Huawei E587 Technical specifications

Product Description
HUAWEI E587 Mobile WiFi
V100R001
Issue
03
Date
2011-11-11
HUAWEI TECHNOLOGIES CO., LTD.

HUAWEI E587 Mobile WiFi V100R001
Product Description
Issue 03 (2011-11-11)
Commercial in Confidence
Page 2 of 22
Huawei Technologies Co., Ltd. provides customers with comprehensive technical support and service.
Please feel free to contact our local office or company headquarters.
Huawei Technologies Co., Ltd.
Address:
Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
Website:
http://www.huawei.com
Email:
[email protected]
Copyright © Huawei Technologies Co., Ltd. 2011. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior
written consent of Huawei Technologies Co., Ltd.
Trademarks and Permissions
and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective
holders.
Notice
The information in this document is subject to change without notice. Every effort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute the warranty of any kind, express or implied.

HUAWEI E587 Mobile WiFi V100R001
Product Description
Issue 03 (2011-11-11)
Commercial in Confidence
Page 3 of 22
About This Document
Summary
This document provides information about the major functions, supported services,
system architecture, and technical references.
The following table lists the contents of this document.
Chapter
Details
1 Overview
The supported network modes, basic services and functions,
and the appearance of the product.
2 Features
The supported features and technical specifications of the
product.
3 Services and Applications
The services and applications of the product.
4 System Architecture
The architecture of the product.
5 Technical Reference
The technical references of the product.
6 Packing List
The items contained in the package of the product.
A Acronyms and Abbreviations
The acronyms and abbreviations mentioned in this document.

HUAWEI E587 Mobile WiFi V100R001
Product Description
Issue 03 (2011-11-11)
Commercial in Confidence
Page 4 of 22
History
Issue
Details
Date
01
Initial draft completed.
2011-02-15
02
Update
2011-09-22
03
Update
2011-11-11

HUAWEI E587 Mobile WiFi V100R001
Product Description
Issue 03 (2011-11-11)
Commercial in Confidence
Page 5 of 22
Contents
1 Overview..........................................................................................................................6
2 Features...........................................................................................................................8
2.1 Main Features .................................................................................................................................. 8
2.2 Technical Specifications ................................................................................................................... 9
2.2.1 Hardware................................................................................................................................. 9
2.2.2 Software................................................................................................................................. 10
3 Services and Applications ...........................................................................................12
3.1 Data Service................................................................................................................................... 12
3.1.1 USB Modem .......................................................................................................................... 12
3.1.2 Wireless Modem.................................................................................................................... 12
3.2 SMS................................................................................................................................................ 13
3.3 Sharing Data Stored on the microSD card..................................................................................... 13
4 System Architecture.....................................................................................................14
4.1 System Architecture ....................................................................................................................... 14
4.2 Functional Modules........................................................................................................................ 15
5 Technical Reference .....................................................................................................16
5.1 DATACOM Products....................................................................................................................... 16
5.2 Wireless Um Interface.................................................................................................................... 16
6 Packing List...................................................................................................................20
A Acronyms and Abbreviations......................................................................................21

HUAWEI E587 Mobile WiFi V100R001
Product Description
Issue 03 (2011-11-11)
Commercial in Confidence
Page 6 of 22
1 Overview
HUAWEI E587 Mobile WiFi (hereinafter referred to as the E587) is a high-speed
packet access (HSPA) universal serial bus (USB) modem. It is a multi-mode wireless
terminal for SOHO (Small Office and Home Office) and business professionals. To
meet requirements from different markets, the E587 has three branch types, E587u-2,
E587u-5, and GP02, within Huawei. The differences lie in their supported bands:
E587u-2: DC-HSPA+/HSPA+/HSPA/UMTS 2100/900MHz (except DC-HSPA+
900MHZ at the first stage), EDGE/GPRS/GSM 1900/1800/900/850 MHz;
E587u-5: DC-HSPA+/HSPA+/HSPA/UMTS 2100/1900/AWS/850 MHz,
EDGE/GPRS/GSM 1900/1800/900/850 MHz;
GP02: DC-HSPA+/HSPA+/HSPA/UMTS 2100/1700 MHz.
The E587 supports the following standards:
Dual Carrier High Speed PacketAccess plus (DC-HSPA+)
High Speed Packet Access Plus (HSPA+)
High Speed Uplink PacketAccess (HSUPA)
High Speed Downlink Packet Access (HSDPA)
Universal Mobile Telecommunications System (UMTS)
Enhanced Data rates for Global Evolution (EDGE)
General Packet Radio Service (GPRS)
Global System for Mobile communications (GSM)
The E587 provides the following services:
DC-HSPA+ packet data service of up to 43.2 Mbit/s
HSPA+ packet data service of up to 21.6 Mbit/s
HSPA (HSUPA/HSDPA)/UMTS packet data service of up to 14.4 Mbit/s
EDGE/GPRS packet data service of up to 236.8 Kbit/s
UMTS/GSM Short Message Service (SMS)
You can connect the E587 with the Wi-Fi, or connect the E587 with the USB interface
of a computer. In the service area of the
DC-HSPA+/HSPA+/HSPA/UMTS/EDGE/GPRS/GSM network, you can surf the
Internet and send/receive messages/emails cordlessly. The E587 is fast, reliable, and
easy to operate. Thus, mobile users can experience many new features and services
with the E587. These features and services will enable a large number of users to use

