hpmont HD31-4T2P2P User manual

V1.1 2017.07
HD31 Series
Aqua Inverter
User Manual
HD31 Series Aqua Inverter

FOREWORD
Thank you for purchasing HD31 series aqua inverter manufactured by Shenzhen
Hpmont Technology Co., Ltd.
This User Manual describes how to use HD31 series inverters and their installation
wiring, parameter setting, troubleshooting and daily maintenance etc.
Before using the product, please read through this User Manual carefully. In addition,
please do not use this product until you have fully understood safety precautions.
Note:
Preserve this Manual for future.
Due to product upgrade or specification change, and for the purpose of
improving convenience and accuracy of this manual, this manual’s contents may
be modified.
If you need the User Manual due to damage, loss or other reasons, please contact
the regional distributor of our company or directly contact our company Technical
Service Center.
For the first time using, the user should carefully read this manual.
If you still have some problems during use, please contact our company Technical
Service Center.
Email address: [email protected]

Co
n
n
ection
w
ith
p
eri
p
h
eral devices
Three-phase AC power supply
MCCB
Contactor
AC input reactor
(accessory)
EMI filter
EMI filter
AC output reactor
(accessory)
Motor
HD31
Braking resistor
(accessory)
DC reactor
(accessory)

Version and Revision Records
The version information is on top of the backbone and the bottom left of the cover.
Time: 2017/07
Version: V1.1
Revised chapter Revised contents
• New model: HD31-4T2P2P, HD31-4T3P7P
• Refer to 2.3 Rated Value, 4.2.1 Wiring specifications of input and output, 9.3 Braking
Resistor and Braking Unit for details
• Modify the input and output lines, see 4.2.1
• New content: 4.2.2 Power terminal lug.
• Add adjustment in switching from variable frequency to power frequeny, see 7.2
• Add fault: E00.37 (Input wrong phase), see Chapter 8
Chapter 6
Appendix A
• Change the pressure unit to: kg/cm2
• Concrete parameter: P00.05, P02.01, P02.04, P02.06, P02.08, P02.10, P02.12, P02.14, P02.16,
P02.18, P02.20, P02.22, P02.24, P02.26, P04.00, P04.02
• Add d00.42 (Set water supply pressure), d00.43 (Actual water supply pressure)
• Add F00.04 (Extension card selection)
• F15.00 – F15.08 (DI function) add: 54 Clear fault records
• F18.02 – F18.13 (Set parameter of run/stop status) modify:
• Add: 35 (Content water supply pressure setting), 36(Actula feedback pressure)
• F18.04, F18.12, F18.13 modify default
• P00.07 (Dormancy enable) add: 3 (No flow dormancy 1), 4 (No flow dormancy 2)
• Modify defination of P00.13, P00.14
• Add P00.23 – P00.30 ((no-flow power function), P00.31 – P00.38 (function of switching from
variable frequency to power frequency), P00.39 – P00.50 (pump contactor function)
• P02.28 (Proportional gain of pressure closed-loop) modify default and range: 0.00 – 10.00
[0.01]
• Add P02.35 (Digital setting for saving selection when power failure)
• Add P05.03 – P05.04 (pressure sensor function), P05.05 (Water supply method)

CONTENTS
Chapter 1 Safety Information and Precautions.................................................................................................... 1
1.1 Safety Definition ............................................................................................................................... 1
1.2 About Motor and Load..................................................................................................................... 1
1.3 About HD31 ....................................................................................................................................... 2
Chapter 2 Product Information............................................................................................................................... 5
2.1 Model.................................................................................................................................................. 5
2.2 Nameplate.......................................................................................................................................... 5
2.3 Rated Value ........................................................................................................................................ 6
2.4 Technical Data ................................................................................................................................... 6
2.5 Parts of Inverter................................................................................................................................. 8
Chapter 3 Machenical Installation.......................................................................................................................... 9
3.1 Precautions ........................................................................................................................................ 9
3.2 Installation Site Requirement ......................................................................................................... 9
3.3 Installation Direction and Space Requirements ........................................................................ 10
3.4 Dimensions and Weight................................................................................................................. 11
3.5 Install and Dismantle Keypad ....................................................................................................... 12
3.6 Dismantle Plastic Cover ................................................................................................................. 13
Chapter 4 Electrical Installation............................................................................................................................ 15
4.1 Precautions ...................................................................................................................................... 15
4.2 Peripheral Accessories Selection.................................................................................................. 15
4.2.1 Wiring specifications of input and output.........................................................................................15
4.2.2 Power terminal lug ....................................................................................................................................16
4.3 Main Circuit Terminals and Wiring ............................................................................................... 16
4.3.1 Supply and Motor Terminal ....................................................................................................................17
4.3.2 Supply and Motor Connection..............................................................................................................18
4.4 Control Board and I/O Board......................................................................................................... 19
4.4.1 Control Board Terminal ............................................................................................................................20
4.4.2 I/O Board Terminal .....................................................................................................................................21
4.4.3 Modbus Communication Terminal ......................................................................................................21
4.4.4 Jumper...........................................................................................................................................................22
Chapter 5 Keypad.................................................................................................................................................... 23
Chapter 6 Function Introduction.......................................................................................................................... 25
6.1 Group d: Display Parameters ........................................................................................................ 26

