HULALA HOME SFHQ0393 User manual

NOTE:
This brochure contains IMPORTANT safty info. Please read
and keep for future reference.
ＩＴＥＭ ＮＯ．ＳＦＨＱ０３９３

A*1 B*1 C*1
E*2 F*2
D*2
G*1 H*1
Right Arm
Left Arm Backrest
Backrest cushion seat cushion
Baseplate
Front rail Metal bar
Weight Limitation
400LBS
-1- -2-

STEP1
J
③
J
①
A
B
①
③
STEP1:Use bolt , allen key to Attach the metal bracket
J to inside of armrest (A/B). Make sure the holes aligned
properly then fasten all bolts to secure.
①③
I*4 K*2 L*2
J*2
M6*16 M4*25 M6
①*36 ②*8 ③*1
M6*16 M4*25
Be sure to check all packing material carefully for
small parts.which may have come loose inside the
carton during shipment.
①*1 ②*1
-3- -4-

STEP3
L
A
C
B
①
③
STEP3:Use bolt , allen key , bracket L to connect
armrest A/B with backrest C. Please don't fasten any bolt
until end of step 5.
①③
STEP2
C
AB
STEP2: With help of adult partner, carefully align
the male and female metal bracket then push the
backrest(C) all the way down in order to secure it to
inside of armrest A/B.
-5- -6-

STEP5
H
G
A
C
B
H
③
①
STEP5:Use bolt to connect metal bar H with armrest A/
B, make sure the metal bar set leveled and bottom edge
of front rail G, armrest A/B, backrest C all aligned then
fasten all bolts to secure.
①
STEP4
K
G
A
C
B
①
③
STEP4:Use bolt , allen key , bracket K to connect
armrest A/B with front rail G, Please don't fasten any bolt
until end of step 5.
①③
-7- -8-

STEP7
DD
G
A
C
B
②
STEP7:Use philips head screwdriver and screw to
attach seat panel D to front rail G and backrest C, fasten
secure.
②
to
③
③
STEP6
I
①
③
STEP6:Use bolt , allen key to attach legs to
the armrest A/B, fasten bolts to secure.
①③
bottom of
I
-9- -10-

STEP9
EE
STEP 9:Put the barkrest cushion E on top of the
cushion F.
seat
STEP8
FF
STEP 8:Put the seat cushion F on the seat panel D.
-11- -12-

Assembly completed
-13-