HUAWEI E587 Mobile WiFi V100R001
Product Description
Issue 03 (2011-11-11)
Commercial in Confidence
Page 7 of 22
the E587 and the average revenue per user (ARPU) of operators will increase
substantially.
Figure 1-1 shows the profile of the E587.
Figure 1-1 E587 profile

HUAWEI E587 Mobile WiFi V100R001
Product Description
Issue 03 (2011-11-11)
Commercial in Confidence
Page 8 of 22
2 Features
2.1 Main Features
The E587 mainly supports the following features:
DC-HSPA+ data service of up to 43.2Mbit/s
HSPA+ data service of up to 21.6 Mbit/s
HSUPA (UL) data service of up to 5.76 Mbit/s
HSDPA (DL) data service of up to 14.4 Mbit/s
UMTS PS domain data service of up to 384 Kbit/s
EDGE packet data service of up to 236.8 Kbit/s
GPRS packet data service of up to 85.6 Kbit/s
PS domain data service based on UMTS and GSM
SMS based on GSM and UMTS
Wi-Fi and WPS
Built-in DHCP Server, DNS RELAY, DHCP Client and NAT
Plug and play (PnP)
Personal computer/Smart card (PC/SC) Driver
USB Extension Cable, easy to connect
Standard micro USB interface
Built-in UMTS and WLAN high gain antenna
Micro Secure Digital Memory (mircoSD) Card
Sharing the microSD card on web page
Windows XP, Windows Vista, Windows 7, Mac OS X 10.5, Mac OS X 10.6, Mac
OS X 10.7

HUAWEI E587 Mobile WiFi V100R001
Product Description
Issue 03 (2011-11-11)
Commercial in Confidence
Page 9 of 22
2.2 Technical Specifications
2.2.1 Hardware
Table 2-1 lists the hardware specifications.
Table 2-1 Hardware specifications
Item
Specifications
Technical
standard
WAN：DC-HSPA+/HSPA+/HSPA/UMTS/EDGE/GPRS/GSM
WLAN: IEEE 802.11b/g/n (1*1 antenna)
Operating
frequency
DC-HSPA+/
HSPA+/HS
PA/UMTS
E587u-2: 2100/900MHz
E587u-5: 2100/1900/AWS/850MHz
GP02: 2100/1700 MHz
EDGE/GPR
S/GSM
E587u-2: 850/900/1800/1900MHz
E587u-5: 850/900/1800/1900MHz
WLAN: 2.401GHz–2.495GHz
Internal memory
128MB Flash, 32MB SD-RAM
Maximum
transmitter
power
UMTS: ≥24 (+1/-3) dBm
WLAN (Battery mode): 4~10dBm
WLAN (Power adapter
mode)
802.11b: 11~17dbm
802.11g: 9~15dbm
802.11n: 4~10dbm
Receiver
sensitivity
UMTS: -106.7dbm/3.84MHz
WLAN 802.11b: -76dBm@11Mbps/-82dBm@1Mbps
WLAN 802.11g: -65dBm@54Mbps
WLAN 802.11n: -64dBm@65Mbps
WLAN speed
802.11b: Up to 11Mbit/s
802.11g: Up to 54Mbit/s
802.11n: Support MCS0–MCS7; Up to 72.2Mbit/s
Maximum power
consumption
4.3W
Power supply
AC: 100V–240V
DC: 5V, 1A