6.1.1 d00: Status Display Parameters.............................................................................................................26
6.2 Group F: General Parameters........................................................................................................ 29
6.2.1 F00: Basic Parameters ...............................................................................................................................29
6.2.2 F01: Protection of Parameters................................................................................................................32
6.2.3 F03: Acc / Dec Parameters.......................................................................................................................33
6.2.4 F05: External Setting Curve Parameters.............................................................................................33
6.2.5 F08: Asynchronous Motor Parameters................................................................................................35
6.2.6 F09: V/f Control Parameters....................................................................................................................36
6.2.7 F15: Digital I/O Terminal Parameters...................................................................................................38
6.2.8 F16: Analogue I/O Terminal Parameters.............................................................................................41
6.2.9 F17: SCI Communication Parameters..................................................................................................43
6.2.10 F18: Display Control Parameters ........................................................................................................44
6.2.11 F19: Function-boost Parameters ........................................................................................................45
6.2.12 F20: Fault Protection Parameters .......................................................................................................47
6.2.13 F23: PWM Control Parameters.............................................................................................................50
6.3 Group P: Special Parameter for Multi-pump Water Supply...................................................... 51
6.3.1 P00: Water Supply Logic Parameter.....................................................................................................51
6.3.2 P01: Water Supply Pump Parameter....................................................................................................56
6.3.3 P02: Water Supply PID Parameter.........................................................................................................57
6.3.4 P03: Water Supply AIO Function Parameter .....................................................................................59
6.3.5 P04: Water Supply Fault Protection Parameter................................................................................61
6.3.6 P05: Water Supply Time Parameter......................................................................................................61
Chapter 7 Application Reference.......................................................................................................................... 63
7.1 Take one-to-six inverter as an example....................................................................................... 63
7.2 Debugging for Switching between VF and IF ............................................................................ 66
Chapter 8 Troubleshooting ................................................................................................................................... 67
Chapter 9 Accessories............................................................................................................................................. 71
9.1 Keypad Installation Assembly ...................................................................................................... 71
9.2 Reactor Selection............................................................................................................................ 71
9.3 Braking Resistor and Braking Unit............................................................................................... 72
Appendix A Parameters ......................................................................................................................................... 73

1
Safety Information and Precautions
2
Product Information
3
Machenical Installation
4
Electrical Installation
5
Keypad
6
Function Introduction
7
Application Reference
8
Troubleshooting
9
Accessories
A
Parameters

Shenzhen Hpmont Technology Co., Ltd. Chapter 1 Safety Information and Precautions
HD31 Series User Manual V1.1 ―1―
Chapter 1 Safety Information and Precautions
1.1 Safety Definition
Danger: A Danger contains information which is critical for avoiding safety hazard.
Warning: A Warning contains information which is essential for avoiding a risk of damage to products or other
equipements.
Note: A Note contains information which helps to ensure correct operation of the product.
1.2 About Motor and Load
Compared to the industrial frequency running
The HD31 series inverters are voltage-type frequency inverters and their output is PWM wave with
certain harmonic wave. Therefore, the temperature, noise and vibration of the motor will be a little
higher than that at industrial frequency running.
Constant torque at low-speed running
When HD31 drives a standard motor at low-speed running for a long time, the output torque ratings
will become worse due to the motor cooling is less effective. In that case, we suggest that you should
choose variable frequency motor.
Thermal protection of motor
When choose the adaptive motor, HD31 can effectively implement thermal protection of motor.
Otherwise it must adjust the motor protection parameters or other protection measures to ensure that
the motor is at a safe and reliable running.
Running above the rated frequency of motor
If the motor runs exceeding its rated frequency, the noise will increase. Pay attention to the motor
vibration as well as ensure the motor bearings and mechanical devices to meet the requirement of
running speed range.
Lubrication of mechanical devices
At long time low-speed running, provide periodical lubrication maintenance for the mechanical
devices such as gear box and geared motor etc. to make sure the drive results meet the site need.
Danger
W
arning
Note
1

