Huawei EP631S User manual

EP631S
V400R005C00
Quick Guide
Issue 02
Date 2018-05-08
HUAWEI TECHNOLOGIES CO., LTD.

Copyright © Huawei Technologies Co., Ltd. 2018. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior written
consent of Huawei Technologies Co., Ltd.
Trademarks and Permissions
and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective
holders.
Notice
The purchased products, services and features are stipulated by the contract made between Huawei and the
customer. All or part of the products, services and features described in this document may not be within the
purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information,
and recommendations in this document are provided "AS IS" without warranties, guarantees or
representations of any kind, either express or implied.
The information in this document is subject to change without notice. Every effort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute a warranty of any kind, express or implied.
Huawei Technologies Co., Ltd.
Address: Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
Website: http://www.huawei.com
Email: [email protected]
Issue 02 (2018-05-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
i

Contents
1 Safety Information........................................................................................................................ 1
2 Appearance..................................................................................................................................... 4
3 Installation and Use...................................................................................................................... 8
3.1 Attaching the Antenna.................................................................................................................................................... 8
3.2 Installing the Battery...................................................................................................................................................... 9
3.3 Installing the Back Clip................................................................................................................................................ 10
3.4 Attaching the Strap....................................................................................................................................................... 11
3.5 Charging the Battery and the Phone............................................................................................................................. 12
3.6 Installing an SIM Card................................................................................................................................................. 13
3.7 Powering On and Powering Off................................................................................................................................... 14
3.8 Indicator Status............................................................................................................................................................. 14
3.9 Others............................................................................................................................................................................15
EP631S
Quick Guide Contents
Issue 02 (2018-05-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
ii

1 Safety Information
This section contains important information pertaining to the operating instructions of your
device. It also contains information about how to use the device safely. Read this information
carefully before using your device.
Medical Device
lFollow rules and regulations set forth by hospitals and health care facilities. Do not use
your device when using the device is prohibited.
lImplantable medical devices, such as pacemakers, implanted cochleas, and hearing aids
may be affected by radio waves generated by this device. If you are using such medical
devices, consult their manufacturers for related restrictions. Pacemaker manufacturers
recommend that a minimum distance of 15 cm be maintained between your device and a
pacemaker to prevent potential interference with the pacemaker. If you are using a
pacemaker, use the device on the opposite side of the pacemaker and do not carry the
device in your front pocket.
Prevention of Hearing Damage
Using a headset at high volume can damage your hearing. To reduce the risk of damage to
hearing, lower the headset volume to a safe and comfortable level.
Safety of Children
Comply with all precautions with regard to children's safety. Letting the child play with your
device or its accessories, which may include parts that can be detached from the device, may
be dangerous, as it may present a choking hazard. Ensure that children are kept away from the
device and accessories.
Potentially Explosive Atmosphere
lPower off your device in any area with a potentially explosive atmosphere, and comply
with all signs and instructions. Triggering of sparks in such areas could cause an
explosion or a fire, resulting in bodily injuries or even deaths. Do not power on your
device at refueling points such as service stations.
lComply with restrictions on the use of radio equipment in fuel depots, storage, and
distribution areas, and chemical plants. In addition, adhere to restrictions in areas where
blasting operations are in progress. Before using the device, watch out for areas that have
EP631S
Quick Guide 1 Safety Information
Issue 02 (2018-05-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1

potentially explosive atmospheres that are often, but not always, clearly marked. Such
locations include areas below the deck on boats, chemical transfer or storage facilities,
and areas where the air contains chemicals or particles such as grain, dust, or metal
powders. Ask the manufacturers of vehicles using liquefied petroleum gas (such as
propane or butane) whether this device can be safely used in their vicinity. Do not store
or transport the device and accessories in the same container as combustible or explosive
gas, liquid or materials.
Traffic Security
Do not use your device while flying in an aircraft. Power off your device before boarding an
aircraft. Using wireless devices in an aircraft may cause danger to the operation of the aircraft
and interrupt the wireless telephone network. It may also be considered illegal.
Operating Environment
lDo not use or charge the device in dusty, damp, and dirty places or places with magnetic
fields. Otherwise, it may result in a malfunction of the circuit.
lOn a stormy day with thunder, do not use your device to prevent any danger caused by
lightning.
lPower off your device if using the device is prohibited.
lIf the ambient temperature is over high or low, the device may be faulty.
Disposal and Recycling Information
The device (and any included batteries and accessories) should not be disposed of as normal
household garbage. Local laws and regulations on the disposal and recycle of such objects
should be followed.
Accessories
Use ONLY original batteries, chargers, and accessories supplied by the device manufacturer.
The use of any other type of battery, charger, or accessory may invalidate any warranty for the
device, may be in violation of local rules or laws, and may be dangerous.
Battery and Charger
lUse ONLY the original charger to charge the battery and equipment.
lUnplug the charger from the electrical plug and the device when not in use.
lDo not connect two poles of the battery with conductors, such as metal materials, keys,
or jewelries. Otherwise, the battery may be short-circuited and may cause burns and
other bodily injuries.
lDo not place the battery or device near any heating device, such as a microwave oven, an
oven, or a radiator. Battery overheat may result in a fire, explosion or other hazard.
lDo not modify or remanufacture, attempt to insert foreign objects into the battery,
immerse or expose it to water or other liquids, Otherwise, it may lead to battery leakage,
overheat, fire or explosion.
lIf battery electrolyte leaks out, ensure that the electrolyte does not touch your skin or
eyes. If the electrolyte touches your skin or splashes into your eyes, wash your eyes and
skin with clean water immediately and consult a doctor.
EP631S
Quick Guide 1 Safety Information
Issue 02 (2018-05-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
2

