HP Pavilion G4T-1000 Installation instructions
EL-MF877-00 Page 1
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Product End-of-Life Disassembly Instructions
Product Category: Other Products
Marketing Name / Model
[List multiple models if applicable.]
HP T1000 G4 NA/JP UPS
HP T1000 G4 INTL UPS
Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions
for the disassembly of HP products to remove components and materials requiring selective treatment, as defined by EU
directive 2002/96/EC, Waste Electrical and Electronic Equipment (WEEE).
1.0 Items Requiring Selective Treatment
1.1 Items listed below are classified as requiring selective treatment.
1.2 Enter the quantity of items contained within the product which require selective treatment in the right column, as
applicable.
Item Description
Notes
Quantity
of items
included
in product
Printed Circuit Boards (PCB) or Printed Circuit
Assemblies (PCA)
With a surface greater than 10 sq cm
PCBA
2
Batteries
All types including standard alkaline and lithium coin
or button style batteries Lead-acid battery
2
Mercury-containing components
For example, mercury in lamps, display backlights,
scanner lamps, switches, batteries
0
Liquid Crystal Displays (LCD) with a surface greater
than 100 sq cm
Includes background illuminated displays with gas
discharge lamps
0
Cathode Ray Tubes (CRT)
0
Capacitors / condensers (Containing PCB/PCT)
0
Electrolytic Capacitors / Condensers measuring
greater than 2.5 cm in diameter or height
Electrolytic Capacitors
3
External electrical cables and cords
2
Gas Discharge Lamps
0
Plastics containing Brominated Flame Retardants
weighing > 25 grams (not including PCBs or PCAs
already listed as a separate item above)
0
Components and parts containing toner and ink,
including liquids, semi-liquids (gel/paste) and toner
Include the cartridges, print heads, tubes, vent
chambers, and service stations.
0
Components and waste containing asbestos
0
Components, parts and materials containing
refractory ceramic fibers
0
EL-MF877-00 Page 2
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Components, parts and materials containing
radioactive substances
0
2.0 Tools Required
List the type and size of the tools that would typically be used to disassemble the product to a point where components
and materials requiring selective treatment can be removed.
Tool Description
Tool Size (if
applicable)
Philips Screw Driver
#2
Torx Head Screw Driver
T10
Socket Wrench
M4
3.0 Product Disassembly Process
3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:
1. Disconnect all power cords, including battery connector;
2. Remove top cover;
3. Remove Front panel assy;
4. Remove batery pack;
5. Remove PCBA and TX
6. Final Disassembly
7. Remove Rubber foot Pads
8.
9.
10.
11.
12.
13.
3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items
contained in the product that require selective treatment (with descriptions and arrows identifying locations).
EL-MF877-00 Page 3
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Step 1: Disconnect all input and output cords, take off front panel manually and then disconnect the battery
wire.
Step 2: Uninstall top cover. Take off 8pcs screws by screwdriver
EL-MF877-00 Page 4
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Step 3: uninstall LCD BOX manually, disconnect the flat wire, and then take off 2pcs screws by screw driver, remove
LCD from LCD BOX.
EL-MF877-00 Page 5
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Step 4: Uninstall battery metal cover by removing screw as below, take out battery
pack.
EL-MF877-00 Page 6
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Step 5: Remove 4 screws on bottom and rear side, disconnect all wires, take off rear panel assy.
EL-MF877-00 Page 7
Template Revision B
PSG instructions for this template are available at EL-MF877-01
EL-MF877-00 Page 8
Template Revision B
PSG instructions for this template are available at EL-MF877-01
EL-MF877-00 Page 9
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Step 6: Remove screws as below picture, uninstall inlets, Fan, USB & PCBA.
EL-MF877-00 Page 10
Template Revision B
PSG instructions for this template are available at EL-MF877-01
EL-MF877-00 Page 11
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Step 7: Disconnect wires, remove screws as below showed, take out main PCBA.
EL-MF877-00 Page 12
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Step 8: Remove screws and uninstall TX.
EL-MF877-00 Page 13
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Step 9: Remove screws from bottom and front side, uninstall the plastic battery bracket.
EL-MF877-00 Page 14
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Step 10: Take off rubber foot PADS manually.
EL-MF877-00 Page 15
Template Revision B
PSG instructions for this template are available at EL-MF877-01