Chapter 1 Safety Information and Precautions Shenzhen Hpmont Technology Co., Ltd.
―2―HD31 Series User Manual V1.1
Mechanical resonance point of load
Set the skip frequency (F05.17 - F05.19) to avoid the load device or the motor mechanical resonance
point.
Start and stop HD31
User should use the control terminal to start and stop HD31.
It is strictly forbidden to use contactor or other switches on the input side of HD31 to start and stop
directly, or it will damage the device.
Check the insulation of the motor
For the first time using of the motor or after long time storage, it needs checking the insulation of the
motor. Worse insulation can cause damage to HD31.
Note:
Use a 500V Mega-Ohm-Meter to test and the insulation resistance must be higher than 5Mohm.
Load and negative torque
For the occasion to boost load and the like, negative torque often occurs. Consider setting proper
parameters of the braking unit if HD31 is prone to overcurrent or overvoltage fault trip.
Requirement for leakage current protector RCD
Since the device generates high leakage current which goes through the protective grounding
conductor, please install B type leakage current protector RCD on one side of the power supply.
For the selection of RCD, users need to consider the possible problems of ground leakage current in
both transient status and steady status at start and during running. It is recommended to choose
either special RCD that can suppress the higher harmonics, or general RCD that has more aftercurrent.
Warning for ground mass leakage current
The device generates mass leakage current, so users need to confirm the reliable grounding before
connect to the power supply. The grounding should comply with the local relative IEC standard.
1.3 About HD31
No capacitor or varistor on the output side
Since HD31 output is PWM wave, it is strictly forbidden to connect capacitor for improving the power
factor or varistor for lightning protection to the output terminals so as to avoid HD31 fault trip or
component damage.
Contactors and circuit breakers connected to the output of HD31
If circuit breaker or contactor needs to be connected between HD31 and the motor, be sure to operate
these circuit breakers or contactor when HD31 has no output, so as to avoid any damage to HD31.
Running voltage
HD31 is prohibited to be used beyond the specified range of running voltage. If needed, please use
suitable voltage regulation device to change the voltage.

Shenzhen Hpmont Technology Co., Ltd. Chapter 1 Safety Information and Precautions
HD31 Series User Manual V1.1 ―3―
Capacitor energy storage
When the AC power supply is cut off, capacitor of HD31 sustains deadly power for a while. So to
disassemble HD31 that is powered, please cut off the AC power supply for more than 10 minutes,
confirm the internal charge indicator is off and the voltage between (+) and (-) of the main circuit
terminals is below 36V.
Generally, the internal circuit enables the capacitor to discharge. However, the discharging may fail in
some exceptions. In these cases, users need to consult Hpmont or our regional distributor.
Lightning surge protection
HD31 internal design has lightning surge overcurrent protection circuit, and has certain self-protection
capacity against the lightning.
Altitude and derating
In area where altitude exceeds 1000 meters, HD31 should be derating since the heatsink efficiency will
be reduced because of the tenuous air.
The rated value of output current derates by 1% for each 100m increase of the altitude. I.e. for the
altitude of 4000m, derated rate is 30% for rated current of HD31. Figure 1–1 is the derating curve of
rated current and the altitude.
Figure 1–1 Derating curve of rated current and altitude
70%
100%
1000m 4000m
Altitude
Rated current of HD31
1

Shenzhen Hpmont Technology Co., Ltd. Chapter 2 Product Information
HD31 Series User Manual V1.1 ―5―
Chapter 2 Product Information
2.1 Model
2.2 Nameplate
HD31-4T7P5-P
Product Series
Power Supply Voltage
380 - 460VAC = 4
Three-phase input = T
Input Phase
Power
Fan and pump = P
Product Type
FWD LOCK REV ALM LO/RE
HZ AVRPM %
MODEL: HD31-4T7P5P
7.5kW
POWER:
3PH 380-460V 19A 50/60Hz
INPUT:
11kVA 0-460V 17A 0-400Hz
OUTPUT:
1.00Version:
Product model
Motor power
Input specification
Output specification
Software version
Serial number
2