HUAWEI E587 Mobile WiFi V100R001
Product Description
Issue 03 (2011-11-11)
Commercial in Confidence
Page 10 of 22
Item
Specifications
Battery
Type: Li (Rechargeable)
Capacity: 3.7V, 2200mAh
Maximum working time: 4.5 hours
Maximum standby time: 210 hours while Wi-Fi is off; 50 hours
while Wi-Fi is often on.
External
interfaces
USB interface: Micro USB
Standard microSD card interface
SIM card: standard 6-pin SIM card interface
Display screen
OLED
Key-press
Power switch, WPS switch, Reset switch
Antenna
Built-in GSM/UMTS primary antenna
Built-in UMTS diversity antenna
Built-in WLAN antenna
External main diversity antenna interface (Optional)
Dimensions
(D ×W ×H)
102.0mm×56.0mm×15.5mm
Weight
about 110g (including the battery)
Temperature
Operating: -10℃to +35℃
Storage: -20℃to +70℃
Humidity
5% to 95%
2.2.2 Software
Table 2-2 lists the software specifications.
Table 2-2 Software specifications
Item
Description
SMS
Writing/Sending/Receiving
Storage: Up to 250 messages can be saved in the
internal memory of the E587.
Setting the SMS center number
New message prompt
Network connection
setup
APN management: create, delete, edit.
Set up network connection.

HUAWEI E587 Mobile WiFi V100R001
Product Description
Issue 03 (2011-11-11)
Commercial in Confidence
Page 11 of 22
Item
Description
WLAN setup
SSID broadcasting and hiding
Open system and shared key authentication
ASCII and HEX keys
64/128-bit WEP encryption
256-bit WPA-PSK and WPA2-PSK encryption
TKIP and AES encryption algorithm
TKIP and AES integrated encryption algorithm
Automatic adjustment of ratios
STA management
Wi-Fi enabling and disabling
Firewall setup
Firewall Switch
LAN IP Filter
Virtual Server
DMZ Service
UPnP Service
WAN Ping block
DHCP setup
DHCP server enabling and disabling
Address pool of the DHCP server setup
DHCP lease time setup
Software installation
Automatic installation (PnP)
System requirement
Windows XP, Windows Vista, Windows7
Mac OS X 10.5, Mac OS X 10.6, Mac OS X 10.7
Your computer’s hardware system should meet or
exceed the recommended system requirements for the
installed version of OS
Display resolution: 1024*768 and above
Other
Network connection settings: Automatic/ Manual network
selection and registration
Network status display: signal, operator name, system
mode, and so on
Selection of network connection types
PIN management: activate/deactivate PIN, PIN lock,
changing PIN, unblocking by using the PUK, auto
validate PIN

HUAWEI E587 Mobile WiFi V100R001
Product Description
Issue 03 (2011-11-11)
Commercial in Confidence
Page 12 of 22
3 Services and Applications
3.1 Data Service
3.1.1 USB Modem
After you connect the E587 and PC with a USB data cable, the E587 driver is installed
on the PC automatically and the shortcut of the web page is displayed on the PC
desktops. You can configureAPN on the E587 web page (or directly use the default
settings) and set up a network connection. Then you can send or receive E-mail,
access the network through wireless connection, and download files through wireless
data channels.
Figure 3-1 One-device access via USB
3.1.2 Wireless Modem
The E587 can be used as a wireless modem when the Wi-Fi is enabled. You can
access the Internet service through setting up the wireless network connection with
the E587.
A maximum of five wireless users can access the E587 at the same time. You can set
up the WLAN with the access point (AP) function.

HUAWEI E587 Mobile WiFi V100R001
Product Description
Issue 03 (2011-11-11)
Commercial in Confidence
Page 13 of 22
Figure 3-2 Multi-device access via Wi-Fi
Smart phone Game machine
Digital camera
Laptop
Figure 3-3 Multi-device access via Wi-Fi and USB at the same time
Smart phone Game machine
Digital camera
Laptop
3.2 SMS
Using the E587, you can:
Write, send, or receive text messages.
Manage messages on the web page, such as Inbox, Outbox, and Draft.
Set the SMS center number.
Save text messages to the E587.
3.3 Sharing Data Stored on the microSD card
After the microSD card is inserted, you can store data on the card or use the web
management page to share data stored on the card.

