HP R1500 User manual

HP R/T3000 G2 UPS
User Guide
Abstract
This document includes installation, configuration, and operation information for the HP R/T3000 G2 UPS. This document is for the person who
installs and maintains power products. HP assumes you are qualified in the servicing of high-
voltage equipment and trained in recognizing hazards
in products with hazardous energy levels.
Part Number: 651176-002
June 2012
Edition: 2

© Copyright 2011, 2012 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express
warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall
not be liable for technical or editorial errors or omissions contained herein.
Microsoft®, Windows®, Windows Server®, and Windows Vista® are U.S. registered trademarks of Microsoft Corporation. Bluetooth® is a
trademark owned by its proprietor and used by Hewlett-Packard Company under license.

Contents 3
Contents
Component identification............................................................................................................... 7
UPS R/T3000 G2 overview........................................................................................................................ 7
UPS front panel......................................................................................................................................... 7
UPS front panel controls ............................................................................................................................. 8
UPS front panel LED indicators .................................................................................................................... 8
HP UPS R/T3000 models ........................................................................................................................... 9
R/T3000 NA and R/T3000j JPN rear panel ................................................................................................ 9
R/T3000h NA and R/T3000h JPN rear panel............................................................................................ 10
R/T3000 INT rear panel.......................................................................................................................... 11
REPO port .............................................................................................................................................. 11
ERM rear panel....................................................................................................................................... 12
Installation ................................................................................................................................. 13
Precautions............................................................................................................................................. 13
Preparing to install the hardware............................................................................................................... 13
Tools and materials........................................................................................................................ 13
Selecting a site.............................................................................................................................. 14
Readying the equipment................................................................................................................. 14
Installing the mounting rails ...................................................................................................................... 14
Installing the UPS in a rack ....................................................................................................................... 17
Connecting the battery leads........................................................................................................... 18
Attaching the UPS front bezel.......................................................................................................... 20
Connecting the host computer ......................................................................................................... 20
Connecting the REPO port .............................................................................................................. 21
Connecting the ground bonding cable ............................................................................................. 23
Connecting the UPS to utility power ................................................................................................. 24
Connecting devices to the UPS ........................................................................................................ 24
Connecting the UPS cord retention clips ........................................................................................... 25
Charging the UPS batteries............................................................................................................. 25
Starting power to the load .............................................................................................................. 26
Installing the ERM in a rack ...................................................................................................................... 26
Connecting the battery leads........................................................................................................... 27
Attaching the ERM front bezel ......................................................................................................... 28
Connecting the ERM to the UPS....................................................................................................... 29
Switching on the ERM circuit breaker ............................................................................................... 30
Charging the ERM batteries ............................................................................................................ 30
Installing the optional UPS Network Module ............................................................................................... 31
Connecting the UPS Network Module .............................................................................................. 32
Installing the UPS as a tower..................................................................................................................... 32
Connecting the battery leads........................................................................................................... 33
Rotating the logo badge................................................................................................................. 33
Attaching the UPS front bezel.......................................................................................................... 34
Attaching the tower conversion stands.............................................................................................. 34
Continuing the installation .............................................................................................................. 34
Installing the ERM as a tower.................................................................................................................... 35
Rotating the logo badge................................................................................................................. 35
Attaching the ERM front bezel ......................................................................................................... 35