Chapter 2 Product Information Shenzhen Hpmont Technology Co., Ltd.
―6―HD31 Series User Manual V1.1
2.3 Rated Value
Refer to section 3.4 Dimensions and Weight (on page 11) for size information.
Model Motor
(kW)
Rated Capacity
(kVA)
Rated Input
Current (A)
Rated Output
Current (A) Size
HD31-4T2P2P 2.2 3.4 7.3 5.1 F2
HD31-4T3P7P 3.7 5.9 11.9 9.0 F2
HD31-4T5P5P 5.5 8.5 15 13 F2
HD31-4T7P5P 7.5 11 19 17 F2
HD31-4T011P 11 16 28 25 F3
HD31-4T015P 15 21 35 32 F3
HD31-4T018P 18.5 24 39 37 F4
HD31-4T022P 22 30 47 45 F4
HD31-4T030P 30 39 62 60 F5
HD31-4T037P 37 49 77 75 F5
HD31-4T045P 45 59 92 90 F6
HD31-4T055P 55 72 113 110 F6
HD31-4T075P 75 100 156 152 F6
HD31-4T090P 90 116 180 176 F7
HD31-4T110P 110 138 214 210 F7
HD31-4T132P 132 167 256 253 F7
2.4 Technical Data
Electrical
Input voltage Three-phase: 380 - 460V, 50/60Hz
Fluctuating within ± 10%, imbalance rate < 3%
Input frequency 50/60Hz ± 5%
Output voltage 0 - input voltage
Output frequency 0 - 400.00Hz
Performance
Control mode V/f, SVC
Max. current 120% rated output current for 5 minutes;
135% rated output current for 35 seconds
Running command Keypad; Terminals; Communication
Speed setting Digital; Analogue; Communication
Speed resulotion Digital setting: 0.01Hz
Analogue setting: 0.1% × max-frequency
SVC
Speed control accuracy: ± 0.5%
Speed control range: 1:100
Torque control response: < 200ms
Start torque: 180% rated torque / 0.5Hz
Torque control accuracy ±5%

Shenzhen Hpmont Technology Co., Ltd. Chapter 2 Product Information
HD31 Series User Manual V1.1 ―7―
Protection Functions
Stall overvoltage Bus voltage can auto-control against overvoltage fault
Auto-limit current protection Output current can auto-limit against overcurrent fault
Overload pre-alarm and
alarm Overload early pre-alarm and protect
Load loss protection Load loss alarm function
Input / Output voltage
phase loss protection Input / Output voltage phase loss auto-detect and alarm function
Braking fault protection Braking detection and alarming function
PID commands and
feedback loss detection PID can auto-identify whether loss the setting and feedback or the alarm function
Power output grounding
fault protection Power output grounding fault protection is enabled
Power output short circuit
protection Power output short circuit protection is enabled
Input / Outpot
Analogue power supply +10V, max. current 100mA
Digital power supply +24V, max. current 200mA
Analogue input
AI1 (control board): voltage 0 - 10V
AI2 (control board): -10 - +10V/0 - 20mA (selectable voltage/current)
AI3, AI4 (I/O board): -10 - +10V/0 - 20mA (selectable voltage/current)
Analogue output AO1, AO2: 0 - 10V/0 - 20mA (selectable voltage/current)
Digital input DI1 - DI6 (control board); DI7 - DI9 (I/O board)
DI6 can be selectable for high-frequency input
Digital output DO1, DO2
DO2 can be selectable for high-frequency output
Relay output R1A/R1B/R1C(control board), R2A/R2C - R10A/R10C(I/O board)
Contact rating: 250VAC/3A or 30VDC/1A
Keypad
LED display
Five LEDs display, 5 unit indicators, 5 status indicators
Setting frequency, output frequency, output voltage, output current, motor speed,
output torque, switching value terminal, status parameter, programm menu
parameter and fault code etc.
LCD display Optional [HD-LCD], display contents in Chinese or English
Parameter copy Both LED and LCD keypad can achieve quick parameter copy
Communication
SCI communication RS-485 interface; Terminal
2