HUAWEI E587 Mobile WiFi V100R001
Product Description
Issue 03 (2011-11-11)
Commercial in Confidence
Page 14 of 22
4 System Architecture
4.1 System Architecture
Figure 4-1 shows the system architecture.
Figure 4-1 System architecture
Modem
Hardware module
AMSS
Application
system
Protocol stack
processing
Bottom layer drivers
(including USB driver)
User
interface USB Hub
Power
Radio
frequency
module
Baseband
signal
processing
PC
USB interface
WEB module
PC driver
WEB Page
WEB Server
USB driver
USB interface

HUAWEI E587 Mobile WiFi V100R001
Product Description
Issue 03 (2011-11-11)
Commercial in Confidence
Page 15 of 22
4.2 Functional Modules
1. Radio Frequency Module: It sends/receives radio signals and
modulates/demodulates the radio frequency (RF) signals and baseband signals.
2. Baseband Signal Processing: It processes
DC-HSPA+/HSPA+/HSPA/UMTS/EDGE/GPRS/GSM baseband digital signals,
including:
Modulating/Demodulating DC-HSPA+/HSPA+/HSPA/UMTS baseband signals
Modulating/Demodulating DC-HSPA+/EDGE/GPRS/GSM baseband signals
Encoding/Decoding DC-HSPA+/HSPA+/HSPA/UMTS channel
Encoding/Decoding EDGE/GPRS/GSM channel
3. Bottom Layer Driver: It drives peripherals, including USB, OLED, microSD and
SIM.
4. Protocol Stack System: It processes protocols of
DC-HSPA+/HSPA+/HSPA/UMTS/EDGE/GPRS/GSM.
5. Application System: It sends laptop commands to the bottom layer protocol for
processing and returns the value to the laptop. Existing applications include the
following:
Message management
CS/PS domain service management
6. User Interface: It provides interfaces to connect peripherals. Interfaces are for
microSD and SIM.
7. Application Management: Through the application window, you can set the
parameters of the E587 and operate the E587.

HUAWEI E587 Mobile WiFi V100R001
Product Description
Issue 03 (2011-11-11)
Commercial in Confidence
Page 16 of 22
5 Technical Reference
5.1 DATACOM Products
Table 5-1 Standards and Communication Protocols of the DATACOM Products
Item
Description
Physical Layer
RFC894
PPP
RFC1915, RFC1962, RFC1994, RFC2433, RFC2759, RFC1332,
RFC1877, RFC1471, RFC1570, RFC2484, RFC1717, RFC1934,
RFC1990, RFC1334, RFC1974, RFC1661
ARP
RFC826
IP
RFC791, RFC1122, RFC1071, RFC1141, RFC1624, RFC792,
RFC950, RFC1256
ICMP
RFC792, RFC950, RFC1256
TCP
RFC793
UDP
RFC768
DHCP
RFC1531, 1533
NAT
RFC1631
5.2 Wireless Um Interface
The wireless Um interface conforms to the UMTS R99, R4, R5, R6, R and R8
standards.

HUAWEI E587 Mobile WiFi V100R001
Product Description
Issue 03 (2011-11-11)
Commercial in Confidence
Page 17 of 22
Table 5-2 Standards and Communication Protocols of the Wireless Um Interface
Item
Description
Layer1
Specifications
(Physical)
Examples of Channel Coding and Multiplexing TR 25.944
(V3.3.0)
Physical Layer –General Description TS 25.201 (V3.1.0)
Physical Channels and Mapping of Transport Channels onto
Physical Channels (FDD) TS 25.211 (V3.5.0)
Multiplexing and Channel Coding (FDD) TS 25.212 (V3.5.0)
Spreading and Modulation (FDD) TS 25.213 (V3.4.0)
Physical Layer –Procedures (FDD) TS 25.214 (V3.5.0)
Physical Layer –Measurements (FDD) TS 25.215 (V3.5.0)
Layer 2
Specifications
(MAC/RLC)
MAC Protocol Specification TS 25.321 (V3.6.0)
RLC Protocol Specification TS 25.322 (V3.5.0)
Layer 3
Specifications
(RRC)
UE Interlayer Procedures in Connected Mode TS 25.303
(V3.6.0)
UE Procedures in Idle Mode TS 25.304 (V3.5.0)
RRC Protocol Specification TS 25.331 (V3.5.0)
Layer 3
NAS/Core
Network (MCM)
Architectural Requirements for Release 1999 TS 23.121
(V3.5.1)
NAS Functions Related to Mobile Station (MS) in Idle Mode TS
23.122 (V3.5.0)
Mobile Radio Interface Signaling Layer 3 –General Aspects TS
24.007 (V3.6.0)
Mobile Radio Interface Layer 3 Specification –Core Network
TS 24.008 (V3.6.0)
PP SMS Support on Mobile Radio Interface TS24.011 (V3.5.0)
GSM Protocol
Specifications
Mobile Radio Interface Layer 3 Specification, Radio Resource
Control Protocol TS 04.18 (V8.10.0)
Mobile Station - Base Station System (MS - BSS) interface;
Data Link (DL) Layer Specification TS 04.06 (V8.11.0)
Digital Cellular Telecommunications System (Phase 2+);
Multiplexing and Multiple Access on the Radio Path TS 05.02
(V8.9.0)
Technical Specification Group GERAN; Channel coding TS
05.03 (V8.6.1)
Digital Cellular Telecommunications System (Phase 2+); Radio
Subsystem Link Control TS 05.08 (V8.a.0)
Digital Cellular Telecommunications System (Phase 2+); Radio
Subsystem Synchronization TS 05.10 (V8.8.0)