lIf there is a case of deformation, color change, or abnormal heating while the battery is
being used, charged or stored, remove the battery immediately and replace it. Otherwise,
it may lead to battery leakage, overheating, explosion, or fire.
lIf the power cable is damaged , or the plug loosens, stop using the cable at once.
Otherwise, it may lead to an electric shock, a short circuit of the charger, or a fire.
lDo not dispose of batteries in fire as they may explode. Batteries may also explode if
damaged.
Cleaning and Maintenance
lKeep the device and accessories dry. Do not use microwave oven or other heaters to dry
the device.
lDo not place your device, battery, and charger in places where they can get damaged
because of collision. Otherwise, it may lead to battery leakage, device malfunction,
overheating, fire, or explosion.
lDo not leave your device, battery, and charger in a place with an extreme high or low
temperature. Otherwise, they may become faulty, and fire or explosion may be caused.
lDo not place sharp metal objects such as pins near the earpiece. The earpiece may attract
these objects and hurt you when you are using the device.
lDo not use any strong chemical detergent, powder, or other chemical agents (such as
alcohol and benzene) to clean the device and the charger. Otherwise, parts of the device
may be damaged or a fire can be caused. You can clean the device and the charger with a
piece of damp and soft antistatic cloth. Power off the device before cleaning or
maintenance, and disconnect the charger from the device. Secure the headset slot cover,
interface cover, and battery cover.
lDo not dismantle the device or accessories. Otherwise, the warranty on the device and
accessories is invalid and the manufacturer is not liable to pay for the damage.
lIf the device screen is broken by colliding with hard objects, do not touch or try to
remove the broken part. In this case, stop using the device immediately, and then contact
an authorized service center in time.
lAvoid dropping, knocking, or vibrating the device. Otherwise, the internal circuit and
structure may be damaged. If the device or battery is dropped, especially on a hard
surface, and the user suspects damage, contact the device manufacturer.
lKeep the headset jack plug, port plug and battery cover installed tightly.
lClear the water from the surface and loudspeaker of the device if it is exposed to water.
Specific Absorption Rate
The maximum Specific Absorption Rate (SAR) of this device is 1.6 watts/kilogram (W/kg).
Others
The functions of Wireless Access Systems including Radio Local Area Networks (WAS/
RLANs) within the band 5150-5350 MHz for this device are restricted to indoor use only
within all European Union countries
(BE/BG/CZ/DK/DE/EE/IE/EL/ES/FR/HR/IT/CY/LV/LT/LU/HU/MT/NL/AT/PL/PT/RO/SI/S
K/FI/SE/UK/TR/NO/CH/IS/LI).
EP631S
Quick Guide 1 Safety Information
Issue 02 (2018-05-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
3

2 Appearance
Phone Body
Figure 2-1 shows the phone body of an EP631S.
Figure 2-1 Phone body of an EP631S
Table 2-1 describes the components on the phone body of the EP631S.
EP631S
Quick Guide 2 Appearance
Issue 02 (2018-05-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
4

Table 2-1 Components on the phone body of an EP631S
Nu
mbe
r
Name Description
1 Group button lIn trunking mode, press to display the fast group switch
list.
lOn the fast group switch list, press to join the selected
group.
Speaker knob lControls the ringing volume, and turns off the ringtone of
an incoming call.
lControls the earpiece volume of an ongoing call or
multimedia playback.
lMoves the cursor up/down on the fast group switch list.
2 Emergency mode
call key
lWhen your phone is powered off , hold down the key to
enter the emergency mode call.
lWhen your phone is in standby state, hold down the key to
enter the emergency mode call. You can wake up a
dormant EP631S by pressing the key.
3 LTE antenna
interface
—
4 Indicator —
5 Earpiece —
6 Screen —
7 Key For details, see Figure 2-2.
8 Speaker —
9 Microphone An EP631S has two MICs.The one on the lower left corner of
the phone body is the primary MIC; the one on the upper right
corner is the secondary MIC.
10 Charger
connection point
—
11 Function key up Custom function key.
By default, this key is a shortcut to the mute function.
12 PTT call button This button is used for a PTT call.
13 Function key
down
Custom function key.
By default, this key is a shortcut to turn off screen light.
14 Multifunctional
interface
The High Definition Multimedia Interface (HDMI) can be
connected with a data cable for battery charging or connected
to other accessories. A locking component is attached to the
interface for securing connections
EP631S
Quick Guide 2 Appearance
Issue 02 (2018-05-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
5