Contents 4
Attaching the tower conversion stands.............................................................................................. 35
Continuing the ERM installation ....................................................................................................... 37
Installing the extension bars (if included) .................................................................................................... 38
Connecting and securing the power cords.................................................................................................. 39
UPS operations........................................................................................................................... 40
Modes of operation................................................................................................................................. 40
Standby mode .............................................................................................................................. 40
Operate mode .............................................................................................................................. 40
Configure mode ............................................................................................................................ 41
Battery mode ................................................................................................................................ 41
Auto-Bypass mode ......................................................................................................................... 41
Operating the UPS front panel controls ...................................................................................................... 41
Configuring the UPS ................................................................................................................................ 42
Initiating a self-test................................................................................................................................... 43
Silencing an audible alarm....................................................................................................................... 44
Verifying the REPO port connection ........................................................................................................... 44
Powering down the UPS........................................................................................................................... 44
Maintenance.............................................................................................................................. 45
Removing the UPS front bezel ................................................................................................................... 45
Removing the ERM front bezel................................................................................................................... 45
Replacing the batteries............................................................................................................................. 45
Important battery safety information ................................................................................................. 46
Battery care and storage guidelines ................................................................................................. 46
Determining when to replace batteries.............................................................................................. 46
Obtaining new batteries................................................................................................................. 47
UPS battery replacement procedure ................................................................................................. 47
Testing the new battery module ....................................................................................................... 48
Replacing the UPS................................................................................................................................... 49
Replacing the ERM .................................................................................................................................. 49
Replacing the UPS option card.................................................................................................................. 49
Updating the UPS firmware ...................................................................................................................... 50
Configuring a USB to serial converter............................................................................................... 50
Reassigning the USB COM ports ..................................................................................................... 51
Power management .................................................................................................................... 53
Power Protector software.......................................................................................................................... 53
Troubleshooting.......................................................................................................................... 55
LED troubleshooting ................................................................................................................................. 55
UPS is in Auto-Bypass mode...................................................................................................................... 56
UPS is in Converter Off mode ................................................................................................................... 57
General alarm condition .......................................................................................................................... 57
Bypass is out of range.............................................................................................................................. 58
Battery condition ..................................................................................................................................... 58
UPS is on battery..................................................................................................................................... 58
Input voltage is out of range ..................................................................................................................... 58
Overtemperature condition ....................................................................................................................... 59
Internal UPS fault condition....................................................................................................................... 59
REPO condition....................................................................................................................................... 59
Site wiring condition................................................................................................................................ 59
Overload condition ................................................................................................................................. 59
Checksum failure error............................................................................................................................. 60
UPS does not start ................................................................................................................................... 60

Contents 5
Low battery shutdowns............................................................................................................................. 60
UPS does not provide the expected backup time ......................................................................................... 60
UPS frequently switches between utility and battery power............................................................................ 60
Specifications............................................................................................................................. 61
UPS physical specifications....................................................................................................................... 61
ERM physical specifications...................................................................................................................... 61
UPS input specifications ........................................................................................................................... 61
UPS output specifications.......................................................................................................................... 61
Power protection specifications ....................................................................................................... 62
Output tolerance specifications........................................................................................................ 62
Output feature specifications........................................................................................................... 62
Battery specifications ............................................................................................................................... 62
High-voltage UPS battery runtimes ............................................................................................................. 63
Low-voltage UPS battery runtimes .............................................................................................................. 63
Environmental specifications ..................................................................................................................... 63
REPO port specifications .......................................................................................................................... 63
Spares....................................................................................................................................... 64
Ordering spares...................................................................................................................................... 64
UPS spare parts list.................................................................................................................................. 64
ERM spare parts list................................................................................................................................. 65
Hardware options ................................................................................................................................... 65
Support and other resources ........................................................................................................ 66
Before you contact HP.............................................................................................................................. 66
HP contact information............................................................................................................................. 66
Warranty information.................................................................................................................. 67
Limited warranty ..................................................................................................................................... 67
$250,000 Computer Load Protection Guarantee......................................................................................... 67
Pre-Failure Battery Warranty ..................................................................................................................... 67
Recommended duration of use .................................................................................................................. 68
Regulatory compliance notices ..................................................................................................... 69
Regulatory compliance identification numbers............................................................................................. 69
Federal Communications Commission notice............................................................................................... 69
FCC rating label............................................................................................................................ 69
FCC Notice, Class A Equipment...................................................................................................... 69
FCC Notice, Class B Equipment ...................................................................................................... 69
Declaration of conformity for products marked with the FCC logo, United States only....................................... 70
Modifications.......................................................................................................................................... 70
Cables................................................................................................................................................... 70
Canadian notice (Avis Canadien).............................................................................................................. 70
European Union regulatory notice ............................................................................................................. 71
Disposal of waste equipment by users in private households in the European Union......................................... 71
Japanese notice ...................................................................................................................................... 72
BSMI notice............................................................................................................................................ 72
Korean notice ......................................................................................................................................... 72
Chinese notice ........................................................................................................................................ 73
Battery replacement notice........................................................................................................................ 73
Taiwan battery recycling notice................................................................................................................. 73
Power cord statement for Japan................................................................................................................. 74
Electrostatic discharge................................................................................................................. 75

