostatic char ge is
discharged from your body to ground.
•Connect all equipment together, including the static-free mat, static strap, routing
nodes, and peripheral units.
•Keep uninstalled printed circuit boards in their protective antistatic bags.
•Handle printed circuit boards by their edges, once you have removed them from their
protective antistatic bags.
Installation Notice
Products designated in the applicable Hewlett-Packard price list as customer-installable
can be installed by computer-knowledgeable customers who carefully read and follow the
instructions provided. Customers who elect to have the product installed by our field
personnel are charged the applicable field installation charge, as covered under the
standard terms and conditions. For more information, please contact your local sales
representative.

Preface
x
Related Manuals
For more information, refer to the following documents:
•The Owner’s Guide that came with your system
•HP-UX Installing Peripherals: HP 9000 Series 700 (B2355–90006)
•Using Your HP Workstation (A2615–90003)
•HP V isual User Envir onment User ’s Guide (B1171–90061)
•System Administration T asks HP 9000 Series 700 Computers (B2355–90040)
•Using HP-UX (B2910–90001)
Documents specific to HP DDS drives:
•HP DDS-2 T ape Drive User ’s Guide (A1658–90689)
•Integration Guide, Vol 2 of HP DDS Technical Manual (C1533–90906)
•The SCSI Interface, Vol 3 of HP DDS Technical Manual (C1533–90907)
•Background to DDS Pr oducts , V ol 4 of HP DDS T echnical Manual (C1533–90908)
•HP DDS Configuration Guide , V ol 5 of HP DDS T echnical Manual (C1533–90915)
Contact your HP supplier for copies.
Revision History
The revision history for each edition of the manual is listed below:
Edition Revision History
E0796 First Printing

Preface
xi
Questions, Suggestions, or Problems
If you have any questions, suggestions, or problems with our hardware, software, or
documentation, please call 1–888–301–5932 (U.S. and Canada), or contact the HP
Response Center for your country.
Documentation Conventions
Unless otherwise noted in the text, this guide uses the following symbolic conventions:
literal values Bold words or characters in formats and command descriptions
represent commands that you must use literally. Pathnames are
also in bold.
user-supplied Italic words or characters in formats and command descriptions
values represent values that you must supply. Italics are also used in
text for emphasis.
screen display Information that the system displays appears in this typeface.
Return A rectangle with rounded corners and a key label denotes a key on
your keyboard. (In this manual we refer to the Return key. On
your keyboard the key may be labeled either Return or Enter.)
This symbol indicates the end of a chapter or appendix.

1–1
Chapter 1
Introduction
This document describes the HP DDS-DC drive (HP model number C1536A), its
installation, operation, troubleshooting, and removal/replacement procedures.
This chapter introduces the DDS-DC drive and contains the following information:
•General description of the drive
•Preparing to install the drive
•Preparing the system
•Powering off the workstation and any peripherals
•Adding or removing the DDS-DC drive bezels or expansion brackets

Introduction
1–2
General Description
The HP DDS-format drives have been developed by Hewlett Packard for data storage
drives that build on DAT technology. The DDS-DC drive has 2-GB native capacity,
yielding up to 4 GB of stored data. Figure 1–1 shows the DDS-DC drive.
Figure 1–1. HP DDS-DC Drive

Introduction
1–3
DDS-DC Drive Environmental Requirements
The DDS-DC drive has the following environmental requirements:
•Ambient Temperature
Operating 5_C to 40_C
(41_F to 104_F)
Non-Operating –40_C to 70_C
(–40_F to 158_F)
•Humidity
Operating 20% to 80%RH (non-condensing)
Non-Operating 5% to 95%RH
Maximum wet bulb temperature = 26_C
•Vibration
Operating (3 axes for drives, 1 axis for autoloaders)
Swept Sine 0.3 g peak, 5–500 Hz @ 1 octave/min
Random 5–350 Hz @ 0.00053 g2/Hz
HP C1534A/ 350–500 Hz @ –6 dB/octave
36A/53A 500 Hz @ 0.000271 g2/Hz (≈0.5 g rms)
Random 5–350 Hz @ 0.0002 g2/Hz
HP C1533A/ 350–500 Hz @ –6 dB/octave
HP C1537A 500 Hz @ 0.0001 g2/Hz (≈0.3 g rms)
Non-Operating
Swept Sine 0.75 g peak, 5–500 Hz @ 1 octave/min
Random 5–100 Hz @ 0.020 g2/Hz
100–137 Hz @ –6 dB/octave
137–350 Hz @ 0.0107 g2/Hz
350–500 Hz @ –6 dB/octave
500 Hz @ 0.0052 g2/Hz (≈2.41 g rms)

Introduction
1–4
•Shock
Operating (3 axes for drives)
no performance change 5.0 g peak for 3 ms: half sine
Operating (3 axes for drives)
no data loss 8.0 g peak for 11 ms: half sine
Non-Operating (3 axes)
no damage 0 km to 15.2 km (0 to 50,000 ft)
•Altitude
Operating 0 km to 4.6 km (0 to 15,000 ft)
Non-Operating 0 km to 15.2 km (0 to 50,000 ft)
•Transportation
Vibration Type 1 package (3 axes)
Swept Sine 0.5 g peak, 5–200–5 Hz @ 1 octave/min
5 min dwell at peak resonance
Random 5–100 Hz @ 0.015 g2/Hz
100–200 Hz @ –6 dB/octave
200 Hz @ 0.0038 g2/Hz(≈1.47 g rms)
(30 min/axis)
Impact Type 1 package
10 vertical impacts (6 faces and 4 bottom package corners from
910 mm height)
•Suspended Particles
Operating and Non–Operating Suspended particle environment,
particles <200 microgram/cubic meter
• Acoustic Noise Emissions
<5.0 bel soundpower

