HULALA HOME SCBSD0807 User manual

HULALA
H O M E
01/25
NOTE:
This brochure contains IMPORTANT safty info. Please read and keep for future
reference.
ITEM NO.SCBSD0807

MAINTAINANCE AND WARNING
1.Keep furniture away from heat sources.
2.Do not clean furniture with harsh cleaner or polishes.Do not use
detergents,solvents,abrasives,spray packs or leather cleaner.
Use non-color mild soa with warm water to clean spills(Mix 1:10
soap to water).
3.Do not place furniture under direct sunlight,material will possibly
fade over time.
4.Do not use on site dry cleaning machine.Children should not climb
or jump on the furniture.
5.Do not write on furniture that is not protectedby a padded barrier.
6.Not for commercial use,only for residential use.
Weight Limitation
90 LBS
02/25

EXPLOSIVE VIEW
2PERSONENS
03/25
A
B
C
D
E
E
F
G
G
HI
I
M
JL
K
N
O
M
JL
KN
O
M
JL
KN
O

PARTS LIST
ABCD x1
E F GH x1
I J K L x3
M N
x1
x2
x3
x1
x1
x3
x3
x1
x2
x2
x3
04/25
Ox3

HARDWARE LIST
05/25
HARDWARE SPARE LIST
x16
#1 x6
x7 x2 x6
x28 x22
∅6*35mm M4*35mm
M7*50mm
M6*50mm M6*35mm
∅3.5*14mm
#2 #3 #4 #5
#6 #7
x1
#1
x1
x1 x1 x1
x2 x2
∅6*35mm M4*35mm
M7*50mm
M6*50mm M6*35mm
∅3.5*14mm
#2 #3 #4 #5
#6
#7

HARDWARE LIST
TOOL LIST
06/25
x12 x12
x28
x4 x4 x2
x28
∅15*11mm
∅8*30mm ∅20mm
x3
#8 #9 #10 #11
#13
#14 #15
#12
x7
#16
Ø13*6.5*1mm
x1 x1
#17 #18
M4

ASSEMBLY INSTRUCTIONS
STEP-1
1.Prepare for part (D&C). Align the holes in part (D&C),
tighten with screwdriver #18 tighten #6。
#6 x4 #18 x1
07/25
∅6*35mm
D
C
#6x4
#18
D&C

ASSEMBLY INSTRUCTIONS
STEP-2
Align the holes in part G, insert wooden dowel #8 by
hand,Insert panel (C&D) into panel (G),make sure all holes
aligned and then insert cam bolt #9 into the corresponding
hole of panel (G),and then tighten cam bolt #9 with
screwdriver #18.after installation, cover the screw holes with
#11.
08/25
x1
C
D
G
G
#18
D&C
G
#18 #9x4
#8x4
D &C
G
D&C
G
#11x4
#8 x4 #9 x4
∅15*11mm
∅8*30mm ∅20mm
#11 x4

ASSEMBLY INSTRUCTIONS
STEP-3
1.Prepare for part A. Align the holes in part A, insert wooden
dowel #8 by hand, tighten with screwdriver #18 tighten #6。
09/25
#8 x4 #18 x1 #6 x6
∅6*35mm ∅8*30mm
#8x4
#18
#6x4
#6x2
#18
A
#6
#8
#6 #8
#6
#8
#6
#8 #6

ASSEMBLY INSTRUCTIONS
STEP-4
1.Insert the preassemble step 3 into the panel (A),make
sure all holes aligned and insert cam bolt #9 into the
corresponding hole of side panel(C)&(D),tighten cam bolt
#9 with screwdriver #18 .after installation, cover the screw
holes with #11.
10/25
x1
#18
#18
#9x4
D
C
A
D&C
AA
D&C
D&C
A
#11x4
#9 x4
∅15*11mm ∅20mm
#11 x4

