HULALA HOME TVSD0826 User manual

HULALA
H O M E
01/25
NOTE:
This brochure contains IMPORTANT safty info. Please read and keep for future
reference.
ITEM NO.TVSD0826

MAINTAINANCE AND WARNING
1.Keep furniture away from heat sources.
2.Do not clean furniture with harsh cleaner or polishes.Do not use
detergents,solvents,abrasives,spray packs or leather cleaner.
Use non-color mild soa with warm water to clean spills(Mix 1:10
soap to water).
3.Do not place furniture under direct sunlight,material will possibly
fade over time.
4.Do not use on site dry cleaning machine.Children should not climb
or jump on the furniture.
5.Do not write on furniture that is not protectedby a padded barrier.
6.Not for commercial use,only for residential use.
Weight Limitation
90 LBS 02/25

EXPLOSIVE VIEW
2PERSON
03/25
A
B
C
D
E
F
G
H
H
I
I
J
J
K
L
M
O
NN

PARTS LIST
A B CDx1
E F GHx2
I J K L x1
M N O
x1
x1
x1
x1
x1
x1
x2
x2
x1
x1
x2
x1
04/25

HARDWARE LIST
HARDWARE SPARE LIST
#1 x12 #2 x20 #3 #4 #5 #6x12 x12 x8 x8
#1 #5
#17
#8 #9 #10 #11 #12
TOOL LIST
#13
#19 #20
x1 x1
x1 x1
x58
x8 x24 x4 x2 x4
x4
M4
05/25
#14 x2 #15 x2
Ø6*35mm Ø8*30mm Ø15*11mm M7*50mm M6*50mm
#16 x4
M4*35mm M3.5*14mm
Ø6*35mm M7*50mm
M6*40mm
#7 x2
#6 x1
M6*50mm M6*40mm
#7 x1 #17 x5
#16 x1
M4*35mm M3.5*14mm
#18 x2

x4x2 #17#14
ASSEMBLY INSTRUCTIONS
STEP-1
Use screw #17 to attach part #14 to the corresponding hole of top
panel(A),tighten screw #4 with screwdriver #20.And then slide the
rebounder #14 into the rebounder base as picture show.
#20 x1
06/25
#17
#14
#14
M3.5*14mm
#20
A
#17
#17x4
The rear protrusion of
therebound member should
facein the direction of the
backpanel.
#14x2

ASSEMBLY INSTRUCTIONS
STEP-2
Screw bolt #1 into top panel (A) ,tighten bolt #1 with screwdriver #20.Insert
wooden dowel #2 into side panel (E)&(F),and then screw bolt #1 into the
corresponding hole of side panel (E)&(F),tighten bolt #1 with screwdriver #20.
#1 x12 #2 x4 #20 x1
07/25
#1x8
#20 #2x4
#1
#1
#1
#1x4
A
EF
Ø6*35mm Ø8*30mm
#2
A
E&F

ASSEMBLY INSTRUCTIONS
STEP-3
Insert panel (G) into the corresponding hole of side panel (E),and then insert cam
bolt #3 into the corresponding hole of panel (G)，tighten cam bolt #3 with
screwdriver #20.Insert panel (F) into the corresponding hole of preassemble panel
(G),and then insert cam bolt #3 into the corresponding hole of panel (G)，tighten
cam bolt #3 with screwdriver #20,finally stick paster #4 to it for look nice.
x4 x4 #20 x1
08/25
#3x4 #20
GE&F
GE&FGE&F
#4x4
#3 #4
#3 #4
G
E
F
Ø15*11mm

ASSEMBLY INSTRUCTIONS
STEP-4
Stick paster #18 to the corresponding hole of panel(I) .
Insert rubber ring into the corresponding hole of panel (I) and then carefully align
and slide panel (I) into the groove along rear edge of pre-assembled step 3.
09/25
I
F&E
F
E
I
G
#18 x1
#18 I