Introduction
1–5
DDS-DC Drive Physical Specifications
Figure 1–2 describes the physical specifications of the DDS-DC drive.
150 mm (5.85 in.)
+++
60 mm
90 mm
4 mm
21 mm
(0.82 in.) (2.34 in.)
(3.51 in.)
41.3 mm
(1.61 in.)
5 mm
(0.20 in.)
101.6 mm (3.96 in.)
41.3 mm
(1.61 in.)
101.6 mm
(3.96 in.)
++
++
94 mm
(3.66 in.)
3.8 mm
(.15 in.)
30.9 mm
(1.20 in.)
70 mm
(2.73 in.)
(0.15 in.)
Figure 1–2. HP DDS-DC Drive Physical Specifications

Introduction
1–6
Preparing to Install a New DDS-DC Drive
The following information describes how to prepare the DDS-DC drive for installation.
Tools Required
The following tools are needed to install the DDS-DC drive:
•#2 Phillips screwdriver
•Small needlenose pliers
•T10 torx wrench
Verifying Kit Contents
Verify that the kit contains one of each of the following:
•DDS-DC drive (part number 0950–3002) and bezel.
•Set of 4 screws (M4x6)
•Power adapter cable
•SCSI I/O cable
•Static strap
•HP DDS-DC T ape Drive User ’ s Guide (A1658–90696)
NOTICE: If any contents of your kit are missing, contact your sales
representative.
Operating System Support
The HP DDS-DC drive supports HP-UX 9.01 and later. This drive does not require any
patches.

Introduction
1–7
Setting the SCSI-2 Address
The DDS-DC drive must have a unique SCSI-2 target address. The DDS-DC drive
jumpers are set at the factory to the SCSI-2 default address of 3, as shown in Figure 1–3.
We recommend that you keep the default address, if possible.
You must also ensure that the Operation Mode jumpers are set for correct drive operation,
as shown in Figure 1–4. We ship the drive with the Operation Mode jumpers set to
operate correctly with your system.
CAUTION: SCSI tape drives are susceptible to mechanical and electrostatic
shock. When handling a DDS-DC drive, always wear the static-
grounding wrist strap that comes in the DDS-DC drive kit, and al-
ways handle the drive carefully.
Electrostatic charges can damage drives. To prevent such damage
from occurring, observe the following precautions during unpack-
ing and installation:
DStand on a static-free mat.
DWear a static strap to ensure that any accumulated electrostatic
charge discharges from your body to ground.
DConnect all equipment together, including the static-free mat,
static strap, routing nodes, and peripheral units.
DKeep uninstalled DDS-DC drives in their protective antistatic
bags.
If you need to change the DDS-DC drive address or operation mode, follow these
instructions, referring to Figures 1–3 and 1–4:
1. Locate the jumpers at the back of the DDS-DC drive.
2. To change the jumper settings, use needlenose pliers to set the drive’s SCSI ID to an
address that is not used by another SCSI device. Check that the other jumpers are set
correctly.

Introduction
1–8
3. If you need to change the Operation Mode switches, locate the switches on the un-
derside of the DDS-DC tape drive. Switches 1 and 2 are used to configure the data
compression operation mode. Switches 3 through 8 are used to specify drive connec-
tivity and functionality according to host or customer requirements. The default set-
ting is all switches ON.
Address Jumpers
To set the drive’s address, use the SCSI-2 address jumpers, and perform the following
steps:
1. Attach the static-grounding wrist strap by following the instructions on the package.
Attach one end of the strap to the system chassis.
2. Locate the address jumpers on the rear of the DDS-DC drive. Figure 1–3 shows the
rear of the DDS-DC drive with the significant bits identified.
3. Set the drive’s SCSI-2 target address to an address that’s not used by another SCSI-2
device. Using Figure 1–3 as a guide, use needlenose pliers to set the jumpers. When
finished, refer to “Preparing the System,” later in this chapter, for information on
verifying the jumpers have been set correctly and your system sees the drive.
NOTICE: Do not use SCSI-2 address 7 because the system’s SCSI-2
controller uses address 7 by default. We advise that you do not
use
SCSI-2 address 6 because the root disk drive uses it.

Introduction
1–9
Bit
2
Bit
1
Bit
0
Bit 2
Bit 1
Bit 0
SCSI Connector
Power Connector
SCSI
ID
(default)
0
1
2
3
4
5
6
Figure 1–3. Rear View of DDS-DC Drive and SCSI Addr ess/Jumper Settings

Introduction
1–10
 " 
#"!

 


 !! !
 !" " 
 !! 
 !" " 
 !! ! !"
 "   !!
 !! 
" !" " 
 

 

 
Figure 1–4. Switch Settings for Data Compr ession Operation Mode