ASSEMBLY INSTRUCTIONS
STEP-5
1.Insert the part (F) into the panel (A),make sure all holes
aligned and insert cam bolt #9 into the corresponding hole
of side panel (F),tighten cam bolt #9 with screwdriver #18
.after installation, cover the screw holes with #11.
11/25
x1
#18
C
D
F
A
#18
#9x2
#11x2
A
F
A
F F
A
#9 x2
∅15*11mm ∅20mm
#11 x2

ASSEMBLY INSTRUCTIONS
STEP-6
slide in the part E into the groove in part (C&F) and(D&F)
and. make sure they are also in groove in part A.
12/25
The grooves must be
align completely.
The grooves must be
align completely.
D
C
F
E
E
A

ASSEMBLY INSTRUCTIONS
STEP-7
1.Connect the part B the pre-assembled unit in step 6.
Insert the wooden dowel #8 into the part C&D as the picture
show.
Then align the holes in part B,Insert screw #5 and push it
down so that it connects to parts C&D. Next,and tighten the
screw #5 with an Allen key #17.
13/25
x1
#17
#5
#5
#8
#5
#5
D
C
B
#8 #8
#5x6
M4
#17
#8x4
B
D&C
#5
#8
#5 x6
M7*50mm
#8 x4
∅8*30mm

ASSEMBLY INSTRUCTIONS
14/25
STEP-8
1.Prepare the leg racks. Align the holes of the (H) part with
the holes of the (I) part, insert the screw #3, and tighten the
screw #3 with the allen key #17.
x1
#3 x2 #17
M4
M6*35mm
I
I
H
#3x2
#17
70%
H
I

ASSEMBLY INSTRUCTIONS
15/25
STEP-9
1.Connect the leg frame to the cabinet.Attach the leg frame
to the pre-assembled unit in step 7 with a screw #2 and
tighten #2 with a allen key #17.
100%
I
I
H
B
x1
#17
M4
#17
#2x7
#16x7
#2&#3
#17
#2 x7
M6*50mm Ø13*6.5*1mm
#16 x7

ASSEMBLY INSTRUCTIONS
16/25
STEP-10
Attention:
Before the next step, adjust the
feet of the locker to keep it
level.
I

ASSEMBLY INSTRUCTIONS
17/25
STEP-11
1.Insert hardware #10 into part E as shown, screw in screw
#1 using screwdriver #18 and tighten fully.
D
C
A
B
E
E
x1
#10 x12 #18#1 x12
∅3.5*14mm
#18
#1x12
#10
#10x12

ASSEMBLY INSTRUCTIONS
18/25
STEP-12
1.Use bolt #7 to attach drawer side (L＆K）to drawer back (J),tighten
bolt #7 with screwdriver #18 ，and use bolt #7 to attach part (O) to
drawer back (J),tighten bolt #7 with screwdriver #18.
slide in the part (M) into the groove in part (K&L) . make sure they are
also in groove in part (J).
2:
x3
The grooves must be
align completely.
x1#7 x18 #18
M4*35mm
K
L
M
x3
1:
K
L
J
O
J
K &L
#7x6
#18
O
J

ASSEMBLY INSTRUCTIONS
19/25
STEP-13
1.Insert bolt #6 into the corresponding hole of drawer front(N),tighten
bolt #6 with screwdriver #18.
2.Insert drawer front (N) into preassemble step 12，make sure all
holes aligned and insert cam bolt #9 into the corresponding hole of
drawer K&L&O，tighten cam bolt #9 with screwdriver #18.after
installation, cover the screw holes with #11.
x3
The grooves must be
align completely.
N
x1
#18
#18
#6x6
N
#18
#11x6
#9x6
N
K
L
N
K&LK&L
N
K&L
N
1:
2:
#9 x18
∅15*11mm
#6 x18
∅6*35mm
#11 x18
∅20mm
Ox3

ASSEMBLY INSTRUCTIONS
20/25
STEP-14
1.Use bolt #4 to attach handle #12 to drawer front（N），tighten
bolts #4 with screwdriver #18.
x3
N
x1
#18
#18
#4x6
#12x3
#4 x6 #12 x3