ASSEMBLY INSTRUCTIONS
STEP-5
Insert wooden dowel #2 into the corresponding hole of panel
(E)&(F),and then insert panel (A) into the preassemble unit at
step 4,and then insert cam bolt #3 ,tighten cam bolt #3 with
screwdriver #20,finally stick paster #4 to it for look nice.
10/25
FE
A
#3
#4
x4
#2
Ø8*30mm
#3x4 #20 #4x4
A
E&FE&FE&F
AA
x4 x4 #20 x1
#3 #4
Ø15*11mm
#2 #2

ASSEMBLY INSTRUCTIONS
11/25
#3x4
#20
#4x4
A
D&C
D
&C
AA
D
&C
#20 x1x4 x4
#3 #4
x4
#2
#2
#2
A
C
D
E
F
I
G
Ø8*30mm Ø15*11mm

ASSEMBLY INSTRUCTIONS
STEP-7
Insert rubber ring #18 into the corresponding hole of panel (I) and then carefully
align and slide panel (I)&(H) into the groove along rear edge of pre-assemble unit
at step 6.
12/25
A
C
D
E
F
G
H
H
I
#18 I
#18 x1

ASSEMBLY INSTRUCTIONS
x8 #19 x1
13/25
STEP-8
Insert wooden dowel #2 into the corresponding hole of panel (C)&(E)&(F)&(D).
Insert panel (B) into the preassemble unit at step 7，make sure all holes
aligned ， then use bolt #5 to attach them，tighten bolt #5 with allen key #19.
#19
#5
#5
#2 #2
#2 #2
C
D
B
H
H
#5x8
#2
A
M4
Ø8*30mm M7*50mm
#2x8
#5x8
E
F

ASSEMBLY INSTRUCTIONS
x2 #19 x1
14/25
STEP-9
Use bolt #7 to attach part (N) to part (M), make sure all holes aligned and tighten all
bolts with allen key #19.
#7x2
#19
#7
#7
M
N
N
#7
M6*40mm M4

ASSEMBLY INSTRUCTIONS
x8 #19 x1
15/25
STEP-10
Use bolt #6 to attach preassemble leg(N)&(M) to bottom panel (B),
tighten bolt #6 with allen key #19.And screw the middle leg(O) into
the bottom panel (B).
#6x8
#19
#6
#6
M
N
N
#6
O
B
O
CH
H
A
B
M6*50mm M4
#6

ASSEMBLY INSTRUCTIONS
16/25
STEP-11
Attention:
Before the next step, adjust the feet of the locker to keep it level.
Attention:
Before the next step, adjust
the feet of the locker to keep
it level.
A
B
C
D
E
F
G

ASSEMBLY INSTRUCTIONS
17/25
STEP-12
Use screw #17 to attach plastic shelf #9 to panel(A)&(B)&(C)&(D)&(E)
&(F)&(G),tighten screw #17 with screwdriver #20.
#9x24
#20
#17x24
#9
D
C
A
B
x24 #9 x24 #20 x1
#17
M3.5*14mm

ASSEMBLY INSTRUCTIONS
x8
18/25
STEP-13
Insert shelf holder #8 into the corresponding hole of
panel(C)&(D)&(E)&(F),and then attach adjustable shelf (J) to it.
J
J
Shelf holder can be
adjusted up or down
#8x8
#8
#8
#8
J
C
D
E
FC&E&F&D
A
B
#8

ASSEMBLY INSTRUCTIONS
x4 #20 x1
19/25
STEP-14
1.Use screw #17 to attach hinge #12 to door (K)&(L),tighten screw
#17with screwdriver #20.
2.Attach the gasket#15 to the door using screws#17,tighten screw
#17with screwdriver #20.
#12
#20 #20
x10#17
#12
#17 #17
#15 x2
L
K
#15
M3.5*14mm
#17x8 #17x2
#15x2
#12x4

ASSEMBLY INSTRUCTIONS
x16 #19 x1
20/25
STEP-15
Use screw #17 to attach preassemble hinge #12 to panel (C)&(D),
tighten screw #17 with screwdriver #20.
#20
#17
A
C
D
K
L
M3.5*14mm
#17x16
#12