HUAWEI E587 Mobile WiFi V100R001
Product Description
Issue 03 (2011-11-11)
Commercial in Confidence
Page 18 of 22
Item
Description
GPRS Protocol
Specifications
Overall Description of the GPRS Radio Interface; stage 2 TS
3.64 (V8.8.0)
Mobile Radio Interface Layer 3 Specification TS 04.08 (V8.0.0)
Mobile Radio Interface Layer 3 Specification: Radio Resource
Control Protocol TS 04.18 (V8.10.0)
General Packet Radio Service (GPRS): Mobile Station (MS) –
Base Station System (BSS) interface; Radio Link Control /
Medium Access Control (RLC/MAC) protocol TS 04.60
(V8.10.0)
Mobile Station - Serving GPRS Support Node (MS-SGSN)
Logical Link Control (LLC) Layer Specification TS 04.64
(V8.6.0)
Mobile Station - Serving GPRS Support Node (MS-SGSN);
Subnetwork Dependent Convergence Protocol (SNDCP) TS
04.65 (V8.1.0)
Multiplexing and Multiple Access on the Radio Path TS 05.02
(V8.9.0)
Channel Coding TS 05.03 (V8.6.1)
Modulation TS 05.04 (V8.3.0)
Radio Transmission and Reception TS 05.05 (V8.10.0)
General Packet Radio Service (GPRS); Stage 1 TS 22.060
(V3.5.0)
Mobile Execution Environment (MexE) TS 23.057 (V3.4.0)
General Packet Radio Service (GPRS) Service description;
stage 2 TS 23.060 (V8.8.0)
General
Specifications
UE Capability Requirements TR 21.904 (V3.3.0)
UE Radio Access Capabilities TR 25.926 (V3.2.0)
Vocabulary TR 25.990 (V3.0.0)
Radio Interface Protocol Architecture TS 25.301 (V3.6.0)
Services Provided by the Physical Layer TS 25.302 (V3.7.0)
Synchronization in UTRAN Stage 2 TS 25.402 (V3.4.0
Performance/Test
Specifications
UE Radio Transmission and Reception (FDD) TS 25.101
(V3.5.0)
Common Test Environments for User Equipment (UE) TS
34.108 (V3.2.0)
Special Conformance Testing Functions TS 34.109 (V3.2.0)
Terminal Conformance Specification TS 34.121 (V3.3.0)
User Equipment (UE) Conformance Specification; Part 1:
Protocol Conformance TS 34.123-1 (V3.2.0)
User Equipment (UE) Conformance Specification; Part 2:
Protocol Conformance TS 34.123-2 (V3.2.0)

HUAWEI E587 Mobile WiFi V100R001
Product Description
Issue 03 (2011-11-11)
Commercial in Confidence
Page 19 of 22
Item
Description
Performance/Test
Specifications
Terminal Conformance Specification, Radio Transmission and
Reception (FDD) TS 34.121 (V3.3.0)
User Equipment (UE) Conformance Specification; Part 1:
Protocol Conformance TS 34.123-1 (V3.2.0)
S48 User Equipment (UE) Conformance Specification; Part 2:
Implementation Conformance Statement (ICS) Specification
TS 34.123-2 (V3.2.0)
USIM
Specifications
SIM and IC Card Requirements TS 21.111 (V3.3.0)
3rd Gen. Partnership Proj Tech. Spec. Group Terminals; SIM
App. Toolkit (USAT) TS 31.111 (V3.3.0)

HUAWEI E587 Mobile WiFi V100R001
Product Description
Issue 03 (2011-11-11)
Commercial in Confidence
Page 20 of 22
6 Packing List
This chapter describes the items contained in the package of the E587.
Table 6-1 lists the items contained in the package of the E587.
Table 6-1 Packing list of the E587
Item
Quantity
Remarks
Mobile WiFi
1
Standard
Rechargeable battery
1
Standard
Power adapter
1
Standard
USB Cable
1
Standard
Quick Start
1
Standard
Warranty Card
1
Optional
Cradle
1
Optional
