HTRC H825AC DUO User manual

00AC /DC DUO
DUODUO
H825AC
Made in China
Dual output Lipo charger for Drones
Dual output Lipo charger for Drones
1200W/25A/8s
Thank you for choosing H825AC DUO dual LiPo/LiHv charger.
This charger is capable of balance charging 2 packs of 8 cell batteries simultaneously. It is specifically
designed for big battery pack. There are working modes, balance charge, storage charge，，
discharge and fast
Five
(suitable for batteries with no balance lead).
Power Swith
AC 100-240V
PC Link1
PC Link2
LiHV
LiHV
: .3 9 V/S
PROGRAM of LiPo/LiHV
START
START
START
START
START
7
and
7 8
8
SPECIFICATION
Features
AC Input Voltage
Discharge Power
Charge Power
Current drain for balancing
Lipo/LiHV cell count
Charge Current Range
100-240V
1200W(600Wx2)
120W/(60WX2)
1.0-25AX2
1.2A
1-8cellsX2
Charging Modes Balan /Fastce /Storage/Charge/Discharger
274x209x120mm
5kg
Size
Weight
Battery connection
Package Accessories
8S LiPO/LiHV Battery
8S LiPO/LiHV Battery
Battery connection: Please connect your batteries to H825AC charger as below:
(Note: Be aware that the Lithium battery to be charged should be 1-8 cells. Make sure the battery balance lead and
charging lead are connected correspondingly to the charger.
Support charging 2 packs of 8s LiPo/LiHV batteries simultaneously
Memorizing last charging current
Four working modes: balance charge, storage, charge,discharge,fast charge
Maximum safety: short circuit protection, reverse polarity protection & over heat protection.
2x16 LCD screen.
Real time charging/ discharging status display
Battery voltage meter
Battery internal resistance meter
Firmware upgrade via USB port
AC cord x1pcs XT90 x2pcs Adapter Boardx2pcs
--
--
Do not cover cooling fan!
Do not cover cooling fan!
AC 100-240V
PC Link 1
PC Link 2
ON OFF
Add the indicator led,the charge is more intuitive
Green light flashingCharging
The light solid green
Full
The red light flashing
Errors
alternately flashing
The red light and green light
Standby

PROGRAM of Extra Function
Hv
Hv
START
START
START
START
78
78
Hv
PROGRAM of User/Settings
H825AC DUO
LiPo/LiHV
H825AC DUO
Dual output Lipo charger for Drones
DUODUO
H825AC
--
too high (Lipo>4.25V,LiHV>4.35V),please check the battery
check the number of cells in the battery pack.
then restart.
The voltage is lower than 2.5V.Please