Chapter 2 Product Information Shenzhen Hpmont Technology Co., Ltd.
―8―HD31 Series User Manual V1.1
Environment
Running temperature
-10 - +40℃, max. 50℃, air temperature fluctuation is less than 0.5℃/min
The derating value of the output current of HD31 shall be 2% for each degree
centigrade above 40℃. Max. allowed temperature is 50℃
Storage temperature -40 - +70℃
Location for use Indoor, preventing from direct sunlight, no dust, corrosive, flammable gases, oil mist,
water vaper, dripping or salt etc.
Altitude Less than 1000 meters, otherwise should be derating use
Humidity Less than 95%RH, non-condensing
Vibration Resistance It is 3.5m/s2in 2 - 9Hz, it is 10m/s2(IEC60721-3-3) in 9 - 200Hz
Protection class IP20
Pollution level Level 2 (Dry, non conducting dust pollution)
Accessories
Bus communication
PROFIBUS option [HDFB-PROFIBUS-DP]
DeviceNet option [HDFB-DeviceNet]
CAN option [HDFB-CAN]
About keypad
LCD keypad (HD-LCD)
Mounting base to keypad (HD-KMB)
1m/2m/3m/6m extension cable to keypad (HD-CAB-1M/2M/3M/6M)
Power units Dynamic braking unit [HDBU]
2.5 Parts of Inverter
Fan cover
Keypad
Upper cover
Lower cover
Mounting hole
Middle enclosure
Bottom enclosur
e
Certification
Nameplate
Size F2 - F4 Size F5 - F7
C
onnection holes
o
fp
o
wer terminal
C
onnection holes
o
fcontrolterminal

Shenzhen Hpmont Technology Co., Ltd. Chapter 3 Machenical Installation
HD31 Series User Manual V1.1 ―9―
Chapter 3 Machenical Installation
3.1 Precautions
• Do not install if HD31 is incomplete or impaired.
• When conveying HD31, please employ suitable tools according to its weight. Avoid scratch to the product. Be
careful: rollover and drop may cause hurt.
• Make sure that HD31 is far from explosive and flammable things.
• Do not do wiring operation until power supply is cut off for more than 10 minutes, the internal charge indicator of
HD31 is off and the voltage between (+) and (-) of the main circuit terminals is below 36V.
• It is required not only carry the keypad and the cover but also bottom enclosure of HD31.
• Do not let wires, screws or residues fall into HD31 when installing.
3.2 Installation Site Requirement
Ensure the installation site meets the following requirements:
•Do not install at direct sunlight, moisture, water droplet location;
•Do not install at flammable, explosive, corrosive gas and liquid location;
•Do not install at oily dust, fiber and metal powder location;
•Be vertical installed on fire-retardant material with a strong support;
•Make sure adequate cooling space for HD31 so as to keep ambient temperature between
- 10 - + 40℃;
•Install at where the vibration is 3.5m/s2in 2 - 9Hz, 10m/s2in 9 - 200Hz (IEC60721-3-3);
•Install at where the humidity is less than 95%RH and non-condensing location;
•Protection level of HD31 is IP20 and pollution level is 2 (Dry, non-conducting dust pollution).
Note:
1. It needs derating use if running temperature exceeds 40
℃
. The derating value of the output current of
HD31 shall be 2% for each degree centigrade. Max. allowed temperature is 50
℃
.
2. Keep ambient temperature between -10 - +40
℃
. It can improve the running performance if install at
location with good ventilation or cooling devices.
Danger
W
arning
3

Chapter 3 Machenical Installation Shenzhen Hpmont Technology Co., Ltd.
―10―HD31 Series User Manual V1.1
3.3 Installation Direction and Space Requirements
To achieve good cooling efficiency, install the inverter
perpendicularly and always provide the following space to
allow normal heat dissipation. The requirements on mounting
space and clearance are shown in Table 3-1.
Table 3-1 Installation space
HD31 power 5.5 - 75kW 90 - 132kW
A (left and right) ≥50mm ≥150mm
B (up and down) ≥100mm ≥350mm
C (upper vent) ≥50mm ≥100mm
D (lower vent) ≥50mm ≥100mm
123
When one inverter is mounted on top of another, an air flow
diverting plate should be fixed between them. Just as shown
in Table 3-2.
Table 3-2 Installation of several inverters
HD31 power 5.5 - 75kW 90 - 132kW
A ≥50mm ≥100mm
B ≥50mm ≥100mm
C ≥50mm ≥100mm
a ≥50mm ≥100mm
b ≥50mm ≥100mm
c ≥50mm ≥100mm
123
C C
B
D
D
B
AA
C
B
a
b
c
A

Shenzhen Hpmont Technology Co., Ltd. Chapter 3 Machenical Installation
HD31 Series User Manual V1.1 ―11―
3.4 Dimensions and Weight
The dimensions and weight of HD31 are as shown in Table 3-3.
For the corresponding model of the mounting size, refer to section 2.3 Rated Value, on page 6.
Size F2 - F4
Size F5 - F6
Size F7
W1
W
H
H1
4-Ød
D
H2
4-Ød
W
W1
H
H1
D
H2
4-Ød
D
W1
W
H
H1
H2
3