Nu
mbe
r
Name Description
15 Back clip —
16 Battery —
NOTE
Functions of the keys vary depending on the setting on the network side and the software version.
Keypad
Figure 2-2 shows the keypad of an EP631S.Table 2-2 describes the keys on the keypad.
Figure 2-2 Keypad of an EP631S
Table 2-2 Keys on the keypad
Nu
mb
er
Name Description
1 Left softkey Used for screen display functions.
2 Center softkey Used for screen display functions.
3 Right softkey Used for screen display functions.
4 Call key It is also called the Green key.
lPress to answer a call.
lPress to display the call record. Select a record and press to
make a Point To Point (PTP) voice call.
5 Navigation key lPress to control up/down, or left/right.
lSet as the hot key to enter the application quickly.
EP631S
Quick Guide 2 Appearance
Issue 02 (2018-05-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
6

Nu
mb
er
Name Description
6 End key It is also called the Red key or Power key.
lWhen an EP631S is off, hold down to power on the EP631S,
and hold down for ten seconds to restart the phone.
lWhen an EP631S is in non-sleep mode, hold down to power
off the EP631S.
lWhen an EP631S is in sleep mode, press to turn on screen
light.
lPress to end a PTP call.
lPress to return to the standby screen.
lDo not press this key simultaneously with other keys.
EP631S
Quick Guide 2 Appearance
Issue 02 (2018-05-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
7

3 Installation and Use
About This Chapter
3.1 Attaching the Antenna
3.2 Installing the Battery
3.3 Installing the Back Clip
3.4 Attaching the Strap
3.5 Charging the Battery and the Phone
3.6 Installing an SIM Card
3.7 Powering On and Powering Off
3.8 Indicator Status
3.9 Others
3.1 Attaching the Antenna
Figure 3-1 illustrates how to attach the antenna of an EP631S.
EP631S
Quick Guide 3 Installation and Use
Issue 02 (2018-05-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
8

Figure 3-1 Attaching the antenna of an EP631S
3.2 Installing the Battery
Figure 3-2 illustrates how to install the battery of an EP631S.
EP631S
Quick Guide 3 Installation and Use
Issue 02 (2018-05-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
9

Figure 3-2 Installing the battery of an EP631S
3.3 Installing the Back Clip
If a back clip is required, install the back clip on a battery, and then install the battery on a
phone.
Figure 3-3 illustrates how to install the back clip of an EP631S.
EP631S
Quick Guide 3 Installation and Use
Issue 02 (2018-05-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
10

Figure 3-3 Installing the back clip of an EP631S
Figure 3-4 shows how to remove the back clip from an EP631S.
Figure 3-4 Removing the back clip of an EP631S
3.4 Attaching the Strap
Figure 3-5 illustrates how to attach the strap of an EP631S.
EP631S
Quick Guide 3 Installation and Use
Issue 02 (2018-05-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
11

Figure 3-5 Attaching the strap of an EP631S
3.5 Charging the Battery and the Phone
Figure 3-6 illustrates how to charge an EP631S and its battery using a charger.
EP631S
Quick Guide 3 Installation and Use
Issue 02 (2018-05-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
12

Figure 3-6 Charging using the charger
NOTE
lPower cables and power plugs vary with power supply standards. The power plugs in preceding figure are
for reference only
lTo prolong the battery lifespan, charge the battery regularly. Charge the battery at least once per three
months. Otherwise, the battery will be damaged.
3.6 Installing an SIM Card
Figure 3-7 illustrates how to install an SIM card on an EP631S. Before installing an SIM
card, open the battery cover and remove the battery.
EP631S
Quick Guide 3 Installation and Use
Issue 02 (2018-05-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
13

Figure 3-7 Inserting an SIM card
3.7 Powering On and Powering Off
Powering On
When an EP631S is off, hold down to power on the EP631S.
Powering Off
When an EP631S is on, hold down to power off EP631S.
3.8 Indicator Status
Table 3-1 describes the relationship between the indicator and working status of the EP631S.
Table 3-2 describes the relationship between the indicator and charging status of the charger.
Table 3-1 EP631S indicator and working statuses
Indicator Status Working Status
Off Running properly
EP631S
Quick Guide 3 Installation and Use
Issue 02 (2018-05-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
14

Indicator Status Working Status
Blinking red slowly Low battery level (< 10%)
Out of network service areas
Steady red Charging in progress
Video surveillance or video sending in progress
Blinking green slowly Receiving a call
Unread message or missed calls
Steady green The floor is obtained and a call can be initiated.
Charging complete (battery level > 90%)
Table 3-2 EP631S charger indicator and charging statuses
Indicator Charger Indicator Status Charging Status
Phone-like indicator Steady green Charging in progress
Steady green Fully charged
Steady red Standby
Blinking red (blinking three times
per second)
Faulty
Battery-like indicator Blinking green slowly (blinking
once per second)
Charging in progress
Steady green Fully charged
Steady red Standby
Blinking red (blinking three times
per second)
Faulty
3.9 Others
For more information, see EP631S User Guide.
EP631S
Quick Guide 3 Installation and Use
Issue 02 (2018-05-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
15