Contents 6
Preventing electrostatic discharge .............................................................................................................. 75
Grounding methods to prevent electrostatic discharge.................................................................................. 75
Acronyms and abbreviations........................................................................................................ 76
Documentation feedback ............................................................................................................. 77
Index......................................................................................................................................... 78

Component identification 7
Component identification
UPS R/T3000 G2 overview
The HP UPS R/T3000 G2 features a 2U rack-mount with convertible tower design and offers power
protection for loads up to a maximum of 3300 VA/3000 W (these numbers might vary by model).
To benefit from the latest product enhancements, update to the latest versions of UPS firmware and software.
NOTE: To download the latest versions of UPS firmware and software, see the HP website
(http://www.hp.com/go/rackandpower).
UPS front panel
Item Description
1 Battery compartment
2 Front panel display

Component identification 8
UPS front panel controls
Item Description Function
1 Test/Alarm Reset button Silences UPS alarms ("Silencing an audible
alarm" on page 44)
2 Off button Places the UPS in Standby mode (on page
40)
3 On button Powers up the UPS ("Starting power to the
load" on page 26)
4 Battery Start button Starts the UPS on battery power when
pressed with the On button
UPS front panel LED indicators

Component identification 9
The front panel is shown with the bezel removed.
Item LED description Load level
1 Self Test On—The load level is greater than 10%.
2 Battery Fault On—The load level is greater than 25%.
3 Site Wiring Fault On—The load level is greater than 50%.
4 Overtemperature On—The load level is greater than 75%.
5 Overload On—The load level is greater than 100%.
6
On Bypass
7 On Battery
8 Utility
For more information, see "LED troubleshooting (on page 55)" .
HP UPS R/T3000 models
UPS model Description
R/T3000 NA and R/T3000j JPN
•
Domestic/Japanese
•
Low-voltage
•
Nondetachable NEMA L5-30 plug
R/T3000h NA and R/T3000h
JPN
•
Domestic
•
High-voltage
•
Nondetachable NEMA L6-20 plug
R/T3000 INT
•
International
•
High-voltage
•
Detachable country-specific plug
R/T3000 NA and R/T3000j JPN rear panel
Item Description
1 UPS option card
2 USB communications port
3 Serial communications port

Component identification 10
Item Description
4 Load segment circuit breaker
5 Load segment 1 (two NEMA 5-20R T-Slot receptacles)
6 Load segment circuit breaker
7 Load segment 2 (two NEMA 5-20R T-Slot receptacles)
8 PDU output (NEMA L5-30R) receptacle (load segment 1)
9 Cord retention clip attachment location
10 Cord retention clip attachment location
11 Ground bonding screw
12 Power cord with L5-30 plug
R/T3000h NA and R/T3000h JPN rear panel
Item Description
1 UPS option card
2
USB communications port
3 Serial communications port
4 Ground bonding screw
5 Load segment 1 and 2 (one IEC-320-C19 receptacle)
6 Load segment 1 (three IEC-320-C13 receptacles)
7 Load segment 2 (three IEC-320-C13 receptacles)
8
PDU output (L6-20) receptacle (load segment 1)
9 Cord retention clip attachment location
10 Cord retention clip attachment location
11 Cord retention clip attachment location
12 Ground bonding screw
13 REPO port
14 Power cord with L6-20 plug
